MF 660/665 COMBINES - 1637108 1 2 45 44 43 46 41 42 3 11 12 4 5 10 6 7 8 9 33 34 35 13 38 39 36 14 37 40 15 25 24 23 22 21 20 26 19 18 32 27 28 16 17 3029 31 Ref2 Page2
MASSEY FERGUSON MF 660/665 COMBINES - 1637108 1637108
2 ItemPart NumberQtyDescription Comments 1 3370976M911 Engine T6.3544 2 356446X11 Plug 3 3371689M911 Hydr Hose 4 3045157M911 Toggle 353919X11 Nut Unf 5 353919X11 Nut Unf 6 3044979M11 Stem 7 525396M11 Buckle 338160X11 Nut 8 3049619M11 Stem 9 353517X12 Screw Unf 10 353446X12 Lock Washer 353755X12 Washer 11 3049017M911 Bearer 12 195612M11 Pin 13 3044960M911 Lever 14 353919X11 Nut Unf 15 3044963M911 Lever 16 353919X11 Nut Unf 17 354057X11 Pin 18 3052849M11 Toggle 19 353919X11 Nut Unf 20 3049619M11 Stem 21 525396M11 Buckle 338160X11 Nut 22 3044979M11 Stem 23 3052849M11 Toggle 24 353919X12 Nut Unf 25 3044952M911 Lever 26 3052849M11 Toggle 27 353919X11 Nut Unf 28 3044982M11 Stem 29 353919X11 Nut Unf 30 3045150M911 Toggle 31 357515X11 Nut Unf 32 353756X11 Washer 355848X11 Snapring 33 358656X11 Nut 34 271675M11 Clevis Pin 35 3044950M911 Lever 36 353919X11 Nut Unf 37 353540X12 Screw Unf 38 3044956M911 Bearer 39 353919X11 Nut Unf 40 3052849M11 Toggle 41 1 Hydr Hose (3) Not serviced, order 3371689M91 42 831497M11 O Ring (3) 43 360059X11 Tie 44 356446X11 Plug 45 353516X11 Screw Unf 46 831497M11 O Ring (3) Ref2 Page2
ENGINE AND ACCESSORIES
MF 660/665 COMBINES - 1637108 40 3 38 6 7 12 8 9 10 2 11 1 4 5 14 59 13 58 60 24 25 26 15 16 30 36 57 28 27 29 56 62 31 17 3937 43 55 42 32 34 54 21 33 35 44 45 50 18 23 22 19 51 49 20 52 46 53 48 47 41 61 Ref4 Page4
MASSEY
MF 660/665 COMBINES - 1637108 1637108 CYLINDER BLOCK 4 ItemPart NumberQtyDescription Comments 1 636141 Cylinder Block 2 06506186 Plug (1) 3 313583936 Liner (1) (A) 3 313583946 Liner (B) 4 324171331 Plug 5 324171341 Plug 6 065061814 Plug 7 06507104 Plug (1) 8 06506181 Plug 9 06505631 Plug 10 06506182 Plug (1) 11 Not Used 12 06506641 Plug (1) 13 074621110 Bolt 14 092000310 Washer 15 324551192 Dowel 16 07464246 Bolt 17 331151296 Washer 18 07462533 Screw 19 09200533 Washer 20 09200033 Washer 21 361253051 Cover 22 371476441 Plate 23 378131131 Plug 24 03500092 Dowel 25 21725302 Capscrew 26 331121112 Washer 27 375138511 Housing 28 24153911 Seal 29 368171571 Joint 30 321611142 Plug 31 08262144 Stud 32 09200534 Washer 33 05760024 Nut 34 09205212 Washer 35 21763692 Screw 36 324171555 Plug (1) 37 24311311 Plug 38 06505861 Plug (1) 39 328131081 Cover 40 24111561 Washer 41 321613171 Plug 42 334351331 Tube 43 324171431 Plug 44 328114084 Joint 45 362778312 Bridge Piece 46 09205212 Washer 47 21763692 Screw 48 3216632914 Bolt (1) 49 3312142114 Washer 50 3314211114 Thimble (1) 51 08262012 Stud 52 09200532 Washer 53 05760022 Nut 54 324171272 Plug 55 324171151 Plug 56 06505662 Plug 57 324171152 Plug 58 321682314 Plug 59 24111574 Washer 60 Not Used 61 Not Used 62 24311311 Plug (A) PRESS FIT (B) SLIP FIT Ref4 Page4
FERGUSON
MF 660/665 COMBINES - 1637108 22 8 17 16 16 14 10 15 7 9 11 33 12 13 34 6 2 4 29 28 32 31 1 27 30 5 3 18 19 20 37 21 23 24 25 26 35 36 Ref8 Page8
Repairs
Not
Not
MASSEY FERGUSON MF 660/665 COMBINES - 1637108 1637108 CRANKSHAFT 8 ItemPart NumberQtyDescription Comments 1 680771 Kit, Crankshaft 2 1 Crankshaft (1) Not serviced, order REF NO1 3 680791 Kit, Bearing (C) 68079AX Kit, Bearing (C) Thickness -0,25MM 3 68079BX Kit, Bearing (C) Thickness -0,50MM 3 68079CX Kit, Bearing (C) Thickness -0,75MM 4 311373112 Washer (1) 31137312X Thrust WasherThickness +0,17MM 5 311373212 Washer (1) 31137322X Thrust WasherThickness +0,17MM 6 890641 Kit, Bearing (1) (C) 6 89064AX Kit, Bearing (C) Thickness 0,25MM 6 89064BX Kit, Bearing (C) Thickness 0,50MM 6 89064CX Kit, Bearing Thickness 0,75MM 7 411529236 Conrod Repairs and replaces 63408 8 1 Piston Rod (7) Not serviced, order REF NO7 9 1 Cap (7) Not serviced, order REF NO7 10 311341311 Bush (7) 11 327621162 Bolt (7) 12 332213282 Nut (7) Repairs and replaces 33221321 13 688026 Kit, Piston (A)
and
13 688036 Kit, Piston (B)
Repairs
replaces 68390
and
14 1 Piston (13)
replaces 68391
serviced,
15 1 Piston Pin (13)
order REF NO13
serviced,
REF NO13 16 2721A0292 Circlip (13) 17 411580056 Kit, Piston RingRepairs and replaces 68238 18 311712111 Gear,Crankshaft 19 05000121 Woodruff Key 20 05000051 Woodruff Key 21 311531611 Pulley,Crank 22 331254121 Spacer 23 24177111 Element 24 324183131 Thrust Plate 25 24156381 O Ring 26 321861333 Screw 27 414252161 Adaptor 28 1 Adaptor (27) Not serviced, order REF NO27 29 25132461 Bush (27) 30 411170881 Flywheel 31 04102641 Gear,Starterring (30) 32 1 Flywheel (30) Not serviced, order REF NO30 33 07468536 Bolt 34 331171216 Washer 35 09200539 Washer 36 00962369 Bolt 37 26356791 Pulley,Crank Up to Serial or Engine Number 26356741 Pulley,Crank From Serial or Engine Number (A) UNTOPPED (B) PRE-TOPPED Ref8 Page8
order
MASSEY FERGUSON MF 660/665 COMBINES - 1637108 1637108 CRANKSHAFT 8 ItemPart NumberQtyDescription Comments (C) PRE-FINNISHED Ref8 Page8
MF 660/665 COMBINES - 1637108 50 43 44 44 48 47 49 45 46 9 8 11 7 10 181920 16 17 14 15 13 6 42 5 40 41 12 4 3 21 39 23 22 21 38 24 25 37 26 27 28 29 36 35 34 31 30 33 32 51 Ref12 Page12
MASSEY FERGUSON MF 660/665 COMBINES - 1637108 1637108 CYLINDER HEAD 12 ItemPart NumberQtyDescription Comments 1 681721 Cylinder Head 2 332617326 Guide (1) 3 332617526 Guide (1) Repairs and replaces 33261754 4 3341511812 Washer (1) 5 3381711712 Seal (1) 6 3174413112 Spring (1) 7 3174512112 Spring (1) 8 3342312212 Cap (1) 9 3317310812 Cotter (1) 10 3216621912 Bolt 11 321662216 Bolt 12 324171276 Plug (1) 13 21721426 Bolt 14 335311312 Nut Up to Serial or Engine Number 15 24311543 Plug (1) 16 3353113213 Nut Repairs and replaces 33531128 17 332421126 Sleeve (1) 18 362377341 Bracket 19 09200542 Washer 20 07464532 Setscrew 21 08262446 Stud 22 09200536 Washer 23 05760026 Nut 24 09407371 Plate 25 04904851 Joint 26 3241712213 Plug (1) 27 21161902 Dowel 28 06505634 Plug (1) 29 368126071 Gasket 30 325263234 Stud Repairs and replaces 32526321 31 325263248 Stud 32 325263192 Stud 33 314319616 Valve Exhaust (1) Repairs and replaces 31431752 34 331521556 Insert (1) 35 314313156 Valve Inlet (1) 36 331521546 Insert (1) 37 321145011 Plug 38 24111571 Washer 39 06502031 Plug 40 00964322 Screw 41 09200542 Washer 42 362377281 Plate 43 377831611 Exhaust Manifold 44 368621912 Gasket 45 368667461 Joint 46 08265094 Stud 47 331151178 Spacer 48 21881354 Nut 49 08264394 Stud 50 21881354 Nut 51 24311541 Plug Ref12 Page12
MF 660/665 COMBINES - 1637108 20 21 22 23 19 1718 1516 14 13 9 10 11 12 8 7 6 31 5 4 3 1 2 30 29 28 27 24 25 26 32 Ref14 Page14
MASSEY FERGUSON MF 660/665 COMBINES - 1637108 1637108 CYLINDER HEAD COVER 14 ItemPart NumberQtyDescription Comments 1 371864711 Cyl.Head Cover 2 368114431 Joint 3 368331252 Joint 4 375368411 Plate 5 357841341 Filler 6 24878451 Cap 7 24111524 Washer 8 07484144 Setscrew 9 07483514 Screw 10 24111514 Washer 11 361711192 Plate 12 04900532 Joint 13 07484142 Setscrew 14 24111522 Washer 15 377355011 Body 16 368331251 Joint 17 335145111 Connection 18 24818041 Clip 19 317541191 Spring Repairs and replaces 31754117 20 327265294 Nut Up to Serial or Engine Number 21 Not Used 22 338171324 Seal 23 04904741 Joint 24 361711221 Plate 25 24111522 Washer 26 07484142 Setscrew 27 338725221 Pipe 28 357311491 Connection 29 01801031 Clip 30 26528451 Body 31 248700021 Joint 32 327265314 Nut From Serial or Engine Number Ref14 Page14
MF 660/665 COMBINES - 1637108 1 2 3 4 15 22 8 8 2312 12 12 12 12 12 9 9 9 9 9 9 10 10 10 10 10 10 7 7 7 7 11 11 11 11 11 11 6 6 5 5 14 13 13 13 13 13 13 16 20 21 18 24 17 19 25 Ref16 Page16
MASSEY FERGUSON MF 660/665 COMBINES - 1637108 1637108 ROCKER ARM 16 ItemPart NumberQtyDescription Comments 1 628431 Rocker Shaft AssRepairs and replaces 68470 2 587681 Rocker Shaft (1) 3 1 Rocker Shaft (2) Not serviced, order REF NO 2 4 06505072 Plug (2) 5 01701512 Circlip (1) 6 331174152 Washer (1) 7 317441234 Spring (1) 8 317431082 Spring (1) 9 375214316 Bracket (1) 10 411514686 Lever (1) Right Hand 11 25114251 Bush (10) 12 411514676 Lever (1) Left Hand 13 25114251 Bush (12) 14 355111111 Pipe (1) 15 07265041 Setscrew (1) 16 338111131 Olive 17 072057912 Screw (1) 18 057605212 Nut (1) 19 22152744 Stud 20 05760544 Nut 21 331161114 Washer 22 00966362 Bolt 23 331161112 Washer 24 3143430712 Pushrod 25 3143416312 Tappet Ref16 Page16
MF 660/665 COMBINES - 1637108 4 17 16 2 13 14 1 15 12 11 10 9 3 3 8 7 6 5 Ref18 Page18
MASSEY FERGUSON MF 660/665 COMBINES - 1637108 1637108 AIR INDUCTION 18 ItemPart NumberQtyDescription Comments 1 377885811 Ind.Manifold 2 24311542 Plug 3 374671052 Joint 4 374671042 Joint 5 24311311 Plug 6 331151292 Washer 7 00964392 Bolt 8 00964422 Bolt 9 331151292 Washer 10 368231321 Joint 11 361221281 Plate 12 09200534 Washer 13 07484134 Setscrew 14 00964364 Bolt 15 331151294 Washer 16 06507221 Plug Up to Serial or Engine Number 17 26661081 Intake HeaterFrom Serial or Engine Number Ref18 Page18
MF 660/665 COMBINES - 1637108 15 23 2021 19 5 18 4 3 2 1 17 24 37 25 36 7 35 6 34 33 31 26 2930 14 39 38 111213 10 8 41 40 43 42 44 16 22 32 2728 9 Ref20 Page20
MASSEY FERGUSON MF 660/665 COMBINES - 1637108 1637108 TIMING GEAR 20 ItemPart NumberQtyDescription Comments 1 00962382 Bolt 2 09200532 Washer 3 09200031 Washer 4 375561491 Inspection Cover 5 368261071 Joint 6 00962394 Bolt 7 09200534 Washer 8 27515391 Hourmeter 9 1 Gasket Not serviced, order REF NO8 10 2 Screw Not serviced, order REF NO8 11 07463534 Setscrew 12 09200534 Washer 13 374462831 Plate 14 368664341 Joint 15 21821221 Setscrew 16 317331211 Washer 17 331154081 Washer 18 331531281 Washer 19 311719311 Gear 20 331531351 Washer 21 06108441 Dowel 22 05000121 Woodruff Key 23 314163031 Camshaft 24 22112242 Nut 25 324131221 Plate 26 335711271 Adaptor 27 07462511 Setscrew 28 24111521 Washer 29 22112242 Nut 30 411150571 Idler Gear Right Hand 31 324131221 Plate 32 411150561 Idler Gear Left Hand 33 25116131 Bush (30) 34 25116131 Bush (32) 35 327185222 Hub 36 03505532 Dowel 37 08265104 Stud 38 368141241 Joint 39 371611741 Cover 40 07462558 Setscrew 41 09200538 Washer 42 00962371 Bolt 43 09200531 Washer 44 2418F4361 Seal Repairs and replaces 2415361 Ref20 Page20
MF 660/665 COMBINES - 1637108 35 52 51 55 54 56 57 53 46 43 4445 39 40 47 50 49 48 24 34 25 36 41 42 23 37 30 29 28 19 27 26 38 18 20 31 16 33 32 11 12 10 22 13 9 1415 21 8 2 5 1 3 4 6 Ref22 Page22
MASSEY FERGUSON MF 660/665 COMBINES - 1637108 1637108 LUBRICATING OIL
22 ItemPart NumberQtyDescriptionComments 1 414241491 Sump 2 1 Housing (1) Not serviced, order REF NO 1 3 21374352 Insert (1) 4 24870042 Plug 5 24112602 Washer 6 074625413 Setscrew 8 07462111 Bolt 9 092005322 Washer 10 09200032 Washer 11 04900071 Joint 12 374811061 Plate 13 08276014 Stud 14 09200534 Washer 15 05760024 Nut 16 07462558 Setscrew 18 07264031 Screw 19 368167071 Joint 20 413141361 Pump 21 00964342 Bolt 22 09200542 Washer 23 368655321 Joint 24 368311221 Joint 25 413711941 Relief ValveRepairs and replaces 41371184 26 1 Body (25) Not serviced, order REF NO 25 27 327127261 Plunger (25) 28 317441511 Spring (25) 29 327121111 Seat (25) 30 01700241 Circlip (25) 31 00962422 Bolt 32 09200532 Washer 33 21313252 Washer 34 317883281 Dipstick 35 338121081 Washer (34) 36 1 Oil Dipstick (34) Not serviced, order REF NO 34 37 357726141 Tube 38 335331031 Nut 39 07462552 Setscrew 40 09200532 Washer 41 357458781 Pipe,Oil 42 368331391 Joint 43 07462541 Setscrew 44 364181381 Bracket 45 09200032 Washer 46 09200531 Washer 47 05760021 Nut 48 07462541 Setscrew 49 09200531 Washer 50 09200031 Washer 51 357174196 Jet 52 06108446 Dowel 53 321843346 Bolt 54 09200056 Washer 55 353538031 Pipe,Oil 56 335321372 Nut (55) 57 05660052 Olive (55) Ref22 Page22
SYSTEM
