GC2400 / GC2410 / GC2600 / GC2610 COMPACT TRACTORS 651875 TABLE OF CONTENT Page00-TOC Page NumberPage Title Page Reference 01-000-TOC ENGINE, FUEL AND EXHAUST SYSTEM01-000-TOC 02-000-TOC FRAME AND SUSPENSION 02-000-TOC 03-000-TOC STEERING SYSTEM 03-000-TOC 04-000-TOC DRIVE TRAIN SYSTEM 04-000-TOC 05-000-TOC BRAKE SYSTEM 05-000-TOC 06-000-TOC HYDRAULIC SYSTEM 06-000-TOC 07-000-TOC ELECTRICAL SYSTEM 07-000-TOC 08-000-TOC CHASSIS 08-000-TOC 09-000-TOC DECALS 09-000-TOC 10-000-TOC WHEELS 10-000-TOC 11-000-TOC IMPLEMENT LIFT SYSTEM 11-000-TOC 12-000-TOC ACCESSORIES 12-000-TOC
Massey Ferguson
Massey Ferguson GC2400 / GC2410 / GC2600 / GC2610 COMPACT TRACTORS 651875 ENGINE, FUEL AND EXHAUST SYSTEM Page01-000-TOC Page NumberPage Title Page Reference 01-0001 FILTER AND BELT GUIDE 91007 01-0002 CYLINDER HEAD 6004-101I-01000200 01-0003 CYLINDER HEAD COVER 6003-110-0100 01-0004 INTAKE MANIFOLD 6003-120B-0100 01-0005 EXHAUST MANIFOLD 6003-140-0100 01-0006 CYLINDER BLOCK 6004-202R-0100 01-0007 ENGINE BEARINGS - UNDERSIZE 6003-209-0100 01-0008 OIL PAN 6004-210F-0100 01-0009 REAR PLATE 6004-220K-0100 01-0010 TIMING GEAR CASE 6004-240V-01000200 01-0011 ENGINE LIFTING 6005-290B-0100 01-0012 ROCKER SHAFT 6004-301-0100 01-0013 CAMSHAFT 6003-310-0100 01-0014 PISTON - STANDARD 6004-340I-0100 01-0015 PISTON - OVERSIZE 6004-349I-0100 01-0016 CRANKSHAFT 6004-351A-0100 01-0017 OIL PUMP 6004-401C-0100 01-0018 WATER PUMP AND THERMOSTAT6004-420D-0100 01-0019 FAN 6004-480P-0100 01-0020 INJECTOR 6004-501C-0100 01-0021 INJECTOR - COMPONENTS 6215-300-036-1B 01-0022 INJECTION PUMP 6004-511F-0100 01-0023 INJECTION PUMP - COMPONENTS6215-600-103-1E 01-0024 FUEL RETURN LINE 6004-550H-0100 01-0025 GOVERNOR STOP 6005-560-0100 01-0026 STARTER AND ALTERNATOR 6004-801J-01000200 01-0027 STARTER - COMPONENTS 6281-100-014-0A 01-0028 ALTERNATOR - COMPONENTS 6281-200-005-0B 01-0029 ELECTRICAL PARTS 6004-820T-01000200 01-0030 DECALS - FUEL 6004-910P-0100 01-0031 OVERHAUL KIT 6004-999G-0100 01-0032 ENGINE MOUNTING 1725-101A-0100 01-0033 COOLING SYSTEM 1725-102A-0100 01-0034 MUFFLER 1725-103C-0100 01-0035 AIR CLEANER 1725-104-0100 01-0036 FUEL PUMP 1725-105B-0100 01-0037 FUEL FILTER - COMPONENTS 1725-105-220-0 01-0038 FUEL TANK 1725-111B-0100 01-0039 HAND THROTTLE CONTROL 1725-117A-0100
GC2400 / GC2410 / GC2600 / GC2610 COMPACT TRACTORS FILTER AND
2 3 5 4 1 Ref91007 Page01-0001
BELT GUIDE
1
2
3
4
5
Massey Ferguson GC2400 / GC2410 / GC2600 / GC2610 COMPACT TRACTORS 651875 FILTER AND BELT
Page01-0001 ItemPart NumberQtyDescription Comments Technical Specification
GUIDE
72201898 1 CARTRIDGE ENGINE
3757472M91 1 ELEMENT AIR CLEANER
4265229M91 1 CHARGE FILTER HYD HYDRAULIC OIL
3608255M1 1 FUEL FILTER ELEMENT
6252466M1 1 BELT ENGINE
GC2400 / GC2410 / GC2600 / GC2610 COMPACT TRACTORS CYLINDER HEAD 2 2 7 4 4 3 8 8 5 6 1 Ref6004-101I-01000200 Page01-0002
Massey Ferguson GC2400 / GC2410 / GC2600 / GC2610 COMPACT TRACTORS 651875 CYLINDER HEAD Page01-0002 ItemPart NumberQtyDescription Comments Technical Specification 1 4266468M93 1 CYLINDER HEAD INCLUDES ITEMS 2-5 2 3704389M1 2 CUP 3 3707877M2 5 PIPE PLUG 1/2" 4 3710256M1 6 VALVE OIL SEAL 5 3711713M1 1 BALL 6 3710144M2 1 CYLINDER HEAD GASKET 7 6252529M1 14BOLT 8 3607420M1 2 STUD BOLT M8 X 71 (1.25)
GC2400 / GC2410 / GC2600 / GC2610 COMPACT TRACTORS CYLINDER HEAD COVER 6 4 4 5 5 2 1 3 Ref6003-110-0100 Page01-0003
Massey Ferguson GC2400 / GC2410 / GC2600 / GC2610 COMPACT TRACTORS 651875 CYLINDER HEAD COVER Page01-0003 ItemPart NumberQtyDescription Comments Technical Specification 1 3608539M92 1 VALVE COVER 2 3710188M1 1 OIL FILLER CAP 3 3710151M1 1 SEAL CYLINDER HEAD COVER 4 3710127M2 2 CAP NUT M8 5 4267629M1 2 SEAL 6 3710124M2 1 HOSE
GC2400 / GC2410 / GC2600 / GC2610
INTAKE MANIFOLD 4 1 2 3 Ref6003-120B-0100 Page01-0004
COMPACT TRACTORS
Massey Ferguson GC2400 / GC2410 / GC2600 / GC2610 COMPACT TRACTORS 651875 INTAKE MANIFOLD Page01-0004 ItemPart NumberQtyDescription Comments
3710307M91 1 INTAKE MANIFOLD
3710309M1 1 GASKET INTAKE
4267567M1 3 HEXAGON FLANGE HEAD BOLT
4267570M1 1 HEXAGON FLANGE HEAD BOLT
1
2
3
4
GC2400 / GC2410 / GC2600 / GC2610 COMPACT TRACTORS EXHAUST MANIFOLD 2 1 4 3 Ref6003-140-0100 Page01-0005
Massey Ferguson GC2400 / GC2410 / GC2600 / GC2610 COMPACT TRACTORS 651875 EXHAUST MANIFOLD Page01-0005 ItemPart NumberQtyDescription Comments Technical Specification 1 4262617M1 1 EXHAUST MANIFOLD 2 3710312M1 1 GASKET EXHAUST 3 3702273M1 6 HEXAGONAL HEAD BOLT 4 3704353M1 2 STUD BOLT M8 X 22
CYLINDER BLOCK 4 4 4 21 21 6 16 16 20 20 23 24 17 28 14 27 25 7 26 19 5 18 3 29 2230 11 11 11 11 13 13 15 12 12 12 12 10 8 1 9 2 Ref6004-202R-0100 Page01-0006
GC2400 / GC2410 / GC2600 / GC2610 COMPACT TRACTORS
Massey Ferguson GC2400 / GC2410 / GC2600 / GC2610 COMPACT TRACTORS 651875 CYLINDER BLOCK Page01-0006 ItemPart NumberQtyDescription Comments Technical Specification 1 3710152M96 1 CYLINDER-BLOCK INCLUDES ITEMS 2-7 2 3710110M2 8 HEX CAP SCREW 3 3710130M2 2 SEALING CAP ?28 MM 4 4265580M1 4 SEALING CUP ?36 MM 5 3704257M1 3 PLUG 6 3710247M2 1 PIN 7 4265579M1 2 CUP 8 3710160M1 4 BEARING CAP SEAL 9 3710161M1 2 BEARING CAP SEAL ?7 MM 103710175M91 1 KIT, BEARING INCLUDES ITEMS 11-13 113711637M1 4 BEARING CRANKSHAFT 123711638M1 4 BEARING CRANKSHAFT 133710184M1 2 BEARING THRUST 144260024M1 1 OIL SEAL 153710137M2 2 DOWEL PIN 164266242M1 2 STRAIGHT PIN ?8 X 16 MM 173757960M1 2 PIN ?6 X 12 MM 183706536M1 1 STUD BOLT M8 X 40 193704806M1 1 STUD BOLT 203704353M1 2 STUD BOLT M8 X 22 213758287M1 2 DOWEL PIN 223704382M1 1 NIPPLE 233754123M1 1 WATER DRAIN PIPE 243710284M1 1 CONNECTORS 253710162M2 1 COVER 263710163M1 1 COVER SEAL 274267405M1 4 HEXAGON FLANGE HEAD BOLT 283710411M1 1 SPRING PIN 296254496M1 1 GAUGE LEVEL 306254497M91 1 DIPSTICK TUBE 6254622M91 BLOCK/SHORT 6254740M91 ENGINE ASY/ ASSY FOR GC2600/GC2610 6254489M91 ENGINE ASY/ASM FOR GC2400/GC2410 4269250M91 1 KIT/HEATER BLOCK ENGINE
GC2400 / GC2410 / GC2600 / GC2610 COMPACT TRACTORS ENGINE BEARINGS - UNDERSIZE 4 4 2 2 1 5 6 3 Ref6003-209-0100 Page01-0007
ENGINE BEARINGS - UNDERSIZE
1
2
Massey Ferguson GC2400 / GC2410 / GC2600 / GC2610 COMPACT TRACTORS 651875
Page01-0007 ItemPart NumberQtyDescription Comments
3710178M91 1 KIT, BEARING .5MM CRANKSHAFT
CRANKSHAFT
3710184M1 2 BEARING THRUST
CRANKSHAFT
3 3710181M91 1 KIT, BEARING 1.0MM
CRANKSHAFT
4 3710184M1 2 BEARING THRUST
.5MM
5 6252648M1 3 BEARING
CONNECTING ROD
1.0MM
6 6252649M1 3 BEARING
CONNECTING ROD
GC2400 / GC2410 / GC2600 / GC2610 COMPACT TRACTORS OIL PAN
Ref6004-210F-0100 Page01-0008
1 4 3 2
1
Massey Ferguson GC2400 / GC2410 / GC2600 / GC2610 COMPACT TRACTORS 651875 OIL PAN Page01-0008 ItemPart NumberQtyDescription Comments Technical Specification
4265444M91 1 OIL SUMP USE RTV SEALANT FOR GASKET
3607358M2 1 PLUG M14 (1.5)
3708620M1 1 O-RING
4267404M1 18HEXAGON FLANGE HEAD BOLT
2
3
4
GC2400 / GC2410 / GC2600 / GC2610 COMPACT TRACTORS REAR PLATE 2 3 1 Ref6004-220K-0100 Page01-0009
Thank you very much for your reading. Please Click Here. Then Get COMPLETE MANUAL.NOWAITING
NOTE:
If there is no response to click on the link above, please download the PDF document first and then clickonit.
Massey Ferguson GC2400 / GC2410 / GC2600 / GC2610 COMPACT TRACTORS 651875 REAR PLATE Page01-0009 ItemPart NumberQtyDescription Comments Technical Specification 1 4265441M1 1 PLATE 2 3757834M1 1 POINTER 3 3704341M1 8 HEXAGONAL HEAD BOLT M10 X 20 (1.25)
