Equans helps bring down energy bills in Leeds Equans has retrofitted 190 homes in Leeds, replacing gas boilers with air source heat pumps, and fitting solarPV. The £9m project in Holt Park for Leeds City Council also saw the global firm complete minor electrical work, including removing and replacing electrical fittings when installing EWI. Before all this happened, Equans made sure that the flats and the grid had sufficient capacity for the new electrical elements being installed.

The aim of this major overhaul was to drive down carbon emissions

and reduce residents' energy bills 150 of the flats are council-owned.

As well as Equans' work, new high-performance windows, doors and insulation have been installed, including specially designed 'warm roofs', which have insulation attached to the floor decking and rafters.

The project was a pilot scheme for the government's Social Housing

"Learnings fromHolt Park willbeused toinform future retrofit projects"

Decarbonisation Fund (SHDF) introduced by the Department for Business, Energy and Industrial Strategy - to improve the energy performance of social-rented homes.

The government has since gone on to release SHDF wave 1 and 2 funding. So learnings from Holt Park will be used to inform future retrofit projects.
