Install the JSS suction valve hose (26) the ° el bow (7) .

INST ALLA TION INSTRUCTIONS

90360329 JOYSTICK STEERING KIT WITH ST ANDARD HYDRAULIC STEERING

APPROXIMA INST ALLA TION TIME: 4.0 hours

Lec 90360330_EN Issue date October 2020 EN

90360329 - JOYSTICK STEERING KIT WITH ST ANDARD HYDRAULIC STEERING

CASE CONSTRUCTION

821G ZBAR EH, NEW CAB TIER2 821G ZBAR EH, NEW CAB TIER2 821G ZBAR EH, NEW CAB TIER2 821G ZBAR EH, NEW CAB TIER2 821G WHEEL LOADER ZBAR-EH, NEW CAB TIER4B 821G WHEEL LOADER ZBAR-EH, NEW CAB TIER4B 821G WHEEL LOADER ZBAR-EH, NEW CAB TIER4B 821G WHEEL LOADER ZBAR-EH, NEW CAB TIER4B 821G WHEEL LOADER XR-EH, NEW CAB TIER4B 821G WHEEL LOADER XR-EH, NEW CAB TIER4B 821G WHEEL LOADER XR-EH, NEW CAB TIER4B 821G WHEEL LOADER XR-EH, NEW CAB TIER4B 821G Wheel loader , T ier (final), standard linkage (ZB) 821G Wheel loader , T ier (final), standard linkage (ZB) 821G Wheel loader , T ier (final), standard linkage (ZB) 821G Wheel loader , T ier (final), standard linkage (ZB) 821G Wheel loader , T ier (final), XR linkage 821G Wheel loader , T ier (final), XR linkage 821G Wheel loader , T ier (final), XR linkage 821G Wheel loader , T ier (final), XR linkage

NEW HOLLAND CONSTRUCTION

W190D ZBAR EH, NEW CAB TIER2 W190D ZBAR EH, NEW CAB TIER2 W190D ZBAR EH, NEW CAB TIER2 W190D ZBAR EH, NEW CAB TIER2

1 - SAFETY INFORMA TION ###_2_###

Basic instructions - Important notice regarding equipment servicing

All repair and maintenance work listed in this manual must carried out only qualified dealership personnel, strictly complying with the instructions given, and using, whenever possible, the special tools.

Anyone who performs repair and maintenance operations without complying with the procedures provided herein shall responsible for any subsequent damages.

The manufacturer and all the organizations its distribution chain, including - without limitation national, regional, local dealers, reject any responsibility for damages caused parts and / components not approved the manufacturer , including those used for the servicing repair the product manufactured marketed the manufacturer . any case, warranty is given attributed the product manufactured marketed the manufacturer in case damages caused parts and / components not approved the manufacturer .

The information in this manual is - - date the date the publication. is the policy the manufacturer for continuous improvement. Some information could not updated due modifications a technical commercial type, changes the laws and regulations dif ferent countries.

case questions, refer your Sales and Service Networks.

Safety rules

W ARNING

A void injury! Always the following before lubricating, maintaining, servicing the machine.

Disengage all drives.

Engage parking brake.

Lower all attachments the ground, raise and engage all safety locks.

Shut off engine.

Remove key from key switch.

Switch off battery key , installed.

W ait for all machine movement stop. Failure comply could result death serious injury .

W0047A

W ARNING

Crushing hazard! Before performing service under the machine, park the machine a level surface, engage the parking brake, and stop the engine. Put blocks the front and rear the tires. Failure comply could result death serious injury .

W0350A

W ARNING

Heavy objects! Lift and handle all heavy components using lifting equipment with adequate capacity . Always support units parts with suitable slings hooks. Make sure the work area clear all bystanders. Failure comply could result death serious injury .

W0398A

W ARNING

Personal Protective Equipment (PPE) required. When assembling, operating, servicing the machine, wear protective clothing and PPE necessary for the particular procedure. Some PPE that may necessary includes protective shoes, eye and / face protection, hard hat, heavy gloves, filter mask, and hearing protection. Failure comply could result death serious injury .

W0353A
