High quality EDM wire Sumitomo

Filtration Systems for all Engineering Process

Media free filtration systems

Committed to the manufacturing of metalworking fluids since 1887.

Since the beginning we have been recognized as a market leader in the development and modernization of all types of oil based lubricants and many of our current products have revolutionised the engineering industry. By continually developing manufacturing techniques and inventing new ones we can guarantee a premium product.

The success of oelheld is due to the fact that each product is carefully manufactured to enhance its particular application.

Whether it’s the addition of ‘satellite electrodes’ to EDM fluid or specially blended synthetic oils for tool grinding both will enhance machine performance, reduce consumable wear and provide a superior end product.

Philipp Storr and Martin Storr

Contents Grinding Fluids

5

Dielectrics

11

AquaTec (Water Soluble)

19

AirForge

25

Filtration Units

33

Indusa

53

Workholding

60

Consumables

70

: 85 : 22 million € : 47%

ISO14001 certification

2

To order call: 01745 814777

To order call: 01745 814777

3

Innovation as the key to success !

“Innovative fluid management and stringent product development and quality assurance are the key to the success of our products.“

Preface oelheld GmbH in Germany is a medium-sized business which can look back on 125 years of tradition and experience. Since its foundation in 1887 by Carl Christian Held oelheld GmbH has established as a lubricant specialist. Partnership, research and Human Technology are grown values and are our tradition that we are proud of.

Numerous machine manufacturers and universities are developing together with us products that are especially designed to the requirements of their machines. This kind of cooperation allows us to meet the specific requirements of our customers and adapt our fluids to the different applications.

Our laboratories are equipped with state of the art analysis and testing devices which meet the latest standards and satisfy our customers‘ wishes.

We are confident that you will find the information at your disposal enlightening and hope for a trustful and forward-looking cooperation.

Grinding Fluids Synthetic intelligence!

Sincerely Yours

Martin Storr CEO managing director 4

4

Philipp Storr CEO managing director

To order call: 01745 814777

To order call: 01745 814777

5

4

SintoGrind

TechnicalData Data Technical

Fully synthetic grinding oils Suitable for any grinding application SintoGrind is the best neat oil grinding fluid on the market. Clear in colour it produces a premium quality component with less wheel wear and is suitable for use with flushing pressures well in excess of 100 Bar. Our PAO (Polyalphaolefins)and GTL (Gas to Liquid) products offer engineered performance through bespoke man made base oils and are therefore recommended by many of the major grinding machine manufacturers to get the best out of their machines.

The right grinding fluid every machine!

The right grinding fluid forfor every machine!

Our grinding candivided be divided Our grinding fluidsfluids can be 3 product categories: into 3into product categories:

– polyalphaolefin PAO PAO – polyalphaolefin (SintoGrind Series) (SintoGrind Series)

High-end High-end product product

Hydrocrack Hydrocrack (DiaGrind Series/DiaMond) (DiaGrind Series/DiaMond) (we have coloured each section (we have coloured each section to help to help distinguish between the sections.) distinguish between the sections.)

Basic Basic product product

Mineral Mineral oil oil (ToolGrind/GearGrind) Mineral oil (ToolGrind/GearGrind)

4

Description

60/208/1000

SintoGrind TTS - For tool and cutter grinding applications

60/208/1000

SintoGrind TTK - For Carbide and High Speed Steel grinding (>50bar Flushing)

60/208/1000

SintoGrind IN - Especially engineered for Inconel

60/208/1000

SintoGrind SI - For grinding glass and technical ceramics

60/208/1000

SintoGrind TCX630 - New GTL based product for general purpose grinding applications

DiaGrind

Semi synthetic grinding oils A semi synthetic grinding oil produced from high purity Hydro-crack Hydrocarbons.

With additives that offer excellent cooling properties it is ideally suited to work requiring extreme precision, DiaGrind also performs well under high pressure situations when other fluids start to breakdown causing micro cracking.

Available in

Description

Foaming behaviour Foaming behaviour of of basic the the basic oilsoils

208/1000

DiaGrind 535/15 - For use gear grinding applications

208/1000

DiaGrind TTK 155 - For Carbide and High Speed Steel grinding

foaming behaviour air release andrelease air release properties of different Poor Poor foaming behaviour and and air release pro- proviourviour and air properties of different perties in filter systems foaming oils. the figures below, the sample perties resultresult in filter systems foaming over over and and basicbasic oils. In theInfigures below, the sample bott-bottgrinding results. the air trapped les were mineral oil, hydrocrack poor poor grinding results.

SinceSince the air trapped in thein the les were each each filled filled with with mineral oil, hydrocrack is compressed, the decompression that occurs and polyalphaolefin and heavily enriched oil is oil compressed, the decompression that occurs and polyalphaolefin and heavily enriched with with it leaves the cooling lubricant nozzle air. creates This creates andair theis air is trapped whenwhen it leaves the cooling lubricant nozzle cau- cauair. This foamfoam and the trapped in in ses cavitation results in increased A basic the basic oil is that is clearly as bubbles. ses cavitation that that results in increased wear.wear.

A the oil that clearly visiblevisible as bubbles.

A A laminar jet no canlonger no longer be directed crucial forfoaming the foaming behaviour and air laminar jet can be directed onto onto the the crucial factorfactor for the behaviour and air grinding wheel.

Theof use of low-foam grinding oil release property is how quickly the trapped grinding wheel.

The use low-foam grinding oil release property is how quickly the trapped air air air release properties increases can escape the basic oil how and how quickly with with goodgood air release properties thus thus increases can escape from from the basic oil and quickly the process reliability.

The tests carried the foam thereby breaks down. the process reliability.

The tests carried out inout ourin our the foam thereby breaks down. development centre illustrate the foaming development centre illustrate the foaming beha-beha-

208/1000

DiaGrind 535/25 - For use in gear grinding and hobbing applications

Mineral oil Mineral oil

6

Standard Standard product product

The choice the right product depends The choice of theofright product depends essentially on respective the respective process essentially on the process factors.

A fundamental qualitative factors.

A fundamental qualitative pre- preselection however, be made. selection can, can, however, be made.

As As polyalphaolefins are synthetically polyalphaolefins are synthetically pro- produced oils, they not only a duced basicbasic oils, they not only have have a particularly are also particularly high high puritypurity but but are also characterised by their resistance. characterised by their resistance.

The The incorporation of special additives incorporation of special additives deve-developed in oelheld’s own laboratories, loped in oelheld’s own laboratories, products are created that impress products are created that impress with with versatility and quality. their their versatility and quality.

Available in

Hydrocrack Hydrocrack

ToolGrind

Semi synthetic grinding oils A semi synthetic (Hydrocrack) oil for production grinding of carbide and steel components. Offers superior performance over standard mineral oils by improving production times and reducing wheel wear. Additional additives prevent cobalt leaching and aid cooling and lubrication making these products exceptionally suited for Carbide grinding as well as High Speed Steel. A good filtration system is also recommended for consistent results and fluid life.

Available in

Description

60/208/1000

Toolgrind TCX 620 - Semi Synthetic base oil with the Sintogrind additive pack

polyalphaolefin polyalphaolefin

To order call: 01745 814777

7

8

To order call: 01745 814777

To order call: 01745 814777

9

When quality...

Really matters!

01745 814777 www.oelheld.co.uk

IonoPlusÂŽ IME-MH Dielectric

To order call: 01745 814777

11

Strong fluids for your application

Whether for roughing work or use in ultrafine finishing – the dielectric has to satisfy the very specific requirements for every application. The high-performance dielectrics from oelheld are made from synthetic base oils and contain discharge-intensifying and wearreducing additives and ageing inhibitors for

use in electric discharge machining (EDM).

By contrast with the conventional mineral oil products, the high-purity synthesis products enriched with the oelheld-patented satellite electrodes from the IonoPlus® series are manufactured in a special blending process.

Quality as the key to success!

The benefits of oelheld

When Carl Christian Held started the production of machine oils and greases in 1887, he laid the foundation stone for a medium-sized company that over the past decades has established itself as a specialist in the lubricants sector. oelheld GmbH has existed in its present form since 1989, and has been managed by Dr. Manfred Storr since 1973.

The dielectrics from oelheld are characterised in particular by performance-enhancing and application-friendly properties.

Innovative fluid management, stringent product development and quality assurance are the key to the success of our products.

Numerous machine manufacturers therefore develop products together with us that are specially tailored to the demands of their machines.

That naturally applies also to our customer.

1948 Our many years of experience with high-tech lubricants also enable us to work intensively to the specific demands of our customers and to adapt existing fluids to a wide range of different production processes.

• • • • • • • “Innovative fluid management, stringent product development and quality assurance are the key to the success of our products.”

Dr. Manfred Storr, Managing Director

Less electrode wear Better polishing results Faster machining No filtration problems Neutral odour No health hazards All oelheld dielectrics can be mixed

The right dielectric for every machine!

EDM erosion discharge machines: IonoPlus® / IME / EcoSpark

Our dielectrics for EDM can be sub-divided into 3 product categories:

IonoPlus® Series

IME Series

High-end product Standard product

(shaded for easier identification)

EcoSpark 105

EDM wire cutting machines: IonoFil / ControFil 2 EDM high-speed boring machines: IonoVit

Starting product

(shaded for easier identification)

12

The dielectrics from oelheld have been tested in extensive series of trials and have proved to be effective in practice for decades. Leading manufacturers of erosion discharge machines and filters expressly recommend our grades.

The dielectrics have very high disruptive strength, are as clear as water (exept IonoPlus®) and practically odourless. Furthermore, they achieve the degree of purity of pharmaceutical white oils and are more or less free of aromatics.

13

The individual dielectrics from the oelheld product series are specially formulated in their different viscosities and additives to the machining steps and materials in questi-

on. In each product series you will find a variant specially formulated for polishing, roughing and universal application.

▲

Good discharge properties Non-irritating to the skin Low price

Made from fully synthetic base oils IonoPlus is safe for the user and the environment having no odour and a greatly extended working life compared to semi synthetic oils .

▲

Additional products for EDM:

Dielectric for starting hole erosion

ControXid Spray Corrosion protection for wire erosion

▲

IonoVit S

▲ ▲

Corrosion protection for wire erosion

▲

ControFil 2

Fully synthetic EDM fluid IonoPlus Synthetic Dielectric was the first EDM fluid to offer more than just a consumable product. With the addition of ‘satellite electrodes’ IonoPlus is able to greatly enhance the performance of any EDM machine whilst at the same time reduce electrode wear and offer a healthier working environment.

EcoSpark 105

• • •

IonoPlus

Available in

Description

60/208/1000

IonoPlus MH - For All EDM Applications

60/208/1000

IonoPlus ET - Lower Viscosity For Finishing Applications

60/208/1000

IonoPlus GL - Higher Viscosity For High Stock removal Applications

IME Series Dielectric

• • • • • • • •

No odour Transparent colour High discharge properties No irritation to the skin Low electrode wear Good surface qualities Excellent polishing properties Long service life of the dielectrics

Irregular ignition during fine machining DATE : 00 000 00 Time : 03:19:00 CH1:

200V : 100us

CH2:

500mV : 100us

0,76 – 0,82 DIN 51757

Viscosity at 40 o C (mm2/s)

1,30 – 3,70 DIN 51562

Flash point o C

56 – 120 DIN EN 22719

Aromatics content (% w/w)

< 0,01 DIN 51378

Regular ignition during fine machining with IonoPlus IME-MH DATE : 00 000 00 Time : 04:04:38

IonoPlus® Series

• • • • • • • • • • •

Combination of high-purity synthetic products Enriched with satellite electrodes Up to 20% higher discharge capacity than the IME dielectrics Free from aromatics No odour Transparent green colour Even lower electrode wear than with the IME dielectrics Excellent surface qualities Ever higher polishing properties Long service life of the dielectrics No toxic or allergic reactions

Technical Data IonoPlus® Series: Density at 15 o C (g/cm3)

0,76 – 0,82 DIN 51757

Viscosity at 40 o C (mm2/s)

1,30 – 3,70 DIN 51562

Flash point o C

14

Aromatics content (% w/w)

Fully synthetic oils (EDM) A fully synthetic dielectric oil for EDM. Offers excellent performance over a broad spectrum of applications from fine finishing to the heaviest roughing applications. If a machine is dedicated to a particular application then the overall performance can be enhanced further by using application specific products i.e IME 126 - heavy roughing applications.

Technical Data – IME Series Density at 15 o C (g/cm3)

IME Dielectric Fluids

CH1:

200V : 100us

CH2:

500mV : 100us

Code

Description

60/208/1000

IME 63 - Continuous fine finishing applications

60/208/1000

IME 82 - General applications requiring high stock removal / low wear

60/208/1000

IME 110 - Fine finishing but with a flashpoint over 100 Deg Centi

60/208/1000

IME 126 - Continuous heavy roughing applications

EcoSpark 105 As can be seen from the diagram above, more regular ignitions per unit of time can be achieved by changing the dielectric from IME to IonoPlus®. That means more discharges and hence shorter discharge times. The secret are the satellite electrodes distributed in the fluid that create a faster discharge bridge that produces an effectiv spark channel.

All oelheld dielectrics have been classified by the Research and Materials Institute Baden- Württemberg as representing no health hazard in their operational safety and industrial hygiene.

Semi synthetic oils (EDM) A semi synthetic (Hydrocrack) dielectric oil for EDM. EcoSpark offers an excellent performance / cost ratio for the production environment where high fluid loses due to frequent component & filter changes occur whilst maintaining a high safety level in terms of flashpoint and user protection.

Code

Description

60/208/1000

Prospark 107 - Production applications with high fluid losses

56 – 120 DIN EN 22719 < 0,01 DIN 51378
