FIGURE 8-3. DECAL INSTALLATION (AUSTRALIAN AND CE SPECS
ITEM PART NUMBER QTY
DESCRIPTION
Ref STANDARD DECAL INSTALLATIONS 0270398 Ref JLG Decals
REV
B
Ref CE Specs: 0275066 Ref Standard Decal Installations 400S with 230kg/500lb Capacity D 0275068 Ref Standard Decal Installations 400S with 340kg/750lbB
Capacity
D 0275067 Ref Standard Decal Installations 460SJ D Ref Australian Specs: 0275066 Ref Standard Decal Installations 400S with 230kg/500lb Capacity
(SN 0300096000 through 0300140364)
D 1001114404 Ref Standard Decal Installations 400S with 230kg/500lb Capacity
(SN 0300140365 through 0300203770)
C 0275068 Ref Standard Decal Installations 400S with 340kg/750lbB
Capacity (SN 0300096000 through 0300140365)
D 0275067 Ref Standard Decal Installations (460SJ SN 0300096000 through
0300140364)
D 1001114405 Ref Standard Decal Installations (460SJ SN 0300140365 through
0300203770)
D 1 1705921 1 Decal - Tipping/Electrocution (Platform) Options: 2 1705822 1 Decal - Electrocution/Safety Manual 3 1705961 3 Decal - Electrocution 4 1701518 3 Decal - Warning Crushing 7 Ref Decal - Model Designation Options: 7 1704472 2 Decal - Model Designation Model 400S 7 1704473 2 Decal - Model Designation Model 460SJ 8 1702861 2 Decal - JLG Lift (8in) 9 1702774 1 Decal - JLG Lift (3.5in) 10 1702773 1 Decal - JLG (5in) 12 1704277 3 Decal - Attach Lanyard Here 13 Ref Decal - Capacity Options: 13 1705978 1 Decal - Capacity 400S with 230kg/500lb Capacity 13 1706382 1 Decal - Capacity 400S with 340kg/750LB Capacity 13 1705978 1 Decal - Capacity 460SJ 14 Ref Decal - Capacity Options: 14 1705978 1 Decal - Capacity 400S with 230kg/500lb Capacity 14 1706382 1 Decal - Capacity 400S with 340kg/750LB Capacity 14 1705978 1 Decal - Capacity 460SJ 15 1705084 1 Decal - Sound Power Level 16 1701502 1 Decal - High Oil Level (SN 0300096000 through 0300128256) 17 1701503 1 Decal - Low Oil Level (SN 0300096000 through 0300128256) 18 1701504 2 Decal - Hydraulic Oil 20 See Note 1 Decal - Bar Code (Note: Not Available for Purchase) 21 Ref Decal - Patent Options: 21 1700584 1 Decal - Patent (SN 0300096000 through 0300161239) 21 Not Required 0 Decal - Patent (SN 0300161240 through 0300203770) 22 See Note 1 Nameplate - Serial Number (Note: Not Available for Purchase) 23 1701509 1 Decal - Manual 24 1702300 AR Decal - Tie Down 25 1701500 4 Decal - Lift 26 1701529 4 Decal - Arrow 27 3251242 1 Nameplate - 240V-50Hz
ITEM PART NUMBER QTY DESCRIPTION
28 0860520 1 Box, Manual Storage 29 1060279 1 Cable, Lanyard (SN 0300096000 through 0300181170) 30 0641408 1 Bolt 1/4in-20NC x 1in (SN 0300096000 through 0300181170) 31 4751400 AR Flatwasher 1/4in Regular 32 3311405 AR Locknut 1/4in-20NC 33 3820001 4 Rivet 34 1705828 1 Decal - Footswitch 35 Ref Decal - Maximum Tire Load Options: 35 Ref Decal - Maximum Tire Load (SN 0300096000 through
0300140364)
35 1706126 4 Decal - Maximum Tire Load 400S with 230kg/500lb Capacity 35 1704829 4 Decal - Maximum Tire Load 400S with 340kg/750LB Capacity 35 1704828 4 Decal - Maximum Tire Load 460SJ 35 Ref Decal - Maximum Tire Load (SN 0300140365 through
0300203770)
35 1706126 2 Decal - Maximum Tire Load 400S with 230kg/500lb Capacity 35 1704829 2 Decal - Maximum Tire Load 400S with 340kg/750LB Capacity 35 1704828 2 Decal - Maximum Tire Load 460SJ 36 1701505 1 Decal - Fuel 41 4420051 209 in/5.3m Decal - Warning Stripes 45 1701499 AR Decal - No Lift 46 Ref Decal - Lift Diagram Options: 46 1705276 1 Decal - Lift Diagram (SN 0300096000 through 0300096581) 46 1707031 1 Decal - Lift Diagram (SN 0300096582 through 0300161284) 46 1001145140 1 Decal - Lift Diagram (SN 0300161285 through 0300203770) 47 1704412 1 Decal - Hydraulic Oil Chart 49 1701691 4 Decal - No Step 50 1704726 4 Decal - Lock Latch 52 1704885 AR Decal - WWW.JLG.COM Options: 52 Ref Decal (SN 0300096000 through 0300173675) 52 Ref Decal (SN 0300173676 through 0300203770) 53 0641406 4 Bolt 1/4in-20NC x 3/4in 55 1001112551 1 Decal - Emergency Controls (Australian Spec Only) (SN
0300140365 through 0300203770)
1001160080 Ref ADDITIONAL DECAL COMPONENTS 253 1001125387 1 Decal - Emission Compliance 254 1001143852 1 Decal - Emission Compliance (Diesel) (SN 0300181170 through
