Project : HAYWOOD

HUP EXTENSION & LIVING ROOF CLIENT : HAYWOOD 16 GILBERTSTONE CLOSE REDDITCH WORCESTERSHIRE B98 7NQ

GOOGLE EARTH IMAGE OF PROPERTY

MEASUREMENTS ALL MEASUREMENTS PROVIDED BY CUSTOMER E PROVIDED AS A GUIDE ONLY AND SHOULD NOT BE RELIED UPON FOR ORDERING OR CUTTING.

VIEW OF REAR OF PROPERTY

f

Note : Signi icant slope from top of drive towards house but even

VIEW OF DRIVEWAY FOR SKIP

Type to enter text

ACCESS TO REAR OF PROPERTY FROM FRONT

Access to rear of property currently via gate to left.

Both gate and fence and low height fence behind along dividing properties likely to be removed in time for work to commence giving good access to rear of property

VIEW OF BACK GARDEN FROM REAR OF HOUSE

VIEW OF BACK GARDEN

CONSUMER UNIT LOCATED IN GARAGE

FLOORPLANS OF PROPERTY Rear of Property

f

Front of Property

Identi ies location of Consumer Unit

WINDOW IN LOUNGE TO BE REPLACED BY SLIDING DOOR SIZE OF EXISTING PATIO DOORS 2,360MM WIDE BY 2020MM HIGH WINDOW (SIZE OF APERTURE)

WINDOW IN DINING ROOM TO BE REPLACED BY SLIDING DOOR OUT ONTO PATIO - SIZE OF EXISTING WINDOW CURRENT SIZE 2,060MM X 1,060 RADIATOR TO BE RELOCATED (CLIENTS RESPONSIBILITY)
