Welcome

Visit pandhengineering. co.uk for regular updates and archived features

The sharp-eyed among you will have noticed some changes. P&H Engineering is going quarterly and getting bigger.

We’ve had some amazing feedback from you so we’re giving you more of what you want. The Journal is going to continue to improve and we’ll also be increasing our content on the P&H website.

It’s going to be a big year. The Institute is stepping up its work and increasing visibility of its activities so we’re starting as we mean to go on by setting out the CIPHE manifesto for change, hearing from someone determined to change the way we live, and getting ready for the UN climate summit.

And if this planet isn’t enough, we’re going out of this world to look at life on the International Space Station. We’ve got a new product news section and more inside. Enjoy the edition, stay safe, and do contact me via the details below with feedback, ideas and suggestions. This will always be your magazine.

20

Contents REGULARS

FEATURES

5 From the CEO

12 Stand and deliver

Kevin Wellman on dealing with difficult times

The CIPHE’s campaigning manifesto for the year ahead

6 Frontline

16 Designs for life

Carbon-cutting targets, the deadly effects of asbestos, and more

How thoughtful design can help vulnerable people live safely at home

28 International outlook

20 Breathe easy

News from our Hong Kong branch

What can be done to deal with negative effects of air pollution?

30 The Fix

25 Out of this world

Ensuring hot water systems meet consumer demands

A look at the workings of the International Space Station

45 Under pressure Make sure you take time to take care of your health

CHRIS SMITH Editor

ON THE COVER

46 Q&A: Michael Walsh

Setting the agenda to help save the planet Page 18

One of our newest members on why he loves his job, and loves learning

pandhengineering@ jamespembrokemedia.co.uk

Editor Chris Smith Project manager Emma Dance Head of design Simon Goddard Publisher James Houston Published by James Pembroke Media, 90 Walcot Street, Bath BA1 5BG Tel 01225 337777 Advertising sales executive Harvey Falshaw, harvey.falshaw@jamespembrokemedia.co.uk Chartered Institute of Plumbing and Heating Engineering (CIPHE) 64 Station Lane, Hornchurch, Essex RM12 6NB Tel 01708 472791

Illustration: Adam Gale

Membership Founded in 1906, the Chartered Institute of Plumbing and Heating Engineering (CIPHE) is the professional body for the UK plumbing and heating industry. Membership is made up of consultants, specifiers, designers, public health engineers, lecturers, trainers, trainees and practitioners.

The CIPHE has a membership of 7,500, including over 150 manufacturers and distributors. The majority of members live in the UK, although over 1,000 are residents in Hong Kong.

The CIPHE is a member of the Construction Industry Council and a licensed member of the Engineering Council.

Subscriptions P&H Engineering is the magazine for the Chartered Institute of Plumbing and Heating Engineering, containing technical articles, latest industry news and environmental and educational updates.

It is published six times a year and sent free to members.

Annual subscription for non-member £120 Annual subscription for overseas non-member £145 To join CIPHE, email tims@ciphe.org.uk

Copyright notice and disclaimer P&H Engineering is published bi-monthly by the Chartered Institute of Plumbing and Heating Engineering. All material is copyright of the Chartered Institute of Plumbing and Heating Engineering and may not be reproduced without written permission. The publishers do not accept responsibility for errors or omissions. The views expressed in the magazine are not necessarily those of the Institute and publication of an advertisement or article does not necessarily mean the Institute endorses those products, materials or techniques.

www.ciphe.org.uk

QUARTER ONE / 2021

P&H ENGINEERING 3

FROM THE CIPHE CEO

I remain concerned that damage has been done

KEVIN WELLMAN Chief executive officer kevinw@ciphe.org.uk

S

ometimes, being proved right is actually pretty empty. The COVID-19 crisis is one of those times. We planned for the long haul and we expect this to be with us beyond the spring months.

The CIPHE has produced resources on safe working practices for members of the plumbing and heating industry so they can keep seeing customers during COVID-19 lockdown. It’s all on the website – which we’re constantly updating.

Now, we are making access to self-testing kits available to members and their businesses to offer further protection and reassurance that can keep you working safely.

LOW CARBON

YOUR INSTITUTE, YOUR VALUES The CIPHE’s manifesto details the Institute’s mission to safeguard public health, to improve education, support research and further our members’ career development. Find out more at https://bit.ly/3klbmwF

www.ciphe.org.uk

There was a flurry of government activity at the end of the year on the drive to hit Net Zero by 2050. We stepped in after a clerical error promising to outlaw gas boilers in new homes by 2023 was accidentally included. But I remain concerned that damage has been done. Currently, the Future Home Standard is due to come into play from 2025 – meaning that gas central heating appliances in all new build properties will be banned and will require an alternative heating source.

SAFER BUILDS We’re members of the Competence Steering Group (CSG) which was set up following the dreadful Grenfell fire. The second and final report ‘Setting the Bar’ was published just before year-end, providing a blueprint to improve competence for those working on

We’ll be living with COVID-19 for some time

higher-risk buildings and drive culture change.

It has been set out by a cross-industry group representing more than 150 organisations in the fire and built environment industries.

There are new competence standards, a system of independent assessment and checks on the people doing it.

If you have been following the Grenfell Tower Inquiry, you’ll have heard the same thing over and over. Nobody checked, nobody questioned, nobody thought. And now the risks of such an approach are laid bare.

The CSG has worked closely with the Ministry of Housing Communities and Local Government and some of the report’s key recommendations have already been adopted.

It has not been easy, but we believe it will save lives.

QUARTER ONE / 2021

P&H ENGINEERING 5

Frontline Front line All that’s happening in plumbing and heating

KEEP INFORMED Read all the latest news, updates, and member benefits Facebook/CIPHE twitter.com/CIPHE www.ciphe.org.uk

Road to Glasgow

COUNTRIES COMMIT TO COP26 CHANGES

Got a news story?

Get in touch with editor Chris Smith using the email address on p3

Campaign

CIPHE SETS COURSE FOR CAMPAIGNING YEAR CIPHE lays out an ambitious agenda, campaigning for important changes over the coming year

I

mproving public health, taking on people traffickers and getting mandatory registration are among the CIPHE’s objectives for 2021.

Despite the challenges of the COVID-19 outbreak, the Institute is set for a year of campaigning on big issues as part of a manifesto aimed at improving public safety and professionalising the industry.

Top priority will be working with industry leaders and the government on the Building Safety Bill which will be introduced in the next session of parliament. It will create the powers for a new regulator.

6 P&H ENGINEERING

The CIPHE will be pushing for the bill to create a demand for professional bodies to maintain registers of competent individuals.

CIPHE chief executive officer Kevin Wellman said “There have already been some early successes thanks to long-term work by the Competence Steering Group to reform building standards.

“Some of the key recommendations have already been adopted, including the proposal for a Committee on Industry Competence as set out in the draft Building Safety Bill. We’re starting 2021 as we mean to go on.”

See more on page 13

QUARTER ONE / 2021

DOZENS OF COUNTRIES have signalled that they are ready to sign up to ambitious carbon cutting targets at this year’s crucial UN climate change summit.

A group of 24 countries announced new commitments, strategies or plans to reach net zero or carbon neutrality ready for November’s UN climate conference COP26 in Glasgow.

The December update from the UN also included pledges from businesses to reduce their emissions.

The CIPHE’s work with the government on cutting housing emissions will feed into the agreement which will be signed at the summit.

United Nations secretary-general António Guterres said: “The summit has now sent strong signals that more businesses are ready to take the bold climate action on which our future security and prosperity depend.”

See more on page 13

Health & Safety

ASBESTOS REMAINS MAJOR KILLER, WARNS HSES ASBESTOS EXPOSURE remains a major killer, according to data from the HSE. Its data for 2019/20 covering workplace health also revealed injury at work costs have topped £16bn.

The key findings were: 1 .6 million working people suffering from • a work-related illness 2,446 mesothelioma deaths due to past • asbestos exposures (2018) • 111 workers killed at work • 693,000 working people sustain an injury at work according to the Labour Force Survey 65,427 injuries to employees reported • under RIDDOR 38.8 million working days lost due to • work-related illness and workplace injury £16.2 billion estimated cost of injuries • and ill health from current working conditions (2018/19)

www.ciphe.org.uk

FRONTLINE

OUT OF THIS WORLD The International Space Station has been enabling crucial research for two decades Page 25

Exclusive

CIPHE backs police call for tougher landlord laws THE CIPHE has backed calls by one of the country’s top police chiefs for tougher regulation of housing providers.

West Midlands Chief Constable Dave Thompson said rogue landlords in his force’s area – including criminal gangs – were exploiting loopholes in the laws covering accommodation for vulnerable people.

As a result, unsafe housing and anti-social behaviour was having to be investigated by his officers.

Investigations have also established links between the landlords and organised crime including money laundering and tenants being used for modern slavery.

He told P&H Engineering: “They are absentee landlords, and vulnerable people are suffering as a result. Local authorities do not have the power to intervene – and they should.”

He added: “It is too easy to set up companies. When we investigate, names change overnight.”

His comments coincided with the

TWITTER TALK The CIPHE mounted a Christmas campaign to stop celebrations going down the drain @CIPHE #dinner may make your mouth water, there is an unsavoury side should the #fat, #oil and #grease (FOG) from cooking #block your #drains. Find out how to avoid a plumbing disaster this Christmas day with the latest advice from www.ciphe.org.uk

release of a report by the National Crime Agency which warned the housing industry remains a top target for international money launderers.

CIPHE chief executive officer Kevin Wellman has backed the chief constable’s call for change.

He said: “Anyone can establish a business regardless of relevant and supporting qualifications. This has allowed a small, but undesirable rogue operator culture to arise and lives are being put at risk.”

@WatersafeUK also wanted to educate the public on safety: What is #backflow, how can it make your #water supply unsafe and what can you do to prevent it? @WRAS_UK helped the public take on utility firms: Need to contact your local water company? @WatersafeUK have it covered with a quick and easy way of locating them and their contact details! Go to https://bit.ly/32BgRxy and select your region.

Our partners Air quality

POLLUTION SCHOOLGIRL VERDICT ‘LANDMARK’ FOR CAMPAIGNERS WORK TO IMPROVE AIR QUALITY is set to increase

following a landmark ruling by a coroner into the death of a schoolgirl.

South London coroner Philip Barlow ruled the death in 2013 of Ella Kissi-Debrah, aged 9, was due to acute respiratory failure due to exposure to pollution.

“Ella died of asthma contributed to by exposure to excessive air pollution,” he said.

The UK has a target for the annual average

www.ciphe.org.uk

concentration level of nitrogen dioxide not to exceed 40 micrograms per cubic metre. The UK has not met it in a decade.

Household emissions from boilers are among the biggest contributors to poor air quality.

London mayor Sadiq Khan said: “Toxic air pollution is a public health crisis.

Ministers and the previous Mayor have acted too slowly in the past, but they must now learn the lessons from the Coroner’s ruling.”

@WhichTraders were raising awareness of safety at home: “There’s never been a more important time to have a working carbon monoxide (CO) alarm in your home.”

And @IWSH_Foundation shared some wonderful news: Launching a new education and training collaboration with BORDA India this week, supporting plumbers in Leh, a city in the remote Himalayan district of Ladakh! https://bit. ly/36X7v4p

Breathe easy: see page 20

QUARTER ONE / 2021
