New Products and Application Guide

The best

just got Bigger!

The Cyclone® family of water heaters just got bigger with the addition of the LV and XL (coming soon) models.

With Cyclone models now ranging from 50 to 250 gallons and 75,000 to 1,000,000 BTU’s, there is a Cyclone for virtually any commercial application!

Cyclone® LV

Cyclone MXi ®

BTH 60-119 USG 120,000 – 499,900 BTU

Cyclone® XL

BTHL 220 & 250 USG 150,000 – 499,900 BTU

BTHS 119 USG 750,000 1,000,000 BTU

To find out more visit

Visit us at CIPHEX-Virtual

www.hotwatercanada.ca November 2nd - 27th

n Advertorial

The

Best just got…

BIGGER

A. O. Smith Cyclone® Family of Commercial High-Efficiency Water Heaters

By Ian Reinhart

A. O. Smith launched the first Cyclone water monitoring are fantastic features for restauheater in 1996 and since then the product famrant owners to keep tabs on operation. The Cyclone MXi (BTH) ily has evolved and expanded to include several power direct vent style is also ideal as using different models. There is a Cyclone for virtuoutdoor, contaminate-free air for combustion available volume to meet this high demand. ally any commercial application! will lessen the chance of nuisance Another brand-new Cyclone model series The most popular models are outages that would otherwise rethat is coming soon to Canada is the Cyclone the MXi (BTH) that were first insult in business down-time. The XL (BTHS). The XL models, like the MXi and troduced in 2014. Ranging in input space-saving design of the MXi LV, have the same feature set but offer much from 120,000 to 500,000 BTU/h provides large hot water output in a higher inputs of 750,000 and 1,000,000 BTU/h. and in 60, 100 and 119 gallon tank small footprint for those generally The unique design of dual stainless steel heat capacities, the MXi line features the cramped commercial kitchens. exchangers allows the XL to provide this high famous helical heat exchanger that If you are looking for something BTU/h input while remaining efficient. The XL provides thermal efficiencies up to a bit larger (literally), the Cyclone models have very high recovery rates and can 98%. This was the first Cyclone to family of water heaters provide a large amount of hot water use a modulating burner, which of fers t he LV line for a longer period. This is ideal for adjusts the firing rate to match (BTHL) that has all applications with a peak demand pedemand requirements, saving the the options of the MXi riod that isn’t necessarily high, but customer money in energy costs. Cyclone LV (BTHL) but with a much larger over a long time frame. Laundromats, The MXi is regarded as the “all-purstorage capacity. The LV for example, are a great application pose” solution in the Cyclone family with models are available in 220 and 250 for the XL as the hot water demand features that suit it for almost any application. gallon tank sizes and are perfect for isn’t high at any given time but is reOne of the more common applications of the applications with extremely high, quired for most of the day and on an MXi line is restaurants; both full-service and but relatively short peak demand on-going basis. Cyclone XL and its fast food as many of the MXi features line up periods. Applications such as hotels high recovery can sustain the outwell for restaurant owners. Titanium powered are a great example of this where put to ensure customers are getting a anodes and PermaGlas® Ultra Coat™ liquid in the mornings when guests are constant flow of hot water. glass lining are features that practically elimgetting ready for their day, hot Cyclone XL (BTHS) With the all-purpose MXi, the inate water quality restrictions. The recently water usage is incredibly high but large volume LV and the high recovupdated touch screen display makes using the generally only lasts for a few hours and then ery XL, there is a Cyclone for any application! water heater as easy as using a smartphone, demand tapers off. This massive dump load For more information visit www. and built-in wi-fi and iCOMM™ remote period is where Cyclone LV shines with the hotwatercanada.ca.

n Advertorial

BAXI

HIGH-EFFICIENCY

BOILERS: We make it easy Baxi Boilers North America is launching the Duo Tec Baxi boiler platform into the Canadian marketplace. The new Baxi Boiler Duo Tec residential boiler platform includes a variety of combi boilers ranging from industry-leading DHW outputs of 205,000 5GPM, 152,000 3.9GPM, to 115,000 2.5 GPM as well as the straight heat CH boilers ranging from 125,000 BTUH to 380,000BTUH.

User- Friendly THINK Control Technology

All Baxi Duo Tec boilers ranging from 125,000 BTUH – 165,000 BTUH are equipped with Baxi’s patented THINK Control. THINK Control allows the boiler to self-commission itself upon start up. By pressing two buttons on the boiler’s THINK control simultaneously you start the commissioning process. Within 20 minutes the boiler is up and running!

THINK Control eliminates the potential setup variances of the commissioning process. The Duo Tec boiler platform allows the use of one boiler regardless of the type of fuel, LPG or NG. There are no springs or orifices to change with the adaptive gas technology and THINK control.

THINK Control technology allows Duo Tec boilers to operate at optimum efficiency.

Baxi Pro Dealers frequently report that they no longer encounter nuisance boiler lockout calls during inclement weather. The boiler’s operating parameters are monitored by the THINK Control every 9 seconds to initiate fan speed adjustments to maintain peak efficiency.

Product Support

BAXI NA and Morden National support the Baxi product line with industr y-leading warranties, including a 15 year residential application warranty on the heat exchanger and a five year warranty on parts.

If you are a registered Baxi Pro Dealer you also enjoy a 1 year labour warranty that is underwritten by Morden National and Baxi NA. All Baxi products, both equipment and support parts, are stocked at Morden National Sales and Marketing located in Wallaceburg Ontario. From the Wallaceburg facility

Morden National stages the Baxi product for shipment to stocking locations at second- step distribution channel partners across Canada.

The team at Morden National also delivers customer support for order entry and live

technical support should you require it, we speak Canadian. Morden National’s goal is to provide their customers across Canada with an uncommon positive customer service experience.

History of Leadership and Partnership

Since 1866 Baxi has always been an innovative, industry- leading boiler manufacturer and the new Baxi Pro Dealer program continues with this tradition. The team of Baxi NA, ECR International and Morden National want all Baxi Pro Dealers to be part of something larger. Therefore Baxi NA has introduced the New Baxi Pro Dealer program for installer teams across Canada. As part of the Baxi Pro Dealer team the installers will undergo intensive deep- dive technical Baxi product training on, “best practices with Baxi products”. Once technical training has been completed, Baxi Pro Dealers will be given exclusive access to the Baxi Pro Dealer website portal. The portal provides access to; • Serial number parts lookups • Technical training videos • Technical bulletins • Sales resources • Exclusive extended warranties for Baxi Pro Dealers • Website listing and lead generation service

Get Rewarded

Most of all, Baxi Pro Dealers will be rewarded for every Baxi boiler installed and registered on the Baxi Pro Dealer portal. Baxi rewards can be used for advertising, swag for employees or to qualify for the annual Baxi Pro Dealer rewards trip. For more information contact Morden National Sales and Marketing at customerservice@mordennational.com or visit www.mordennational.com.

Residential Combi Models with gas adaptive THINK technology: • • • • • • • • • • •

Duo-tec Compact 30 GA 93 MBH Input in CH Mode / 115.5 MBH in DHW Mode 2.5 gpm (US) 11.4 liters/min at 70 °F/ 39 °C Rise Luna Duo-tec 40 GA 125 MBH Input in CH Mode / 152.8 MBH in DHW Mode 3.9 gpm (US) 14.7 liters/min at 70 °F/ 39 °C Rise Luna Duo-tec 60 GA 164 MBH Input in CH Mode / 205 MBH in DHW Mode 5 gpm (US) 18.9 liters/min at 70 °F/ 39 °C Rise

Residential Heating Models with gas adaptive THINK technology: • • • •

Luna Duo-tec 1.33 GA 125 MBH Input Luna Duo-tec 1.48 GA 164 MBH Input

Light Commercial Heating Models: • • • •

Luna Duo-tec 1.70 MP 240 MBH Input Luna Duo-tec 1.110 MP 380 MBH Input

n Advertorial

V I P E R T P O TA B L E & R A D I A N T P E - R T T U B I N G

The Evolution of PEX CB

Supplies proudly manufactures VIPERT Potable & Radiant PE-RT Tubing in Canada, designed to perform as well or better than PEX. Stronger, greener, and more flexible. VIPERT is all you need!

VIPERT has increased flexibility and relaxed memory, so installers will experience less spring-back. The tubing is pliable, allowing it to be bent to the shape you want and remain in that position. In extreme cold outdoor temperatures, the pipe maintains its flexibility.

This makes the tubing very easy to use.

VIPERT offers superior hydrostatic strength at high temperatures and burst pressures that far surpass required industry standards. VIPERT is also very versatile, as it is compatible with all PEX fittings systems, including cold expansion, push-fittings, and crimp fittings.

Perhaps the most unique trait of PE-RT is that it can be recycled. No PEX can be recycled, due to the additives required for cross-linking, but PE-RT is a more pure material which does not require cross-linking in its manufacturing process in order to create very high quality tubing. This means that installers can put scrap material in the recycling bin and keep it out of land-fills. PE-RT also requires less energy to be produced, creating a smaller environmental footprint.

PE-RT has been successful in Europe for many years, but it took longer to bring PE-RT to the North American market due to the higher chlorine content in the water. PE-RT resin was re-designed by the experts at Dow Chemical to meet this challenge, and the result was a stronger material that still allows great flexibility and recyclability. CB Supplies is proud to be one of the original pipe producers that worked closely with Dow to test several versions of PE-RT materials and provide feedback to help bring the best possible version of PE-RT to the North American market.

CB Supplies stands behind VIPERT Potable

and Radiant tubing with a comprehensive 25-year warranty. From applications and specifications to certifications, you will find everything you need to know at www.

VIPERT.com.

About CB Supplies

CB Supplies was founded in 1962 in Burnaby, BC and started manufacturing PEX in 1999 under the Vanguard Pipe & Fittings brand, which was later amalgamated into CB Supplies. In March of 2012, CB Supplies, and its related businesses were purchased by the Lowe family, a Canadian family that also owns American Granby Inc. in NY. Vanguard Pipe & Fittings was then consolidated into CB Supplies. VIPERT was launched in 2016 and has become a key part of the company’s offering.

With four dedicated branches across Canada (Surrey BC, Calgary AB, Mississauga ON and Bois-des-Filion QC), CB Supplies maintains exceptional local service across the country.

The Big Moves

In November 2015, CB Supplies moved from three rented buildings in Burnaby, BC into a new 126,500 sq. ft., purpose built, state-ofthe-art manufacturing facility in Surrey BC. This move put manufacturing, distribution, and the head office under one roof, with the potential to triple manufacturing capacity.

This facility will be the cornerstone of the business for years to come.

In 2016 CB Supplies’ Calgary branch was relocated across the street from a 14,000 sq. ft. unit to a new 28,000 sq. ft. warehouse. This enabled an increase in stock levels to better serve the Alberta, Saskatchewan, Manitoba, and Thunder Bay, ON markets.

In January 2020 CB Supplies moved

its Mississauga, Ontario branch from a 43,000 sq. ft. warehouse to an 81,000 sq. ft. custom-built facility. This significant upgrade provides ample room to grow in Canada’s largest market and serves as a hub for the other warehouses across the country.

Most recently, in November 2020, CB Supplies moved its branch in Laval, QC into a brand-new 20,000 sq. ft facility in Bois-desFilion, QC. This will allow for increased stock levels and improved service going forward to more effectively serve Quebec and the Atlantic provinces.

Now with Modulation and BMS Integration.

Bradford White’s Commercial eF Series® Ultra High Efficiency Gas Water Heater has long set the standard for outstanding commercial performance, reliability and efficiency.

Now the eF120T includes modulation for increased energy savings – and BMS Integration for remote monitoring and faster, easier troubleshooting.

Even your most demanding commercial customers will be satisfied with the performance, efficiency and innovation of the eF120T. To learn more, visit bradfordwhite.com/eF-120T

©2020, Bradford White Corporation. All rights reserved. BWPLHV1020

The Bar Has Been Raised – Again.

The eF120T: Performance, Efficiency & Innovation.

Bradford White’s Commercial eF Series® Ultra High Efficiency Gas Water Heater is already well-known for its commercial performance and efficiency. Now, it is evolving yet again to meet the needs of the most demanding commercial customers.

The eF120T now includes modulation and BMS Integration for remote monitoring, which allows for easier troubleshooting, increased efficiency and longer life. The eF120T delivers: • Outstanding Performance & Efficiency. The eF120T boasts a highly efficient, modulating down-fired premix power burner. The fully condensing design automatically regulates fuel flow for optimum combustion with a 3:1 turn down ratio. When compared to a traditional noncondensing water heater, the ENERGY STAR® certified, new modulating design could save thousands of dollars each year in energy costs.

• BMS Integration. BMS integration is now available via Modbus and BACnet® protocols. Once integrated, remote monitoring allows for real-time visibility which can provide quicker troubleshooting assistance.

• 119-Gallon Capacity. With this large capacity, the eF120T can satisfy the needs of even the most demanding commercial customers.

• Plus Quality Bradford White Features including the Hydrojet® Sediment Reduction System, Vitraglas® tank lining, protective powered anodes, three-pass fire tube heat exchange system, and improved venting versatility.

ASME Code comes standard on all models.

n Advertorial

Canplas

®

Adjustable Angle Bath Waste Adjustable Angle and Overflow Kits

Easy Installation

Chrome Finish

ABS (Black)

PVC (Grey)

Adjust Joint rotates

10˚ degrees FR-Pro (Grey) 25-50 Flame & Smoke Rated in any direction

Determine pipe length

333854 adjustable Plug & Chain, angle Chromebath 323854 Chrome & Chain, to adjust to tubChrome Chrome wastePlug and& Chain, overflow kits, 383854 from Plug angle. Chrome 333856 Lift & Turn, Chrome 323856 Lift & Turn, ChromeAdjust 383856 Liftwall & Turn, Canplas®, Barrie, Ont., adjust 10 degrees front to back and side 333858 Pop Up, Chrome 323858 Pop Up, Chrome Joint rotates 383858 Pop Up, Chrome Turn to side matching different tub wall angles.

10˚ degrees No screws or metal plate in any direction simply tighten faceplate A modern design for simple the overflow is to adjust to tub Easyinstallation, Installation retainer by hand to secur wall angle. designed with a secured gasket and a retainer nut that can be Soldtightened.

Separately An enhanced faceplate simply snaps firmly on hand without the use of unsightly screws or bolts.

The kits are available in ABS, PVC grey or PVC FR-PRO grey. Fig. 1 Also available, separately, for Canplas’s adjustable angle bath Polished Chrome Brushed Nickel Matte Black waste and overflow kits are new trim kits, which are available in 332809PCL Lift & Turn Adjust 332809BNL Lift & Turn 332809MBL Lift & Turn Jointand rotates Snap & Rotate or lift turn and comePop-Up in polishedTurn chrome, brushed Pop-Up Pop-Up 332809PCP pop-up 332809MBP 10˚ degrees 332809BNP Fig. 1plates, Simply snap and rotate the No screws or metal nickel and matte black. in any direction faceplateCanplas clockwise ontoPlumbing has been a premier manufacturer of simply tighten faceplate to adjust to tub the retainer. retainer by hand to secure. leak-free, corrosion-free drain, waste and vent fittings for over wall angle.

Easy Installation Determ ine pipe 50 years, and continues to look for new ways to develop its length You choose complete range of ABS and PVC plumbing products. outlet The company’s FR-Pro fittings are one example of its direction commitment to innovation. This product line is smoke and Plumbers putty You chooseflame-rated for non-combustible construction and was designed outlet to serve as a lightweight alternative to heavy cast iron fittings in Adjust direction Smooth side of gasket Fig. 1 Fig. 2 faces up Joint rotates high buildings.

Snap & Rotate Turn 10˚ degrees Simply snap and rotate the No screws or metal plates, Whether it isInDire DWV fittings, sewer fittings or speciality in any direction faceplate clockwise onto Bushing simply tighten faceplate to adjust to tub the retainer. plumbing products, Canplas Plumbing is committed to retainer by hand to secure.

Determ ine pipe wall angle. length continuous improvement. With the help its team of engineers, Fig. 2 and long-standing relationships with plumbers, homeowners, InDirect Bottom and inspectors, Canplas actively seeks feedback and incorporates suggestions to ensure customers are happy. Its one reason why You choose Plumbers putty Canplas says it offers consistent quality, competitive pricing, outlet direction and widely available stock from a single source.

Smooth side of gasket faces up Fig. 1 Canplas offers a comprehensive range of integrated solutions to meet the needs of engineers, contractors and distributors in Bushing commercial, institutional, industrial and residential construction.

Determ ine pipe length Fig. 2 Learn more about how Canplas offers consistent quality and InDirect Rear InDirect Bottom Direct competitive pricing at www.canplasplumbing.com.

Determine pipe length

Trim Kits

Determine pipe length

Determine pipe length

Installation

You choose outlet direction

Canplas Industries Ltd. 500 Veterans Drive, P.O. Box 1800 Barrie, Ontario, Canada L4M 4V3 Tel: (705) 726-3361

Toll Free: 1-800-461-5300

EXPERIENCE YOU CAN COUNT ON. PROFESSIONALS YOU CAN TRUST!

Adjustable Angle Bath Waste and Overflow Kits

Snap on faceplate with self-locking mechanism...with no unsightly screws

Canplas offers a comprehensive range of integrated solutions to meet the needs of engineers, contractors and distributors in commercial, institutional, industrial and residential construction.

Consistent quality and supply of plumbing fittings for over 50 years! canplasplumbing.com | 1-800-461-5300

n Advertorial

MINIMIZING CONTACT: Contact free reporting and e-mails help with social distancing as no physical paperwork needs to be handed to the client. This can all be done electronically. In addition, useful alerts, warnings, and notifications designed to keep the DC710 running optimally between annual certifications, reduces the need for human interaction or unnecessary service orders.

Making use of your Flue Gas Analyzer can help with challenges the “New Normal” may pose as you get back to work. With decades of FGA design and manufacturing experience, TPI has developed a product that provides solutions to today’s issues.

COST: Undoubtedly, overall costs of running a business will be re-evaluated. The DC710 Bluetooth FGA allows users to save money while making money. With smart design, we have reduced the build costs of the DC710 by removing components that cost the most: display, keypad, operating system, and processors. Smart phones and/or tablets already provide technicians with a far more enhanced and powerful display & processor than we could ever put into an FGA. Additionally, when designing the DC710 we kept proven technologies, such as the existing Flue Gas & Temperature Sampling Probe with Water Stop Technology. Keeping these standard accessories “standard” also works to keep units affordable.

Low cost servicing, or cost of ownership, is also a hallmark of the TPI brand.

FLEXIBILITY: The TPI View app is continually enhanced with updates which keep performance in step with constantly improving technology. This is not a static product which becomes obsolete the moment it’s off the shelf.

TPI DC710 and the accompanying TPI View app., offer following features: • 0 – 10,000 ppm CO sensor for residential, commercial, or even industrial use.

• GPS, date, and time tagged reports provide unequivocal proof of completed work.

• Notifications of Next Calibration Due Date, and reminders to put the test cap back on or to pick up all your test equipment at the end of the job help you manage your work.

• Detailed warnings of potential water or dust ingress using water stop technology and stopping the pump, protect the instrument from unnecessary downtime.

• The ability to add data from airflow, IAQ, pressure or temperature Smart Probes maximizes efficiency and thoroughness of reporting.

• All reports can easily be emailed to multiple recipients.

In short, TPI provides technology which reduces costs, lightens the workload, and keeps the FGA in optimal performance. Most significantly the DC710 provides security and peace of mind for the contractors and clients by making it easy to accurately determine the efficiency and safety of all fueled appliances.

Innovations in Air Distribution put the focus on health.

We are all spending a tremendous time indoors these days. On average, that’s about 21,000 indoor breaths every single day. A new technology debuting in Canada has come on the scene at precisely the right time. AIR EXCELLENT, the new air mangaement system from Centrotherm is reshaping the indoor air quality industry AIR EXCELLENT, a system that’s already improving air quality in many homes throughout Europe, is now available in Canada.

Simply put, AIR EXCELLENT is a fully engineered system of air distrubtion components that work together to precisely balance supply/return air individually to each room. The system easily clicks together to form an air-tight seal. Flexible ductwork, seal kits, and configured distribution boxes allow for quick system installation to provide fastest install for the contractor and the highest indoor air quality to the end-user.

How does it work?

Centrotherm’s proprietary software does all the calculations.

One of Centrotherm’s Air Excellent design engineers factors in the appliance type, and the dimensions of the house, then these data points are entered into the system.

Once complete, the software details the length of the runs, and the necessary modifications that will produce the required or desired air flow. It sounds complicated, but with the simplicity of Air Excellent’s engineering - the process is extremely quick and easy. Adjust the rings to the recommended size and that’s it.

Fresh air in every breath.

AIR EXCELLENT promotes overall wellness through the reduction of out-gassed VOCs and other indoor pollutants that affect asthma, allergies, and other respiratory afflictions.

Comprised of anti-static polymers, AIR EXCELLENT is also resistant to dust, and will reduce allergens and microbes from living spaces.

Our lives are all changing and it’s time to put indoor air quality at the forefront, and give deep consideration to the air we breathe.

AIR EXCELLENT

The New Air Management system from Centrotherm

A new day in air management has dawned. Providing the highest indoor air quality has become a major consideration for everyone involved in the construction process and AIR EXCELLENT is the solution.

Design limitations have been erased, and the highest indoor air quality can now be achieved.

Dream. Design. Build. Live. http://airexcellent.ca | 518.434.3400

www.multihvac.ca

Wall Mounted HVAC

Residential, Commercial, VRF

/

info@multihvac.ca

Condo HVAC

Multi HVAC Inc. is a value added HVAC distributor that specialize in a number of diverse HVAC product offerings.

Hisense S-Series Heat Recovery VRF is the latest addition to our line-up. The S-Series is a complete comfort solution for commercial and residential applications utilizing advanced VRF (variable refrigerant flow ) technology to economically cool and heat zones or rooms within a building by efficiently transferring waist heat between these zones operating in different modes (i.e. heat or cool) thus minimizing electrical consumption.

Air To Water In addition, waist heat can also be transferred to domestic hot water and in floor radiant systems by utilizing the Hydro Box air to water module.

AHU Connection Interface The S-Series line also features an Air Handling Unit Interface (AHU Kit) that is used to seamlessly integrate 3rd party air handling units, make up air units and/or DOAS equipment into the heat recovery VRF system.

Indoor Units Indoor units are available in a wide range of styles and capacities to match each installation requirement Low Ambient Heating Operation The state of the art Hisense “Hi-Heat” technology vapor injection scroll compressor, allows heating at outdoor temperatures as low as – 25°C, while maintaining exceptional heating capacity and COP. Advanced Evaporator Temperature Control Range The S-Series feature industry leading evaporator temperature control that is adjustable between 2°C to 16°C providing the following benefits:

•

Rapid cooling

•

Cold draft prevention by limiting uncomfortable cold discharge air temperatures (commonly associated with some other VRF brands)

•

Sensible Heat Ratio adjustment to match the application sensible and latent load requirements

•

Dehumidification applications requiring low dew point control

Scalable Controls A full line of controls are available ranging from local controls, Central Controls, Wi-Fi and BMS interfaces with advanced energy consumption proportioning for multi tenant buildings.

Service support your can trust Our knowledgeable staff provides personalized pre and post sales, product, technical and service parts support. Please contact us for more information .

Quality Meets Affordability !

Large Capacity

Computer Room

Wall Mounted HVAC

Air-Conditioners

Single & Multi Split Ductless

Stay tuned for SOMETHING

NEW!

Trades Talk A Plumbing & HVAC podcast series sponsored by:

January 2021 Podcast: Feature: How to attract youth into the trades with John and Leah Tech Talk: Drain Cleaning with Dave Dunbar from General Pipe Cleaners.
