Self-Propelled Articulating Booms ZX -135/70 ™
Specifications
Range Of Motion ZX-135/70
Model
ZX-135/70
Measurements
Metric
US
Working height maximum* Platform height maximum Horizontal reach max - riser extended Horizontal reach max - riser retracted Up and over clearance maximum riser extended riser retracted Below ground reach A Platform length - 8 ft / 6 ft model B Platform width - 8 ft / 6 ft model C Height - stowed D Length - stowed E Width - axles extended Width - axles retracted F Wheelbase - axles extended Wheelbase - axles retracted G Ground clearance - center
43.15 m 41.15 m 18.03 m 21.26 m
141 ft 135 ft 59 ft 2 in 69 ft 9 in
23.01 m 9.91 m 5.87 m 0.91 m / 0.76 m 2.44 m / 1.83 m 3.09 m 12.93 m 3.94 m 2.49 m 4.11 m 4.11 m 0.38 m
75 ft 6 in 32 ft 6 in 19 ft 3 in 3 ft / 2 ft 6 in 8 ft / 6 ft 10 ft 1.5 in 42 ft 5 in 12 ft 11 in 8 ft 2 in 13 ft 6 in 13 ft 6 in 1 ft 3 in
140 ft
42.67 m
130 ft
39.62 m
120 ft
36.58 m
110 ft
33.53 m
100 ft
30.48 m
90 ft
27.43 m
80 ft
24.38 m
70 ft
21.34 m
60 ft
18.29 m
50 ft
15.24 m
40 ft
Productivity
12.19 m
Lift capacity Platform rotation Vertical jib rotation Turntable rotation Turntable tailswing - axles extended riser up Turntable tailswing - riser down Drive speed - stowed Drive speed - raised** Lift speed to full height Gradeability - stowed*** Inside turning radius - axles extended Inside turning radius - axles retracted Outside turning radius - axles extended Outside turning radius - axles retracted Controls Tyres
30 ft
272 kg 160° 110°
600 lbs 160° 110° 360° continuous 0.81 m 2 ft 8 in 4.29 m 14 ft 1 in 4.8 km/h 3.0 mph 1.1 km/h 0.68 mph 96 sec 96 sec 45% 45% 2.90 m 9 ft 6 in 8.03 m 26 ft 4 in 6.17 m 20 ft 3 in 9.96 m 32 ft 8 in 12 V DC proportional 445/65 D22.5 18 ply foam-filled
9.14 m
20 ft 6.1 m
10 ft
3.05 m
0 ft
0m
-10 ft
-3.05 m
-20 ft
-6.1 m
Power Power source Auxiliary power unit Hydraulic tank capacity Fuel tank capacity
Deutz TD 2011 L04i turbo diesel 4-cylinder 74hp (55kW) Stage IIIA Deutz TCD2.2 L3 turbo diesel 3-cylinder 74hp (55 kW) Stage V 12 V DC 12 V DC 246.1 L 65 gal 151.4 L 40 gal
-30 ft -20 ft -10 ft
0 ft
10 ft
20 ft
30 ft
-9.14 m
0m
3.05 m
6.1 m
9.14 m 12.19 m 15.24 m 18.29 m 21.34 m
87.1 dBA 74 dBA <2.5 m/s²
87.1 dBA 74 dBA <8 ft 2 in/s²
21,092 kg
46,500 lbs
Weight**** CE
Standards Compliance EU Directives: 2006/42/EC - Machinery (harmonized standard EN280:2013+A1:2015); 2004/108/EC (EMC); 2000/14/EC (Outdoor Noise)
A
E
B
C
G D
www.genielift.com/en-gb
-3.05 m
40 ft
50 ft
60 ft
70 ft
*T he metric equivalent of working height adds 2 m to platform height. U.S. adds 6 ft to platform height. ** I n lift mode (platform raised), the machine is designed to be operated on firm, level surfaces only. *** G radeability applies to driving on slopes. See operator’s manual for details regarding slope ratings. **** W eight will vary depending on options and/or country standards
Sound & Vibration Levels Sound pressure level (ground workstation) Sound pressure level (platform workstation) Vibration
-6.1 m
F
