MF 384 S TRACTOR, ->| 30/09/93 - 3311548 1 Ref1 Page1
ENGINE - A4.236 ENGINE
ItemPart NumberQtyDescriptionComments
A4.236 ENGINE
1 LD31200X Parts Book (C)
LD 39303X Short Engine (C) (C)
FOR MF 384F/384S AND LANDINI 7560F/7560L TRACTORS ONLY
MASSEY FERGUSON MF 384 S TRACTOR, ->| 30/09/93 - 3311548 3311548
1
Ref1 Page1
MF 384 S TRACTOR, ->| 30/09/93 - 3311548 15 9 11 14 28 10 2 12 26 8 25 4 19 20 21 27 22 23 16 1817 13 7 24 3 29 1 5 6 Ref2 Page2
CYLINDER BLOCK - A4.236
MASSEY FERGUSON MF 384 S TRACTOR, ->| 30/09/93 - 3311548 3311548
ENGINE 2 ItemPart NumberQtyDescription Comments A4.236 ENGINE 1 ZZ 501451 Kit,Cyl.BlockRepairs and replaces ZZ50110 Repairs and replaces ZZ50114 2 3135X0314 Liner (1) (A) 2 3135X032X Liner (B) 3 06507106 Plug (1) Repairs and replaces 0650563 4 324181224 Plug (1) 5 3314211110 Thimble (1) 6 3216632910 Bolt (1) 7 311341641 Bush (1) Repairs and replaces 31134163 Repairs and replaces 31134132 8 06507102 Plug (1) Repairs and replaces 0650563 9 2485A2041 Plug (1) 10 324161051 Plug (1) 11 06505821 Plug (1) Repairs and replaces 32168212 12 3311R0031 Washer (1) Repairs and replaces 0920130 13 06505882 Plug (1) 14 324171341 Plug 15 3681E0181 Head GasketRepairs and replaces 36812352 16 4142V0641 Housing Repairs and replaces 4142V061 17 2418F4751 Seal (16) 18 368171571 Joint 19 074621110 Bolt 20 092000310 Washer 21 03500092 Dowel 22 21725302 Capscrew 23 331121112 Washer 24 06505941 Plug 25 06505774 Plug 26 321611142 Plug 27 06505881 Plug 28 324521131 Pointer 29 321141431 Plug (A) PRESS FIT (B) SLIP FIT Ref2 Page2
MF 384 S TRACTOR, ->| 30/09/93 - 3311548 10 26 13 12 25 9 17 18 15 11 14 4 5 1 2 22 3 24 7 8 6 21 20 19 16 23 Ref3 Page3
CRANKSHAFT, PISTONS AND CONNECTING RODS - A4.236 ENGINE
MASSEY FERGUSON MF 384 S TRACTOR, ->| 30/09/93 - 3311548 3311548
3 ItemPart NumberQtyDescription Comments A4.236 ENGINE 1 ZZ 900811 Kit, CrankshaftRepairs and replaces U5BG0024 2 1 Crankshaft (1) Not serviced, order REF.1 3 815581 Kit, Bearing (1) (A) 3 81558AX Kit, Bearing (A) Thickness (-)0.25MM Thickness (-)0.010" 3 81558BX Kit, Bearing (A) Thickness (-)0.50MM Thickness (-)0.020" 3 81558CX Kit, Bearing (A) Thickness (-)0.75MM Thickness (-)0.030" 4 850421 Kit, Bearing (1) (A) 4 85042AX Kit, Bearing (A) Thickness (-)0.25MM Thickness (-)0.010" 4 85042BX Kit, Bearing (A) Thickness (-)0.50MM Thickness (-)0.020" 4 85042CX Kit, Bearing (A) Thickness (-)0.75MM Thickness (-)0.030" 5 311375512 Thrust Washer (1) 31137312X Thrust WasherThickness (+)0.19MM Thickness (+)0.0075" 6 311375612 Thrust Washer (1) 31137322X Thrust WasherThickness (+)0.19MM Thickness (+)0.0075" 7 3242T0011 Thrust Block (D) 8 321861393 Screw (D) 9 ZZ 900094 Kit, Conrod 10 1 Conrod (9) Not serviced, order REF.9 11 1 Cap (9) Not serviced, order REF.9 12 311341231 Bush (9) 13 327621442 Bolt (9) 14 332213282 Nut (9) 15 U5LU00254 Kit, Piston (B) U5LP00354 Kit, Piston (C) 16 1 Piston (15) Not serviced, order REF.15 17 1 Pin (15) Not serviced, order REF.15 18 01700021 Circlip (15) 19 01700021 Circlip (15) 20 411580414 Kit, Piston Ring 21 311716811 Gear,CrankshaftNumber of teeth/spines 28 22 05000121 Woodruff Key 23 311487971 Pulley,Crank 24 331254161 Washer 25 04102361 Starter Ring Number of teeth/spines 115 26 331171276 Washer Repairs and replaces 33117121 (A) PRE-FINISHED (B) UNTOPPED (C) PRE-TOPPED (D) NOT SUPPLIED WITH ASSEMBLY Ref3 Page3
->| 30/09/93
22 29 20 28 32 33 31 21 27 19 59 26 18 60 25 17 58 16 24 13 14 5 4 11 36 12 52 9 51 10 54 53 39 3 8 4041 6 7 43 35 42 1 2 38 44 30 15 23 50 37 55 57 49 56 48 47 46 34 45 Ref4 Page4
MF 384 S TRACTOR,
- 3311548
CYLINDER HEAD - A4.236 ENGINE
MASSEY FERGUSON MF 384 S TRACTOR, ->| 30/09/93 - 3311548 3311548
4 ItemPart NumberQtyDescription Comments A4.236 ENGINE
U5BD0001 2 ZZ 801571 Kit, Cyl. Head (1) Repairs
ZZ80061 Repairs
ZZ80004 3 1 Cylinder Head (2) Not serviced, order REF.2 4 3343F0024 Guide (2) 5 3343J0024 Guide (2) 6 06502031 Plug (2) 7 24111571 Washer (2) 8 06507101 Plug (2) 9 3623K0071 Plate 10 3685R0041 Joint 11 07464522 Setscrew 12 09200542 Washer 13 07462554 Setscrew Repairs and replaces 0746254 14 09200534 Washer 15 314318814 Valve Exhaust (D) Alternative 31431886 15 3142A0524 Valve Exhaust (1) (C) 16 334151184 Washer (1) 17 317441314 Spring (1) 18 317451214 Spring (1) 19 2415B2014 O Ring (1) 20 334231474 Cap (1) 21 338171174 Seal (1) 22 331731088 Cotter (1) (A) 23 314316414 Valve Inlet (1) 24 334151184 Washer (1) 25 317441314 Spring (1) 26 317451214 Spring (1) 27 338171174 Seal (1) 28 334231474 Cap (1) 29 331731088 Cotter (1) (A) 30 331521534 Insert 31 321663372 Screw 32 3216633812 Bolt 33 321663398 Screw 34 377627051 Body Repairs and replaces 37762706 35 368535141 Joint 36 24856591 Thermostat 37 24311541 Plug 38 24311541 Plug 39 22172021 Stud 40 05760511 Nut 41 09200541 Washer 42 00962381 Bolt 43 09200531 Washer 44 00964391 Bolt 45 09200541 Washer 46 07462552 Setscrew 47 09200532 Washer 48 00964342 Bolt 49 09200542 Washer 50 24857911 Pin 51 1 Connection (B) 52 368621511 Joint 53 00964332 Bolt 54 09200542 Washer 55 3648C0041 Plate Ref4 Page4
1 ZZ 800721 Kit, Cyl. HeadRepairs and replaces ZZ80062 Repairs and replaces ZZ80015 Repairs and replaces
and replaces
and replaces
CYLINDER HEAD - A4.236 ENGINE
(A) SERVICED IN PAIRS
(B) NOT SUPPLIED BY PERKINS ENGINES LIMITED.
(C) REMOVE AND FIT 31431881
(D) FITTED IN PLACE OF EXHAUST VALVES SUPPLIED WITH CY LINDER HEAD ASSEMBLY
FERGUSON
3311548
MASSEY
MF 384 S TRACTOR, ->| 30/09/93 - 3311548
4
ItemPart NumberQtyDescription Comments 56 07464532 Setscrew 57 09200542 Washer 58 361771111 Plate 59 07464532 Setscrew 60 09200542 Washer
Ref4 Page4
MF 384 S TRACTOR, ->| 30/09/93 - 3311548 28 27 24 26 25 31 30 22 23 20 21 11 12 10 9 32 2 34 3 8 35 4 1 5 33 16 14 15 19 7 6 18 17 13 29 Ref5 Page5
MASSEY FERGUSON MF 384 S TRACTOR, ->| 30/09/93 - 3311548 3311548
SHAFT - A4.236 ENGINE 5 ItemPart NumberQtyDescription Comments A4.236 ENGINE 1 ZZ 900071 Rocker Shaft AssRepairs and replaces ZZ90030 2 ZZ 900321 Rocker Shaft (1) 3 1 Shaft (2) Not serviced, order REF.2 4 06505072 Plug (2) 5 3818X9014 Bracket (1) Repairs and replaces 37521334 Repairs and replaces 37521332 6 373712814 Lever (1) Right Hand 7 411514814 Rockerarm (1) Left Hand Repairs and replaces 37371271 8 317441232 Spring (1) 9 317431082 Spring (1) 10 3775E0121 Connection (1) (A) 11 22312361 Setscrew (B) 22330221 Screw (1) (C) 12 331174262 Shim (1) 13 01701512 Circlip (1) 14 331174342 Washer (1) 15 07205798 Screw (1) 16 05760528 Nut (1) 17 314341638 Tappet 18 314343078 Pushrod 19 338111131 Olive 20 00966344 Screw 21 09200064 Washer 22 371881411 Cyl.Head Cover 23 3681A0261 Joint Repairs and replaces 36811132 24 21725134 Screw 25 09200024 Washer 26 09200524 Washer 27 24878451 Cap 28 1 Cap (27) Not serviced, order REF.27 29 248700021 Joint (27) 30 338725161 Pipe,Breather 31 218251951 Clip Repairs and replaces 0180063 32 357311441 Pipe,Breather 33 00962151 Screw Up to Serial or Engine Number U226708S 21873331 Screw From Serial or Engine Number U226709S 34 09200031 Washer Up to Serial or Engine Number U226708S 35 09200531 Washer Up to Serial or Engine Number U226708S (A) WAS 3775E011 USE 3775E012/2233022. (B) USED ONLY WITH 3775E011 (C) USED ONLY WITH 3775E012 Ref5 Page5
ROCKER
MF 384 S TRACTOR, ->| 30/09/93 - 3311548 3 3 4 4 1 8 7 2 20 9 21 10 17 19 18 13 22 23 26 25 16 11 14 15 12 24 Ref6 Page6
MASSEY FERGUSON MF 384 S TRACTOR, ->| 30/09/93 - 3311548 3311548 AIR INDUCTION AND EXHAUST SYSTEM - A4.236 ENGINE 6 ItemPart NumberQtyDescription Comments A4.236 ENGINE 1 377813331 Exhaust Manifold 2 368621592 Joint 3 08264102 Stud 4 21881352 Nut 5 08265101 Stud 6 21881351 Nut 7 08264901 Stud 8 21881351 Nut 9 08266273 Stud 10 413166511 Induct.Manifold 11 1 Manifold (10) Not serviced, order REF.10 12 375375911 Plate (10) 13 368671671 Joint (10) 14 22272388 Screw (10) 15 22312371 Screw (10) 16 09200241 Washer (10) 17 00964451 Screw 18 09200041 Washer 19 09200541 Washer 20 00964335 Bolt 21 09200545 Washer 22 06502041 Plug 23 26661081 Intake Heater 24 368664621 Joint 25 368621331 Joint 26 368621311 Joint Ref6 Page6
TRACTOR, ->| 30/09/93
12 13 14 38 2 1 39 4 16 15 40 41 37 35 34 45 9 9 10 42 7 5 48 8 49 19 17 4447 11 27 23 22 21 33 20 28 31 25 32 30 24 18 36 6 46 43 29 26 3 Ref7 Page7
MF 384 S
- 3311548
TIMING GEAR AND CAMSHAFT - A4.236 ENGINE
MASSEY FERGUSON MF 384 S TRACTOR, ->| 30/09/93 - 3311548 3311548
7 ItemPart NumberQtyDescription Comments A4.236 ENGINE 1 371616421 Timing Case 2 368141371 Joint 3 21832058 Screw 4 09200538 Washer 5 07462111 Bolt 6 09200531 Washer 7 334261611 Hub 8 411150231 Idler Number of teeth/spines 63 9 00503452 Bush (8) 10 09410821 Plate 11 21846343 Screw 12 314153741 Camshaft 13 331531211 Washer 14 21160531 Pin 15 3117L0111 Gear,Camshaft Number of teeth/spines 56 16 05000121 Woodruff Key 17 371664011 Timinggear Cover 18 2418F4361 Seal 19 368131371 Joint 20 00962384 Bolt 21 09200534 Washer 22 218320510 Screw 23 092005310 Washer 24 21832054 Screw 25 09200534 Washer 26 3241H0041 Plate 27 338254191 Joint 28 21832034 Screw 29 09200534 Washer 30 361711211 Plate 31 368331191 Joint 32 21831042 Screw 33 09200522 Washer 34 321612171 Screw 35 331154081 Washer 36 317331211 Washer 37 331531281 Washer 38 362351181 Plate 39 368621381 Joint 40 21832042 Screw 41 09200532 Washer 42 375561481 Plate 43 368614291 Joint 44 07485051 Screw 45 22381531 Nut 46 09200541 Washer 47 22321512 Screw 48 22381532 Nut 49 09200542 Washer Ref7 Page7
MF 384 S TRACTOR, ->| 30/09/93 - 3311548 37 38 32 17 33 16 31 35 15 4 2 3 26 25 27 1 28 29 30 7 9 8 13 24 20 5 22 21 23 12 11 10 36 18 6 14 34 19 Ref8 Page8
(A)
COMPONENT PARTS SUPPLIED BY C.A.V. LTD
MASSEY FERGUSON MF 384 S TRACTOR, ->| 30/09/93 - 3311548 3311548 FUEL INJECTION EQUIPMENT (DIESEL) - A4.236 ENGINE 8 ItemPart NumberQtyDescription Comments A4.236 ENGINE 1 383771 Injection Pump (A) Up to Serial or Engine Number U208937P 1 2643C2781 Injection Pump (A) From Serial or Engine Number U208938P 2 26449511 Sleeve 3 317181041 Seal 4 317181051 Wire 5 04906851 Joint 6 22171393 Stud 7 05760023 Nut 8 09200033 Washer 9 09200533 Washer 10 411151361 Gear,Fuel PumpNumber of teeth/spines 56 11 1 Gear (10) Not serviced, order REF.10 12 03500101 Dowel (10) 13 07462543 Setscrew 14 09200533 Washer 15 353430251 Injection Pipe NO.1 CYL. 16 353430261 Injection Pipe NO.2 CYL. 17 353430271 Injection Pipe NO.3 CYL. 18 353430281 Injection Pipe NO.4 CYL. 19 365111232 Plate 20 365111232 Plate 21 368441162 Bridle 22 368441162 Bridle 23 07265052 Setscrew 24 22114012 Nut 25 26456664 Atomiser 26 26464601 Holder (25) 27 26468421 Nozzle (25) 28 09211734 Washer 29 338131294 Spacer 30 338131314 Seal 31 00962328 Bolt 32 3558X0111 Leak-Off Pipe 33 00953153 Banjo Bolt 34 09211763 Washer 35 09211763 Washer 36 02015261 Union 37 09211761 Washer 38 09211761 Washer
Ref8 Page8
