Hello! I am Marc Gregory Olanio I am an Architectural Technologist and licensed Architect in the Philippines with over 8 years of professional experience.

A recent graduate of SAIT’s Architectural Technologies program, I now work at DIALOG, contributing to a range of projects from conceptual design to construction documentation—including high-rises, commercial spaces, residential buildings, cultural centers, and transit projects. With expertise in Building Information Modeling (BIM) and a commitment to effective project coordination, I bring a pragmatic, adaptable approach to every project, whether working independently or as part of a team.

Curriculum Vitae

EDUCATION

SOFTWARES

Diploma in Architectural Technologies Southern Alberta Institute of Technology 2024-2025

Revit | Advanced AutoCAD | Advanced Navisworks | Basic Sketchup | Advanced Lumion | Advanced D5 Render | Intermediate Bluebeam | Advanced Adobe Illustrator | Intermediate Adobe Photoshop | Intermediate Adobe InDesign | Intermediate Adobe Lightroom | Intermediate Microsoft Office Suite | Advanced

Bachelor of Science in Architecture Adamson University 2009-2014

WORK EXPERIENCES DIALOG Architectural Technologist | 2025-Present IAS Studio Architect | 2022-2023 Viatechnik Inc. BIM Specialist | 2019-2021 Arcadis GEC Architect II | 2016 –2019 AO+R Design and Associate Project Architect | 2015-2016 Arch Haus Asia Project Coordinator | 2014-2015 Phinma Properties Technical Assistant | 2014

RECOGNITIONS 2025 | Southern Alberta Institute of Technology METAFOR Capstone Scholarship Award 2024 | CSC Student Design Competition Second place | People’s Choice Award
