Nissan Truck D21 Service Manual 97

TEST VALUE AND TEST LIMIT (GST ONLY — NOT APPLICABLE TO CONSULT-II)

The following is the information specified in Mode 6 of SAE J1979. The test value is a parameter used to determine whether a system/circuit diagnostic test is “OK” or “NG” while being monitored by the ECM during self-diagnosis. The test limit is a reference value which is specified as the maximum or minimum value and is compared with the test value being monitored.

Items for which these data (test value and test limit) are displayed are the same as SRT code items. These data (test value and test limit) are specified by Test ID (TID) and Component ID (CID) and can be displayed on the GST screen.

SRT item Self-diagnostic test itemDTC

CATALYSTThree way catalyst function

EVAP SYSTEM

HO2S

HO2S

HTR

EGR SYSTEM

: Applicable ･: Not applicable Test value (GST display) Te s t limit ApplicationUnit

TIDCID

P042001H01HMax. XP0420★102H81HMin. X-

Heated oxygen sensor 1

Heated oxygen sensor 2

Heated oxygen sensor 1 heater

Heated oxygen sensor 2 heater

EGR function

EGRC-BPT valve function

EVAP control system (Small leak)P044005H03HMax. XEVAP control system purge flow monitoringP144706H83HMin. XmV P013009H04HMax. Xms P01300AH84HMin. XmV P01300BH04HMax. XmV P01300CH04HMax. XmV P01300DH04HMax. Xs P013619H86HMin. XmV/500ms P01361AH86HMin. XmV P01361BH06HMax. XmV P01361CH06HMax. XmV P013529H08HMax. XmV P01352AH88HMin. XmV P01412DH0AHMax. XmV P01412EH8AHMin. XmV P040031H8CHMin. X℃ P040032H8CHMin. X℃ P040033H8CHMin. X℃ P040034H8CHMin. X℃ P040035H0CHMax. X℃ P040236H0CHMax. XP040237H8CHMin. X-

★1：Models B15 GA16DE engine 1997MY only.
