3VE0
HYDRAULIC HOSE
Very High Pressure, Non-Conductive
Hose I.D. mm
Hose O.D. in
mm
Burst Pressure
Max. Operating Pressure in
bar
psi
bar
psi
Min. Bend Radius mm
Weight
in
Length
kg/m
lbs/ft
m
ft
Bulk
Bulk
3VE0-03
-03
5
4,8
0.19
13,2
0.52
689
10,000
2,758
40,000
38,0
1.50
0,11
0.08
3VE0-03-250BX
-03
5
4,8
0.19
13,2
0.52
689
10,000
2,758
40,000
38,0
1.50
0,11
0.08
76,2
250
3VE0-04
-04
6
6,4
0.25
15,1
0.60
689
10,000
2,758
40,000
64,0
2.50
0,16
0.11
Bulk
Bulk
3VE0-04-250BX
-04
6
6,4
0.25
15,1
0.60
689
10,000
2,758
40,000
64,0
2.50
0,16
0.11
76,2
250
3VE0-06
-06
10
9,5
0.38
19,8
0.78
551
8,000
2,206
32,000
76,0
3.00
0,23
0.16
Bulk
Bulk
3VE0-06-250BX
-06
10
9,5
0.38
19,8
0.78
551
8,000
2,206
32,000
76,0
3.00
0,23
0.16
76,2
250
Operating Parameters: Temperature Range -40°C to +66°C (-40°F to +150°F)
General hydraulic systems that may contact high voltage sources Rescue equipment and tools Mobile machinery Aerial equipment
Features: SAE J517 non-conductive hose construction. Less than 50 micro-amperes leakage when subjected to 75,000 volts/ft for five minutes Compact size Low elongation
SYNFLEX Fittings
AEROQUIP/TTC FITTINGS
Change in working length at working PSI ±2%
Applications:
WEATHERHEAD (U & Z SERIES) FITTINGS
Tube: Nylon-lined Reinforcement: Spiral high-tensile aramid fiber Cover: Orange, non-perforated polyurethane
3VE0 Hose Assembly Includes: 3VE0 hose 90V permanent steel fitting 45J0 hose guard
ASSEMBLY EQUIPMENT & Information
Construction:
tRUCK Hose
DN
AEROQUIP/POLYON FITTINGS
Hose Size
Warning tag
Fitting Reference
Page
90V
F23
9CV Stainless
F29
For hose fittings details, please see the fittings section.
www.HoseWarehouse.com www.TheCatalogRoom.com EATON Synflex Hose and Fittings Technical Catalog E-HOOV-MC001-E2 September 2013
