Mandala Custom Homes Plan Design Book

Welcome to the world of Mandala Custom Homes. We are happy that you have discovered us and that you are interested in learning more about our work!

As you may know, we are experts in designing and prefabricating faceted round structures that are beautiful and extraordinarily energy efficient. We ship building packages all over Canada and the USA (including Alaska and Hawaii).

Our clients are dedicated to creating the unique home of their dreams and are delighted to work with a company that supports them 100% in that realization.

Inside these pages you will find sample residential floor plans that are grouped according to six different Mandala series: The Aspen, the Magnolia, the Elmwood, the Juniper, the Trillium and the Tamarack. (Contact our office if you are interested in sample commercial projects.) These floor plans are examples that you and your in-house designer can use to begin customizing.

Our design process takes into account your dreams plus the needs of your site, your people and your budget. We are dedicated to your success and have found that working with your needs is the key to a successful project.

Mandala Custom Homes was founded with the inspiration to integrate sacred spaces into everyday living. Our concept combines skillful design principles with leading edge building science. With our professional and down-to-earth team you can feel confident that you are in good hands.

Enjoy browsing the pages of this book, then contact our office and request your complimentary Home Owner Road Map. This comprehensive document explains the steps and timelines to building your Mandala Home from the very beginning, all the way to moving into your new dream home.

benefits of a mandala custom HOME

For those craving a new home, Mandala Custom Homes provides unique dwellings that are meaningful, healthy and energy efficient. Our guarantee that your new home will be more comfortable than a standard home comes from the experience of building British Columbia’s first ENERGY STAR certified home in 2011. Mandala Custom Homes’ full design and planning service is backed by over 70 years of house building expertise. After creating a fully customized design, your expertly crafted home package is shipped directly to your site where it is assembled and finished to rest in place for many generations to come.

Purchasing a Mandala Custom Home can support your change to a more comfortable and relaxing lifestyle along with low monthly energy costs and architecture that nourishes the soul. Our work is rooted in traditional design principles combined with performance based building technology. We have a clear dedication to listen carefully to you so we can design and build the custom home of your dreams.

“to dwell in the round is to dwell in nature”

SAFER HOMES

• Our round homes are naturally safer than a conventional home. Plus our engineers fortify for extreme winds, snow loads and earthquake conditions

• Wind wraps around a round home making it safer in high winds

• We offer fire-safe cladding and insulation to ensure a safer home for you, your family and your investment.

PREFAB CONSTRUCTION

• Pre-building your home components in our production facility results in less waste, more precision and faster onsite assembly.

• You can enjoy the ease of house building and contributing to a better world while your home is quickly constructed to weathertight.

• Reduced construction time can save considerable money.

HEALTH AND HARMONY

• The circular nature of a Mandala Custom Home holds a special kind of energy

• Dwelling in a round home, surrounded by the warmth of wood, you are embraced with a sense of wellbeing that contributes to a healthy and harmonious life

ENERGY EFFICIENCY

• A Mandala Custom Home is designed and built to be Energy Star certified and can be Net Zero ready to ensure that you live comfortably in all seasons

• Our homes require smaller heating and cooling systems, which means lower initial costs while also reducing monthly energy costs

our people

our story

Lars Chose and Rachel Ross, owners of Mandala Custom Homes, are dedicated to creating a better world through their work in sustainable building. With backgrounds in construction, education, communication and design, Lars and Rachel are the ideal husband and wife team to lead their award winning company by using best practices in customer service, product development and organizational culture. You know that you’ve got the best when you come home to Mandala Custom Homes.

The people on our team are :

COMMITTED to our company mission statement “Make Life More Wonderful”

TRUE to our triple bottom line. The health of the Planet, the People and Sustainability. In every decision we make, we consider each aspect to be of equal value.

KNOWLEDGABLE about the art and science of building round. About cutting edge energy efficiency. And most importantly, about how to make your dreams of home come true.

LIVING THE LIFESTYLE that we endorse. We proudly live in a stunning part of the world that is rich in the best resources for creating one-of-a-kind buildings. We not only deliver a top quality service and product, but a little pristine BC air and the fragrance of the north woods waft from the special home package that we ship to you.

PEOPLE who work hard on your behalf. From our sales staff, office team, design studio, production crew to our building scientists - you will be surprised and delighted by the friendly support and care that you receive from every single person at Mandala Custom Homes.

“We love our home and are grateful for being able to do business with Mandala Custom Homes.”

-David and Melon, Christina Lake, B.C.

design services

Work with our designers to fully customize every detail of your new home. From decks and window placement to kitchen layout and material selection.

Your dream of the ideal home takes shape over time and is a unique reflection of you and your needs. When the time comes to make your dream into a reality, you deserve the best. Your Mandala Custom Home is the result of your amazing vision supported by our years of building expertise. Our team of trained designers know the value of good listening and great design.

Public and commercial projects

• Co-Housing

• Retreat Centres

• Temples

• Sacred Spaces

• Schools

• Visitor Centres

• Yoga Studios

“We just accepted our“BCTop Green Business” Award!

We sincerelywant to thankyou forhelping ourdream come true. Our Mandala Custom Home is an asset to our communityandwe are proud to haveworkedwithyou.”

-Kym and Kevin, Down to Earth Health Shop

Mandala Custom Homes builds more than homes. For almost two decades, we have designed and built a range of public and commercial buildings. We apply our same core values and professional skill to these projects. We work seamlessly with your commercial building team to create a unique space that fosters

• Community

• Connection

• Cost Predictability

• Green Building

• Unique Design

• Energy Efficiency

• Panoramic Views

We practice architecture that inspires the heart and minds of people. The use of organic architecture and sacred geometry is embedded in our design process. The result is a powerful balance of proportions that contributes to the beauty and presence of the building. Through the classic process of a design charrette, we work closely with your team. Our collaborative style is a discovery process that leads to the best representation of your vision and values combined with our knowledge in this field.

SERIES overview

ASPEN Pg.14

ELMWOOD Pg.42

MAGNOLIA Pg.32

JUNIPER Pg.52

TAMARACK Pg.58

TRILLIUM Pg.56

aspen SERIES

Floor Area: 3480 SQ FT

Bedrooms: 4

Bathrooms: 2.5

Width: 53’3

Depth: 53’3

- Structural Walls (Included)

- Nonstructural Walls (Not Included)

-

Second Floor

Floor Area: 3480 SQ FT

Bedrooms: 4

Bathrooms: 2.5

Width: 53’3

Depth: 53’3

- Structural Walls (Included)

- Nonstructural Walls (Not Included)

- Foundation Walls (Not Included)

*SHOWN AS PREMIUM PACKAGE

Floor Area: 2236 SQ FT

Bedrooms: 3

Bathrooms: 2.5

Width: 53’3

Depth: 53’3

-

-

Floor Area: 1747 SQ FT

Bedrooms: 3

Bathrooms: 2.5

Width: 30’2

Depth: 30’2

- Structural Walls (Included)

- Nonstructural Walls (Not Included)

- Foundation Walls (Not Included)

Floor Area: 1747 SQ FT

Bedrooms: 3

Bathrooms: 2.5

Width: 30’2

Depth: 30’2

- Structural Walls (Included)

- Nonstructural Walls (Not Included)

- Foundation Walls (Not Included)

*SHOWN

Loft (not to scale)

Floor Area: 1641 SQ FT

Bedrooms: 2

Bathrooms: 2

Width: 45’7

Depth: 45’7 *SHOWN

-

- Nonstructural Walls (Not Included)

- Foundation Walls (Not Included)

Aspen 1500- 3s 3 Storey

Floor Area: 1497 SQ FT

Bedrooms: 3

Bathrooms: 1.5

Width: 27’10

Depth: 27’10 *SHOWN AS

- Structural Walls (Included)

- Nonstructural Walls (Not Included)

- Foundation Walls (Not Included)

Floor Area: 1497 SQ FT

Bedrooms: 3

Bathrooms: 1.5

Width: 27’10

Depth: 27’10

Floor Area: 1378 SQ FT

Bedrooms: 2

Bathrooms: 2

Width: 41’9

Depth: 41’9

- Structural Walls (Included)

- Nonstructural Walls (Not Included)

- Foundation Walls (Not Included)

*SHOWN AS PREMIUM PACKAGE

Floor Area: 1212 SQ FT

Bedrooms: 2

Bathrooms: 1.5

Width: 27’10

Depth: 27’10 *SHOWN

Floor Area: 1212 SQ FT

Bedrooms: 2

Bathrooms: 1.5

Width: 27’10

Depth: 27’10

- Foundation Walls (Not Included)

Floor Area: 1137 SQ FT

Bedrooms: 2

Bathrooms: 1

Width: 37’11

Depth: 37’11

- Structural Walls (Included)

- Nonstructural Walls (Not Included)

- Foundation Walls (Not Included)

*SHOWN

Floor Area: 919 SQ FT

Bedrooms: 2

Bathrooms: 1

Width: 34’1

Depth: 34’1 *SHOWN

- Structural Walls (Included)

- Nonstructural Walls (Not Included)

- Foundation Walls (Not Included)

magnolia SERIES

Floor

Bedrooms: 4

Bathrooms: 2.5

Width: 62’8

Depth: 48’8 *SHOWN

Floor Area: 1868 SQ FT

Bedrooms: 3

Bathrooms: 2

Width: 58’10

Depth: 44’10

-

*SHOWN

Magnolia 1600

Floor Area: 1583 SQ FT

Bedrooms: 2

Bathrooms: 2

Width: 55’

Depth: 42’3

- Nonstructural Walls (Not Included)

- Foundation Walls (Not Included)

Floor

Bedrooms: 2

Bathrooms: 2

Width: 48’11

Depth: 37’11

Floor Area: 1301 SQ FT

Bedrooms: 2

Bathrooms: 2

Width: 48’11

Depth: 38’3 *SHOWN

-

Magnolia 1300

Floor Area: 1078 SQ FT

Bedrooms: 2

Bathrooms: 1

Width: 45’2

Depth: 34’ *SHOWN

-

- Nonstructural Walls (Not Included)

- Foundation Walls

Magnolia 1100

elmwood SERIES

Main Floor

Floor Area: 3738 SQ FT

Bedrooms: 3

Bathrooms: 2.5

Width: 84’4

Depth: 42’9

- Structural Walls (Included)

- Nonstructural Walls (Not Included)

- Foundation Walls (Not Included)

3 Storey

-

Loft (not to scale)

Floor Area: 3738 SQ FT

Bedrooms: 3

Bathrooms: 2.5 Width: 84’4

Floor Area: 3064 SQ FT

Bedrooms: 5

Bathrooms: 2.5

Width: 67’3

Depth: 42’3

- Structural Walls (Included)

Elmwood

3050- 2s

*SHOWN AS PREMIUM PACKAGE

Floor Area: 3064 SQ FT

Bedrooms: 5

Bathrooms: 2.5

Width: 67’3

Depth: 42’3

- Structural Walls (Included)

- Nonstructural Walls (Not Included)

Elmwood 2850- 2s

2 Storey

- Page 1 of 2-

Main Floor

Floor Area: 2842 SQ FT

Bedrooms: 5

Bathrooms: 3

Width: 63’

Depth: 53’5

- Structural Walls (Included)

- Nonstructural Walls (Not Included)

*SHOWN AS PREMIUM PACKAGE

Floor Area: 2842 SQ FT

Bedrooms: 5

Bathrooms: 3

Width: 63’

Depth: 53’5 *SHOWN

- Structural Walls (Included)

Elmwood

2850- 2s

Floor Area: 2402 SQ FT

Bedrooms: 3

Bathrooms: 2.5

Width: 63’

Depth: 53’5

- Structural Walls (Included)

- Nonstructural Walls (Not Included)

Second Floor

Floor Area: 2402 SQ FT

Bedrooms: 3

Bathrooms: 2.5

Width: 63’

Depth: 53’5

- Structural Walls (Included)

- Nonstructural Walls (Not Included)

*SHOWN

Floor

Bedrooms: 3

Bathrooms: 2.5

Width:

-

-

-

*SHOWN

Elmwood 2300- 2s

Bedrooms: 3

Bathrooms: 2.5

Width:

*SHOWN

Elmwood 2000

Floor Area: 2008 SQ FT

Bedrooms: 3

Bathrooms: 2

Width: 76’5

Depth: 63’8

- Structural Walls (Included)

- Nonstructural Walls (Not Included)

- Foundation Walls (Not Included)

*SHOWN AS PREMIUM PACKAGE

Elmwood 1750

Floor Area: 1762 SQ FT

Bedrooms: 2

Bathrooms: 2

Width: 63’

Depth: 53’5

- Structural Walls (Included)

- Nonstructural Walls (Not Included)

Floor Area: 1200 SQ FT

Bedrooms: 2

Bathrooms: 2

Width: 57’7

Depth: 53’2

-

Elmwood 1200

JUNIPER SERIES

Floor Area: 2332 SQ FT

Bedrooms: 3

Bathrooms: 2

Width: 100’8

Depth: 35’

- Structural Walls (Included)

- Nonstructural Walls (Not Included)

- Foundation Walls (Not Included)

*SHOWN AS PREMIUM PACKAGE

Juniper 2350

Floor Area: 1626 SQ FT

Bedrooms: 2

Bathrooms: 1

Width: 78’

Depth: 35’

- Structural Walls (Included)

- Nonstructural Walls (Not Included)

*SHOWN AS PREMIUM PACKAGE

- Foundation Walls (Not Included) SKYLIGHT

Juniper 1650

Trillium SERIES

Trillium 2550

Floor Area: 2569 SQ FT

Bedrooms: 4

Bathrooms: 2.5

Width: 121’

Depth: 44’7

- Structural Walls (Included)

- Nonstructural Walls (Not Included)

- Foundation Walls (Not Included)

*SHOWN AS PREMIUM PACKAGE

TAMARACK SERIES

Floor Area: 3627 SQ FT

Bedrooms: 4

Bathrooms: 2.5

Width: 104’3

Depth: 69’9

- Structural Walls (Included)

- Nonstructural Walls (Not Included)

- Foundation Walls (Not Included)

*SHOWN

Tamarack 3650

“Working with the Mandala Custom Homes team to design our home was a breeze - they were flexible, thoughtful, and very knowledgeable. The entire process was very positive, and we highly recommend them.”

-Robbin and Jon. Missoula, MT.
