CUBE® 30 - The ideal replacement for mesh gratings Get more advantages compared to the ordinary mesh grating - at the same price level!

30mm CUBE® steel gratings - ideal for industrial projects The new CUBE® 30 grating programme offers steel gratings and planks.

The 30mm height combined with 1.5 mm thickness provides a much lighter product without compromising with strength making the product ideal for industrial projects where the EN-ISO-14122 standard is valid. In addition, the low weight combined with practical and modern design offers new opportunities for industrial projects where ordinary mesh gratings have been the traditional choice. CUBE 30 gratings can with great advantage replace mesh gratings with mesh sizes from 30mm up to 45mm.

The CUBE® 30 grating offers an excellent R12 slip-resistant surface designed with our Oyster feature. The new 30mm height allows the CUBE 30 grating to be used for any industrial project as either a replacement or to be installed together with ordinary mesh gratings.

Design and Functionality

Mesh gratings reimagined The PcP gratings CUBE® 30 embrace design, quality and safety and can be applied for industrial applications where mesh gratings are used today.

2 |

Engineering Safety™

The new CUBE® 30 grating offers an improved and simplistic design. It is a unique state-of-the-art product in the market, where no other grating type can deliver the same advantages and attributes when it comes to safety, weight, strength and not least the reasonable price level introduced. The unique design is characterized by modern look and HSR* curled flanges to provide the desired load capacity for industrial applications. The grating is designed with our newest Cube pattern and punched holes with Oyster design for the highest slip-resistance. The light-weight design supports our strategy for a greener way of working and is regarded as a more responsible choice.

Adaptable Strength The CUBE® 30 design allows for high flexibility in regards to strength. With the unlimited possibility to install bearing bars in the 30mm high grating, the gratings and planks are easily adaptable to strength criteria that is needed.

CUBE® 30 is ideal for industrial projects where the following applications are included: 9 9 9 9

Walkways Platforms Industrial flooring Mezzanine Engineering Safety™ | 3

Comparison

Benefits

CUBE vs Mesh gratings

Enhanced slip resistance The slip resistance offered by the CUBE® is tested in with DIN 51130.

Slip resistance

R12 acc. to DIN 51130

Design

Modern - invented in 2020

Adaptable strength (view page 3)

Yes

Strength to weight ratio

High

ü ü ü

Traditional mesh gratings

R11

Traditional - invented in 1970

No

High strength & low weight The CUBE® grating has the optimal balance between weight and strength, making it a suitable and costefficient solution for all types of industrial applications.

Unique design Designed by PcP the CUBE® is the latest innovation, a modern alternative to the traditional mesh grating, offering a unique and modern design.

Low

More advantages & low price Airflow

High

High

Price Level

Competitive to mesh

-

Get more advantages compared to the ordinary mesh grating - at the same price level!

Simple & quick installation We designed the CUBE® gratings to be simple and easy to install - saving valuable time and enabling quick commissioning

EN ISO 14122 CUBE® gratings comply with the European standard EN ISO 14122 for loading and BS 4592 Part 0: 2006 + A1:2012.

4 |

Engineering Safety™

Engineering Safety™ | 5

Standard Gratings - Steel 240 YP

CUBE® 30 Gratings and planks

Item

Length

Width

Height

Thickness

Weight

Max. span

Finish

Item No.

Plank grating

700

1000

30

1.5

10,8

700

Hot-dip galv.

F004800101

Plank grating

700

1000

30

1.5

10,2

700

Self colour

F004800100

Plank grating

800

1000

30

1.5

12,2

800

Hot-dip galv.

F004790101

Plank grating

800

1000

30

1.5

11,5

800

Self colour

F004790100

Plank grating

900

1000

30

1.5

13,6

900

Hot-dip galv.

F004780101

Plank grating

900

1000

30

1.5

12,8

900

Self colour

F004780100

Plank grating

1000

1000

30

1.5

15,0

1000

Hot-dip galv.

F004770101

Plank grating

1000

1000

30

1.5

14,1

1000

Self colour

F004770100

Measurements in mm / weight in kg Weight includes reinforcement bars.

Technical Specifications Slip resistance Displacement space Flange design

R12 = 35° > slope > 27° acc. to DIN 51130 V10 acc. to DIN 51130 High Strength Rolled - HSR

Standard Planks - Steel 240 YP Item

Length

Width

Height

Thickness

Weight

Finish

Item No.

Plank

4000

200

30

1.5

8,9

Self colour

C050860100

43,5 x 43,5 mm

Plank

4000

250

30

1.5

9,8

Self colour

C050870100

Oyster - serrated dia 6,5 mm

Plank

4000

333

30

1.5

10,7

Self colour

C050880100

Downward drainage holes

34x34 mm

Plank

4000

500

30

1.5

12,5

Self colour

C050890100

Concentrated load capacity

1,5 kN / 200 x 200 mm acc. to EN ISO 14122

C-C grid Upward grip holes

Ballproff Uniform distributed load capacity:

Applications Access Walkways Industrial flooring Mezzanines

35 mm in accordance with EN ISO 14122-2 2 kN/m² acc. to EN ISO 14122

Plank specifications Plank width ( Pw )

200

250

333

500

no. of CUBES ( Pw )

3

4

6

10

Weight per meter (steel)

3,3

3,8

4,5

6,3

Weight per m2 (steel)

16,3

15,0

13,5

12,5

Weight per m2 ( galvanised )

17,6

16,2

14,6

13,5

Open area, min.

41%

43%

50%

54%

measurements in mm / weight in kg weight without reinforcement bars

Accessories Fixing clip, upper part Ma44/CUBE Fixing clip, lower part Socket button head screw - M8x60 Socket button head screw - M8x80 Square nut - M8x6.5

6 |

Engineering Safety™

Engineering Safety™ | 7

Trusted partnership

Bespoke Solutions How we can help to design your next project From your first request to design, manufacturing, and delivery, PcP strives to meet your project expectations in every way possible. At PcP, we believe successful customised projects consists of committed collaboration combined with years of experience.

We work with each client to understand their needs and develop customised solutions to meet each project criteria. Our experienced team is ready to take you through the challenging task from design and development to manufacturing and on-time delivery. In close collaboration, we help you define which minimum requirements your customised solution should meet. To design your solution, we only need a construction drawing of your application. When entering into a project partnership with PcP, you can expect to receive support for the following project elements: 9 9 9 9 9 9 9

Static calculations The optimal layout of pcp products in the construction for the most economical solution Physical testing of the solution if necessary 2D drawing material on the finished solution Approval of drawings at the customer premises Production Delivery

No matter the industry or application, CUBE® is an improved alternative to mesh gratings. It provides you with the benefit of high safety, combined with a unique design at affordable prices. Since the beginning of PcP in 1927, we have helped customers design and delivered bespoke solutions of very high quality. Over the years, PcP has built up an excellent production capability, vast knowledge and broad experience in what it takes to make a good, safe and economically optimal solution for a wide range of applications.

8 |

Engineering Safety™

Engineering Safety™ | 9

Load capacity tables

Load capacity tables

Apply the following load capacity tables for customised solutions.

Apply the following load capacity tables for customised solutions.

Plank 200 x 30 x 1,5 mm

Plank 333 x 30 x 1,5 mm - with 1 reinforcement bar 25x3 per plank

Free span mm, Ls

500

600

700

800

900

1000

1100

Concentrated load kN/200x200 mm

7,5

6,0

5,0

4,3

3,7

3,3

Deflection mm, concentrated load

0,8

1,2

1,6

2,0

2,5

Uniform distributed load kN/m

60,0

42,0

31,0

24,0

Deflection mm, uniform distributed load

0,9

1,3

1,8

2,3

2

Free span mm, Ls

500

600

700

800

900

1000

1100

3,0

Concentrated load kN/200x200 mm

4,1

3,2

2,7

2,3

2,0

1,8

1,6

3,1

3,8

Deflection mm, concentrated load

0,8

1,1

1,5

2,0

2,4

3,0

3,6

18,0

15,0

12,0

Uniform distributed load kN/m

39,0

27,0

20,0

15,0

12,0

9,5

8,0

2,8

3,6

4,2

Deflection mm, uniform distributed load

0,9

1,2

1,7

2,2

2,8

3,4

4,2

2

Maximum span for EN ISO 14122-2 requirement: 1200 mm

Maximum span for EN ISO 14122-2 requirement: 1100 mm

Plank 200 x 30 x 1,5 mm - with 1 reinforcement bar 25x3 per plank

Plank 333 x 30 x 1,5 mm - with 2 reinforcement bars 25x3 per plank

Free span mm, Ls

500

600

700

800

900

1000

1100

Concentrated load kN/200x200 mm

8,1

6,5

5,3

4,6

4,0

3,6

Deflection mm, concentrated load

0,8

1,2

1,6

2,0

2,6

Uniform distributed load kN/m

65,0

45,0

33,0

25,0

Deflection mm, uniform distributed load

0,9

1,3

1,8

2,3

2

Free span mm, Ls

500

600

700

800

900

1000

1100

3,2

Concentrated load kN/200x200 mm

5,3

4,2

3,5

3,0

2,6

2,3

2,1

3,1

3,7

Deflection mm, concentrated load

0,8

1,2

1,5

2,0

2,5

3,0

3,7

20,0

16,0

13,0

Uniform distributed load kN/m

42,0

29,0

21,0

16,0

13,0

10,0

8,5

2,9

3,6

4,2

Deflection mm, uniform distributed load

0,9

1,3

1,7

2,2

2,8

3,3

4,2

2

Maximum span for EN ISO 14122-2 requirement: 1300 mm

Maximum span for EN ISO 14122-2 requirement: 1200 mm

Plank 250 x 30 x 1,5 mm

Plank 500 x 30 x 1,5 mm - with 4 reinforcement bars 25x3 per plank

Free span mm, Ls

500

600

700

800

900

1000

1100

Free span mm, Ls

500

600

700

800

900

1000

1100

Concentrated load kN/200x200 mm

5,4

4,3

3,7

3,1

2,7

2,4

2,1

Concentrated load kN/200x200 mm

5,4

4,3

3,6

3,1

2,7

2,4

2,1

Deflection mm, concentrated load

0,8

1,1

1,6

2,0

2,5

3,0

3,6

Deflection mm, concentrated load

0,8

1,1

1,5

2,0

2,5

3,0

3,5

Uniform distributed load kN/m2

48,0

24,0

24,0

19,0

15,0

11,0

9,5

Uniform distributed load kN/m2

32,0

22,0

16,0

12,0

10,0

8,0

6,5

Deflection mm, uniform distributed load

0,9

1,3

1,7

2,3

2,9

3,2

4,1

Deflection mm, uniform distributed load

0,9

1,2

1,7

2,1

2,6

3,5

4,1

Maximum span for EN ISO 14122-2 requirement: 1200 mm

Maximum span for EN ISO 14122-2 requirement: 1100 mm

Plank 250 x 30 x 1,5 mm - with 1 reinforcement bar 25x3 per plank

Plank 500 x 30 x 1,5 mm - with 5 reinforcement bars 25x3 per plank

Free span mm, Ls

500

600

700

800

900

1000

1100

Concentrated load kN/200x200 mm

7,2

5,7

4,8

4,1

3,6

3,2

Deflection mm, concentrated load

0,8

1,1

1,5

2,0

2,5

Uniform distributed load kN/m

51,0

36,0

26,0

20,0

Deflection mm, uniform distributed load

0,9

1,3

1,7

2,2

2

Maximum span for EN ISO 14122-2 requirement: 1300 mm

Free span mm, Ls

500

600

700

800

900

1000

1100

2,9

Concentrated load kN/200x200 mm

5,8

4,6

3,9

3,3

2,9

2,6

2,3

3,0

3,7

Deflection mm, concentrated load

0,8

1,1

1,6

2,0

2,5

3,1

3,6

16,0

12,0

10,0

Uniform distributed load kN/m

34,0

23,0

17,0

13,0

10,0

8,5

7,0

2,9

3,3

4,0

Deflection mm, uniform distributed load

0,9

1,2

1,7

2,2

2,7

3,5

4,2

2

Maximum span for EN ISO 14122-2 requirement: 1200 mm

According to EN ISO 14122-2 the maximum deflection is 1 over 200 of the free span: Ls/200, and the deflection for the concentrated load, on the edge of the grating, must be maximum 4,0 mm compared to the adjacent flooring, to prevent tripping hazards.

10 |

Engineering Safety™

Engineering Safety™ | 11

Addressing a Growing Need In Zeewolde, a park was established to house labor migrants temporarily.

As the park underwent expansion, the plan encompassed the construction of four identical buildings. These structures required the installation of platforms and staircases between them, enabling residents to access their front doors conveniently.

The Innovative Solution In this context, PcP recommended the utilization of 30mm-high CUBE 30 gratings featuring the OYSTER serrated upward grip holes. These gratings do not only meet the required load-bearing standards but also allowed ample light transmission and featured an anti-slip profile to enhance safety.

This combination, coupled with competitive pricing and rapid delivery, convincingly led Staalbouw van Beek to adopt this solution.

Approximately 730 square meters of platforms were supplied using just four different grating sizes. The integration of standard B-CUBE® steps, sourced from our readily available stock, a cohesive and aesthetically pleasing result was achieved.

Advantages of CUBE® 30 in the Solution

Enhancing Housing Solutions for Migrant Workers: A Collaborative Success In a fruitful partnership with Staalbouw van Beek, we embarked on a journey to design effective housing solutions for migrant workers.

Originating as specialists in crafting steel structures for industrial and agricultural projects, Staalbouw van Beek transitioned its focus to cater to the evolving needs of labor migrants, marking a significant shift in their path.

Modern Design As the latest innovation from PcP, CUBE® presents a modern alternative to the traditional mesh grid, contributing to an updated aesthetic.

High Load-Bearing Capacity Despite being lightweight, CUBE 30 gratings strike an optimal balance between strength and weight, making them a competitive solution for diverse applications.

Effective Light Transmission The design of CUBE 30 gratings ensures sufficient light permeation throughout the spaces between the buildings, enhancing the overall environment.

Anti-Slip Platform With an anti-slip value compliant with R12 according to DIN 51130, CUBE® gratings prioritise safety and prevent accidents.

12 |

Engineering Safety™

Engineering Safety™ | 13

Explore other product patterns Safety gratings and treads for applications across industries

CUBE Oyster

OPTIMO O2

OPTIMO O3

steel | stainless steel | aluminium max slip resistance pattern: dia. 9/5 mm

steel | stainless steel | aluminium max slip resistance pattern: dia. 14/8,5 mm

steel | stainless steel max slip resistance pattern: serrated dia 6,5/34x34 mm

OPTIMO E

OPTIMO G

OPTIMO D

steel | stainless steel heel proof | closed surface

steel heel proof | closed surface rubber plugs available

steel | stainless steel | aluminium heel proof | closed surface

OPTIMO O5

OPTIMO LHD

OPTIMO STAR

MESH

steel slip resistant | heel proof pattern: dia. 5/5 mm

steel fire protection | slip resistant pattern: dia. 6/6 mm

steel | stainless steel | aluminium increased open area | slip resistant pattern: serrated dia. 21/21 mm

steel | stainless steel | aluminium | corten countless mesh combinations available optional slip resistance properties

Explore our products at www.pcp.corp.com

OPTIMO US

OPTIMO SPS

OPTIMO K

steel | stainless steel | aluminium increased open area | slip resistant pattern: serrated 48x14/48x14 mm

steel | stainless steel | aluminium heel proof | slip resistant pattern: dia. 5 mm

steel decreased open area | slip resistant pattern: dia. 14/9 mm

14 |

Engineering Safety™

PcP’s product range covers a vast range of gratings, treads and planks in various materials, finishes and patterns. PcP designs, develops and manufactures gratings to provide safety no matter the industry or application.

Explore our brands; CUBE®, OPTIMO®, MESH™ at www.pcp-corp.com.

Engineering Safety™ | 15

Engineering Safety™ Safety is at the very heart of our products and through everything we do. Our drive is to enable our customers - no matter their industry - to safely operate in their business routine, supported and surrounded by innovative PcP solutions.

DENMARK

SWEDEN

NORWAY

GERMANY

PcP. Danmark A/S Sverigesvej 2-4 7480 vildbjerg +45 97 13 12 00 salg@pcp-corp.dk

PcP. Sverige AB J A Gahms gata 6 421 31 Västra Frölunda +46 31 53 59 60 forsaljning@pcp-corp.se

PcP. Norge AS Kanalvegen 8 4033 Stavanger +47 51 95 00 50 salg@pcp-corp.no

PcP. Deutschland GmbH Duisbergstraße 13 58339 Breckerfeld +49 2338 91 81 10 verkauf@pcp-corp.de

BELGIUM

NETHERLANDS

UNITED KINGDOM

S.A. PcP. Belgium N.V. Rue de Remouchamps 34D 4140 Sprimont +32 4 360 94 50 vente@pcp-corp.be

PcP. Nederland B.V. Havendijk 21 4731 TA Oudenbosch +31 165315300 info@pcp-corp.nl

PcP. Gratings Ltd. Enterprise Drive, Four Ashes WV10 7DF Wolverhampton +44 1902 791 792 sales@pcp-corp.co.uk

www.pcp-corp.com
