Truck Hose
Features
Applications
Contents
• Specifically designed for modification and repair of OEM fuel systems that use Synflex 4294 or 4297 series fuel tubing • Utilize VOSS OEM barbed end fittings to maintain O-ring sealing end connection of the original OEM fuel system • OEM colors to maintain the same OEM color code integrity in the modified or repaired fuel system
• Transportation – trucks, busses, off-highway • Construction machinery & equipment • Agriculture machinery and equipment • Diesel engines & parts Synflex 4KGEN kits can be used to modify tank locations, routings and repair fuel systems in these and may other applications where diesel fuel is used.
Synflex 4KGEN Kits contain:
HIGH PRESSURE
Diesel 4KGEN Fuel Kits
TWIN LINE HOSE
• OEM male, female , straight and 90 degree VOSS barbed fittings • Synflex 4294 or 4297 series tubing
Kit Part #: 4KGEN-08-001
Kit Part #: 4KGEN-10-001
Contains the following:
Contains the following:
• 1/2� Plastic Female Fittings (P/N 4408-08710 - Qty. 4)
• 5/8� Brass Female Fittings (P/N 4408-10710 - Qty. 4)
s v 0LASTIC ƒ &ITTINGS 0 . 1TY
s v 0LASTIC ƒ &ITTINGS 0 . 1TY
• 1/2� Plastic Straight Fittings (P/N 4408-08310 - Qty. 2)
• 5/8� Plastic Straight Fittings (P/N 4408-10310 - Qty. 2)
• 1/2� Black Fuel Tubing (P/N 4294-0810K - 25 feet)
• 5/8� Black Fuel Tubing (P/N 4297-1010X001 - 25 feet)
• 1/2� Silver Fuel Tubing (P/N 4294-081FK - 25 feet)
• 5/8� Silver Fuel Tubing (P/N 4297-101FX-001 - 25 feet)
SPECIALTY HOSE
5/8� FUEL TUBING EXTENSION
Available at www.EatonProducts.com EATON Synflex Hose and Fittings Technical Catalog E-HOOV-MC001-E1 March 2008
25
TECHNICAL DATA
ACCESSORIES
HOSE ASSEMBLY EQUIPMENT
HOSE FITTINGS
1/2� FUEL TUBING EXTENSION
TRUCK HOSE
AIR, WATER & TUBING
• Contact Synflex for other kits or assemblies
