Technical data Ecorium Floating Floors Ecorium Fix Glue Down Tiles Level of use Standard Unit Residential EN ISO 10874 Class 23 23 Commercial EN ISO 10874 Class 31 31 General Properties Standard Unit Dimensions EN ISO 24342 mm 1164x300 ±0.1% 600x450 ±0.2% Thickness EN ISO 24346 mm 9,5 ±0.2 4 ±0.15 Squareness EN ISO 24342 mm < 0.3 < 0.4 Straightness EN ISO 24342 mm < 0.2 < 0.3 Mass per unit area EN ISO 23997 g/m2 8400 ±10% 3400 ±10% Flatness of the panel Length concave/convex Width concave/convex EN ISO 20326 % < 0.1 / 0.5 < 0.05 / 0.1 Opening between panels EN ISO 20326 mm < 0.1 Height difference between panels EN ISO 20326 mm < 0.15 Locking strength Long / Short ISO 24334 kN/m >3 / >4 Thickness swelling ISO 24336 % < 15 Dimensional variation caused by changes in atmospheric humidity EN ISO 20326 % < 0.25 Residual indentation EN ISO 24343-1 mm < 0.25 EN ISO 23999 % ≤ 0.25 EN 12105 % ≤6 EN ISO 23999 mm EN 14354 Rev. Safety Properties Standard Unit Reaction to fire EN 13501-1 Class 254 8 007 7 Dimensional stability Curling 600 x 450 x 4 mm glue-down installation < 0,3 Moisture Content Wear resistance 1164 x 300 x 9.5 mm click installation ≤ |4| 2500 2500 Dfl-s1 Cfl-s1 Formaldehyde emission EN 717-2 Class E1 Slip resistance EN 14041 Class DS DS > 0.34 (R11) > 0.34 (R11) Sliding coefficient EN 13893 Coeff Additional Properties Standard Unit Thermal resistance EN 12667 m2.K/W 0.09 0,06 Thermal conductivity EN 12667 W/m.K 0.11 0.09 Impact noise reduction ΔLw EN ISO 10140-3 dB 17 14 Light fastness EN ISO 105-B02 blue scale 6 6 Scratch resistance EN 438-2 Scale Rating 2 Rating 2 Impact resistance (small ball) EN 438-2 N > 40 > 40 Other Features Installation system UNICLIC® Glue-down Finish AQUA2K+ AQUA2K+ FSC® certification FSC® certified available on request FSC® certified available on request VOC Emission Certifications Greenguard Gold; AgBB; A+ Greenguard Gold; AgBB; A+ Antibacterial protection CLEANSURFACE + CLEANCORK Powered by Microban® CLEANSURFACE Powered by Microban® Warranty (wear through) Years 10 Residential / 5 Commercial 10 Residential / 5 Commercial m2 (units) per carton m2 (un) 2.44 m2 (7) 5.94 m2 (22) m2 (cartons) per pallet m2 (un) 117.3 m2 (48) 261.4 m2 (44) Weight of cartons Kg 21 20 High-quality AQUA2K+ 2 component waterborne finish Swell-resistant HDFCORE fibreboard Genuine recycled leather 2 mm thickness Uniclic® click system for fast installation sound insulation, with Microban® antibacterial protection Industry’s leading UNICLIC click system for simple and fast installation. Floor or wall tiles for glue-down installation. HDFCORE low-swelling High Density Fibreboard. Very low emissions 2-component waterborne finish, based on polyurethane resins with high final hardness, great elasticity and excellent chemical resistance. Bevelling edges for aesthetic enhancement. Formaldehyde-free, PVC-free and phthalates-free cork agglomeration technology. Certification assuring that strict chemical emissions limits are met. FSC® C044061 Certified chainof-custody system, meeting the requirements of Forest Stewardship Council® standards. Attention Although every effort has been made to ensure accuracy during the production of this catalogue, GRANORTE disclaims potential product changes and possible print errors. The product photos may not accurately match the real colour and texture of the finished product. CleanCork underlay for thermal and 7 High-density natural cork composite International symbol used to identify products made with genuine cork. ECORIUM floor and wall coverings are made with high quality, natural materials and should be handled accordingly. In spite of all due care given during manufacturing, there will be variations in appearance (colour, gloss, and texture). This should be verified before installation, distributing the planks/tiles in a way that variations are not striking. Leather surface may change colour when exposed to sunlight over long periods of time. ECORIUM products are easy to maintain. However, it requires continuous and proper cleaning and care so that the surface protection and the attractive appearance of the product are maintained. Micro-bevelled edges European certification for safety and energy-saving performance. FSC® certified products are available upon request. Integrated antibacterial protection, powered by exclusive Microban® technology. Limited wear through warranty of 10 years (Residential) or 5 years (Commercial), under normal residential or commercial use and with proper care and maintenance. Level of use: Residential 23 Level of use: Commercial 31
