LOW/MEDIUM PRESSURE
Medium Pressure Hose
CONSTANT PRESSURE HOSE
3130 Medium Pressure Hose HIGH PRESSURE
Meets SAE 100R7 Specifications
r PART NUMBER
TWIN LINE HOSE AIR, WATER & TUBING TRUCK HOSE
3130-02003* 3130-03003 3130-04003 3130-04007 3130-05003 3130-05005 3130-06003 3130-06005 3130-08001 3130-08003 3130-12008 3130-16008
NOMINAL I.D.
MAXIMUM O.D.
MINIMUM BEND RADIUS
MAXIMUM WORKING PRESSURE
MINIMUM BURST PRESSURE
WEIGHT LB KG
AVAILABLE LENGTHS
in
mm
in
mm
in
mm
psi
bar
psi
bar
100ft
100m
feet
1/8 3/16 1/4 1/4 5/16 5/16 3/8 3/8 1/2 1/2 3/4 1
3.2 4.8 6.4 6.4 7.9 7.9 9.5 9.5 12.7 12.7 19.1 25.4
.335 .427 .510 .510 .594 .594 .669 .669 .816 .816 1.067 1.340
8.5 10.8 13.0 13.0 15.1 15.1 17.0 17.0 20.7 20.7 27.1 34.0
1/2 3/4 1-1/4 1-1/4 1-3/4 1-3/4 2 2 3 3 5 8
13 19 32 32 44 44 51 51 76 76 127 203
2,500 3,000 3,000 3,000 2,500 2,500 2,250 2,250 2,000 2,000 1,250 1,000
172 207 207 207 172 172 155 155 138 138 86 69
10,000 12,000 12,000 12,000 10,000 10,000 9,000 9,000 8,000 8,000 5,000 4,000
689 827 827 827 689 689 620 620 552 552 345 276
2.6 4.5 6.1 6.1 7.5 7.5 8.4 8.4 11.4 11.4 17.6 31.1
3.7 6.8 8.5 8.5 10.3 10.3 14.1 14.1 21.0 21.0 28.7 39.3
250 250 250 750 250 500 250 500 400 250 200 200
* SAE 100R7 does not apply to 1/8” size. The nylon core tube is a single wall and not bonded to the reinforcement.
SPECIALTY HOSE
Applications
Construction
• Long continuous lengths • Low elongation • Best value 100R7 hose
• • • •
• Black perforated polyurethane Cover • Spiraled or braided synthetic fiber reinforcement • Nylon-lined core tube Temperature Range • -40°F to 212°F (-40°C to 100° C) or to 150°F (66°C), with water-based or fire-resistant fluids
HOSE FITTINGS
Features
General hydraulics Material handling Forklift High pressure gas transfer • Chemical transfer
HOSE ASSEMBLY EQUIPMENT ACCESSORIES TECHNICAL DATA
Available at www.EatonProducts.com 8
EATON Synflex Hose and Fittings Technical Catalog E-HOOV-MC001-E1 March 2008
DIE & FITTING CHART
Part No.
Swage Die*
Permanent Fitting Series**
3130-02 3130-03 3130-04 3130-05 3130-06 3130-08 3130-12 3130-16
302 303 304 305 306 308 312 316
903 903 903 903 903 903 903 903
* Part No. 4540 **For stainless steel fittings availability, see hose fitting selection chart on page 28.
