路ANYDISCREPANCYINDRAWINGSSHALLBEBROUGHTTOTHE NOTICEOFTHEARCHITECTIMMEDIATELYBEFOREEXECUTION.
路ALLDIMENSIONSAREINFT&INCH.
STONEVENEER PANNELING
LEDLIGHTSTRIP BEHINDNAMEPLATE
DESCRIPTIONOFPROPOSAL&PROPERTY
PROPOSEDFURNITURE DESIGNFORFLATNO.-2/74 -KAMDHENUCHS, THANEEAST
SIGNATUREOFARCHITECT
INPASSAGEAREA
路ANYDISCREPANCYINDRAWINGSSHALLBEBROUGHTTOTHE NOTICEOFTHEARCHITECTIMMEDIATELYBEFOREEXECUTION. 路ALLDIMENSIONSAREINFT&INCH.
TVUNITWALL
DESCRIPTIONOFPROPOSAL&PROPERTY
PROPOSEDFURNITURE DESIGNFORFLATNO.-2/74 -KAMDHENUCHS, THANEEAST
SIGNATUREOFARCHITECT
FALSECEILING
BEDWALLANDWARDROBE
INTERNALDETAILOF
INTERNALDETAILOF BARUNIT ANDWARDROBE
INTERNALDETAILOF
PVCRAFTERSAT CEILING
PVCRAFTERSAT CEILING
LIVINGROOM BALCONY
NOTES
路ANYDISCREPANCYINDRAWINGSSHALLBEBROUGHTTOTHE NOTICEOFTHEARCHITECTIMMEDIATELYBEFOREEXECUTION.
路ALLDIMENSIONSAREINFT&INCH.
CONTENTOFSHEET
CONTENTOFSHEET
FALSECEILING LAYOUT
DESCRIPTIONOFPROPOSAL&PROPERTY
PROPOSEDFURNITURE
DESIGNFORFLATNO.-2/74 -KAMDHENUCHS, THANEEAST
SIGNATUREOFARCHITECT
SOCKETFORAC
COVESTRIPLIGHT
CONNECTEDTOSB1 ANDSB3
LEDSTRIPOVERTVUNIT
CONNECTEDTOSB2
LIGHTSINSIDESIDESTORAGE
CONNECTEDTOSB2ANDSB3
SOCKETFORDIWALILANTERN
SOCKETFORAC
LEDSTRIP INSIDEWARDROBE
KITCHEN
BEDROOM
LEDSTRIP INSIDEWARDROBE
LIVINGROOM
SOCKETFORAC
SWITCHBOARDLEGEND
SWITCHBOARDSAREAHEIGHT
SB1LIVINGROOM5'-0"
SB2LIVINGROOM2'-0"
SB3LIVINGROOM2'-0"
SB4 DINING5'-0"
SB5 KITCHEN5'-0"
SB6 KITCHEN
SB7 KITCHEN
SB8 KITCHEN
SB9BEDROOM15'-0"
SB10BEDROOM12'-0"
SB11BEDROOM12'-0"
SB12BEDROOM11'-6"
SB13 BASIN PASSAGE4'-0"
SB14M.BEDROOM3'-0"
SB15M.BEDROOM5'-0"
SB16M.BEDROOM1'-6"
SB17M.BEDROOM4'-0"
SB18M.BEDROOM2'-0"
SB19M.BEDROOM2'-0"
SOCKETLEGEND
SOCKETSAREAHEIGHT
LEDSTRIP INSIDEWARDROBE
S1 ABOVEDOOR (OUTSIDE)7'-3"
S2LIVINGROOMAC7'-6"
S3LIVINGROOMBALCONY7'-3"
S4KITCHENCHIMNEY2'-11"
S5KITCHENFORDISHWASHER1'-5"
S6KITCHENFORFRIDGE5'-0"
S7BEDROOM1FOR
DRYBALCONY
SAFETYDOORWITH FALSECEILING& WALLPANELING
