Brass Products Pipe Bushing
L
(Ref. SAE No. 130140) D C
Union
L C
D
Coupling
C
D
Reducer Coupling
C
(Ref. SAE No. 130138)
L
D A
Restriction Pipe Adapter (With .0625 Orifice)
A1
Catalog C D L Number
1/4* 3/8 3/8* 1/2* 1/2* 1/2* 3/4* 3/4*
3220x4x2 3220x6x2 3220x6x4 3220x8x2 3220x8x4 3220x8x6 3220x12x6 3220x12x8
1/8 1/8 1/4 1/8 1/4 3/8 3/8 1/2
5/8 11/16 11/16 7/8 7/8 7/8 1-1/8 1-1/8
.339 .328 .438 .530** .438** .562 .562 .703
0.59 0.75 0.69 0.75 0.75 0.75 0.88 0.88
*PTF Short Thread
**Optional Counterbore
Fem. Pipe Thread
Catalog C D L Number
1/4* 1/2
3250x4 3250x8
1-1/16 1-9/16
.438 .703
1.31 1.81
*PTF Short Thread
L
(Ref. SAE No. 130138)
Male Fem. Pipe Pipe Thread Thread
Fem. Pipe Thread
Catalog C D L Number
1/16 1/8 1/4 3/8 1/2 3/4
3300x1 3300x2 3300x4 3300x6 3300x8 3300x12
Fem. Fem. Pipe Pipe Thread Thread A A1
Catalog C D L Number
1/4 3/8 3/8 1/2
3300x4x2 3300x6x2 3300x6x4 3300x8x6
1/8 1/8 1/4 3/8
Male Female Pipe Pipe Thread Thread
Catalog Number
1/8
1512
1/8*
7/16 9/16 3/4 7/8 1-1/16 1-1/4
3/4 7/8 7/8 1-1/16
.339 .339 .438 .578 .703 .906
.339 .339 .438 .562
0.75 0.75 1.12 1.12 1.50 1.53
0.96 0.94 1.16 1.38
C D L
1/2
.0625
0.75
*PTF Short Thread
NOTE: Other orifice sizes available (special order only).
