Adjus table
• Dual Handle Design
• Adjustable T-Bar
KEY FEATURES
• T-Bar can be used for low rows , kneeling high pulls, or as an anchor for assisted Nordic curl
• T-Bar Storage is incorporated into rack design
• 600 lb Weight Stack
• 2:1 resistance ratio when both handles are being used
• 1:1 resistance ratio when both handles used simultaneously or linked together
• Handle connecting plate is included. This allows for the 2 pulley cables to be connected to single attachment handles & accessories
• Cable – USA manufactured and designed
• EXERFLEXPRO® Fitness Cable is manufactured with 7×19 construction (19 strands each containing 7 wires) preformed galvanized steel wire rope with a 3/16 black nylon jacket made specifically for this use.
• Cables are lot tested to ensure safety and durability, cables are assembled in an ISO 9000 certified facility
Adjustable Column Key Features
• 3”x3” 11 Gauge (.120 wall) Polished Stainless steel using 240 grit polishing pad
• Laser Cut numbers and holes
• 1” Holes spaced every 2 inches on all 4 sides, allows for 3x3 attachments to be used in conjunction with ACC
• Optional Attachments
• Dip
• Nordic Curl
Accessory Tube
• Laser Cut numbers and holes
• 1” Holes spaced every 2 inches on all 4 sides, allows for 3x3 attachments to be used or stored
Compatible with Dip Attachment
Dual Handle Adjustable Pulley Device
• Dual Handles having all cables behind 3x3 column
• Allows 3x3 column to be used for multiple exercises
• Design allows for smooth and effortless vertical adjustments
• Constructed with machined aluminum pulley housings for lightweight design
• 1 inch Pull-Pin engages into 1 inch holes that are spaced every 2 inches, added safety factor
• 4 rollers machined from Delrin High Strength plastic on 2 sides of upright
• Each Delrin Rollers contains (2) 608 2RS Abec-7 Bearings, 8 in total
• 1 inch Knurled Aluminum Handle
Adjustable Handle Assembly Handle Adjustment Rollers and 3x3 Stainless Column
Band Hooks - Standard
T-Bar Short T-Bar Extended
• Connecting Brace Chin Handle unit is currently the only ACC with this design/setup. Plans call for incorporating this design into the other ACC units including on a Dual Stack Functional Training Unit, as a wall or rack mounted station, and as part of a modular unit. No timeframe is available for the other versions.
