ENGINE - CYLINDER BLOCK & LINERS
ItemPart NumberQtyDescription
002371U91 ENGINE ASSY 4226503M91 BLOCK, SHORT
1 4225300M911 BLOCK ASSEMBLY, CYLINDER
2 1 BLOCK, CYLINDER (ORDER ITEM 1)
3 1 CAP, BEARING (ORDER ITEM 1)
4 1 CAP, BEARING (ORDER ITEM 1)
5 1 CAP, BEARING (ORDER ITEM 1)
6 1 CAP, BEARING (ORDER ITEM 1)
7 733072M18 THIMBLE 8 1476108X18 SCREW
9 4224829M11 BUSH, CAMSHAFT
10 4224874M11 PLUG 11 731356M11 PLUG 12 731354M11 PLUG 13 4224873M12 PLUG 14 4224863M11 PLUG
15 4224866M11 PLUG
16 4225254M11 PIPE, WATER
17 4224781M11 PLUG, BLANKING
18 4224865M11 PLUG 19 4224717M13 JET, PISTON COOLING
20 3641648M13 SCREW
21 4224936M12 PLATE, BLANKING 22 4224973M12 JOINT 23 3637092M18 SCREW 24 4225132M11 PLUG 25 355547X11 PLUG
461A005 PR: t04c29n49d0001
ENGINE - REAR END SEAL, OIL
ItemPart NumberQtyDescription
1 4224762M11 HOUSING, REAR SEAL, OIL
2 4224860M110 BOLT, METRIC
461A010 PR: t04c29n49d0002
ENGINE - CRANKSHAFT, MAIN & BIG END BEARING
ItemPart NumberQtyDescription
1 4225301M911 CRANKSHAFT ASSEMBLY
2 1 CRANKSHAFT (ORDER IT. 1)
3 4225305M911 BEARING KIT, MAIN
4 4225306M911 BEARING KIT, BIG END
5 747128M12 WASHER, THRUST 735742M12 WASHER, THRUST [A]
6 747129M12 WASHER, THRUST 735743M12 WASHER, THRUST [A]
[A] SERVICE OPTION
461A015 PR: t04c29n49d0003
ENGINE - CRANKSHAFT, MAIN & BIG END BEARINGS
ItemPart NumberQtyDescription
1 4224833M11 GEAR, CRANKSHAFT
2 709058451 KEY, WOODRUFF
461A020 PR: t04c29n49d0004
ENGINE - PISTONS & RINGS
ItemPart NumberQtyDescription
1 4225019M913 PISTON AND RING KIT
2 1 PISTON (ORDER ITEM 1)
3 1 PIN, PISTON (ORDER ITEM 1
4 4222135M12 CIRCLIP
5 4225072M911 RING KIT, PISTON
461A025 PR: t04c29n49d0005
ENGINE - CONNECTING RODS
ItemPart NumberQtyDescription
1 4225016M913 ROD KIT, CONNECTING [A] BLUE MARK ON ROD 4225015M913 ROD KIT, CONNECTING [A] PURPLE MARK ON ROD 4225014M913 ROD KIT, CONNECTING [A] GREEN MARK ON ROD 4225013M913 ROD KIT, CONNECTING [A] WHITE MARK ON ROD 4225012M913 ROD KIT, CONNECTING [A] ORANGE MARK ON ROD 4225011M913 ROD KIT, CONNECTING [A] RED MARK ON ROD
2 1 ROD, CONNECTING (ORDER ITEM 1)
3 1 CAP (ORDER ITEM 1)
4 4224827M11 BUSH, SMALL END
5 4224864M12 BOLT, CONNECTING ROD [B]
ENGINE - CYLINDER HEAD ASSEMBLY
ItemPart NumberQtyDescription
1 4225299M911 HEAD ASSEMBLY, CYLINDER
2 1 HEAD, CYLINDER (ORDER ITEM 1)
3 4224895M13 INSERT, INLET VALVE
4 4223987M13 GUIDE, VALVE
5 4224896M13 INSERT, EXHAUST VALVE 6 4223987M13 GUIDE, VALVE
7 742555773 PLUG
8 3637015M13 PLUG
9 4224009M12 DOWEL
10 4224867M15 SCREW
11 4224868M13 SCREW
12 4224847M13 VALVE, INLET
13 4224763M13 SEAL, VALVE STEM
14 4224856M13 SPRING, VALVE 15 4224898M13 CAP, VALVE 16 4222141M16 COTTER
17 4224846M13 VALVE, EXHAUST 18 4224763M13 SEAL, VALVE STEM 19 4224856M13 SPRING, VALVE 20 4224898M13 CAP, VALVE 21 4222141M16 COTTER
22 4224884M11 PLUG 23 4224752M11 O-RING 24 709179703 PLUG
461A035 PR: t04c29n49d0007
ENGINE - CYLINDER HEAD ASSEMBLY
ItemPart NumberQtyDescription
1 4225388M11 GASKET, CYLINDER HEAD 461A040 PR: t04c29n49d0008
ENGINE - ROCKER SHAFT ASSEMBLY
ItemPart NumberQtyDescription
1 4225289M911 SHAFT ASSEMBLY, ROCKER
2 4225290M911 SHAFT ASSEMBLY, ROCKER (INCLS 3-4)
3 1 SHAFT, ROCKER (ORDER ITEM 2)
4 4224780M12 PLUG
5 4225020M913 ARM ASSEMBLY, ROCKER (INCLS 6-9)
6 1 ARM, ROCKER (ORDER ITEM 5)
7 1 PAD (ORDER ITEM 5)
8 353430X11 NUT
9 4223933M11 SCREW
10 4224855M12 SPRING, ROCKER SHAFT
11 4225021M913 ARM ASSEMBLY, ROCKER (INCLS 12-15)
12 1 ARM, ROCKER (ORDER ITEM 11)
13 1 PAD (ORDER ITEM 11)
14 353430X11 NUT
15 4223933M11 SCREW
16 3638812M12 CIRCLIP
17 4224720M12 WASHER
18 4224742M11 SCREW
19 4224743M12 SCREW
461A045
PR: t04c29n49d0009
