How to Use Orca Slicer

How to Use Orca Slicer: A Complete Guide Orca Slicer is a powerful and rapidly evolving open-source 3D slicing software based on Bambu Studio and PrusaSlicer. Whether you’re printing with Bambu Labs printers or third-party machines, Orca Slicer provides enhanced speed, control, and reliability.

This guide covers everything you need to know about using Orca Slicer—from installation to print-ready G-code.

✅ 1. What Is Orca Slicer?

Orca Slicer is a fork of Bambu Studio, tailored for advanced slicing control and customization.

It's loved for: ●​ Automatic calibration​ ●​ Arc and Pressure Advance support​ ●​ Input shaping and Klipper compatibility​ ●​ Broad third-party printer support​

🔧 2. Installing Orca Slicer Step 1: Download

👉

Go to the official website:​ https://orca-slicer.com/ Choose the appropriate installer for: ●​ Windows (.exe) ●​ macOS (.dmg) ●​ Linux (.AppImage)​

Step 2: Install ●​ Windows/macOS: Double-click the installer and follow instructions.​ ●​ Linux: Make the AppImage executable (chmod +x OrcaSlicer.AppImage) and launch.​

🔌 3. Setting Up Your Printer Step 1: Add a Printer When you launch Orca Slicer for the first time: ●​ Choose “Add New Printer.”​ ●​ Select from a pre-configured list (Bambu, Prusa, Creality, Voron, etc.).​ ●​ If not listed, choose “Custom FDM Printer” and manually enter:​ ○​ Build volume​ ○​ Nozzle diameter​ ○​ Heated bed options​ ○​ Firmware type (Klipper, Marlin, etc.)​

Step 2: Network Setup (Optional) If you have a Bambu printer or Klipper-based one: ●​ Enable Wi-Fi sync​ ●​ Add IP address or use QR scanning for Bambu Labs​

🎯 4. Loading and Preparing Your Model

Step 1: Import Model ●​ Click “Open File” or drag and drop a .stl or .3mf file into the workspace.​

Step 2: Model Placement Use the left-side toolbar: ●​ Move: Shift model on the bed​ ●​ Scale: Resize proportionally or independently​ ●​ Rotate: Align to the flat surface or reorient​ ●​ Mirror: Flip geometry​ ●​ Arrange: Auto-place multiple models efficiently​

⚙️ 5. Slicing Settings Overview Orca Slicer provides 3 main profiles: ●​ Standard: Balanced speed and quality​ ●​ High Speed: Fast with coarser layer heights​ ●​ High Quality: Slower, detailed layers​

You can further customize:

A. Print Settings ●​ Layer Height: Typically 0.2mm; lower for finer detail​ ●​ Perimeters: Wall strength—3 is common​ ●​ Infill: 15-20% grid or gyroid for general models​

B. Filament Settings ●​ Set temperature for nozzle and bed​ ●​ Adjust fan speeds and retraction based on filament type (PLA, ABS, PETG, etc.)​

C. Speed Settings Orca allows aggressive tuning: ●​ Wall speed: 40–60 mm/s​ ●​ Infill speed: 80–100 mm/s​ ●​ Travel speed: 150+ mm/s (depends on printer stability)​

🧠 6. Smart Features in Orca Slicer 🔁 Adaptive Layer Height

Automatically varies layer height for smooth surfaces and fast print times: ●​ Enable in Layer Height > Adaptive Mode​ ●​ Set min/max layer heights and thresholds​

🌀 Input Shaping & Pressure Advance For Klipper printers: ●​ Go to Printer > Firmware Settings​ ●​ Enable Input Shaping and Pressure Advance​ ●​ You can import calibration results or manually set the values​

🛑 Support Material

●​ Auto-generate supports under overhangs​ ●​ Customize support density, pattern, and Z-distance​ ●​ Use “Paint-on Supports” for fine-grained control​

🖨️ 7. Previewing Your Slice Once slicing is complete: ●​ Click the “Preview” tab​ ●​ Scroll through layers to inspect:​ ○​ Travel moves​ ○​ Infill patterns​ ○​ Support generation​ ○​ Flow rate (color-coded)​

You can spot potential issues here like missing supports, stringing zones, or thin wall failures.

📤 8. Exporting & Printing Method 1: Save to File ●​ Save G-code to SD card/USB​ ●​ Insert into printer​

Method 2: Upload Over Network ●​ For Bambu and Klipper printers:​

○​ Use “Send to Printer”​ ○​ Monitor print status live via Orca or integrated webcam (Klipper)​

Method 3: Send to OctoPrint or Fluidd ●​ Go to Printer Settings > Integrations​ ●​ Add your OctoPrint or Moonraker IP​ ●​ Authenticate and sync directly​

📚 9. Advanced Tools in Orca Slicer 🔄 Modifier Meshes

Want different settings in different parts of your model?

1.​ Right-click the model > Add Modifier​ 2.​ Choose Cylinder, Cube, or Custom STL​ 3.​ Apply custom speeds, temperatures, or infill just to that region​

✂️ Cut Objects ●​ Cut tall models for smaller printers​ ●​ Add dowel holes for easy assembly​ ●​ Export separate parts automatically​

🛑 Custom G-code Scripts Found under Printer Settings > Custom G-code ●​ Start G-code: Prime nozzle, auto-leveling​

●​ End G-code: Cooling, moving away​ ●​ Insert macros for advanced behaviors​

🧪 10. Calibration & Testing Tools ●​ Use Orca Slicer’s built-in calibration generator to tune:​ ○​ Flow rate​ ○​ Retraction​ ○​ PA & IS values (Klipper)​ ○​ Temperature towers​ ●​ Go to “Calibration” tab > Generate Test Prints​

💡 11. Tips & Best Practices ●​ Use 3MF format for saving projects—it preserves print profiles and modifiers.​ ●​ Print a Temp Tower for each filament brand.​ ●​ Keep firmware and Orca Slicer updated for bug fixes.​ ●​ Use "Arc Welder" plugin if using Marlin firmware to compress G-code.​ ●​ Always preview before printing, especially for custom supports and fine parts.​

🛠️ 12. Troubleshooting Common Issues Issue

Solution

Model not sticking

Increase bed temp or use brim/raft

Stringing

Enable retraction; dry filament

Bad overhangs

Lower speed; add support

Gaps in walls

Increase wall count or flow rate

Extruder clicking

Lower speed/temp; unclog nozzle

🧾 Conclusion Orca Slicer brings the speed of Bambu Studio and the versatility of PrusaSlicer into a single, powerful interface. Whether you're a beginner printing cute dragons or an engineer optimizing airflow ducts, Orca Slicer gives you full control.

✅ Beginners love it for its easy setup.​ 🎯 Pros love it for its modifier meshes, Klipper tuning, and slicing flexibility.

Once you learn how to harness its power, Orca Slicer becomes your most valuable 3D printing tool.
