HARISH RAGHAVENDAR S
HARISH RAGHAVENDAR S
JUNIOR ARCHITECT
“The architect must be a prophet... if he can't see at least ten years ahead, don't call him an architect.” Frank Lloyd Wright. This quote embodies my aspirations and serves as a guiding principle for my architectural journey. I envision the next phase of my life, including pursuing a master's degree, as a pivotal step toward shaping the future of the built environment .
+91-9080522822
H E A L T H C A R E C A N O P Y C O V E I N T E R N S H I P F R E E L A N C E
COMMUNITY HEALTH CENTRE
COMMUNITY HEALTH CENTRE
“Community Health Centre located in Thirumalisai, designed on a site spanning 4,431 sqm, with a built-up area of 1,400 sqm. The design adheres to hospital planning standards, incorporating sanitary corridors and space optimization. The spatial layout is based on the triage concept to ensure efficient patient flow and functional zoning.”`
The design integrates the exploration of diverse materials and innovative architectural forms to optimize thermal performance and enhance passive cooling strategies, effectively reducing heat gain within the building. Additionally, the use of biophilic design elements, natural lighting, and spatial configurations aims to foster a calming environment, promoting psychological well-being and improving the mental health of patients and visitors.
Based on the study and analyses, there are several factors which contribute to energy consumption in the building, including:
*Building orientation *Window shade *Window-to-wall ratio*Window glass*Wall construction*Roof construction*Lighting efficiency
-These energy consumption factors can be reduced by using appropriate technology for designing the building envelope, which plays an important role in the consumption of energy in the building. It is concluded from the simulation results that by proper use of shading devices and window glass help in the reduction of energy consumption wherein the roof construction showed less energy benefits.
SECTION SUN HEAT ANALYSIS CONCEPT
EGG-CRATE LOUVERS DESIGN CAN PROVIDE EFFECTIVE SHADING TO WINDOWS COMPARED WITH HORIZONTAL PROJECTION.THEY PROVIDE LOW THERMAL TRANSMITTANCE AND A EFFECTIVE SHADING COEFFICIENT.
ANALYSIS
-The analysis done during the study highlights the importance of reducing the heat gain through the building envelope and improving the thermal comfort level and energy efficiency in residential buildings in Chennai.
-The simulation results show the possible façade design that can efficiently control the amount of insolation, maintain a satisfactory quality of indoor environment, contribute to the reduction in energy demand, and at the same time support and consolidate the architectural vision.
ANALYSIS ZONE LOAD SUMMARY
CONCEPT
EGG -CRATE:
EGG-CRATE LOUVERS DESIGN CAN PROVIDE EFFECTIVE SHADING TO WINDOWS COMPARED WITH HORIZONTAL PROJECTION. THEY PROVIDE LOW THERMAL TRANSMITTANCE AND A EFFECTIVE SHADING COEFFICIENT.
CANOPY COVE RETREAT
ISLAND RESORT
ISLAND NAME: GUNDU ISLAND
TOTAL SITE AREA: 6 ACER
PROJECT NAME: CANOPY COVE RESORT
AREA STATEMENT
PERMISSIBLE FSI-2.5
PERMISSIBLE PLOT COVERAGE IN LAND-40%[9712 SQ.M]
TOTAL BUILT UP AREA IN LAND-8800SQ.M
TOTAL BUILD UP AREA IN WATER-5500SQ.M
CRZ-II
An island resort project is a compelling endeavor due to its potential to offer unique, serene, and exclusive experiences in a naturally beautiful setting. It provides substantial economic benefits, opportunities for environmental stewardship, cultural preservation, and innovative design. Additionally, it meets the growing market demand for luxury and wellness tourism, contributing to the sustainable development of the tourism industry.
The Island Resort - Canopy Cove is a meticulously designed retreat that harmoniously blends private, semi-private, and public spaces to cater to diverse user needs. The layout is thoughtfully planned to provide a seamless balance between adventurous activities and tranquil environments, ensuring an inclusive experience for visitors of all age groups.
Strategically zoned areas accommodate a range of functions, from exclusive private villas and semi-private relavxation zones to dynamic public spaces, promoting interaction while preserving privacy where needed. The resort integrates active zones for adventure sports such as snorkeling, kayaking, and zip-lining with passive recreation areas, offering serene settings for yoga, meditation, and leisure. The incorporation of adaptive spatial planning and sustainable design principles ensures that Canopy Cove not only delivers a luxurious and enjoyable experience but also minimizes environmental impact.
THE CANOPY ADMIN
The entrance to the resort, aptly named The Canopy, serves as an architectural centerpiece and a gateway to the immersive experience of Canopy Cove. This grandiose structure is designed to evoke a sense of awe, with its monumental scale and dynamic form, drawing inspiration from cinematic visuals akin to the iconic “boat entering a building” scene in Spy Kids. The Canopy s dramatic design establishes a memorable first impression, symbolizing a seamless blend of architecture and nature.
Structurally, the entrance is supported by a large-span space frame system, chosen for its ability to cover expansive areas with minimal intermediate supports while maintaining structural integrity and stability. The primary material utilized is bamboo, strategically selected for its lightweight properties, tensile strength, and sustainability, reducing the overall structural load and environmental footprint. The innovative use of bamboo, combined with the precision-engineered space frame, creates a harmonious interplay of natural materials and modern construction techniques, setting the tone for the resort s eco-conscious design philosophy.
MATERIAL PALATE
MANTIS RAY
FLOATING RESTAURANT
The Mantis Ray is a cutting-edge floating restaurant, exemplifying innovation in design and engineering while enhancing the experiential and architectural appeal of the resort. As a semi-public dining space, it offers a distinctive feature for guests, with a seating capacity of 150, providing a unique blend of functionality, luxury, and sustainability.
MASTER SECTION
The restaurant is supported by EPS foam blocks a lightweight, buoyant material that ensures stability and floatation. These blocks are reinforced by RCC piers, which anchor the structure securely to the island's seabed, providing resistance against tidal forces and enhancing overall durability. To maintain precise positioning and mitigate lateral movement, the Mantis Ray employs a vertical gyroscopic guidance pole, a state-of-the-art system that stabilizes the structure while allowing flexibility to adapt to dynamic water conditions.
WEAVERS CABIN
TREE HOUSE TYPE
The cabin is accessed via a suspended bridge running from the ground to the treetop structure. The bird nests enveloping the glass-clad cabin vary in size according to bird types. The dark interior directs the guests' attention outwards, and a roof terrace allows for panoramic views of the forest.
BOAY CABINS
FLOTING HOUSE TYPE
FLOOD LEVELS, FREEBOARD AND FETCH
A. Considering the normal operating level, the high water level, the 1 in 100 year flood level and the deck height of the jetty to determine the risk and likelihood of hydrostatic forces and inundation.
B. If inundation is likely, the jetty shall be designed to withstand uplift, inundation and submergence.
Pontoon-Type Structures:
These are generally found in streams, lakes, and still water sources.
Pontoon type structures have a simple box structure and have high stability, low manufacturing cost and easy maintenance and repair. The houseboats, floating neighbourhoods and built on usually the still water bodies come under this category.
WATER HAVEN
SWIMMING POOL
The swimming pool area is designed to offer a multifaceted adventure experience, where people of various age groups can enjoy it.
Starting at the LOWEST LEVEL is the CHILDREN'S AREA, featuring shallow waters and interactive play elements designed for safety and enjoyment of young guests.
The design incorporates gentle slopes and graduated depth transitions, ensuring accessibility and comfort for children.
Ascending to the next level, the mid bay serves as a relaxation zone with a serene atmosphere.
Architecturally, this section is characterized by a spacious design with sun bath areas,
. Here, guests can unwind and enjoy refreshments from the ADJACENT BAR, strategically placed to offer panoramie views of the surrounding landscape or ocean vista.
At the PINNACLE OF THE POOL COMPLEX LIES THE INFINITY POOL, showcasing architectural excellence with its seamless edge design that visually merges with the horizon.
Throughout the pool area, architectural lighting plays a crucial role,
GREEN WATERS
APPARTMENT COMPLEX
A COUNTY OF BLISSFUL LIVING NESTLED IN THE HEART OF A SERENE SETTING, DR GREEN WATERS IS AN APARTMENT PROJECT THAT IS WARM AND WELCOMING AT GUNJUR, BENGALURU, KARNATAKA. THIS PREMIUM APARTMENT AT GUNJUR EMBRACES THE LUSH GREENERY, AND OFFERS A TRANQUIL OASIS AWAY FROM THE HUSTLE.
WITH ITS THOUGHTFULLY DESIGNED ARCHITECTURE AND MODERN AMENITIES, DR GREEN WATERS PROMISES COMFORTABLE AND LUXURIOUS APARTMENTS FOR SALE.
WHETHER YOU SEEK A PEACEFUL RETREAT OR A VIBRANT COMMUNITY, THIS APARTMENT PROJECT CATERS TO DIVERSE LIFE-STYLES. EMBRACE THE HARMONIOUS BLEND OF NATURE AND URBAN LIVING AT DR GREEN WATERS AT GUNJUR, BANGALORE, WHERE YOU CAN CREATE CHERISHED MEMORIES AND FIND SOLACE.
CLUB HOUSE
SETTING NEW HEIGHTS IN REAL ESTATE
DSR GROUP IS ONE OF THE TOP BUILDERS IN SOUTH INDIA NAMELY, BENGALURU, HYDERABAD AND CHENNAI. IT WAS ESTABLISHED IN 1988 WITH THE VISION OF TRANSFORMING THE REAL ESTATE INDUSTRY. TODAY, DR GROUP S REPERTOIRE HAS A WIDE ARRAY OF EXCLUSIVE REAL ESTATE PROJECTS SUCH AS, VILLAS,
LUXURY HOMES, GATED COMMUNITIES, CORPORATE OFFICES AND MANY MORE. EACH OF ITS PROPERTIES IS DESIGNED TO PERFECTION BY A TEAM OF WELL SKILLED ARCHITECTS AND CONSTRUCTED TO LAFF GENERATIONS.
In the DSR project, I took the lead in 3D modeling the clubhouse, designed as the focal point of the residential complex. The design strategy involved dynamic height manipulation, creating a visually striking and modern and cohesive visual identity to the clubhouse while functioning as sun-shading devices.
The first-floor cantilever extends boldly over the ground-level swimming pool, not only maximizing usable space but also providing a shaded area that enhances the poolside experience.
To optimize both aesthetics and performance, I integrated vertical fins along the building s façade. These fins serve a dual purpose: they act as architectural elements that lend a modern and cohesive visual identity to the clubhouse while functioning as sun-shading devices.
SWIMMING DRESSING AREA
APARNA
During my work on Aparna Residency, I was extensively involved in the preparation of construction drawings and Good for Construction (GFC) drawings, ensuring clarity and precision for seamless execution on-site. This included detailed coordination of toilet layouts, where I developed comprehensive plans and sections, specifying fixture placements, drainage slopes, waterproofing layers, and tile patterns to maintain functionality and aesthetic standards. Additionally, I focused on joinery details, preparing meticulous drawings for door and window assemblies that addressed material specifications, frame dimensions, and installation techniques.
. This hands-on involvement not only strengthened my technical drawing skills but also enhanced my understanding of construction workflows and on-site problem-solving, contributing to the project s overall success.
CHENNAI HYDROMATICS
OFFICE SPACE
The Chennai Hydromatic office space in Iyapakkam, Chennai, was meticulously designed to meet the specific requirements of the client, Mr. Sudharshan. The project began with an in-depth understanding of the client s needs, which informed the planning process. The design was then developed in Revit, ensuring precise and efficient 3D modeling for seamless visualization and coordination.
The design featured an optimized layout tailored for functionality and aesthetics, aligning with the client s vision. High-quality renders were created in Lumion, providing realistic visualizations that guided design decisions and helped the client envision the final outcome.
JAIKUMAR RESIDENCE
RESIDENCE PROJECT
The residential elevation project for Mr. Jaikumar, located in Avadi, Chennai, was designed to reflect the client s vision of a striking and modern façade. Following extensive discussions and a thorough trend and user analysis, the elevation was conceptualized to combine aesthetic appeal with functionality.
The design features a CNC-cut pattern that adds a contemporary and artistic touch, complemented by exposed brickwork, which introduces a sense of warmth and timelessness to the structure. Extended roof slabs were incorporated to enhance the architectural character while providing practical benefits such as shade and protection from the elements.
This carefully curated design balances modern trends with the client s preferences, resulting in a façade that stands out while seamlessly integrating into its surroundings. The elevation not only meets the client s expectations but also adds a unique identity to the residence.
OG’Z CAFE
CAFE PROJECT
OG'Z Café stands out as a remarkable project, not only for its unique design but also for its rapid execution. The entire process, from design to construction and interior work, was completed within an impressive timeframe designed in just 2 days, constructed in 20 days, and opened on the 25th day. This fast-paced project was overseen by me, managing every stage with precision, from planning and construction to the intricate interior details.
The café was designed with a classy aesthetic, blending natural and modern elements to create a warm and inviting ambiance. The interiors feature wooden textures paired with veneer flooring, which adds sophistication and durability. Careful attention was given to every detail, including the selection of paint finishes and furniture, ensuring a cohesive design language that aligns with the client s vision.
Despite the tight timeline, the project was executed flawlessly, with the final outcome exceeding expectations. The café s stylish design, comfortable interiors, and attention to detail left the client highly satisfied, making it a standout addition to the local dining scene. This project not only showcases my ability to deliver under pressure but also highlights my expertise in blending design creativity with practical execution, resulting in a space that is both functional and visually appealing.
SQUZO ANNA NAGR
ICE CAFE PROJECT
SCUZO, a live popsicle-making café, is located in the bustling area of Anna Nagar, Chennai, occupying a compact 450 sqft space on the first floor. The limited area posed a significant challenge, especially during the furniture arrangement and interior planning stages, requiring careful consideration to maximize functionality while maintaining aesthetic appeal. Collaborating with the interior design team demanded seamless coordination to align their creative input with the practical layout requirements. This process involved intense brainstorming sessions and rapid adjustments to ensure every detail was executed perfectly within the two-day planning phase.
The primary challenge was to create an inviting and efficient design that accommodated the café's live production setup without compromising on customer comfort. Balancing the client s vision of a trendy yet functional space with the constraints of the area required innovative solutions. From custom-designed furniture to strategic placement of equipment, every element was meticulously planned.
Despite the tight timeline and spatial constraints, constant communication and flexibility among the teams ensured a cohesive design outcome. SCUZO not only showcases my ability to navigate design complexities and team dynamics but also highlights the importance of collaboration and adaptability in delivering a successful project.
