Case Drott 40 Series E Crawler Excavator
Service Manual PDF
INSTANT DOWNLOAD LINK
We Offers manuals high quality images, diagrams, instructions to help you to operate, maintenance, diagnostic, and repair your truck. This document is printable, without restrictions, contains searchable text, bookmarks, crosslinks for easy navigation.
This professionally reproduced factory service manual contains the service procedures for the Case Drott 40 Series E (40E) crawler excavator. View the service manual on your computer or print off detailed service and maintenance as well as illustrations as needed.
Topic list:
GENERAL
General Specifications
Detailed Engine Specifications
Maintenance and Lubrication
Torque Charts
Noise Control
General Cleaning Instructions
Safety Rules
ENGINE (Case 504BDT or Detroit V71)
Engine Tune-Up
Exhaust System and Muffler
Cylinder Head, Valve Train and Camshaft
Cylinder Block, Sleeves, Piston and Rods
Crankshaft, Main Bearings, Flywheel and Oil Seals
Lubrication System
Air Cleaner
Pump Drive Plate
Cooling System
Engine Troubleshooting
Reconditioning Engine Cylinder Block
Turbocharger Failure Analysis
DETROIT DIESEL Series 71 ENGINE SHOP MANUAL
FUEL SYSTEM
Fuel System and Filters
Fuel Injection Pump
Fuel Tank, Fuel Lines, Fuel Storage and Engine Controls
Fuel Injectors
ELECTRICAL SYSTEM
Diagnosis, Tests and Checks
Wiring Harness
Battery Servicing and Testing
Starter and Starter Solenoid
Alternator
CRAWLER UNDERCARRIAGE
Troubleshooting
Track Chain and Shoes
Track Rollers, Carrier Rollers, Idlers and Sprockets
POWER TRAIN
Troubleshooting
Drive Motor Circuit and Lines
Drive Motor- Dual Speed
Drive Motor-Single Speed
Final Drive Transmission
BRAKE SYSTEMS
House Brake
Track Digging Brake
HYDRAULIC SYSTEM
Maintenance Service
Diagnostic Tests and Checks
Equipment Hydraulic Pump
Excavator Control Valves
Swing Motor Hydraulic Circuit, Swing Motor and Cross-Over Relief Valve
Hoist Hydraulic Circuit
Crowd Hydraulic Circuit
Tool Hydraulic Circuit
Leveler Hydraulic Circuit
Hydraulic Swivel
Power Sensing Valve
Hydraulic Cylinders
CHASSIS/MOUNTED EQUIPMENT
Troubleshooting
Controls and Linkages
Swing Gear Box
“E” Boom
“Y” Boom
Attachments
Turntable Leveler Assembly
Turntable, Bearing and Related Parts
Covers: Case Drott 40 Series E Crawler Excavators, S/N 6271140 & after 7/81-12/82
Pages: 1,321
Format: PDF
File size: 202mb
Compatibility: Windows/Mac/Tablet
Note: Instant digital download only – no printed copy or CD-ROM media.
