FIGURE 2-28. GENERATOR INSTALLATION (KOHLER) (OPTIONAL
ITEM PART NUMBER QTY
DESCRIPTION
0238925 Ref GENERATOR INSTALLATION (KOHLER) 1 2460011 1 Generator - Powermite 110 (Includes Item 20 also) 1 3580134 1 Pulley 1 7012558 1 Generator Assembly Only 1 7020108 4 Brush 1 7020109 4 Holder, Brush 1 7012513 4 Caps, Brush Holder 1 7012514 1 Fan 1 7020193 1 Cord, Power 1 7026199 1 Armature 1 7020110 1 End Bell, Front 1 7020111 1 End Bell, Rear 1 7020190 2 Bearing 2 0641508 2 Bolt 5/16in-18NC x 1in 3 4761500 2 Lockwasher 5/16in 4 0641506 1 Bolt 5/16in-18NC x 3/4in 5 4761500 1 Lockwasher 5/16in 6 4751500 1 Flatwasher 5/16in 7 0361610 1 Bracket (Lower) 8 0641508 1 Bolt 5/16in-18NC x 1in 9 4751500 1 Flatwasher 5/16in 10 4761500 1 Lockwasher 5/16in 11 3311501 1 Nut 5/16in-18NC 12 0901491 1 Bracket (Upper) 13 0641608 2 Bolt 3/8in-16NC x 1in 14 4751600 2 Flatwasher 3/8in 15 4761600 2 Lockwasher 3/8in 16 3311601 2 Nut 3/8in-16NC 18 2880408 1 Key 19 0480047 1 Belt 20 7003657 1 Box, Electrical (Supplied with Generator) Ref Note: Replacement 110V Control Box comes with 2 std
Receptacles p/n 4460190. Optional Industrial Twist Lock Receptacles p/n 4460027 must be ordered separately.
20 2420203 1 Voltmeter 20 4360542 1 Breaker, Circuit 20 4460190 2 Receptacle 20 2920162 1 Lamp 20 7020191 1 Switch, Toggle 20 3520028 1 Plug, Hole 21 0641406 2 Bolt 1/4in-20NC x 3/4in 22 4751400 2 Flatwasher 1/4in 23 4761400 2 Lockwasher 1/4in 24 3311401 2 Nut 1/4in-20NC 25 0901492 1 Bracket 26 3311401 3 Nut 1/4in-20NC 27 4761400 3 Lockwasher 1/4in 28 4300031 3 Stud (Welded on Parts)
REV
D
