ENGINE AND ACCESSORIES
ItemPart NumberQtyDescriptionComments
1 966177M12 Stud
2 966440M911 Cable
3 966719M911
See Page - Reference Number 955067M1 966412M911 See Page - Reference Number 955067M1 955659M911
4 966423M11 Strap
5 966860M11 Thermostat
6 966421M11 Bearer
7 966426M911 Fan
8 353677X11 Screw Unc 353755X11 Washer
9 966427M11 Belt
10 966424M11 Pulley
11 353519X12 Screw Unf 353916X12 Nut Unf
12 353517X12 Screw Unf 355618X12 Washer
13 966422M11 Bearer
14 966416M911 Dynamo Alternative 966414M911 Dynamo Alternative
15 353697X11 Screw Unc
16 353701X11 Screw Unc
17 966413M911 StartermotorAlternative 966448M911 StartermotorAlternative
NOT ILLUSTRATED 966441M911 Cable NO. 16
GENERATOR
ItemPart NumberQtyDescription Comments
1 1601816M11 Bearing
2 1601831M11 Brush
3 1801552M911 Bearing CarrierCOMP. 1,5
4 1601830M11 Brush
5 1600505M12 Spring
6 1601829M11 Armature 1801554M911 Connector
7 1601834M11 Key
8 1801561M11 Coil
9 1801563M12 Stem
10 1601835M11 Plate
MF 25/825 TRACTORS - 955068
STARTER - PARIS-RHONE D11E85, 966413M91
ItemPart NumberQtyDescription Comments
PARIS-RHONE D11E85, 966413M91
1 1601865M11 Spring 2 1601566M14 Spring 3 1601862M11 Washer
4 1601358M12 Brush 5 1601855M12 Stem 6 1601869M11 Washer 7 1601870M11 Junction 8 1601873M11 Dowel 9 1802491M911 Support COMP. NO. 10 10 1601858M11 Bush 11 1802490M11 Thrower 12 1600467M11 Skid 13 1601859M911 Fork COMP. NO. 12 14 1601853M11 Armature 15 1601851M11 Coil 1601329M14 Bolt 16 1801878M911 Solenoid 17 1601863M11 Washer 18 1802139M11 Washer 19 1601044M11 Bush 20 1601852M12 Brush 21 1601843M911 Washer 22 1601841M911 Bearing CarrierCOMP. NOS. 2, 19 ET 21 23 1601866M11 Washer 24 1601867M11 Washer 25 1601868M11 Screw 26 1601872M11 Bonnet
ItemPart NumberQtyDescription Comments
1 1802738M911
Bearing CarrierCOMP. NO. 2 A 5
2 2 Rivet See Page - Reference Number 5
3 1 Washer See Page - Reference Number 5 4 175047M11 Bearing
5 1801732M911 Parts Pack 6 1801734M911 Parts Pack 7 1801679M11 Bush 8 1802734M11 Inductor 9 1801418M21 Washer 1802737M11 Washer
10 1600173M11 Bush 11 1801419M12 Brush 1801417M12 Spring
12 1802735M911 Bearing CarrierCOMP. REF. 10 1801730M911 1801408M911 Connector 1802736M11 1801403M911 Weight 1600147M11 Connector
13 2 Washer See Page - Reference Number 17 14 2 Nut See Page - Reference Number 17 1801422M14 Screw 16 1802732M11 Armature 17 1801733M911 Kit
18 1 Pulley See Page - Reference Number 2 19 1 Washer See Page - Reference Number 6 20 1 Nut See Page - Reference Number 6
STARTER - DUCELLIER
ItemPart NumberQtyDescription Comments
1 1802752M11 Parts Pack
2 1802753M11 Parts Pack
3 1806388M12 Parts Pack
4 1806351M911 Solenoid 5 1630856M14 Screw 6 1802766M11 Cable 7 1638956M11 Connection 8 1805423M24 Spring 9 1801790M12 Brush 10 1645956M11 Kit 11 1802765M11 Skate 13 1802801M11 Bonnet 14 1805171M12 Kit 15 1802759M911 Bearing CarrierCOMP. REF. 8, 13 ET 16
1802760M12 Intake 1802761M12 Holder 1802747M12 Kit 16 1644438M911 Parts Pack 17 1801789M12 Brush 18 1802746M11 Kit 19 1630995M11 Armature 20 1802758M11 Bearing Carrier 21 1802757M911 Bearing CarrierCOMP. NO. 22-23 22 1600173M11 Bush 23 1806478M11 Plug 25 1801806M11 Dowel 26 1805617M11 Kit, Gasket 27 1802756M911 Thrower 1802819M11 Wheel 1802820M11 Washer 1802821M11 Spring 1801831M11 Pulley 1801832M11 Clip 28 1801823M12 Skid 29 1802755M911 Fork COMP. NO. 28 1801803M11 Clevis Pin
