Southland Trailers Renn

Southland

Trailers

and

Renn, a winning combination of strength and tradition.

Combining Southland Trailer’s 30 plus years of manufacturing experience with Renn’s 60 year history of strength and tradition, delivers a tough and reliable product that outclasses all of the competition. With this proven track record you can be confident that when the going gets tough we’re right behind you. Southland Trailers and Renn, the best work partners you’ll ever have.

Specifications and product may vary upon locale. Renn reserves the right to change or modify specific product and specifications without prior notice. Standard models may be shown with options. Actual body weights may vary slightly due to allowable steel tolerance variations. For additional information and pricing contact your nearest dealership or visit us online at www.southlandtrailers.com

STRENGTH & TRADITION

Superior Design, Superior Strength.

Renn designs and builds toughness into every inch of it products. Constructed to have the best strength to weight ratio, Renn gravel products are the strongest on the market, period.

When it comes to heavy work you want something that can stand up to the impact of daily wear and tear and our conventional double wall system is designed to do just that.

Renn boxes are built with sloped load clearing interior walls and debris shedding exterior surfaces.

Tough Choices.

For extra heavy duty work that requires a higher impact, increased abrasion and sliding wear resistance, the Hardox Rock Box option is your best choice.

Hardox steel combines toughness with hardness for a longer, more useful life. Our Hardox tub models have an increased load carrying capacity because of weight reduction.

Whatever choice you make, Renn’s strength and tradition is there for you through your working day.

Our unique double wall design can stand up to the hardest day’s work. It’s built from 12 gauge high-tensile steel sheet with inner and outer liner continuously welded to a durable one-piece .188” AR200 steel floor.

During tests, Hardox 450 showed significantly less dents and drop damage than regular steel. During the testing, it was repeatedly exposed to impacts from a 300 kg weight dropped from a height of 2 meters.

2 meters

TEAM WORK

Renn sources industry leading products such as Dunlop tires, Bendix brake systems and other well established brands to produce a combination that proves itself again and again. We pick suppliers who have a reputation as tough and dependable as our own.

Our Rock Box uses high quality Hardox 450 plate, a high abrasion and impact resistant product that adds extra strength for hauling heavy rock, cement and other large debris that would damage a conventional body.

When it comes to safety, our Bendix® brake system offers a quality and performance factor that is second to none. For over 80 years, Bendix has been setting the industry safety standard for commercial vehicle air brake charging and control systems.

Dunlop commercial truck tires provide better traction and handling and a longer tread life. Dunlop truck tires are constructed with durability and efficiency in mind. Fuel-saving compounds that promote energy efficiency mean less fuel costs and a safer more cost-effective tire. They come with a Fountain Tire Canada wide warranty, entitling you to a free replacement if the tire is removed from service during the first year.

Better performance, safer hauling, improved fuel efficiency and longer tire life begins with the suspension. Ingersoll Axles and SAF Holland Air Ride suspension systems deliver the goods.

With so many community, state, and provincial regulations requiring increased safety and a reduction in wear and tear on infrastructure, Renn offers an affordable and adaptable option for our customers to comply with emerging regulations.

Renn partners with Hutchens Industries, the industry leader in spring suspension technology, to deliver a heavy-duty spring suspension system that can handle your toughest jobs.

It’s components like these that make Renn one of the toughest products on the market today.

GRAVEL BOXES

Built with the user in mind

Renn gravel boxes have built-in toughness and are designed to carry large loads easily and efficiently.

Debris-shedding outer sides are formed from a 50,000 lb. yield high tensile steel sheet that comes with a formed top rail and plank brackets.

The smooth sloped box interior is specifically designed to reduce material buildup.

The conventional box is availabe in either doghouse or flat-front—you choose the design that suits your needs best. Both come with fully welded and gusseted trunion mounts for easy installation.

Built with unwavering strength and dependability, Renn gravel boxes are coated with a preservative primer and ready to install.

SOLID ROCK

Greaseable Hinge

Boxes come standard with 1 1/4” quick remove pins and grease zerks.

Tailgate

Our dirt shedding traditional gate is constructed from AR200 plate and comes in either a sloped or straight style complete with spreader chains. Also available in a high lift version or with 12” setback hinges.

Sloped backed

Straight backed

Tailgate Latches

Adjustable case hardened steel latches

Floor

RENN’s traditional box floor design is one of the most durable in the industry. RENN uses a single piece of 3/16” AR200 plate on the floor which slopes up the wall providing a powerful debris free corner.

Gravel Box

Board Gussets

Standard on all gravel boxes.

Visibility

Our lighting packages meets all requirements of CMVSS 108. All lamps are rubber mounted and recessed for durability and powered through a heavy duty Philips STA-DRY one-piece wiring harness. * Light kits must be ordered separately from box

Front

Comes either doghouse or flat-front fabricated from a 10 gauge AR200 one piece plate.

Sills

RENN’s superior ‘hat’ style floor sills are formed from high tensile steel plate.

Side Walls

Our traditional double side wall is constructed of a 12 gauge outer layer, with a plate that forms the inner wall and part of the floor sheet.

THE ROCK BOX

The Renn Rock Box is built from impact resistant HARDOX 450 plate, enabling the box to withstand the extreme wear and tear of more rugged materials such as boulders and demolition debris.

TOUGH HARDOX

Tailgate

The dirt shedding Hardox gate comes in either a sloped or straight style and is lined with 3/16” Hardox 450. Spreader chains are included. Also available in a High Lift version or with 12” setback hinges.

HARDOX wear steel has a high and uniform hardness. This enables the steel to resist wear very effectively and have much higher resistance to sliding wear than ordinary steels.

IMPACT & ABRASION RESISTANT

Sills

RENN’s superior ‘hat’ style floor sills are formed from high tensile steel plate.

Greaseable Hinge

Boxes come standard with 1 1/4” quick remove pins and grease zerks.

Tailgate Latches

Adjustable case hardened steel latches.

Floor

RENN’s Rock Box Floor is one of the strongest in the industry. RENN uses a single piece of .250 “ Hardox plate on the floor which slopes up the wall providing a powerful debris free corner.

* Shown with optional Flip Tarp System.

Board Gussets Front

Rock Box

Standard on all gravel boxes.

Comes in either a doghouse or a flat-front style with .188” AR200 Hardox plate.

Side Walls

Our traditional double side wall is constructed of a 12 gauge outer layer, with a Hardox 450 plate that forms the inner wall and part of the floor.

Visibility

Our lighting package meets all requirements of CMVSS 108. All lamps are rubber mounted and recessed for durability and powered through a heavy duty Philips STA-DRY one-piece wiring harness.

* light kits must be ordered separately from box

Comes with:

• 1/4” HARDOX 450 Floor

• 3/16” HARDOX 450 Inserts

• 3/16” HARDOX 450 Tailgate

• 3/16” AR200 Front

Tarp Lock Recessed Lights Board Gussets Optional Flip Tarp System

Options

Electric or Manual Tarp System

High Front (54”-60”)

Full or Partial Cab Shield

Aluminum Skirt Covers

Mud Flap Brackets

Reflex Coating

Body Vibrator

Floor Liner

Hardox 450 Upgrade

Air or Hydraulic High Lift Tailgate

Manual High Lift—12” offset

2” x 12” Side Boards—wood, steel or aluminum

Heavy Duty Apron

Product Containment system

Shovel Holder

Broom Holder

Custom Tool Box

Custom Paint

Underbody or Post Hoist

Flat Front or Dog House

Sloped or Straight Tailgate

2 - Way (barn door) Tail gate

Tailgate Containment Seal & Lock

Middle Gate—load divider

Asphalt Chute

Walk Rails

Side Ladder

Safety Props

Plywood Sides

Pintle Hitch kits

Hitch Flap

Hydraulic Wet Kits

12V Pneumatic control kits

OPTIONS SPECS

FEATURES

Air Operated Tailgate with Adjustable Latches

Heavy Duty One-Piece Wiring Harness

One Year Warranty

12 Board Gussets

Debris Shedding Double Side Walls

Hat Style 8” Sills

Greaseable Tailgate Hinges

One-Piece 3/16” AR200 Floor

Sloped Inner Walls

12 Gauge High-tensile Steel Double Wall

3/16” AR200 Dirt Shedding Tailgate

Heavy Duty Spreader Chains

No Underbody Crossmembers

Greaseable Trunion Blocks

Standard Side

Side Height: 30”

Front Height: 42”

Width 96”

High Side

Side Height: 34”

Front Height: 46”

Width: 96”

Hardox Lined

Conventional AR Plate

Specifications are for installed boxes and will vary by dealer or installation shop.

DOUBLE THE PAYLOAD DOUBLE THE PROFIT

Renn pups are designed and manufactured to meet the needs of gravel haulers. With a Renn gravel pup trailer behind your truck, you double your payload every trip, which at the end of the day, puts more money in your pocket.

A heavy duty wide-flange beam frame creates a strong durable frame that withstands the rough conditions of the daily grind. Renn pups come with fourteen-foot (tandem axle) or seventeen-foot (triple axle) boxes and are available with spring or air-ride suspensions.

All Renn pup boxes and frames are sandblasted, phosphate washed, primed and coated with urethane paint, using a state of the art paint process to ensure long-lasting protection.

The wiring is fully enclosed and utilizes a modular wiring harness that protects against moisture, corrosion and damage.

PAYLOAD

FENDER SKIRT

Comes

MAIN FRAME

RECESSED LIGHTS

Renn pup trailers are your best choice for long lasting quality and performance.

Comes with lower crank assembly.

FLIP TARP

Heavy duty wide flange beam.

Rubber mounted with fully enclosed modular wiring harness.

with mud flaps.

SL 1700 Gravel Pups

AUTOMOTIVE FINISH

Polyurethane paint for a longer lasting finish.

SL1400 SL 1700

STANDARD FEATURES

• Fully Enclosed Wiring

• ABS Air Brakes

DOUBLE WALLS

Superior strength from double wall design.

• Painted Box White or Silver

• Painted Frame

• Document Holder BOX SPECS

•

• Auto Slack Adjusters

• Ride Height Control Valves (Air Suspension Models)

CRANK JACK

• Inner Sides.......12 gauge High Tensile Steel Full Inside Liner

•

• Floor..................One-piece 3/16” AR200 Plate

• Tailgate.............12 gauge Outer with 3 Cross Ribs & 3/16” Inner Liner

• Tipping Sill........4”

DOUBLE UP FOR PROFIT

COMBO best

Renn Gravel Boxes and Gravel Pups are unbeatable when working in tandem. Carrying two payloads safely and effectively and making fewer trips increases profit.

Because of Renn’s well known and proven reputation for toughness and minimal down time, this combination lets you work hard and work more effectively.

It`s the little things that can sometimes make a big difference and we make sure that Renn quality goes into the smallest of details.

The work day can be a long one but with this combo you get the job done twice as fast!

Gravel Box & Pup Combo

Mud flaps

Safety side steps

Tailgate latch

Board gussets

Rubber mounted lights

Work Smarter

The Renn Belly Dump is impressive with it`s capacity,strength and trouble free operation. Increased hauling capacity coupled with minimal downtime means increased profits.

We built this unit to be tougher than the day is long with the structural integrity being supplied by our light weight design. Lighter construction means better fuel economy and increased payloads.

TOUGH BUILT

5th WHEEL

The oscillating design reduces trailer and vehicle stress over rough terrain.

• Painted Box White or Silver

DOUBLE HOPPER SPECS

Hopper Front & Rear

10 gauge high tensile steel upper slopes c/w formed rib supports Hopper Sides

Upper sides -10 gauge high tensile steel

Lower Sides- 3/16”AR200 plate

Hopper Gates.

• Ride Height Control Valves

53° front and rear slope 3/16” high tensile main sheet c/w 1/4” sides.

Double bumper system for increased protection to the front of the unit.

FRONT BUMPER

DOUBLE HOPPERS

Smooth sided interiors with a front hopper angle of 61 degrees and a rear angle of 50 degrees.

Belly Dumps GCD 3228AR

LIGHTING

Recessed and rubber mounted lights with sealed and protected wiring junction boxes.

HD STEEL GATES

Independent pneumatically operated 3/16” steel gate release complete with air dryer & oiler.

BRAKE SYSTEM

2S-1M ABS system.

TIRES

Radial tires with 10 bolt uni-mount rims

Flat out, THE BEST THERE IS.

decks heavy duty

Heavy duty work takes a heavy duty trailer and with an engineered chassis that provides the best strength to weight ratio, Renn Highboy flatdecks can easily get the job done.

With a standard width of 102”and available in a tandem (24’) or tridem (28’) configuration, and payload weights of up to 54,980 lbs. the Highboy Flatdeck is your best bet for all of your hauling needs.

STANDARD SPECS

• 28 foot working deck

• 102`` deck Width ( 9 ft. available )

• 36 ``deck height

• S-P-F rough plank deck

• I- beam main frame

• Junior I-beam cross members

• 90,000 lb. adjustable lunette eye

• Two -12,000 lb. drop foot jacks

STANDARD FEATURES

• Beavertail and ramps

• 8 recessed D-rings ( 4 per side)

• Checkerplate over wheels

• Safety chains and hooks

• Totally enclosed wiring

• Frame painted and pinstriped

RUNNING GEAR

• Three tandem dual 22500 lbs. spring axles

• Air brakes c/w ABS (2S/1M)

• 255R22.5 tires

TOughness guaranteed

A combination of a tough liner* and one of the best engineered frames earns the SL2500 the reputation of being one of the lightest and strongest on the market today. With a payload of over 22,700 kgs, moving more in less trips means more money in your pocket.

These units are loaded with safety and convenience features. Debris shedding exteriors and a shedder angle on the hitch help to prevent material build up.

For ease of maintenance or box removal , bolt on tipping hinges are available on all wagons, end dumps and pups.

Anti-lock braking systems and dust shields that protect brake shoes and drums and impact resistant materials all contribute to road and job safety.

We know you work hard and we build our wagons to work hard too.

* (tub models are constructed with impact resistant steel)

heavy duty

Tub Box Model

General Information

Model: 25’ Quad Tub Wagon with Air Ride Suspension

Capacity: 24cu.yds

Trailer weight: Approx 17,380 lbs.

Box Specifications

Overall width: 8 ft.

Overall length: 25 ft.

Box Front: 3/16” AR200 Plate

60” Sloped Front

Custom Fleet Colours are available. See your dealer for details

Conventional Box Model

Wagons SL2500AR Quad Wagon

Frame and Running Gear

Frame: Engineered beam

Hitch/Jack: Shedder angle on hitch

3000 lbs. Swivel Jack with frame storage pipe

Pintle eye on top of hitch

Axles: Quad, Dual Wheel, 22,500 lbs. axles

Suspension: Air Ride Suspension 17” Ride Height

Manual dump valve & load gauge for dolly & rear

Brakes: Air Brakes & Anti -lock Braking System

3030 Spring Brake Chambers Auto Slack Adjusters

Outboard Drums & Dust Shields

Tires: 11R24.5 16 Ply On & Off Road Tires

24.5 x 8.25 10 Hole Unimount

Hoist: 45 ton

BIGGER IS BETTER

The SL3300 is designed to take the most punishing work and provide the biggest payload without extra effort.

The 40 ton capacity hoist with five lift stages makes for faster offloading. Control and stability is provided by a beefy suspension with a 60” axle spread.

Because of the wide track and the HD 22,500 lb. axles, handling heavy loads is safer and more effective. For increased raised box stability the airbag system auto-dumps when the box is raised.

We built the box tough. The outer sides are formed with 12 gauge high tensile steel and the interior is designed with smooth slopes and corners. The floor is a solid one piece 3/16” plate that can handle the toughest loads.

DUMPS heavy duty

General Information

Model: 33’ End dump with air ride suspension

Trailer Weight: Approx. 17,380 lbs.

Frame and Running Gear

Tailgate: 50” straight tailgate c/w air trip

Outer: 12 gauge high tensile steel c/w formed cross ribs

Inner: 3/16” AR200 steel plate

Tipping Sill: 3/16” steel - 4” high

“Hat” Style – 43.5” on center

Plank Brackets: 4 each side

Accommodates 2 x12” boards

Coating: Sandblasted & primed painted with two-part polyurethane

Standard Features

Fully enclosed wiring

Sealed, rubber mounted lights

22 oz. Black vinyl roll tarp c/w lower crank assembly

Conspicuity tape

Document holder

End Dumps SL3300AR

bolt on tipping hinges

checkerplate top deck

Rubber cushion

Box Colors: White or silver

Frame Color: Black

Standard rear impact guard

Box Specifications

Overall width: 8 ft.

Overall width: 33 ft.

Box Front 0.188” AR200 plate

60” sloped front

HD mud flaps airbags

Make work safer and easier

HEAVY DUTY

Working smarter not harder. We build safety and convenience into every one of our products.

The telescoping drop legs saves time and money. The anti lock braking system ensures your saftey even in the most severe braking situations. Factory installed dust shields protect your brake shoes and drums from rocks and other debris.

Our frame, one of the strongest on the market, is made of engineered and reinforced beams with weight reducing cut outs. The formed tipping sills use 3/16’” steel.

Hassle free equipment and worksite safety is a driving force behind all of Renn’s products.

General Information

Model: 29” tandem end dump single point suspension

Top of Side Capacity: 26.30 yd/3

Trailer weight: Approx 16,440 lbs.

Box Specifications

Box Front: 10 gauge high tensile steel

60” Sloped Front

8” cylinder hoist (45 ton capacity) 235”

with 5 stroke stage

Outer: 12 gauge high tensile steel - formed 38” high

Inner:12 gauge high tensile steel - full inside liner

Full Length Fender Skirts (10 gauge)

Frame and Running Gear

Frame: Engineered & reinforced beam

Jack: Double landing gear: 62,500 lbs. per set

Axles: Tandem, dual wheel, 22,500 lbs. axles

End Dumps SL2900

Suspension: Hutch single point suspension

Brakes: Air brakes & anti lock braking system

3030 Spring brake chambers auto slack adjusters

Outboard drums & dust shields

Tires: 11R24.5 16 Ply on & off road tires

24.5 x 8.25 10 hole unimount

FEATURES STANDARD & OPTIONAL STANDARD

TOUGH CHOICES

Renn products are designed with the working man in mind. We`ve incorporated a lot of “common sense” ideas as standard features that will make the work day safer and more efficient.

Renn is all about flexibilty and with a variety of options available, you can customize your unit to best suite your needs.

• HD Trip Rod

• Hydraulic Trip Cylinder

• Reflex Coating

• Aluminum Rims

• Electric Tarp

• HD Mudflaps

• Checkerplate Finishing

• Custom Colors

• ¾” Bullet Lighting

• Bolt on Tipping Hinge

• Side Ladder

• 3M polyethylene protective tape

side ladder

sloped corners

Dunlop tires

hand crank

bolt on tipping hinges

HD trip rod

FEATURES & OPTIONS

OPTIONS

ONE TWO for

Adjustable pintle eye hitch

Towable fiFIfth wheel toughness

Renn’s reputaion for toughness really comes through when it’s all about tandem towing and increasing your delivery profit margin.

Renn’s A-Train model is a double configuration, single axle unit with a payload capacity of 54,980 lbs. It’s built with Renn’s traditonal robustness and strength so you can get the job done.

• Superior performance

• Easy yard handling

• Low maintenance costs

• Outstanding durability

• Great customer service

HD drop leg jack with caster wheel

Converter Dolly

25,000 lb. axle with auto slack adjusters

Bendix airbrake system with ABS

Full LED lighting

air bags

aluminum wheels electrical system

engineered pintle eye mount

fifth wheel

CDT 171 0

Single Axle Wagon Converter

The flFLeet ADVANTAGE

Once you’ve decided to start or expand your fleet decide on Renn for:

wide

Engineered and built to your specifications*

• Latest manufacturing technology

• Less down time

• Proven history of excellent maintenance

• Standardize your fleet

• Decreased parts inventories

• Mechanics training time is reduced

• Driver training is reduced

• Time from acquisition to utilization is minimized

* See dealer for details
