Link Belt Crane HTT-8675 II Service Manual

Page 1

                     

   

      


BoomRestExtension,R&I

Thisprocedurecoverstheremovalandinstallationof theboomrestextensions.Forremovalandinstallation oftheremainingboomrestcomponents,seeSM KeysheetArea01---001.

Removal

1.Lower,detach,andsecureload,asrequired.

2.Stabilizethecraneforserviceasfollows:

a.Parkthecraneoutofthewayonafirmandlevel surface.

b.Engagetheparkbrakeand/orproperlyblock thetires.

c.Engagetheswingparkbrakeortravelswing lock,asrequired.

d.Levelthecraneonfullyextendedoutriggers.

e.Fullyretractandlowertheboomovertherear ofthecarrier.

3.Shutdowntheengineanddisengagethemainhydraulicpump.

WARNING

Solventsandcleaningsolutionscanbe hazardous.Seriouspersonalinjurymay resultfrommisuseoftheseproducts.Read andfollowallthemanufacturer’s recommendationsconcerningsolventsand cleaningsolutions.

4.Thoroughlycleanareatobedisassembledwithan approvedcleaningsolvent.Allowtheareatoair dry.

RefertoFigure1.

5.Removethecapscrews,washers,andlocknuts(1).

6.Separatethelocatorcap(2)fromtheboomrest extension(3).

7.Supporttheboomrestextension(3),andremove thecapscrews,washers,andlocknuts(4).

8.Removetheboomrestextension(3)fromthepivot assembly(5).

9.RepeatSteps5thru8fortheremovaloftheoppositeboomrestextension(3),asrequired.

ServiceManual 0505 SM01---001---008.00 1of2
Figure1 BoomRestExtensions 1.Capscrews,Washers,&Locknuts 2.LocatorCaps
1 2 3 4 F2PrefixL8PrefixN3Prefix 1 2 3 4 1 2 3 4 5 5 5 16.24” (41.25cm) 17.00” (43.18cm) 16.75” (42.55cm)
3.BoomRestExtensions 4.Capscrews,Washers,&Locknuts 5.PivotAssembly
