Update Date : 2020/04/27 Print Date : 2022/03/17

RTV1140CPX >> HAEUFIG VERWENDETE TEILE / FREQUENTLY USED ITEMS >> 000000 HAEUFIG VERWENDETE TEILE / FREQUENTLY

RTV1140CPX

HAEUFIG VERWENDETE TEILE / FREQUENTLY USED ITEMS >> 000000 HAEUFIG VERWENDETE TEILE / FREQUENTLY

Update Date : 2020/04/27 Print Date : 2022/03/17 No. Part Number Part Name (POL) Part Name (ENG) QTY IC Serial No./PIN Kg Remarks 010 15321-73016 GRP.THERM OSTAT ASSY THERMOSTA T 1 0.070 020 K7571-62112 ANLASSERS CHALTER STARTER SWITCH 1 0.075 030 PL501-68920 SCHLUESSEL KEY,STARTE R 1 0.018 SET 040 K7311-62240 KOMBINATIO NSCHALTER SWITCH,COM BINATION 1 0.045 050 T1060-30430 SICHERUNG 5A FUSE,MINI (5A) 3 0.005 5A 060 T1060-30440 SICHERUNG 10A FUSE,MINI (10A) 3 0.005 10A 070 T1060-30450 SICHERUNG 15A FUSE,MINI (15A) 3 0.005 15A 080 T1060-30460 SICHERUNG 20A FUSE,MINI (20A) 1 0.002 20A 090 T1060-30470 SICHERUNG 30A FUSE,MINI (30A) 2 0.005 30A 100 T1060-30530 SICHERUNG FUSE,SLOWBLOW(50A) 1 0.007 50A 110 T1150-30500 SICHERUNG (60A) FUSE,SLOWBLOW(60A) 1 0.007 60A 120 T1060-30490 SICHERUNGS ZIEHER FUSE PULLER 1 0.005 130 K7571-54340 GLUEHBIRNE BULB 1 0.000 37.5W 140 K7501-62740 GLUEHBIRNE BULB,LAMP 1 0.030 21/5W 150 HH150-32094 OELFILTERP ATRONE FILTER (CARTRIDGE, OIL) 1 0.300 160 12581-43012 GRP.KRAFTS TOFFILTER ASSY FILTER,FUEL 1 0.034 170 HHK71-14080 OELFILTER FILTER (OIL,CARTRID GE) 1 0.350 ORANGE 170 HHK72-14080 OELFILTER FILTER,OIL 1 >> 0.364 ORANGE 180 HHK70-14070 OELFILTER FILTER(OIL) 2 0.390 GELB 190 TC020-16320 FILTEREINSA TZ COMP.FILTE R,A/C 1 0.500 195 T0270-93220 LUFTFILTER EINSATZ, INNEN ASSY ELEMENT, INNER 1 0.100

RTV1140CPX >> HAEUFIG VERWENDETE TEILE / FREQUENTLY USED ITEMS >> 000000

Update Date : 2020/04/27 Print Date : 2022/03/17 No. Part Number Part Name (POL) Part Name (ENG) QTY IC Serial No./PIN Kg Remarks 200 16206-97013 KEILRIEMEN BELT 1 0.070 210 K7711-83170 AUSPUFF KOMP. COMP.MUFFL ER 1 4.100 220 K7711-83140 AUSPUFFTO PFROHR PIPE,MUFFLE R 1 0.325 230 K7611-85170 SCHLAUCH HOSE,WATE R LOWER 1 0.000 240 K7711-85230 ABDECKKAP PEN CAP,RADIAT OR 1 0.025 250 K7711-34120 TANKVERSC HLUSS CAP,FUEL 1 <=60163 0.105 250 K7711-34122 TANKVERSC HLUSS CAP,FUEL 1 >> >=60164 0.105 260 K7611-85150 SCHLAUCH HOSE,WATE R UPPER 1 1 0.000 270 K7611-85160 SCHLAUCH HOSE,WATE R UPPER 2 1 0.000

HAEUFIG VERWENDETE TEILE / FREQUENTLY

BKIDK5044 >> RTV1140CPX >> MOTOR / ENGINE >> 000100 KURBELGHAEUSE / CRANKCASE

Update Date : 2020/04/27 Print Date : 2022/03/17

BKIDK5044 >> RTV1140CPX >> MOTOR / ENGINE >> 000100 KURBELGHAEUSE / CRANKCASE

Update Date : 2020/04/27 Print Date : 2022/03/17 No. Part Number Part Name (POL) Part Name (ENG) QTY IC Serial No./PIN Kg Remarks 010 1G910-01012 KOMP.KURBE LGEHAEUSE COMP.CRAN KCASE 1 30.000 020 15451-96270 KAPPE CAP,SEALING 4 0.010 030 15221-03490 STOPFEN CAP,SEALING 1 0.020 040 15261-96010 STOPFEN PLUG 3 0.002 050 1G910-96020 STOPFEN PLUG 1 0.090 AUßER GEBRAUCH 060 16241-96010 STOPFEN PLUG 3 0.007 070 15521-96020 STOPFEN PLUG 2 0.003 080 17391-96160 STOPFEN PLUG,EXPAN SION 3 0.003 090 16271-96160 STOPFEN PLUG,EXPAN SION 1 0.025 100 05012-00508 ZYLINDERSTI FT PIN,STRAIGH T 2 0.001 110 05012-00814 ZYLINDERSTI FT PIN,STRAIGH T 2 0.006 120 05012-00610 ZYLINDERSTI FT PIN,STRAIGH T 2 0.003 130 15231-33960 ROHRSTIFT PIN,PIPE 2 0.001 140 16241-33650 ROHRSTIFT PIN,PIPE 1 0.002 150 16241-96262 STOPFEN PLUG,FUEL CAMSHAFT 1 0.007 160 16261-56280 STARTFEDER STIFT PIN(START SPRING) 1 0.004 170 16282-96010 STOPFEN PLUG 1 0.090 180 16271-55350 BUCHSE BUSHING (GEAR,GOBE RNOR) 1 0.060 190 1G896-33610 BOLZEN PLUG 1 0.008 200 15021-33660 DICHTUNGSP LATTE PACKING 1 0.001 210 06311-55020 STOPFEN PLUG 1 0.031 220 04724-00130 DICHTUNGSP LATTE GASKET 1 0.003 230 1G910-17760 GELENK JOINT 1 0.370

Update Date : 2020/04/27 Print Date : 2022/03/17

BKIDK5044 >> RTV1140CPX >> MOTOR / ENGINE >> 000200 OL-FANGER / OIL PAN

BKIDK5044 >> RTV1140CPX >> MOTOR / ENGINE >> 000200

OL-FANGER / OIL PAN

Update Date : 2020/04/27 Print Date : 2022/03/17 No. Part Number Part Name (POL) Part Name (ENG) QTY IC Serial No./PIN Kg Remarks 010 1G910-01500 OELWANNE,K OMP. COMP.OIL PAN 1 1.600 020 13901-33750 ENTLEERUN GSSTOPFEN PLUG,DRAIN 1 0.025 030 6C090-58960 DICHTUNGSP LATTE GASKET 1 0.005 040 01023-50614 BOLZEN BOLT,SEMS 24 0.005 045 01023-50614 BOLZEN BOLT,SEMS 2 0.005 050 1G910-32110 KRAFTSTOFF ILTER FILTER,OIL 1 0.100 060 01123-50816 SCHRAUBE BOLT,SEMS 1 0.011 070 04814-00160 O RING O RING 1 0.001

RTV1140CPX >> MOTOR / ENGINE >> 000301 ZYLINDERKOPF / CYLINDER HEAD ## S.Nr.<=1CXZ999 S.No.;<=1CXZ999 / S.No.<=1CXZ999

Update Date : 2020/04/27 Print Date : 2022/03/17 KUBOTA

RTV1140CPX >> MOTOR / ENGINE >> 000301 ZYLINDERKOPF / CYLINDER HEAD ## S.Nr.<=1CXZ999 S.No.;<=1CXZ999 / S.No.<=1CXZ999

Update Date : 2020/04/27 Print Date : 2022/03/17 No. Part Number Part Name (POL) Part Name (ENG) QTY IC Serial No./PIN Kg Remarks 010 15221-01750 MOTORHAKE N HOOK,ENGIN E 2 0.040 020 01123-50814 BOLZEN BOLT,SEMS 2 0.010 030 1G053-03044 KOMP.ZYLIN DERKOPF COMP.CYLIN DER HEAD 1 9.734 040 15321-96260 KAPPE CAP,SEALING 1 0.014 050 15261-03370 STOEPSEL,A BDICHTUNG CAP,SEALING 2 0.005 060 16261-13540 EINLASSVEN TILFUEHRUN G GUIDE,INLET VALVE 3 0.020 070 16261-13560 AUSLASSVEN TILFUEHRUN G GUIDE,EXHA UST VALVE 3 0.019 080 15261-96010 STOPFEN PLUG 2 0.002 090 16241-03450 ZYLINDERKO PFSCHRAUB E BOLT,HEAD (CYLINDER) 13 0.050 100 16216-03450 ZYLINDERKO PFSCHRAUB E BOLT,CYLIND ER HEAD 1 0.070 110 1G063-03310 ZYLINDERKO PFDICHTUNG GASKET (HEAD,CYL) 1 0.160

RTV1140CPX >> MOTOR / ENGINE >> 000302 ZYLINDERKOPF / CYLINDER HEAD ## S.Nr.>=1CY0001 S.No.;>=1CY0001 / S.No.>=1CY0001

rights reserved.

RTV1140CPX >> MOTOR / ENGINE >> 000302 ZYLINDERKOPF / CYLINDER HEAD ## S.Nr.>=1CY0001 S.No.;>=1CY0001 / S.No.>=1CY0001

Update Date : 2020/04/27 Print Date : 2022/03/17 No. Part Number Part Name (POL) Part Name (ENG) QTY IC Serial No./PIN Kg Remarks 010 15221-01750 MOTORHAKE N HOOK,ENGIN E 2 0.040 020 01123-50814 BOLZEN BOLT,SEMS 2 0.010 030 1J096-03040 KOMP.ZYLIN DERKOPF HEAD,CYL,C OMP 1 9.300 040 15321-96260 KAPPE CAP,SEALING 1 0.014 050 15261-03370 STOEPSEL,A BDICHTUNG CAP,SEALING 2 0.005 060 16261-13540 EINLASSVEN TILFUEHRUN G GUIDE,INLET VALVE 3 0.020 070 16261-13560 AUSLASSVEN TILFUEHRUN G GUIDE,EXHA UST VALVE 3 0.019 080 15261-96010 STOPFEN PLUG 2 0.002 090 16241-03450 ZYLINDERKO PFSCHRAUB E BOLT,HEAD (CYLINDER) 13 0.050 100 16216-03450 ZYLINDERKO PFSCHRAUB E BOLT,CYLIND ER HEAD 1 0.070 110 1G063-03310 ZYLINDERKO PFDICHTUNG GASKET (HEAD,CYL) 1 0.160

>> MOTOR / ENGINE >> 000401 GETRIEBE GEHAEUSE / GEAR CASE ## S.Nr.<=1DHZ999 S.No.;<=1DHZ999 / S.No.<=1DHZ999

RTV1140CPX

reserved.

RTV1140CPX >> MOTOR / ENGINE >> 000401 GETRIEBE GEHAEUSE / GEAR CASE ## S.Nr.<=1DHZ999 S.No.;<=1DHZ999 / S.No.<=1DHZ999

Update Date : 2020/04/27 Print Date : 2022/03/17 No. Part Number Part Name (POL) Part Name (ENG) QTY IC Serial No./PIN Kg Remarks 010 1G900-04022 KMP.GETRIE BEGEHAEUS E COMP.CASE, GEAR 1 <=1CTZ999 2.950 010 1G900-04024 KMP.GETRIE BEGEHAEUS E COMP.CASE, GEAR 1 >> >=1CU0001 2.950 020 06311-85016 STOEPSEL,A BDICHTUNG CAP,SEALING 1 0.003 030 16241-96020 STOPFEN PLUG 2 0.015 040 15521-96020 STOPFEN PLUG 1 0.003 050 04011-50180 SCHEIBE WASHER,PLA IN 1 0.012 060 15241-32290 VERBINDUNG SSTUECK JOINT,PIPE 1 0.053 070 16241-36950 FEDER SPRING 1 <=1CTZ999 0.015 070 1J050-36950 FEDER SPRING 1 NI >=1CU0001 0.004 080 16241-36930 SITZ,VENTIL SEAT,VALVE 1 <=1CTZ999 0.032 080 1J050-36930 UEBERLAUFV ENTIL VALVE (RELIEF) 1 >=1CU0001 0.005 100 16241-35070 ROTOR KOMP. ASSY ROTOR,OIL PUMP 1 0.270 110 16251-35130 DECKEL, OELPUMPE COVER,OIL PUMP 1 0.090 120 03017-50620 SCHRAUBE SCREW,BINDI NG(PHILLIPS) 5 0.005 130 05012-00410 ZYLINDERSTI FT PIN,STRAIGH T 2 0.001 140 1G700-04132 DICHTUNG GASKET,GEA R CASE 1 0.015 150 01023-50645 BOLZEN BOLT,SEMS 3 0.010 160 01023-50650 BOLZEN BOLT,SEMS 4 0.012 170 01023-50655 BOLZEN BOLT,SEMS 2 0.012 180 01023-50670 BOLZEN BOLT,SEMS 2 0.015 190 01023-50685 BOLZEN BOLT,SEMS 4 0.018 200 16245-91530 STEHBOLZEN STUD 1 0.010 210 02751-50060 MUTTER NUT,FLANGE 1 0.005 220 16241-04212 OELDICHTUN GSRING SEAL,OIL 1 0.012 230 16245-91540 STEHBOLZEN STUD 2 0.005

2015.

KUBOTA (c)

RTV1140CPX >> MOTOR / ENGINE >> 000401 GETRIEBE GEHAEUSE / GEAR CASE ## S.Nr.<=1DHZ999 S.No.;<=1DHZ999 / S.No.<=1DHZ999

Update Date : 2020/04/27 Print Date : 2022/03/17 No. Part Number Part Name (POL) Part Name (ENG) QTY IC Serial No./PIN Kg Remarks 240 E9151-33140 OELEINFUEL LSTOPFEN PLUG(OIL FILLER) 1 0.017 250 1J001-96770 O RING O RING 1 0.001 260 16264-83342 DECKEL, GETRIEBEGE HAEUSE COVER,GEAR CASE 1 0.010

>> MOTOR / ENGINE >> 000401 GETRIEBE GEHAEUSE / GEAR CASE ## S.Nr.<=1DHZ999 S.No.;<=1DHZ999 / S.No.<=1DHZ999

RTV1140CPX

reserved.

RTV1140CPX >> MOTOR / ENGINE >> 000401 GETRIEBE GEHAEUSE / GEAR CASE ## S.Nr.<=1DHZ999 S.No.;<=1DHZ999 / S.No.<=1DHZ999

Update Date : 2020/04/27 Print Date : 2022/03/17 No. Part Number Part Name (POL) Part Name (ENG) QTY IC Serial No./PIN Kg Remarks 070 16241-36950 FEDER SPRING 1 <=1CTZ999 0.015 070 1J050-36950 FEDER SPRING 1 NI >=1CU0001 0.004 080 16241-36930 SITZ,VENTIL SEAT,VALVE 1 <=1CTZ999 0.032 080 1J050-36930 UEBERLAUFV ENTIL VALVE (RELIEF) 1 >=1CU0001 0.005 090 07715-00201 KUGEL BALL 1 <=1CTZ999 0.008 KUBOTA

RTV1140CPX >> MOTOR / ENGINE >> 000402 GETRIEBE GEHAEUSE / GEAR CASE ## S.Nr.>=1DJ0001 S.No.;>=1DJ0001 / S.No.>=1DJ0001

Update Date : 2020/04/27 Print Date : 2022/03/17 No. Part Number Part Name (POL) Part Name (ENG) QTY IC Serial No./PIN Kg Remarks 010 1G900-04025 KMP.GETRIE BEGEHAEUS E COMP.CASE, GEAR 1 2.950 020 06311-85016 STOEPSEL,A BDICHTUNG CAP,SEALING 1 0.003 030 16241-96020 STOPFEN PLUG 2 0.015 040 15521-96020 STOPFEN PLUG 1 0.003 050 04011-50180 SCHEIBE WASHER,PLA IN 1 0.012 060 15241-32290 VERBINDUNG SSTUECK JOINT,PIPE 1 0.053 070 1J050-36950 FEDER SPRING 1 0.004 080 1J050-36930 UEBERLAUFV ENTIL VALVE (RELIEF) 1 0.005 100 1J050-35070 ROTOR KOMP. ROTOR,ASSY (OIL PUMP) 1 0.244 110 1J050-35132 DECKEL, OELPUMPE COVER(OIL PUMP) 1 0.085 120 03017-50614 SCHRAUBE SCREW,BINDI NG(PHILLIPS) 5 0.005 140 1G700-04132 DICHTUNG GASKET,GEA R CASE 1 0.015 150 01023-50645 BOLZEN BOLT,SEMS 3 0.010 160 01023-50650 BOLZEN BOLT,SEMS 4 0.012 170 01023-50655 BOLZEN BOLT,SEMS 2 0.012 180 01023-50670 BOLZEN BOLT,SEMS 2 0.015 190 01023-50685 BOLZEN BOLT,SEMS 4 0.018 200 16245-91530 STEHBOLZEN STUD 1 0.010 210 02751-50060 MUTTER NUT,FLANGE 1 0.005 220 16241-04212 OELDICHTUN GSRING SEAL,OIL 1 0.012 230 16245-91540 STEHBOLZEN STUD 2 0.005 240 E9151-33140 OELEINFUEL LSTOPFEN PLUG(OIL FILLER) 1 0.017 250 1J001-96770 O RING O RING 1 0.001 260 16264-83342 DECKEL, GETRIEBEGE HAEUSE COVER,GEAR CASE 1 0.010

BKIDK5044 >> RTV1140CPX >> MOTOR / ENGINE >> 000500 VENTILDECKEL / HEAD COVER

Update Date : 2020/04/27 Print Date : 2022/03/17

BKIDK5044 >> RTV1140CPX >> MOTOR / ENGINE >> 000500

VENTILDECKEL / HEAD COVER

Update Date : 2020/04/27 Print Date : 2022/03/17 No. Part Number Part Name (POL) Part Name (ENG) QTY IC Serial No./PIN Kg Remarks 010 1G032-14506 VENTILDECK EL COVER,ASSY (HEAD,CYL) 1 <=1DFZ999 0.750 010 1G032-14507 VENTILDECK EL ASSY COVER,CYL. HEAD 1 >> >=1DG0001 0.750 010 1G032-14508 ZYLINDERKO PFHAUBE ASSY COVER,CYL. HEAD 1 >> >=1FJ0001 0.750 030 16261-14520 VENTILDECK ELDICHTUNG GASKET,HEA D COVER 1 <=1DFZ999 0.010 030 16261-14524 VENTILDECK ELDICHTUNG GASKET,HEA D COVER 1 >> >=1DG0001 0.010 040 1G911-05203 ENTLUEFTER COMP VALVE,BREA THER 1 0.010 050 1G801-05120 ENTLUEFTER DECKEL COVER,BREA THER 1 0.035 060 03024-50510 SCHRAUBE SCREW,SEM S(PAN HEAD) 4 0.002 070 17331-73342 WASSERROH R PIPE,WATER RETURN 1 0.010 080 15952-92330 MUTTER NUT,CAP 3 0.010 090 15951-96660 DICHTUNGSP LATTE PACKING 3 0.001 100 E9151-33140 OELEINFUEL LSTOPFEN PLUG(OIL FILLER) 1 0.017 110 1J001-96770 O RING O RING 1 0.001 120 1G032-05510 ENTLUEFTUN GSROHR TUBE,BREAT HER 1 0.017 130 09318-88150 SCHLAUCHBI NDER CLAMPHOSE 1 0.004 140 16259-05580 SCHLAUCHBI NDER BAND,PIPE 1 0.030

BKIDK5044 >> RTV1140CPX >> MOTOR / ENGINE >> 000600 OELFILTER / OIL FILTER

Update Date : 2020/04/27 Print Date : 2022/03/17

BKIDK5044 >> RTV1140CPX >> MOTOR / ENGINE >> 000600 OELFILTER / OIL FILTER

Update Date : 2020/04/27 Print Date : 2022/03/17 No. Part Number Part Name (POL) Part Name (ENG) QTY IC Serial No./PIN Kg Remarks 010 HH150-32094 OELFILTERP ATRONE FILTER (CARTRIDGE, OIL) 1 0.300 KUBOTA (c) 2015. All rights reserved.

BKIDK5044 >> RTV1140CPX >> MOTOR / ENGINE >> 000700 OELMESSSTAB UND FUEHRUNG / DIPSTICK AND GUIDE

Update Date : 2020/04/27 Print Date : 2022/03/17

BKIDK5044 >> RTV1140CPX >> MOTOR / ENGINE >> 000700 OELMESSSTAB UND FUEHRUNG / DIPSTICK AND GUIDE

Update Date : 2020/04/27 Print Date : 2022/03/17 No. Part Number Part Name (POL) Part Name (ENG) QTY IC Serial No./PIN Kg Remarks 010 16809-36420 FUEHRUNG, OELMESSST AB GUIDE (GAUGE,OIL) 1 0.028 020 16335-36412 OELMESSST AB GAUGE,OIL 1 0.040 030 1G513-36550 STOPFEN, OELMESSST AB PLUG,OIL GAUGE 1 0.004

BKIDK5044 >> RTV1140CPX >> MOTOR / ENGINE >> 010000 HAUPTLAGERGEHÄUSE / MAIN BEARING CASE

Update Date : 2020/04/27 Print Date : 2022/03/17

BKIDK5044 >> RTV1140CPX >> MOTOR / ENGINE >> 010000 HAUPTLAGERGEHÄUSE / MAIN BEARING CASE

Update Date : 2020/04/27 Print Date : 2022/03/17 No. Part Number Part Name (POL) Part Name (ENG) QTY IC Serial No./PIN Kg Remarks 010 16292-07095 GRP.LAGERG EHAEUSE CASE,BRG,A SSY(WHEEL) 1 1.100 015 16292-23494 LAGERSCHA LE METAL,CRAN KSHAFT 1 0.070 STD/SET 020 16241-04540 BOLZEN,LAG ERKASTEN BOLT,BEARIN G CASE 2 0.020 030 16264-04360 DICHTUNG GASKET,BRG .CASE 1 <=1CTZ999 0.002 030 1G679-04360 DICHTUNG,L AGER GASKET (BRG.CASE) 1 >> >=1CU0001 0.006 030 1J095-04360 DICHTUNG,L AGER GASKET (BRG.CASE) 1 >> >=1DW0001 0.006 040 16241-04815 DECKEL,LAG ERKASTEN COVER (CASE,BRG) 1 0.220 050 16271-04460 OELDICHTUN GSRING SEAL,OIL 1 0.040 060 16264-04822 DICHTUNG GASKET 1 0.008 070 01023-50625 BOLZEN BOLT,SEMS 8 <=1CMZ999 0.007 070 1G679-91010 BOLZEN BOLT 8 >> >=1CN0001 0.007 080 01023-50620 BOLZEN BOLT,SEMS 9 <=1CMZ999 0.006 080 1G679-91020 BOLZEN BOLT 9 >> >=1CN0001 0.006 090 16261-07047 GRP.LAGERG EHAEUSE ASSY BRG.CASE,M AIN 1 0.860 095 16292-23483 LAGERSCHA LE METAL,CRAN KSHAFT 1 0.050 STD/SET 100 16241-04540 BOLZEN,LAG ERKASTEN BOLT,BEARIN G CASE 2 0.020 110 16241-04560 BOLZEN,LAG ERKASTEN BOLT (CASE,BRG) 2 0.030 120 16261-07057 GRP.LAGERG EHAEUSE ASSY BRG.CASE,M AIN 1 0.800 125 16292-23483 LAGERSCHA LE METAL,CRAN KSHAFT 1 0.050 STD/SET 130 16241-04540 BOLZEN,LAG ERKASTEN BOLT,BEARIN G CASE 2 0.020

BKIDK5044 >> RTV1140CPX >> MOTOR / ENGINE >> 010000 HAUPTLAGERGEHÄUSE / MAIN BEARING CASE

Update Date : 2020/04/27 Print Date : 2022/03/17

BKIDK5044 >> RTV1140CPX >> MOTOR / ENGINE >> 010000 HAUPTLAGERGEHÄUSE / MAIN BEARING CASE

Update Date : 2020/04/27 Print Date : 2022/03/17 No. Part Number Part Name (POL) Part Name (ENG) QTY IC Serial No./PIN Kg Remarks 030 16264-04360 DICHTUNG GASKET,BRG .CASE 1 <=1CTZ999 0.002 030 1G679-04360 DICHTUNG,L AGER GASKET (BRG.CASE) 1 >> >=1CU0001 0.006 030 1J095-04360 DICHTUNG,L AGER GASKET (BRG.CASE) 1 >> >=1DW0001 0.006

Update Date : 2020/04/27 Print Date : 2022/03/17 KUBOTA

ENGINE >> 010101 NOCKENWELLE UND

SHAFT ## S.Nr.<=1CXZ999 S.No.;<=1CXZ999

FREILAUFGETRIEBEWELLE / CAMSHAFT AND IDLE GEAR

NOCKENWELLE UND FREILAUFGETRIEBEWELLE / CAMSHAFT AND IDLE GEAR SHAFT ## S.Nr.<=1CXZ999

>> 010101

ENGINE

S.No.;<=1CXZ999 Update Date : 2020/04/27 Print Date : 2022/03/17 No. Part Number Part Name (POL) Part Name (ENG) QTY IC Serial No./PIN Kg Remarks 010 1G673-15550 STOESSEL TAPPET 6 0.035 020 16241-15114 STOESSELST ANGE PUSH ROD 6 0.028 030 16261-16912 NOCKENWEL LE KOMP. ASSY CAMSHAFT 1 1.700 040 07715-00401 KUGEL BALL 1/4 1 0.001 050 16241-16510 ZAHNRAD GEAR,CAM 1 0.450 060 05712-00518 KEIL FEATHER KEY 1 0.003 070 16241-16270 NOCKENWEL LENSPERRPL ATTE STOPPER,CA MSHAFT 1 0.040 080 01023-50616 BOLZEN BOLT,SEMS 2 0.006 090 1G910-24010 KEGELRAD,K OMP. COMP.GEAR,I DLE 1 0.610 100 1G910-24980 BUCHSE BUSH,IDLE GEAR 1 0.028 110 16251-24360 HUELSE COLLAR(IDLE GEAR) 1 0.012 120 15741-24370 HUELSE COLLAR(IDLE GEAR) 1 0.015 130 15741-24320 SEEGERING CIR CLIP,IDLE GEAR 1 0.010 140 16251-24250 WELLE SHAFT,IDLE GEAR 1 0.360 150 01023-50616 BOLZEN BOLT,SEMS 3 0.006

Update Date : 2020/04/27 Print Date : 2022/03/17 KUBOTA

ENGINE >> 010102 NOCKENWELLE UND FREILAUFGETRIEBEWELLE / CAMSHAFT AND IDLE GEAR SHAFT ## S.Nr.>=1CY0001 S.No.;>=1CY0001

reserved.

NOCKENWELLE UND FREILAUFGETRIEBEWELLE / CAMSHAFT AND IDLE GEAR SHAFT ##

ENGINE >> 010102

S.No.;>=1CY0001 Update Date : 2020/04/27 Print Date : 2022/03/17 No. Part Number Part Name (POL) Part Name (ENG) QTY IC Serial No./PIN Kg Remarks 010 1G673-15550 STOESSEL TAPPET 6 0.035 020 16241-15114 STOESSELST ANGE PUSH ROD 6 0.028 030 1J096-16010 GRP.NOCKE NWELLE CAMSHAFT,A SSY 1 1.550 040 07715-00401 KUGEL BALL 1/4 1 0.001 050 16241-16510 ZAHNRAD GEAR,CAM 1 0.450 060 05712-00518 KEIL FEATHER KEY 1 0.003 070 16241-16270 NOCKENWEL LENSPERRPL ATTE STOPPER,CA MSHAFT 1 <=1EKZ999 0.040 070 1J097-16270 NOCKENWEL LE SPERRPLATT E STOPPER (CAMSHAFT) 1 >> >=1EL0001 0.030 080 01023-50616 BOLZEN BOLT,SEMS 2 0.006 090 1G910-24010 KEGELRAD,K OMP. COMP.GEAR,I DLE 1 0.610 100 1G910-24980 BUCHSE BUSH,IDLE GEAR 1 0.028 110 16251-24360 HUELSE COLLAR(IDLE GEAR) 1 0.012 120 15741-24370 HUELSE COLLAR(IDLE GEAR) 1 0.015 130 15741-24320 SEEGERING CIR CLIP,IDLE GEAR 1 0.010 140 16251-24250 WELLE SHAFT,IDLE GEAR 1 0.360 150 01023-50616 BOLZEN BOLT,SEMS 3 0.006

S.Nr.>=1CY0001

Update Date : 2020/04/27 Print Date : 2022/03/17 KUBOTA

ENGINE >> 010102 NOCKENWELLE UND FREILAUFGETRIEBEWELLE / CAMSHAFT AND IDLE GEAR SHAFT ## S.Nr.>=1CY0001 S.No.;>=1CY0001

(c)

rights reserved.

2015. All

Please write to us. Our email: aservicemanualpdf@yahoo.com Please go to the homepage to get the full manual, or other brand PDF manuals. Home Site: aservicemanualpdf.com

Thank you very much for your reading. Please Click Here. Then Get COMPLETE MANUAL. NO WAITING

NOTE:

If there is no response to click on the link above, please download the PDF document first and then click on it.

GET MORE OTHER MANUALS https://www.aservicemanualpdf.com/ GET MORE OTHER MANUALS https://www.aservicemanualpdf.com/

UND FREILAUFGETRIEBEWELLE / CAMSHAFT AND IDLE GEAR SHAFT

ENGINE >> 010102 NOCKENWELLE

S.No.;>=1CY0001 Update Date : 2020/04/27 Print Date : 2022/03/17 No. Part Number Part Name (POL) Part Name (ENG) QTY IC Serial No./PIN Kg Remarks 070 16241-16270 NOCKENWEL LENSPERRPL ATTE STOPPER,CA MSHAFT 1 <=1EKZ999 0.040 070 1J097-16270 NOCKENWEL LE SPERRPLATT E STOPPER (CAMSHAFT) 1 >> >=1EL0001 0.030

## S.Nr.>=1CY0001

010201 ABSTUETZUNG RECHTS VORNE / PISTON AND CRANKSHAFT ## S.Nr.<=1CXZ999 S.No.;<=1CXZ999

Update Date : 2020/04/27 Print Date : 2022/03/17

MOTOR

ENGINE >>

(c)

KUBOTA

2015.

>> 010201 ABSTUETZUNG RECHTS VORNE / PISTON AND CRANKSHAFT ## S.Nr.<=1CXZ999 S.No.;<=1CXZ999

/ ENGINE

Update Date : 2020/04/27 Print Date : 2022/03/17 No. Part Number Part Name (POL) Part Name (ENG) QTY IC Serial No./PIN Kg Remarks 010 16060-21114 KOLBEN PISTON 3 0.400 STD 010 16060-21914 KOLBEN PISTON 3 0.415 +0.50mm 020 16292-21050 GRP.KOLBEN RING RING,PISTON ,ASSY 3 0.001 STD 020 16292-21090 GRP.KOLBEN RING RING,PISTON ,ASSY 3 0.014 +0.50mm 030 16241-21310 KOLBENBOLZ EN PIN,PISTON 3 0.135 040 16241-21330 SEEGERING CIRCLIP (PIN,PISTON) 6 0.002 050 16292-22016 GRP.PLEUEL STANGE ROD,CONNE CTING,ASSY 3 0.526 060 1G700-21980 BUCHSE,KOL BENSTIFT BUSH,PISTO N PIN 3 0.010 070 16241-22142 BOLZEN BOLT (CONNECTIN G ROD) 6 0.024 080 16292-22310 LAGERSCHA LE METAL (PIN,CRANK) 3 0.040 STD SET 080 16292-22972 LAGERSCHA LE METAL,CRAN KPIN 3 0.033 -0.20mm/SET 080 16292-22982 LAGERSCHA LE METAL,CRAN KPIN 3 0.034 -0.40mm/SET 090 1G910-23012 BAUGRP.KUR BELWELLE CRANKSHAF T,COMP 1 <=1CVZ999 8.610 090 1G910-23013 KOMP.KURBE LWELLE COMP.CRAN KSHAFT 1 NI >=1CW0001 8.610 110 1A055-24110 ZAHNRAD GEAR (CRANKSHAF T) 1 0.142 120 16271-95230 KEIL KEY 1 0.005 130 16241-35630 ZAHNRAD GEAR(OIL PUMP DRIVE) 1 <=1CVZ999 0.102 130 1J050-35630 ZAHNRAD GEAR(OIL PUMP DRIVE) 1 NI >=1CW0001 0.090 150 16271-23250 HALSRING COLLAR,CRA NKSHAFT 1 <=1CVZ999 0.055 150 1G700-23250 HALSRING COLLAR (CRANKSHAF T) 1 NI >=1CW0001 0.045
