The Platform Grove - Portfolio

The Platform Grove Morgan Ripley

Contents Project Overview

The Platform Grove- Botanic Railway Platforms.

This project aims to create a bar space that can be functional at all times of the day. Due to its location, there is a need for somewhere to go throughout the day when visiting the gardens.

For this reason, I wanted to create a design that would work for a quick coffee or a late-night drink. The materials and colours need to work for this purpose. The space is underground, meaning lighting and the entrance are important elements to consider.

I was interested in this type of design as hospitality is my main interest in the interior design field. To create something that has different experiences for anyone that comes to it, is what interests me the most. After working in the hospitality industry, myself, it was also key for me to create a design with the employees in mind too. As the key design details of these spaces are for the customers, I thought it would be an interesting take to design for the staff as well.

The underground bar is not new to Glasgow but having a bar in a Botanical Garden and on an old railway line is something I haven’t seen before. The platforms are an important yet forgotten about section of Glasgow’s history, as it has stayed abandoned for over 40 years. To reinvent this space was something that was interesting to me. I kept the original purpose of the site in mind throughout the design and wanted to make nods to it as well.

Project Introduction and Elevation....................................................................................2 The Site................................................................................................................................4 Site Context.........................................................................................................................5 Floor Plan............................................................................................................................6 Visuals of Front of House...................................................................................................8 Stairs and Lift Staircase and Lift ..................................................................................................10 Staircase and lift- Material Board.......................................................................12 Staircase Detailing................................................................................................13 The Bar area The Bar .................................................................................................................14 The Bar - Material Board....................................................................................16 The Bar - Detailing...............................................................................................17 The Booth Seating The Booths ...........................................................................................................18 The Booths- Material Board...............................................................................20 Conversation Pits Conversation Pits - Material Board................................................................... 21 Conversation Pit ..................................................................................................22 Conversation Pit - Detailing................................................................................23 The Bathroom The Bathrooms ...................................................................................................24 The Bathrooms- Material Board.......................................................................26 The Staff Room The Staff Room- Material Board......................................................................27 The Staff Rooms- Details...................................................................................28

2

3

5 4

A

1

9 7

The Platform grove, an underground bar beneath the busy city street and nestled in the Botanic Gardens. A design with the fusion of natural beauty and industrial nostalgia- perfect for any outing.

Platform Grove isn’t just a bar, to me, it is a unique experience for every person in it. Designed with both customers and the staff in mind. Spanning over 61 meters long and 15.8 meters wide, with around 49 meters of that being customer facing (or front of house) areas.

At the heart of the design lies the centrepiece. The two repurposed train carts, sitting on top of the train tracks below. They have been converted into the bar area, holding two separate bars inside. The train carts are used to be a nod to the original purpose of the site. Step aboard to indulge in all the space has to offer. Alongside the bar, you can discover inviting conversation pits along with a plethora of other seating choices, like cosy booths. It is the perfect place for all, if you are having an intimate gathering, a night out with friends or even just a quiet moment of reflection. This space will be for you.

A 6

Welcome to The Platform Grove - where every visit is a journey worth savouring.

12

11

13 14

15

4

5

Site Context The Site-Glasgow Botanic Railway Platforms Gla

ss H

ouse

08

s

B8

My chosen site is the Botanic Railway Station Platforms. This site was opened in 1896 and was then closed during the war time. It was then re-opened again in 1919. The railway platforms weren’t popular with locals as the interior was soot-stained as the main trains were steam. After a steady decline in passengers, the railway line closed in 1939. After this the building was mainly left abandoned. The platforms have remained unused since then, with only the railway station main building being used for other purposes. Even though the area was barricaded, there is lots of graffiti plastered across the walls. It is a derelict building that has had no purpose since 1939.

tan

Bo orm

tf Pla ay ailw e) ic R my sit (

Kibble Palace

Gr ea

Gr osv

tW

en

est e

rn

Ro ad

or T

8

B80

tree mS ha

ne

ng

s Ln Cre

r La

ad

By

re

o sR

cki

r eno

no

Bu

sv Gro

Gr osv e

t

err ac e

6

7

Floor Plan

13

4

1- Bar Area/ Train Carriages 2- Lowered Seating Area 3- Version 1 Booths 4- Version 2 Booths 5- Stage

7

2

5

1

12

14

2

16

3 6

11

9 8 10

6- Mens Toilets 7- Womens Toilets 8- Disabled Toilet 9- Staircase and Lift (Entance/Exit)

15

10- Managers Office 11- Staff Room 12- KItchen 13- Staff Lift (Staff Entrance/Exit) 14- Staff Toilets and Lockers 15- Storage area with lockable areas x2 16- Keg Room with Keg Lift

8

9

Visuals of the Front of House View at 6 PM

View at 9 AM

Renders of the full public section of my design. It shows how each seperate section comes together to create the full bar experience.

VIew at 9 AM

10

11

(B)

View at 6 PM

The Staircase and Lift 13

4

7

12

14

1

5

(B)

16

15

9 8

Section Shown

(2)

(A)

The stairs and lift are very important element of the site. They are the only way for people to get into the bar itself, so it’s important for them to be detailed. I wanted the stairs to have a slight focus on them but still feel as if they blend in to the surrounding space. Using the glass on the landings of the stairs, it gives a slightly open feeling whilst keeping the safety. It was my intention that the customers can look out as they are coming down the stairs and see the full design.

(A) View at 6 PM

12

13

Stairs and lift Material Board

Detail of the Stairs

326mm

200mm

Right View of stairs - Scale 1:5 @A3

825mm

1500mm

587mm

Dark Concrete- Stairway Light Concrete- Flooring Glass- Handrail Metal Poles- Lift

1400 m

m

Right Isometric of Section 2 of the stairs.

1400mm

1400 m

m

14

15

The Bar 13

4

7

1

5

(B)

12

14

2

16

3 6

(A)

11

9 8 10

Section Shown

15

The bar was the key element of my design. I wanted to use old train carts as the main section of the bar to give another nod to the old purpose of the site. I used two old train carts welded together to create a 6m wide bar area. It is 6m x 10m to give pleanty of space for the two bars. I also wanted to show the train tracks below by creating a glass platform between the conversations pits on either site of the train carts.

VIew at 9 AM

View at 6 PM

Scale 1:200 @A3

16

17

Detail of the Bar

430mm

The Bar Material Board

Front Isometric Red Metal

mm

683

Matt Black Painswick Silver Sage Engineered Oak Click

TE081B Royal Blue

1067mm

Hope Blue Gloss Wall Tiles

Side View - Scale 1:25 @A3

MA003

mm

8 356

Plants

1499mm

150mm

Back View - Scale 1:25 @A3 234mm

1497mm

430mm

4218mm

3568mm

1135mm 1273mm

18

A view to show what the space will look like with different groups of people in it. Showing how the space can be utilised by a variety of different types of people.

The lunchtime meet up- for a quiet place to chat.

The Booths

Scale 1:200 @ A3

View at 6 PM

View at 12PM

19

A range of people coming to the bar after work.

Section detailed

5

16

9

15

The boothing was the area of seating that was most important to me. As working in bars and restaurants it is the seating type that people want the most. I wanted to show this area as it needed more detail across the walls, to stop it being plain. The elevation shows the decor on the shelving and the lamps that I want to use in the space.

20

21

The Booths Material Board

Conversation Pit Material Board

Country Farmhouse Multicolour Slate Tiles- Flooring COSMOS INDIGO FABRIC SAMPLE- Back of Booths Amber Leaf Leather- Seat of Booths Elgin Beach Engineered Oak- Booth Wood Painswick Silver Sage Engineered Oak Click- Table Top Matt Black- Table Frame Studley Earth Oak- Framing Wood

Booth Seating- Turin 2978 Shelving Wood- Studley Earth Oak Back of Booth Seating- DESTA CHARCOAL FABRIC Table Base- matt black Table Top- Painswick Silver Sage Engineered Oak Click Wood In Booths- Elgin Beach Engineered Oak

22

23 860mm 300mm

Booth Construction Details

25mm

The Conversation Pits

Support Beams Support beams boothsthemselves themselvestotobe befully fullysupported supported and andload loadbearing ForFor thethe booths they need to have support beams to help taketothe load. bearing.

They need to have support beams help takeThere the is a horizontal beam into the wall and then thewall vertical load. There is adrilled horizontal beam drilled into the andsupport then is drilled into this.

Thisisisdrilled repeated theislength of the booth the vertical support intoalong this. This repeated along theto ensure along the whole stretch.along the whole stretch. lengththe of support the booth to ensure the support

560mm 700mm 430mm

510mm

Booth Sizing Details

VIew at 9 AM

880mm 400mm

775mm

910mm

15

480mm

400mm

430mm

440mm 100mm

Anchor Points

This keeps the booth secured to the floor from multiple Anchor Points sections.

Keeps the booth secured to the floor from multiple To make secure: sections.

-fix Fixanchor anchorbrackets bracketstotothe thewooden woodenblock, block,drill drill20mm 20mm holesinto intothe theconcrete, concrete,insert insert rawbolts into concrete, holes rawbolt, tighten and then insert the bolts throughcaps. bracket hole into rawbolt, tighten, attach protective 9

attach protective caps.

1

Section detailed

Scale 1:25

Flooring Detail

Country Farmhouse Multicolour Slate

Flooring- Bibury Natural Distressed Engineered Oak

5

4

3

Mesh Reinforcements

Motar Bed Reinforcement Mesh

Waterproof Membrane

Waterproofing Material

Raw Concrete Concrete

Section Represented

The conversation pit at the bottom of the stairs, showing the possible lighting and the seating options with different groups of people.

24

25

The Toilets 4

(B)

13

(B) 7

12

View at 6 PM

(C)

View at 6 PM

14

1

5

15

(C)

6 9

11

(A)

Section Shown

(A)

View at 6 PM

The toilets were an element of the design which I wanted to show elements of the train station and train carriages. The use of red tiling and wood panels on the stalls where a nod to the design of old train carriages. The beige tiles and marble countertops of the sinks are influenced by flooring from the photos i’ve taken from different stations. The other aspect I focused on was the lighting for the toilets. I wanted it to have a relaxed atmosphere as most toilets have quite sterile white lights and I wanted to avoid that type of lighting.

26

27

The Bathroom Material Boards

Concrete- Flooring Light Beige- Paint Candy Red Tiles- Inside stalls Mirror Marble- sink top Beige Tiles- sink counter Lighting Blue Tiles- Wall Royal Blue- Wall

The Staff Room Material Boards

Rug Terracotta- paint circle Mint Counter fronts MA081 – Bardiglio- Counter Top MA094 - Verde Guatemala- Back Splash Dark Wood- Flooring

Concrete- Flooring

28

29

The Staff Room

Elevation of staff kitchen area

“Cozy Corner” A place for the staf to relax while on break.

The Staff Room needed to be a comfortable, relaxing space. Usual hospitality places don’t have very good staff rooms or staff rooms at all, so with my design brief I knew I had to make a space that would be a place I would want to have my breaks in. I wanted to give options, for seating and lighting. People spend their breaks in different ways, so having options for relaxing or eating food was something i needed to consider.

30

The Platform Grove Morgan Ripley Interior design Y4 Glasgow School of Art 2024
