Takeuchi TB290 Hydraulic Excavator Parts Catalogue Manual (Serial No. 190200001 and up)

TB290 [P-TB290H-CD] Book No. BM2Z001-1 S/N 190200001Index

0 ﾍﾟｰｼﾞ 0

Reference

Reference M1A010 ﾍﾟｰｼﾞ 1-1 M1A010 S=1/16 1 14 3 11 8 13 4 10 7 11 8 6 14 3 10 7 2 13 15 12 9 5

TB290 [P-TB290H-CD] Book No. BM2Z001-1 S/N 190200001LOWER FRAME

Page:1-1 ItemPart numberDescriptionQ'tyChan.Serial No.Serv.Remarks FRAME ASSY, lower 1X ********** FRAME1 2 0561036010 COVER1 3 0561027020 COVER2 4 0561017400 COVER2 5 0561019400 COVER2 6 1508710010 PLUG1 7 1100040816 BOLT8 8 1100041020 BOLT6 9 1100041225 BOLT4 10 1140020008 WASHER, spring8 11 1140020010 WASHER, spring6 12 1140020012 WASHER, spring4 13 1141110008 WASHER8 14 1141110010 WASHER6 15 1141110012 WASHER4 M1a013

LOWER FRAME Reference:M1A010

ﾍﾟｰｼﾞ 1-2

S=1/16 1 2 3 4 1 4 2 3

TB290 [P-TB290H-CD] Book No. BM2Z001-1 S/N 190200001STEP (for steel crawler) Reference M1A020

M1A020

STEP (for steel crawler)

ItemPart numberDescriptionQ'tyChan.Serial No.Serv.Remarks

STEP ASSY (550mm shoe)

1 0561037510 STEP2

2 1100041230 BOLT8

3 1130040012 NUT8

4 1140020012 WASHER, spring8

M3a010

Reference:M1A020

Page:1-2

ﾍﾟｰｼﾞ 1-3 1-4 1-2 1-1-6 1-3 1-1-2 1-1-1 1-1-9 1-1-7 1-1-9 1-1-8 1-1-10 1-1-11 1-1-5 1-1-11 1-1-3 1-1-4

TB290 [P-TB290H-CD] Book No. BM2Z001-1 S/N 190200001CRAWLER BELT (steel) Reference M1A050

CRAWLER BELT (steel)

ItemPart numberDescriptionQ'tyChan.Serial No.Serv.Remarks

BELT ASSY, steel crawler (450mm shoe)

BELT ASSY, steel crawler (550mm shoe)

1 1914308000 BELT, steel crawler (450mm shoe)2 1914308100 BELT, steel crawler (550mm shoe)2

1-1 1914308098 LINK ASSY2

1-1-1 1914308001 LINK (R.H.)38

1-1-2 1914308002 LINK (L.H.)38

1-1-3 1914308003 LINK, master (R.H.)1

1-1-4 1914308004 LINK, master (L.H.)1

1-1-5 1914308007 BUSHING38

1-1-6 1914308005 PIN, track38

1-1-7 1914308008 BUSHING1

1-1-8 1914308006 PIN, master1

1-1-9 1914308009 COLLAR2

1-1-10 1914308011 PIN, split1

1-1-11 1914308010 SEAL76

1-2 1914308012 BOLT156

1-3 1914308013 NUT156

1-4 1914308014 PLATE39450mm shoe 1914308114 PLATE39550mm shoe

M3a021

Reference:M1A050 Page:1-3

TB290 [P-TB290H-CD] Book No. BM2Z001-1 S/N 190200001CRAWLER BELT (rubber)

M1A060 ﾍﾟｰｼﾞ 1-4 M1A060 S=FREE 1

Reference

CRAWLER BELT (rubber)

ItemPart numberDescriptionQ'tyChan.Serial No.Serv.Remarks

BELT ASSY, rubber crawler

1 1914086020 BELT, rubber crawler2

M3a030

Reference:M1A060

Page:1-4

TB290 [P-TB290H-CD] Book No. BM2Z001-1 S/N 190200001CARRIER ROLLER

Reference M3A040 ﾍﾟｰｼﾞ 1-5 M3A040 S=1/4 2 3 1-5 1-7 1-4 1-9 1-8 1-1 1-2 1-5 1-6 1-3

Page:1-5 ItemPart numberDescriptionQ'tyChan.Serial No.Serv.Remarks ROLLER ASSY, carrier 1 0561205600 ROLLER SUB ASSY2 1-1 0561205601 ROLLER1 1-2 0561205602 SHAFT1 1-3 0561205603 PLATE1 1-4 0561205604 COVER1 1-5 1300006207 BEARING2 1-6 0561205606 SEAL, oil1 1-7 1420000620 O-RING1 1-8 1221000072 RING, snap1 1-9 0561205609 PLUG1 2 1101041675 BOLT2 3 1130540016 NUT2 M3a040

CARRIER ROLLER Reference:M3A040

Thank you very much for your reading. Please Click Here. Then Get COMPLETE MANUAL.NOWAITING

NOTE:

If there is no response to click on the link above, please download the PDF document first and then clickonit.

TB290 [P-TB290H-CD]

Reference M1A090 ﾍﾟｰｼﾞ 1-6 M1A090 S=1/6 1-1 1-5 1-6 1-2 1-9 1-8 1-7 1-4 1-7 1-5 1-6 1-3 1-8 3 2 3 2

Book No. BM2Z001-1 S/N 190200001TRACK ROLLER

ROLLER ASSY, track

1 0561311100 ROLLER SUB ASSY, track10

1-1 0561311110 ROLLER1

1-2 0561311130 COVER1

1-3 0561311140 COVER1

1-4 0561311120 SHAFT1

1-5 0561311150 BUSHING2

1-6 0561311160 SEAL, floating2

1-7 0561311170 O-RING2

1-8 0561311180 PIN, spring2

1-9 1501820001 PLUG1

2 1101041455 BOLT40

3 1141550014 WASHER40 M1a091

Reference:M1A090

TRACK ROLLER

numberDescriptionQ'tyChan.Serial No.Serv.Remarks

Page:1-6 ItemPart

Reference M1A210 ﾍﾟｰｼﾞ 1-7 M1A210 S=1/6 1-1 1-5 1-6 1-2 4 1-9 1-8 1-7 1-4 1-7 1-5 1-6 1-3 1-8 3 4 2 3 2

TB290 [P-TB290H-CD] Book No. BM2Z001-1 S/N 190200001TRACK ROLLER (for steel crawler)
