INDUKURI LAKESHORE
4 BHK PREMIUM VILLAS.
LOCATION : GOURELLY ROAD,HAYATH NAGAR, GOURELLY R.R.DISTRICT. R.R.DISTRICT
TYPE OF PROJECT : RESIDENTIAL
CLIENT : INDUKURI LIFE SPACES
SITE AREA : 24.5 ACRES.
PLOTTED AREA : 14.58 ACRES.
OPEN SPACE : 2.46 ACRES.
YEAR OF COMMENCEMENT : 2019
YEAR OF COMPLETION : UNDER CONSTRUCTION
TEAM : TEAM KARTHIKEYAN
TOTAL VILLAS : 224 VILLAS
TOTAL VILLA TYPES : 15 TYPES
EAST FACINGS - 120
WEST FACINGS - 103
NORTH FACING - 1
TOTAL CLUB HOUSES : 2 CLUB HOUSES
CONTRIBUTION - WORKING DRAWINGS
19
450 W2a W2a D1 01 03 15 17 19 22 24 26 28 30 42 21 OPEN TERRACE V3 05 10000 2950 450 3300 (21 EQ RISERS) 3300 (21 EQ RISERS) GROUND FLOOR LVL. FIRST FLOOR LVL. SECOND FLOOR LVL. ROOF LVL. FIN. GROUND LVL 34 36 38 40 32 01 03 DETAIL-B 300 150 0.02M0.01M 0.03M 0.02M 150MM LEDGE WALL DN UP 01 03 05 07 09 11 13 15 17 19 21 S2 W2a 320 22 24 26 28 30 32 34 36 38 40 42 S2 DN W2a S2 320 22 24 26 28 30 32 34 36 38 40 42 This drawing is copyright and may not be copied without prior written consent. The contractor shall verify all dimensions on site before commencing any work or shop drawing. Any discrepancies occurring in this drawing must be referred to the Architect before the commencement of work. PRELIMINARYINFORMATIONAPPROVAL TENDER CONSTRUCTION RELEASED FOR CHECKED BY DRAWN BY APPROVED ARCHITECT SCALE DATE 1. All specialist works, details and any deviations from this construction drawing, the contractor sub-contractor are to provide shop drawings for architect's Engineer's approval prior to construction. 2. This drawing should be read and not measured. 3. All dimensions are in millimeters and levels are in meters unless stated otherwise. 4. All drawings must be cross reference in case of any doubt discrepancy. 5. SFL represents structural floor levels and FFL represents finish floor levels. All dimensions shown in the drawings are structural masonry dimensions. 6. All architectural drawings must be referred coordination with structural drawings. 7. ±0.00 Level refers to the FFL at the entry of each villa and the same to be referred in the Master Plan entry for the individual. 8. All landscape details to be referred only in Landscape drawings. 9. All the PHE to be constructed as per detail. 10. All the external walls are 200mm thick and all the internal walls are 100mm thick unless mentioned. GENERAL NOTES R E V. SD KK SD KEY PLAN 25-10-2022 PLOT TYPENO. OF PLOTS PLOT NUMBERS SL DRAWING TITLE PROJECT TITLE CLIENT LANDSCAPE CONSULTANT MEP CONSULTANT STRUCTURAL CONSULTANT ARCHITECTURE CONSULTANT: NORTH M/s. INDUKURI LIFESPACES LLP INDUKURI LAKESHORE VILLAS @ HYATTNAGAR DRAWING NO Lanscape Architects Plot No-321/C, Jubilee Hills,Near P Obul Reddy Public School Road no-26. naveen@ecodes.in, ecodenaveen@gmail.com N REV. DESCRIPTION DONE BYDATE www.fhdindia.com FHD India Consultants LLP Plot 15,8-3-684 3-15, LIC Colony, Srinagar Colony, Hyderabad 500073 P: +91 40 23743324 25 F: 91 40 66621253 ARCHITECTURE LEGEND 200 MM THICK WALL 100 MM THICK WALL 150 MM THICK LOW WALL OF 1200MM HEIGHT TYPICAL STAIRCASE DETAILS TYPE-N EF 5 DETAIL @ A 1:10 6 DETAIL @ B 1:2 1 GROUND FLOOR PLAN 1:50 2 FIRST FLOOR PLAN 1:50 3 SECOND FLOOR PLAN 1:50 4 SECTION - S1 1:50 20
LAWN SP PD V3 150MM LEDGE WALL 800 300 POWDER ROOM 3'-6"7'-0" A B C D 150 150 2100 1200 600 BAL150 450 700 PD SP 1200 PD V3 SP 1060 150 600 1200 ±0.00 MM BAL 12 14 16 19 21 450 1100 V3 300 300 300 225 225 600 +150MM PD V3 800 450 SP 1060 150 1200 ±0.00 MM BAL 12 14 16 19 21 BAL GROUND FLOOR LVL. FIRST FLOOR LVL. 450 3300 LINTEL LVL FIN. GROUND LVL GROUND FLOOR LVL. FIRST FLOOR LVL. 450 3300 LINTEL LVL FIN. GROUND LVL PD V3 150MM LEDGE WALL POWDER ROOM 3'-6"7'-0" A B C D LAWN LAWN UTILITY 3.75 0.90 E1 E2 LIVING 22'-8"14'-4" UP S2 UP DINING KITCHEN BEDROOM-01 11'-8"15'-4" DRESS E3 800 1105 1000 2100 3300 PD V3 150MM LEDGE WALL 800 300 POWDER ROOM 3'-6"7'-0" A B C D 150 150 150 450 700 This drawing is copyright and may not be copied without prior written consent. The contractor shall verify all dimensions on site before commencing any work or shop drawing. Any discrepancies occurring in this drawing must be referred to the Architect before the commencement of work. PRELIMINARYINFORMATIONAPPROVAL TENDER CONSTRUCTION RELEASED FOR CHECKED BY DRAWN BY APPROVED ARCHITECT SCALE DATE 1. All specialist works, details and any deviations from this construction drawing, the contractor sub-contractor are to provide shop drawings for architect's Engineer's approval prior to construction. 2. This drawing should be read and not measured. 3. All dimensions are in millimeters and levels are in meters unless stated otherwise. 4. All drawings must be cross reference in case of any doubt discrepancy. 5. SFL represents structural floor levels and FFL represents finish floor levels. All dimensions shown in the drawings are structural masonry dimensions. 6. All architectural drawings must be referred coordination with structural drawings. 7. ±0.00 Level refers to the FFL at the entry of each villa and the same to be referred in the Master Plan entry for the individual. 8. All landscape details to be referred only in Landscape drawings. 9. All the PHE to be constructed as per detail. 10. All the external walls are 200mm thick and all the internal walls are 100mm thick unless mentioned. GENERAL NOTES R E V. SD KK SD KEY PLAN 29-08-2022 SL DRAWING TITLE PROJECT TITLE CLIENT LANDSCAPE CONSULTANT MEP CONSULTANT STRUCTURAL CONSULTANT ARCHITECTURE CONSULTANT: NORTH M/s. INDUKURI LIFESPACES LLP INDUKURI LAKESHORE VILLAS @ HYATTNAGAR DRAWING NO Lanscape Architects Plot No-321/C, Jubilee Hills,Near P Obul Reddy Public School Road no-26. naveen@ecodes.in, ecodenaveen@gmail.com 1:50 N REV. DESCRIPTION DONE BYDATE www.fhdindia.com FHD India Consultants LLP Plot 15,8-3-684 3-15, LIC Colony, Srinagar Colony, Hyderabad 500073 P: +91 40 23743324 25 F: 91 40 66621253 ARCHITECTURE LEGEND 200 MM THICK WALL 100 MM THICK WALL 150 MM THICK LOW WALL OF 1200MM HEIGHT TOILET DETAILS-1 POWDER ROOM 4 WALL ELEVATION- A 1:50 A00-00 5 WALL ELEVATION- B 1:50 A00-00 6 WALL ELEVATION- C 1:50 A00-00 7 WALL ELEVATION- D 1:50 A00-00 1 FLOORING LAYOUT 1:50 A00-00 2 FURNITURE LAYOUT 1:50 A00-00 3 ELECTRICAL LAYOUT 1:50 A00-00 COTTO GREY TILE FLOORING (600 X 1200) 6449 TILE DADO (600 X 1200) 150MM THICK LEDGE WALL FOR E.W.C. E.W.C AS/SPECS. HEALTH FAUCET AS/SPECS. COTTO GREY TILE FLOORING (600 X 1200) 6449 TILE DADO (600 X 1200) CHEQUED TILES (300 X 300) COTTO GREY TILE FLOORING (600 X 1200) 6449 TILE DADO (600 X 1200) COTTO GREY TILE FLOORING (600 X 1200) 6449 TILE DADO (600 X 1200) E.W.C AS/SPECS. FLOOR TRAP AS/SPECS WASH BASIN AS/SPECS. WASH BASIN AS/SPECS. MIRROR AS/SPECS. MIRROR LIGHT AS/SPECS. 6449 TILE DADO (600 X 1200) COTTO GREY TILE FLOORING (600 X 1200) HEALTH FAUCET AS/SPECS. L-EF 21
MASONRY LINE DADO LINE DADO DETAIL-D' 10MM 'C' GROOVE 22MM INTERNAL PLASTER 15 25 12 14 2MM GROOVE BETWEEN TILES. FINISHED WITH EPOXY GROUTING AS/ SPECS. 12MM FLOORING TILE AS/SPECS. SCREED 12MM TILE DROP FINISHED WITH EPOXY EPOXY GROUNTING FFL S1 D2 V1 x TOILET 6'-0"9'-0" A B C D SP 150MM LEDGE WALL 2700 150 150 1800 150 150 1200 BAL 600 450 1100 450 1100 D2 V1 300MM SUNK SP 125 125 300 650 1100 650 750 750 450 300 600 BAL +150 MM ±0.00 MM V1 300MM SUNK SP 1200 1200 150 600 BAL 1200 ±0.00 MM D2 D2 300MM SUNK SP 125 400 750 750 1200 600 BAL ±0.00 MM 800 450 V1 800 450 300MM SUNK SP 750 1200 150 750 1200 600 1200 BAL ±0.00 MM S1 D2 V1 x TOILET 6'-0"9'-0" A B C D 150MM LEDGE WALL 900 EQ EQ 450 300 1210 D2 V1 TOILET 6'-0"9'-0" A B C D 150MM LEDGE WALL GROUND FLOOR LVL. FIRST FLOOR LVL. 450 3300 LINTEL LVL FIN. GROUND LVL GROUND FLOOR LVL. FIRST FLOOR LVL. 450 3300 LINTEL LVL FIN. GROUND LVL 1.5M 14.2M 2.5M 18.2M 7.8M 1.3M 10.1M GROUND FLOOR PLANLAWN LAWN LAWN UTILITY 3.75 0.90 12.0 M WIDE DRIVEWAY TOILET 800 3500 800 1105 6800 3300 800 This drawing is copyright and may not be copied without prior written consent. The contractor shall verify all dimensions on site before commencing any work or shop drawing. Any discrepancies occurring in this drawing must be referred to the Architect before the commencement of work. PRELIMINARYINFORMATIONAPPROVAL TENDER CONSTRUCTION RELEASED FOR CHECKED BY DRAWN BY APPROVED ARCHITECT SCALE DATE 1. All specialist works, details and any deviations from this construction drawing, the contractor sub-contractor are to provide shop drawings for architect's Engineer's approval prior to construction. 2. This drawing should be read and not measured. 3. All dimensions are in millimeters and levels are in meters unless stated otherwise. 4. All drawings must be cross reference in case of any doubt discrepancy. 5. SFL represents structural floor levels and FFL represents finish floor levels. All dimensions shown in the drawings are structural masonry dimensions. 6. All architectural drawings must be referred coordination with structural drawings. 7. ±0.00 Level refers to the FFL at the entry of each villa and the same to be referred in the Master Plan entry for the individual. 8. All landscape details to be referred only in Landscape drawings. 9. All the PHE to be constructed as per detail. 10. All the external walls are 200mm thick and all the internal walls are 100mm thick unless mentioned. GENERAL NOTES R E V. SD KK SD KEY PLAN 29-08-2022 SL DRAWING TITLE PROJECT TITLE CLIENT LANDSCAPE CONSULTANT MEP CONSULTANT STRUCTURAL CONSULTANT ARCHITECTURE CONSULTANT: NORTH M/s. INDUKURI LIFESPACES LLP INDUKURI LAKESHORE VILLAS @ HYATTNAGAR DRAWING NO Lanscape Architects Plot No-321/C, Jubilee Hills,Near P Obul Reddy Public School Road no-26. naveen@ecodes.in, ecodenaveen@gmail.com 1:50 N REV. DESCRIPTION DONE BYDATE www.fhdindia.com FHD India Consultants LLP Plot 15,8-3-684 3-15, LIC Colony, Srinagar Colony, Hyderabad 500073 P: +91 40 23743324 25 F: 91 40 66621253 ARCHITECTURE LEGEND 200 MM THICK WALL 100 MM THICK WALL 150 MM THICK LOW WALL OF 1200MM HEIGHT TOILET DETAILS-1 GROUND FLOOR BEDROOM TOILET L-EF 1 DADO DETAIL 1:5 A00-00 2 TILE DROP DETAIL 1:5 A00-00 4 WALL ELEVATION- A 1:50 A00-00 5 WALL ELEVATION- B 1:50 A00-00 6 WALL ELEVATION- C 1:50 A00-00 7 WALL ELEVATION- D 1:50 A00-00 1 FLOORING LAYOUT 1:50 A00-00 2 FURNITURE LAYOUT 1:50 A00-00 3 ELECTRICAL LAYOUT 1:50 A00-00 LEGEND MUSHROOM GREY TILE FLOORING (600 X 1200) SUPERB EMPERADOR TILE DADO (600 X 1200) E.W.C AS/SPECS. FLOOR TRAP AS/SPECS WASH BASIN AS/SPECS. FLOOR TRAP AS/SPECS SHOWER SET AS/SPECS. SUPERB EMPERADOR TILE DADO (600 X 1200) COUNTER FOR WASH BASIN COUNTER FOR WASH BASIN HEALTH FAUCET AS/SPECS. E.W.C AS/SPECS. SUPERB EMPERADOR TILE DADO (600 X 1200) SUPERB EMPERADOR TILE DADO (600 X 1200) SUPERB EMPERADOR TILE DADO (600 X 1200) WASH BASIN AS/SPECS. MIRROR AS/SPECS. MIRROR LIGHT AS/SPECS. TILE DROP AS/DETAIL LEGEND MUSHROOM GREY TILE FLOORING (600 X 1200) COUNTER FOR WASH BASIN TILE DROP AS/DETAIL LEGEND MUSHROOM GREY TILE FLOORING (600 X 1200) LEGEND MUSHROOM GREY TILE FLOORING (600 X 1200) 1 GROUND FLOOR KEYPLAN LAYOUT - A00-00 L-EF LEGEND MUSHROOM GREY TILE FLOORING (600 X 1200) 22
ALLIANCE PHASE - 2 02
SITE AREA : 10.85 ACRES.
BUILT-UP AREA : 5,17,491 SQ.M.
OPEN SPACE : 4,401 SQ.M.
YEAR OF COMMENCEMENT : 2021
YEAR OF COMPLETION : UNDER CONSTRUCTION
TEAM : TEAM KARTHIKEYAN
CONTRIBUTION - 3D RENDERS, WORKING DRAWINGS
1983.16 SQ.M BUFER AREA PARKING BELOW NALLA & BUFFER 1164.69O.S.R-06SQ.M BUFERAREA TOWER B TOWER TOWER TOWER E 18.0 M WIDE ROAD 18M 18M SERVICE TRANSFORMER 569.69 SQ.M 12M O.S.R 404.34 SQ.M 12.0MWIDEDRIVEWAY 12.0 WIDEDRIVEWAY NALLA & BUFFER PHASE -01 ENTRY 11.0 WIDE DRIVEWAY 11.0 WIDE DRIVEWAY 11.0 M WIDE DRIVEWAY WIDE DRIVEWAY 11.0MWIDEDRIVEWAY 11.0 WIDE DRIVEWAY NALLA BUFFER NALLA BUFFER SERVICE 441.05 SQ.M O.S.R 02 278.12 SQ.M CLUB HOUSE G+5 FLOOR 200' WIDE ROAD TOWARDS BACHUPALLY TOWARDS MIYAPUR 18M 8M 18M 18.62M 18M 19.01M 19.97M 18.57M 8.87M 2B+4P+42FLOORS 2B+4P+42FLOORS 2B+4P+42FLOORS PARKING BELOW FUTURE EXPANSION EXISTINGNALA EXISTINGNALA EXISTING NALA EXISTING NALA EXISTING NALA TOWER LINE SITEBOUNDARYLINE SITEBOUNDARYLINE SITEBOUNDARYLINE BASEMENTLINE BASEMENTLINE TOWER -A TOWER TOWER CLUB HOUSE 1 8 0 M W I D E R O A D
23
PHASE -2 RENDERS 24
PODIUM OPTION 2
PODIUM OPTION 1
25
PODIUM OPTION 2
RAILNILAYAM 03
LOCATION : CHILAKALGUDA,RIFLE RANGE, SECUNDERABAD.
TYPE OF PROJECT : RESIDENTIAL
CLIENT : SOUTH CENTRAL RAILWAY
SITE AREA : 5.71 ACRES.
ROAD WIDENING : 0.73 ACRES.
BUILT-UP AREA : 39,341 SQ.M
OPEN SPACE : 0.38 ACRES.
YEAR OF COMMENCEMENT : 2023
TEAM : TEAM KARTHIKEYAN
CONTRIBUTION - PLANNING,WORKING DRAWINGS
26
PRINCIPAL ARCHITECT CERTIFICATE: It is hereby certified that FHD INDIA consultant LLP has been appointed as Principal Architect by Sri Varaaha Infra to provide architectural and allied services for the project of Lease land Grant for developement of Railway Land for 99 years including redevelopment of Railway Staff Colony of Rifle Range All the drawings have been prepard by FHD INDIA Consultant LLP and the same are being issued to Rail Land Development Authority and Sri Varaaha Infra for approvals. hereby undertake the responsibility of all architectural and allied services drawings and state that all the drawings are in confirmity with the applicable building bye laws of Government of Telangana and compliance of applicable provisions of National Building code 2016. shall be held responsible if there is any discrepancy found in the drawings. FHD INDIA consultant LLP S.DHAMOTHARAN REGD.ARCHITECT- CA/2003/31131 Address- Plot No: 15, 8-3, 684/3-15, Lane No 3, Sri Nagar Colony, LIC Colony, Hyderabad, Telangana 500073 S.No. W1 PANNELLED DOOR DOOUBLE SHUTTER WITH IRON GRILL & S.STEEL MOSQUITO PROOF WIRE MESH 1000 X 2100 FLUSH DOOR SINGLE SHUTTER 750 X 2100 900 UPVC FULLY GLAZED WINDOW 900 X 900 DESCRIPTION SCHEDULE OF DOORS & WINDOWS PER EACH UNIT WARD ROBE 650 DEPTH MARK SILL LEVELSIZE 1D 2D1 3D2 4D3 O 900 X 2100 PANNELED DOOR SINGLE SHUTTER 750 X 2100 PVC DOOR SINGLE SHUTTER OPENING 900 X 2100 1950 X 1200 900 W2 UPVC FULLY GLAZED WINDOW 1500 X 1200 W3 KW1 10 V1 1200 X 1200 UPVC FULLY GLAZED WINDOW RCC VENTILATOR WITH SS MOSQUITO MESH 600 X 600 BEAM BOTTOM-300 11 MGMS GRILL FULL HEIGHT 900 12 WR 13 1200 EXHAUST FAN 230Ø 900 100 2600 UPVC FULLY GLAZED WINDOW ALL UPVC WINDOWS ARE TO BE THREE TRACK ie TWO TRACKS WITH GLAZED PANE AND ONE TRACK WITH SS MOSQUITO MESH AND ALL WINDOWS SHALL BE PROVIDED WITH M.S. SAFETY GRILL KS 14 KITCHEN SHLEVES 2100 100 OS 15 OPEN SHELVES 2100 100 KW2 UPVC FULLY GLAZED WINDOW 1200 1500 X 900 16 Building Document Part-v Schedules and Specifications January 29,2020 Page no.40-43: Annexure 5: General Specifications. 17 18 VRCC VENTILATOR WITH SS MOSQUITO MESH 750 X 600 BEAM BOTTOM-300 2400 X 2100 SDSLIDING DOOR 2100 X 2100 SD1SLIDING DOOR 19 NOTES 1. ALL DIMENSIONS ARE SHOWN IN MILLIMETERS UNLESS OTHER WISE STATED. 2. THIS BUILDINGS IS TO BE DESIGNED FOR B+S+11 FLOORS. SPECIFICATIONS: 1. CODE OF SPECIFICATION: ALL CIVIL ENGINEERING WORKS RELATED TO BUILDING WORKS, ROAD WORKS & HORTICULTURE WORKS SHALL CONFIRM TO CPWD SPECIFICATIONS Vol. & CIRCULATED VIDE CE/Works lr. No. SCR-HQOENGG(SOR)/18/2019-DYCE/WORKS/SCR dtd. 26.02.2020 2. LEVELING COURSE SHALL BE CEMENT CONCRETE 1:3:6 USING 40mm MAX. SIZE GRADED HARD STONE AGGREGATE OF APPROVED QUALITY. 3. FOUNDATION RCC FRAMED STRUCTURE WITH M25 GRADE DESIGN MIX CONCRETE OF APPROVED QUALITY. 4. BASEMENT COURSED RUBBLE STONE MASONRY 2ND SORT IN CEMENT MORTAR 1:6 5. PLINTH FILLING MOORUM FILLING TO BE WELL WATERED AND CONSOLIDATED TO REQUIRED LEVEL. 6. ANTI-TERMITE TREATMENT WHERE TERMITES ARE FOUND ANTI-TERMITE TREATEMENT TO BE PROVIDED AS SHOWN IN DRAWING NO. GM(W)SC/3552. 7. SUPER STRUCTURE BRICK WORK WITH NON MODULAR BRICKS IN CEMENT MORTAR 1:6 FOR FULL BRICK (230mm THICK) WALLS AND 1:4 FOR HALF BRICK (115mm THICK) WALLS. 8. RCC WORK RCC M25 GRADE DESIGN MIX OF APPROVED QUALITY AS PER IS 456:2000. 9. DOORS FRAMES (EXCEPT TOILET) 2ND CLASS TEAK WOOD/UPVC EXTRUDED FRAME SECTONS WITH WALL THICKNESS MINIMUM 2.0mm POWDER COATED OR EXTRUDED/ TUBULAR SECTION/ENGINEERED WOOD SECTION. TOILET: 2ND CLASS TEAK WOOD/UPVC EXTRUDED FRAME SECTIONS WITH WALL THICKNESS MINIMUM 2.00mm /POWDER COATED/ ANODISED ALUMINUM EXTRUDED TUBULAR SECTION/ ENGINEER WOOD SECTION. SHUTTERS A)MAIN DOOR/EXTERNAL DOOR: DOUBLE SHUTTERS ONE WITH PAINTED IRON GRILL WITH STAINLESS STEEL GRADE 304 MOSQUITO PROOF WIRE MESH AND OTHER 35mm THICK FACTORY MADE HARDWOOD FRAMED PANELLED SHUTTERS WITH MELAMINE POLISH (OR) 35mm THICK MS TUBULAR BOX SECTION STYLES AND RAIL FRAMES WITH HARD WOOD PANEL (OR) FACTORY MADE FLUSH DOOR. B) KITCHEN DOOR 35mm THICK SHUTTER HAVING 12mm THICK PRELAMINATED (ONE SIDE DECORATIVE AND OTHER SIDE BALANCING) PARTICLE BOARD PANEL AT THE BOTTOM PART AND STAINLESS STEEL WIRE MESH AT UPPER PART. C)OTHER DOORS 35mm THICK HARD WOOD STYLES AND RAILS WITH PANNELLING, BOTH SIDES DECORATIVE PRELAMINATED PARTICLE BOARD AND FINISHED IN MELAMINE POLISH/ FACTORY MADE FLUSH DOOR. D)TOILET DOORS PVC FRAME AND PVC PANELS (OR) LAMINATE FLUSH DOOR ONE SIDE DECORATIVE OTHER SIDE BALANCING. 10. WINDOWS ALL UPVC WINDOWS ARE TO BE THREE TRACK ie TWO TRACKS WITH GLAZED PANE AND ONE TRACK WITH SS MOSQUITO MESH AND ALL WINDOWS SHALL BE PROVIDED WITH M.S. SAFETY GRILL 11. ROOF FINISHING A SLOPE OF 1 IN 100 OR STEEPER TO BE PROVIDED DEPENDING UPON THE TYPE OF WATER PROOFING SYSTEM FOR EFFECTIVE DRAINAGE. 12. PLASTERING ALL THE EXTERNAL SURFACES SHALL BE 18mm THICK IN Cm 1:5 II) ALL THE INTERNAL SURFACES SHALL BE 15mm THICK IN Cm1:6 III) CEILING SHALL BE 12mm THICK IN Cm 1:3. 13. POINTING RAISED & CUT POINTING ON STONE MASONARY IN Cm 1:3. 14. FLOORING I) LIVING, DINING & LOUNGE - VITRIFIED TILE FLOORING OF SIZE NOT LESS THAN 400mm 400mm. II) BED ROOMS SCRATCH RESISTANT VITRIFIED TILE FLOORING OF SIZE NOT LESS THAN 400mmX400mm. III) KITCHEN - ANTI SKID VITRIFIED TILE FLOORING OF SIZE NOT LESS THAN 300mm X 300mm. IV) COOKING PLATFORM 700 WIDTH MARBLE/GRANITE STONE WITH NOSING. V)COMMON CIRCULATION AREA GRANITE FOR UPPER FLOORS AND CC PAVER BLOCKS FOR PARKING FLOOR. VI) TOILET/BATH/WC ROOMS GLAZED CERAMIC ANTI-SKID OF SIZE NOT LESS THAN 300mmX300mm. 15. SKIRTING 100mm HIGH SKIRTING MATCHING WITH THE FLOOR MATERIAL. 16. DADO I) KITCHEN-CERAMIC TILES OF SIZE NOT LESS THAN 200mmX300mm UPTO LINTEL LEVEL. II) TOILETS/BATH/WC CERAMIC TILES OF SIZE NOT LESS THAN 200mmX 300mm UPTO DOOR HEIGHT WITH DECORATIVE BAND. 17. CLADDING GRANITE UPTO 2100 mm HIGH IN THE COMMON AREA. 18. FINISHINGS I) INTERNAL FINISHES: TREATED WITH P.O.P (ONE TIME ONLY) AND PAINTED WITH ACRYLIC WASHABLE DISTEMPER. II) EXTERNAL FINISHES: QUARTZ REINFORCED ACRYLIC FINISH/ACRYLIC SMOOTH WATER PROOF EXTERIOR FINISH. III) WOOD WORK & STEEL: SYNTHETIC ENAMEL PAINT ON ALL WOOD WORK & STEEL WORK. 19. SANITARY & WATER SUPPLY ARRANGEMENTS: 1. KITCHEN SINK STAINLESS STEEL WITH DRAIN BOARD. 2. WASH BASIN CERAMIC WITH CP BRASS MIXTURE 1 No. 3. ORISSA WC PAN 1 No. WITH LOW LEVEL FLUSHING PVC CISTERN. 4. EUROPEAN CLOSET 1 No. PEDESTAL TYPE WITH SEAT, LID AND LOW LEVEL FLUSHING PVC CISTERN ALONGWITH WATER JET/HEALTH FAUCET. 5. TAPS PTMT BIBCOCK WITH QUARTER TURN. 6. SHOWER: SHOWER WITH CP BRASS MIXTURE TYPE FOR HOT & COLD WATER, PTMT TOWEL RAIL. 7. MIRROR WITH FLOAT GLASS OF SIZE 600mm X 450mm WITH EACH WASH BASIN. 8.PLUMBING ARRANGEMENTS FOR WATER PURIFIER IN KITCHEN AND GEYSER IN TOILETS SHALL BE MADE. 9. STORAGE TANK SEPARATE TANKS FOR KITCHEN AND TOILETS AS PER REQUIREMENT. 20. SCALE OF AMENITIES (CIVIL/ELECTRICAL) SHALL BE PROVIDED AS PER THE RAILWAY BOARD Lr. `No.2013/LMB/10/15 dtd. 11-12-2013 FOR THE ITEMS NOT MENTIONED ABOVE. APPROVAL OF ENGINEER-IN-INCHARGE SHALL BE OBTAINED FOR THE DEVIATIONS, IF ANY. DRAWING TITLE TYPE-III QUARTER- TYPICAL FLOOR PLAN & 11TH FLOOR PLAN "REFERENCE TO SANCTION PARTICULARS" "LEASE AGREEMENT NO. RLDA/20211LA157 DATED 16-09-2021 RAILWAY SOUTH CENTRAL RAILWAY DIVISION HYDERABAD SCALE 1:150 SHEET SIZE : A1 DATE: SHEET NO 04/13 REV.NO. DATE: DRG.NO. PROJECT: "REDEVELOPMENT OF HIGH RISE RAILWAY QUARTERS WITH CLUB HOUSE AND RAILWAY OFFICE BUILDING AT RIFLE RANGE COLONY, SECUNDERABAD, TELANGANA STATE." DRAWING HEADING: PLAN SHOWING THE TYPICAL FLOOR PLAN OF TOWER-1, TYPE-III QUARTERS (S+10) AND 11TH FLOOR PLAN. "OWNER/CHECKED AND APPROVED BY RAILWAY LAND DEVELOPMENT AUTHORITY (MINISTRY OF RAILWAYS)" DEVELOPER "CPM/SC/ RLDA "JGM/PLNG/RLDA" 01
01 FLOOR PLAN -
GREENBELT KEY PLAN TOWER-01 F.noBUILT UP AREA 1 818.12 2 818.12 3 818.12 4 818.12 5 818.12 6 818.12 7 818.12 8 818.12 9 818.12 10 818.12 11 452.12 TOTAL 8633.32 PLINTH AREA OF ONE UNIT = 102.26 SQM MAIN UNIT BALCONY UTILITY AREA/BALCONY DESCRIPTION PERMITTED PLINTH AREA AS PER Rly.Bd lr.11-12-2013 (Sq.m) 63.00 06.50 3.50 PLINTH AREA AS PER DRG. (Sq.m) 66.24 5.25 3.72 PLINTH AREAS COMPARISON STATEMENT FOR UNITS UP TO 10TH FLOOR AREA EXCL. STAIRS & CIRCULATION 73.00 75.2 INCLUDING CIRCULATION AREA-27.06 SQM. PLINTH AREA OF ONE UNIT = 113.03 SQM MAIN UNIT BALCONY UTILITY AREA/BALCONY DESCRIPTION PERMITTED PLINTH AREA AS PER Rly.Bd lr.11-12-2013 (Sq.m) 63.00 06.50 3.50 PLINTH AREA AS PER DRG. (Sq.m) 66.24 5.25 3.72 PLINTH AREAS COMPARISON STATEMENT FOR UNITS IN 11TH FLOOR AREA EXCL. STAIRS & CIRCULATION 73.00 75.2 INCLUDING CIRCULATION AREA-37.83 SQM 2.0 M WIDE CORRIDOR W1 UTILITY 2.62 1.42M M.BED ROOM 3.65 3.35 M TOILET 1.375X 2.0M TOILET 1.375 2.0M LIVING DINING 5.57 X 3.35 KITCHEN 2.62X 2.03M BED ROOM 3.65 3.35M BALCONY 3.75 1.40M MD W2 V1 D3 D2 SD1 W2 UTILITY 2.62 X 1.42M M.BED ROOM 3.65 3.35 M TOILET 1.375X 2.0M TOILET 1.375 2.0M LIVING DINING 5.57 3.35 M KITCHEN 2.62X 2.03M BED ROOM 3.65 3.35M W2 KW2 D1 BALCONY 3.75 1.40M SD1 W1 2.0 M WIDE CORRIDOR OPEN TERRACE OPEN TERRACE OPEN TERRACE OPEN TERRACE ENTRY M.BED ROOM 3.65 3.35 M TOILET 2.0X 1.375M BED ROOM 3.65 3.35M MD W2 W2 V1 D3 D2 SD1 BALCONY 3.75 X 1.42M UTILITY 1.22 X 2.62M LIVING DINING 3.35 5.57 M KITCHEN 2.62X 2.03M TOILET 2.0X 1.375M ENTRY M.BED ROOM 3.65 X 3.35 M TOILET 2.0X 1.375M BED ROOM 3.65 3.35M MD W2 W2 V1 D3 D2 SD1 BALCONY 3.75 1.42M UTILITY 1.22 2.62M LIVING DINING 3.35 5.57 M KITCHEN 2.62X 2.03M TOILET 2.0X 1.375M W1 LIFT 2.0 M 2.5M LIFT 2.0 2.5M 1.6M FIRE TOWER LOBBY LIFT 2000 X 2600 DN LIFT 2.0 M 2.5M LIFT 2.0 2.5M 2.0 M WIDE CORRIDOR 2.0 M WIDE CORRIDOR 2.0 M WIDE CORRIDOR 2.0 M WIDE CORRIDOR M.BED ROOM 3.65 3.35 M TOILET 2.0X 1.375M BED ROOM 3.65 3.35M MD W2 V1 KW2 D3 SD1 BALCONY 3.75 X 1.42M UTILITY 1.22 X 2.62M LIVING DINING 3.35 5.57 M KITCHEN 2.62X 2.03M TOILET 2.0X 1.375M M.BED ROOM 3.65 X 3.35 M TOILET 2.0X 1.375M BED ROOM 3.65 3.35M MD W2 KW2 D3 D1 SD1 D1 BALCONY 3.75 1.42M UTILITY 1.22 2.62M LIVING DINING 3.35 5.57 M KITCHEN 2.62X 2.03M TOILET 2.0X 1.375M W1 M.BED ROOM 3.65 3.35 TOILET 2.0X 1.375M BED ROOM 3.65 3.35M MD W2 V1 KW2 D1 D2 SD1 D1 BALCONY 3.75 1.42M UTILITY 1.22 2.62M LIVING DINING 3.35 X 5.57 KITCHEN 2.62X 2.03M TOILET 2.0X 1.375M W1 M.BED ROOM 3.65 3.35 TOILET 2.0X 1.375M BED ROOM 3.65 X 3.35M MD W2 V1 KW2 D1 D2 SD1 BALCONY 3.75 1.42M UTILITY 1.22 X 2.62M LIVING DINING 3.35 X 5.57 KITCHEN 2.62X 2.03M TOILET 2.0X 1.375M W1 W1 UTILITY 2.62 1.42M M.BED ROOM 3.65 X 3.35 M TOILET 1.375X 2.0M TOILET 1.375 X 2.0M LIVING DINING 5.57 3.35 M KITCHEN 2.62X 2.03M BED ROOM 3.65 X 3.35M BALCONY 3.75 1.40M W2 V1 KW2 D1 D1 D2 SD1 UTILITY 2.62 1.42M M.BED ROOM 3.65 3.35 TOILET 1.375X 2.0M TOILET 1.375 2.0M LIVING DINING 5.57 3.35 M KITCHEN 2.62X 2.03M BED ROOM 3.65 3.35M W2 KW2 D1 D1 D2 BALCONY 3.75 1.40M SD1 W1 W1 UTILITY 2.62 1.42M M.BED ROOM 3.65 3.35 M TOILET 1.375X 2.0M TOILET 1.375 2.0M LIVING DINING 5.57 X 3.35 KITCHEN 2.62X 2.03M BED ROOM 3.65 3.35M BALCONY 3.75 1.40M W2 KW2 D1 SD1 UTILITY 2.62 X 1.42M M.BED ROOM 3.65 3.35 M TOILET 1.375X 2.0M TOILET 1.375 2.0M LIVING DINING 5.57 3.35 M KITCHEN 2.62X 2.03M BED ROOM 3.65 3.35M W2 KW2 D1 BALCONY 3.75 1.40M SD1 W1 UP DN 2.0 M WIDE CORRIDOR FIRE TOWER LOBBY LIFT 2000 X 2600 UP DN SLOPE SLOPE SLOPE SLOPE SLOPE SLOPE SLOPE SLOPE SLOPE DN E1 TOWER-1 E2 TOWER-1 S1 TOWER-1 S2 TOWER-1 E1 TOWER-1 E2 TOWER-1 S1 TOWER-1 S2 TOWER-1 3M 24M 3M 7M 3M 7M 3M 7M 3M 7M 3M 7M 10M 2M 10M 7M 3M 7M 7M 3M 7M 3M 7M 3M 7M 3M 7M 3M 24M 9M 3M 13M 21M 7M 9M 3M 13M 7M 3M 7M 3M 8M 3M 7M 3M 8M NO.OF STEPS 20 RISER- 152.5MM TREAD-300MM NO.OF STEPS 20 TREAD-300MM NO.OF STEPS 20 RISER- 152.5MM TREAD-300MM NO.OF STEPS 20 RISER- 152.5MM TREAD-300MM TOWER-1 TOWER-1 T-01 FIRE TOWER T-01 FIRE TOWER N ORIENTATION 27
TYPICAL FLOOR PLAN
(1st to 10th Floor) (11th Floor)
- (TOWER-1)
NOTES 1. ALL DIMENSIONS ARE SHOWN IN MILLIMETERS UNLESS OTHER WISE STATED. 2. THIS BUILDINGS IS TO BE DESIGNED FOR B+S+11 FLOORS. SPECIFICATIONS: 1. CODE OF SPECIFICATION: ALL CIVIL ENGINEERING WORKS RELATED TO BUILDING WORKS, ROAD WORKS & HORTICULTURE WORKS SHALL CONFIRM TO CPWD SPECIFICATIONS Vol. & 2 CIRCULATED VIDE CE/Works lr. No. SCR-HQOENGG(SOR)/18/2019-DYCE/WORKS/SCR dtd. 26.02.2020 2. LEVELING COURSE SHALL BE CEMENT CONCRETE 1:3:6 USING 40mm MAX. SIZE GRADED HARD STONE AGGREGATE OF APPROVED QUALITY. 3. FOUNDATION RCC FRAMED STRUCTURE WITH M25 GRADE DESIGN MIX CONCRETE OF APPROVED QUALITY. 4. BASEMENT COURSED RUBBLE STONE MASONRY 2ND SORT IN CEMENT MORTAR 1:6 5. PLINTH FILLING MOORUM FILLING TO BE WELL WATERED AND CONSOLIDATED TO REQUIRED LEVEL. 6. ANTI-TERMITE TREATMENT WHERE TERMITES ARE FOUND ANTI-TERMITE TREATEMENT TO BE PROVIDED AS SHOWN IN DRAWING NO. GM(W)SC/3552. 7. SUPER STRUCTURE BRICK WORK WITH NON MODULAR BRICKS IN CEMENT MORTAR 1:6 FOR FULL BRICK (230mm THICK) WALLS AND 1:4 FOR HALF BRICK (115mm THICK) WALLS. 8. RCC WORK RCC M25 GRADE DESIGN MIX OF APPROVED QUALITY AS PER IS 456:2000. 9. DOORS FRAMES (EXCEPT TOILET) 2ND CLASS TEAK WOOD/UPVC EXTRUDED FRAME SECTONS WITH WALL THICKNESS MINIMUM 2.0mm POWDER COATED OR EXTRUDED/ TUBULAR SECTION/ENGINEERED WOOD SECTION. TOILET: 2ND CLASS TEAK WOOD/UPVC EXTRUDED FRAME SECTIONS WITH WALL THICKNESS MINIMUM 2.00mm /POWDER COATED/ ANODISED ALUMINUM EXTRUDED TUBULAR SECTION/ ENGINEER WOOD SECTION. SHUTTERS A)MAIN DOOR/EXTERNAL DOOR: DOUBLE SHUTTERS ONE WITH PAINTED IRON GRILL WITH STAINLESS STEEL GRADE 304 MOSQUITO PROOF WIRE MESH AND OTHER 35mm THICK FACTORY MADE HARDWOOD FRAMED PANELLED SHUTTERS WITH MELAMINE POLISH (OR) 35mm THICK MS TUBULAR BOX SECTION STYLES AND RAIL FRAMES WITH HARD WOOD PANEL (OR) FACTORY MADE FLUSH DOOR. B)KITCHEN DOOR 35mm THICK SHUTTER HAVING 12mm THICK PRELAMINATED (ONE SIDE DECORATIVE AND OTHER SIDE BALANCING) PARTICLE BOARD PANEL AT THE BOTTOM PART AND STAINLESS STEEL WIRE MESH AT UPPER PART. C)OTHER DOORS 35mm THICK HARD WOOD STYLES AND RAILS WITH PANNELLING, BOTH SIDES DECORATIVE PRELAMINATED PARTICLE BOARD AND FINISHED IN MELAMINE POLISH/ FACTORY MADE FLUSH DOOR. D)TOILET DOORS PVC FRAME AND PVC PANELS (OR) LAMINATE FLUSH DOOR ONE SIDE DECORATIVE OTHER SIDE BALANCING. 10. WINDOWS ALL UPVC WINDOWS ARE TO BE THREE TRACK ie TWO TRACKS WITH GLAZED PANE AND ONE TRACK WITH SS MOSQUITO MESH AND ALL WINDOWS SHALL BE PROVIDED WITH M.S. SAFETY GRILL 11. ROOF FINISHING A SLOPE OF IN 100 OR STEEPER TO BE PROVIDED DEPENDING UPON THE TYPE OF WATER PROOFING SYSTEM FOR EFFECTIVE DRAINAGE. 12. PLASTERING I) ALL THE EXTERNAL SURFACES SHALL BE 18mm THICK IN Cm 1:5 II) ALL THE INTERNAL SURFACES SHALL BE 15mm THICK IN Cm1:6 III) CEILING SHALL BE 12mm THICK IN Cm 1:3. 13. POINTING RAISED & CUT POINTING ON STONE MASONARY IN Cm 1:3. 14. FLOORING I) LIVING, DINING & LOUNGE VITRIFIED TILE FLOORING OF SIZE NOT LESS THAN 400mm X 400mm. II) BED ROOMS SCRATCH RESISTANT VITRIFIED TILE FLOORING OF SIZE NOT LESS THAN 400mmX400mm. III) KITCHEN ANTI SKID VITRIFIED TILE FLOORING OF SIZE NOT LESS THAN 300mm X 300mm. IV) COOKING PLATFORM 700 WIDTH MARBLE/GRANITE STONE WITH NOSING. V)COMMON CIRCULATION AREA GRANITE FOR UPPER FLOORS AND CC PAVER BLOCKS FOR PARKING FLOOR. VI) TOILET/BATH/WC ROOMS GLAZED CERAMIC ANTI-SKID OF SIZE NOT LESS THAN 300mmX300mm. 15. SKIRTING 100mm HIGH SKIRTING MATCHING WITH THE FLOOR MATERIAL. 16. DADO I) KITCHEN-CERAMIC TILES OF SIZE NOT LESS THAN 200mmX300mm UPTO LINTEL LEVEL. II) TOILETS/BATH/WC CERAMIC TILES OF SIZE NOT LESS THAN 200mmX 300mm UPTO DOOR HEIGHT WITH DECORATIVE BAND. 17. CLADDING GRANITE UPTO 2100 mm HIGH IN THE COMMON AREA. 18. FINISHINGS I) INTERNAL FINISHES: TREATED WITH P.O.P (ONE TIME ONLY) AND PAINTED WITH ACRYLIC WASHABLE DISTEMPER. II) EXTERNAL FINISHES: QUARTZ REINFORCED ACRYLIC FINISH/ACRYLIC SMOOTH WATER PROOF EXTERIOR FINISH. III) WOOD WORK & STEEL: SYNTHETIC ENAMEL PAINT ON ALL WOOD WORK & STEEL WORK. 19. SANITARY & WATER SUPPLY ARRANGEMENTS: 1. KITCHEN SINK STAINLESS STEEL WITH DRAIN BOARD. 2. WASH BASIN CERAMIC WITH CP BRASS MIXTURE No. 3. ORISSA WC PAN 1 No. WITH LOW LEVEL FLUSHING PVC CISTERN. 4. EUROPEAN CLOSET 1 No. PEDESTAL TYPE WITH SEAT, LID AND LOW LEVEL FLUSHING PVC CISTERN ALONGWITH WATER JET/HEALTH FAUCET. 5. TAPS PTMT BIBCOCK WITH QUARTER TURN. 6. SHOWER: SHOWER WITH CP BRASS MIXTURE TYPE FOR HOT & COLD WATER, PTMT TOWEL RAIL. 7. MIRROR WITH FLOAT GLASS OF SIZE 600mm X 450mm WITH EACH WASH BASIN. 8.PLUMBING ARRANGEMENTS FOR WATER PURIFIER IN KITCHEN AND GEYSER IN TOILETS SHALL BE MADE. 9. STORAGE TANK SEPARATE TANKS FOR KITCHEN AND TOILETS AS PER REQUIREMENT. 20. SCALE OF AMENITIES (CIVIL/ELECTRICAL) SHALL BE PROVIDED AS PER THE RAILWAY BOARD Lr. `No.2013/LMB/10/15 dtd. 11-12-2013 FOR THE ITEMS NOT MENTIONED ABOVE. APPROVAL OF ENGINEER-IN-INCHARGE SHALL BE OBTAINED FOR THE DEVIATIONS, IF ANY. DRAWING TITLE TYPE-III QUARTER- ELEVATIONS & SECTIONS "REFERENCE TO SANCTION PARTICULARS" "LEASE AGREEMENT NO. RLDA/20211LA157 DATED 16-09-2021 RAILWAY SOUTH CENTRAL RAILWAY DIVISION : HYDERABAD SCALE 1:200 SHEET SIZE A1 DATE: SHEET NO 05/13 REV.NO. DATE: DRG.NO. PROJECT: "REDEVELOPMENT OF HIGH RISE RAILWAY QUARTERS WITH CLUB HOUSE AND RAILWAY OFFICE BUILDING AT RIFLE RANGE COLONY, SECUNDERABAD, TELANGANA STATE." DRAWING HEADING: ELEVATIONS & SECTIONS OF TOWER-1, TYPE-III QUARTERS "OWNER/CHECKED AND APPROVED BY RAILWAY LAND DEVELOPMENT AUTHORITY (MINISTRY OF RAILWAYS)" DEVELOPER "CPM/SC/ RLDA "JGM/PLNG/RLDA" BEDROOM LIVING ROOM CORRIDOR CORRIDOR BEDROOM LIVING ROOM CORRIDOR CORRIDOR BEDROOM LIVING ROOM CORRIDOR CORRIDOR BEDROOM LIVING ROOM CORRIDOR CORRIDOR BEDROOM LIVING ROOM CORRIDOR CORRIDOR BEDROOM LIVING ROOM CORRIDOR CORRIDOR PARKING PARKING
SECTION-S1 -
PRINCIPAL ARCHITECT CERTIFICATE: is hereby certified that FHD INDIA consultant LLP has been appointed as Principal Architect by Sri Varaaha Infra to provide architectural and allied services for the project of Lease land Grant for developement of Railway Land for 99 years including redevelopment of Railway Staff Colony of Rifle Range All the drawings have been prepard by FHD INDIA Consultant LLP and the same are being issued to Rail Land Development Authority and Sri Varaaha Infra for approvals. hereby undertake the responsibility of all architectural and allied services drawings and state that all the drawings are in confirmity with the applicable building bye laws of Government of Telangana and compliance of applicable provisions of National Building code 2016. shall be held responsible if there is any discrepancy found in the drawings. FHD INDIA consultant LLP S.DHAMOTHARAN REGD.ARCHITECT- CA/2003/31131 Address- Plot No: 15, 8-3, 684/3-15, Lane No 3, Sri Nagar Colony, LIC Colony, Hyderabad, Telangana 500073 S.No. 6 W1 PANNELLED DOOR DOOUBLE SHUTTER WITH IRON GRILL & S.STEEL MOSQUITO PROOF WIRE MESH 1000 X 2100 FLUSH DOOR SINGLE SHUTTER 750 2100 900 9 UPVC FULLY GLAZED WINDOW 900 X 900 DESCRIPTION SCHEDULE OF DOORS & WINDOWS PER EACH UNIT E WARD ROBE 650 DEPTH MARK SILL LEVELSIZE 1D 2D1 3D2 4D3 5 O 900 2100 PANNELED DOOR SINGLE SHUTTER 750 2100 PVC DOOR SINGLE SHUTTER OPENING 900 2100 1950 X 1200 7 900 W2 UPVC FULLY GLAZED WINDOW 1500 X 1200 8 W3 KW1 10 V1 1200 X 1200 UPVC FULLY GLAZED WINDOW RCC VENTILATOR WITH SS MOSQUITO MESH 600 X 600 BEAM BOTTOM-300 11 MGMS GRILL FULL HEIGHT 900 12 WR 13 1200 EXHAUST FAN 230Ø 900 100 2600 UPVC FULLY GLAZED WINDOW ALL UPVC WINDOWS ARE TO BE THREE TRACK ie TWO TRACKS WITH GLAZED PANE AND ONE TRACK WITH SS MOSQUITO MESH AND ALL WINDOWS SHALL BE PROVIDED WITH M.S. SAFETY GRILL KS 14 KITCHEN SHLEVES 2100 100 OS 15 OPEN SHELVES 2100 100 KW2 UPVC FULLY GLAZED WINDOW 1200 1500 900 16 Building Document Part-v Schedules and Specifications January 29,2020 Page no.40-43: Annexure 5: General Specifications. 17 18 VRCC VENTILATOR WITH SS MOSQUITO MESH 750 X 600 BEAM BOTTOM-300 2400 X 2100 SDSLIDING DOOR 2100 X 2100 SD1SLIDING DOOR 19 TERRACE FLOOR LVL. RD FLOOR LVL. STILT FLOOR LVL. ST FLOOR LVL. 2ND FLOOR LVL. TH FLOOR LVL. TH FLOOR LVL. 8TH FLOOR LVL. TH FLOOR LVL. TH FLOOR LVL. TH FLOOR LVL. 10 TH FLOOR LVL. 3.9M 3.05M 3.05M 3.05M 3.05M 3.05M 3.05M 3.05M 3.05M 3.05M 3.05M 33.55M 11 TH FLOOR LVL. 3.05M W2 W2 01 ELEVATION E1 - (TOWER-1) TERRACE FLOOR LVL. RD FLOOR LVL. STILT FLOOR LVL. ST FLOOR LVL. 2ND FLOOR LVL. TH FLOOR LVL. TH FLOOR LVL. 8TH FLOOR LVL. TH FLOOR LVL. TH FLOOR LVL. TH FLOOR LVL. 10 TH FLOOR LVL. 3.9M 3.05M 3.05M 3.05M 3.05M 3.05M 3.05M 3.05M 3.05M 3.05M 3.05M 33.55M 11 TH FLOOR LVL. 3.05M W2 W2 01 ELEVATION E2
TOILET LIVING/DINING CORRIDOR TOILET LIVING/DINING CORRIDOR TOILET LIVING/DINING CORRIDOR TOILET LIVING/DINING CORRIDOR TOILET LIVING/DINING CORRIDOR TOILET LIVING/DINING CORRIDOR TOILET LIVING/DINING CORRIDOR TOILET LIVING/DINING CORRIDOR TOILET LIVING/DINING CORRIDOR TOILET LIVING/DINING CORRIDOR TOILET LIVING/DINING CORRIDOR TOILET LIVING/DINING CORRIDOR LIVING/DINING CORRIDOR LIVING/DINING CORRIDOR LIVING/DINING CORRIDOR LIVING/DINING CORRIDOR TOILET TOILET TOILET TOILET TOILET LIVING/DINING CORRIDOR TOILET LIVING/DINING CORRIDOR TOILET LIVING/DINING CORRIDOR TOILET LIVING/DINING CORRIDOR LIVING/DINING CORRIDOR LIVING/DINING CORRIDOR LIVING/DINING CORRIDOR LIVING/DINING CORRIDOR TOILET TOILET TOILET TOILET 01
TOILET LIVING/DINING CORRIDOR TOILET LIVING/DINING CORRIDOR TOILET LIVING/DINING CORRIDOR TOILET LIVING/DINING CORRIDOR TERRACE FLOOR LVL. RD FLOOR LVL. STILT FLOOR LVL. ST FLOOR LVL. 2ND FLOOR LVL. TH FLOOR LVL. TH FLOOR LVL. 8TH FLOOR LVL. TH FLOOR LVL. TH FLOOR LVL. TH FLOOR LVL. TH FLOOR LVL. 3.9M 3.05M 3.05M 3.05M 3.05M 3.05M 3.05M 3.05M 3.05M 3.05M 3.05M 318.59 Sq.m 67.47 Sq.m GREENBELT N ORIENTATION 28
01
(TOWER-1)
SECTION-S2 - (TOWER-1)
