Cam & Groove Fittings
Dixon™ Butt Weld to Tube Cam and Groove Application: • designed to be butt welded to standard sanitary tubing Feature: • 316 stainless steel investment casting
C
adapter x butt weld to tube end 316 Stainless Steel Part # RE100BT RE150BT RE200BT RE300BT
Size 1" 1½" 2" 3"
Price/E $130.00 147.30 169.15 357.00
Boss-Lock™ coupler x butt weld to tube end 316 Stainless Steel Part # RC100BT RC150BT RC200BT RC300BT
Size 1" 1½" 2" 3"
Price/E $195.00 240.00 260.00 425.00
Dixon™ Adapters for Welding Feature: • not all configurations are stocked • line drawings are for reference only, consult Dixon™ for specific dimensions • final weld preparation, as with all weld fittings, is the responsibility of the welder
socket weld to schedule 40 pipe Size
Bore
¾" 1" 1½" 2" 3" 4" 5" 6" 8" DIX 8" BL
1.065 1.330 1.915 2.390 3.530 4.530 5.593 6.655 8.711 8.711
356T6 Aluminum Part # ----150AWSPAL 200AWSPAL 300AWSPAL 400AWSPAL 500AWSPAL 600AWSPAL 800AWSPAL 1 801AWSPAL 1
Price/E ----$63.00 46.35 58.60 80.00 123.75 135.00 474.00 453.00
316 Stainless Steel Part # 75AWSPSS 100AWSPSS 150AWSPSS 200AWSPSS 300AWSPSS 400AWSPSS 500AWSPSS 600AWSPSS -----
Price/E $104.20 97.95 117.00 110.00 196.35 298.00 450.00 474.00 -----
butt weld to schedule 40 pipe / socket weld to nominal OD tubing Size
Bore
¾" 1" 1½" 2" 3" 4" 5" 6" 8" BL
.765 1.015 1.515 2.015 3.015 4.015 5.015 6.020 8.035
1
60
356T6 Aluminum Part # ----150AWBPSTAL 200AWBPSTAL 300AWBPSTAL 400AWBPSTAL 500AWBPSTAL 600AWBPSTAL 801AWBPSTAL 1
Price/E ----$60.00 39.15 58.60 80.00 123.75 142.00 440.00
316 Stainless Steel Part # 75AWBPSTSS 100AWBPSTSS 150AWBPSTSS 200AWBPSTSS 300AWBPSTSS 400AWBPSTSS 500AWBPSTSS 600AWBPSTSS ---
Price/E $104.20 97.95 117.00 110.00 196.35 298.00 450.00 474.00 ---
Dixon™ and Boss-Lock™ cam and groove couplings do not interchange in the 8" size. 877.963.4966 • dixonvalve.com
