FIGURE 6-1. HYDRAULIC DIAGRAM - AXLE LOCKOUT

ITEM PART NUMBER QTY DESCRIPTION REV

2791883 Ref HYDRAULIC DIAGRAM - AXLE LOCKOUT WITH SWIVEL 1 2220773 4 Fitting, 90 2 2220371 5 Fitting, Straight 3 2220582 1 Fitting, Straight 4 2220635 1 Fitting, Tee 5 2220609 1 Fitting, Reducer 6 2220385 1 Fitting, Tee 7 2220619 1 Fitting, Reducer 8 2750900 1 Hose 9 2751006 2 Hose 10 2751005 2 Hose 12 2751004 1 Hose 0100020 AR Sealant

FIGURE 6-1. HYDRAULIC DIAGRAM - AXLE LOCKOUT
