STORAGE
F
SQUARE BIN STORAGE
O
Supplying the feed and food industry
by Cimbria A/S, Denmark nce again Cimbria had a busy year with many interesting square silo installations around the world. Also, on the Scandinavian market, there has been increased activities and enterprise, and Cimbria has supplied a number of square silo constructions for the feed and food industry.
Silo facilities for fish feed at Cargill, Norway
At the EWOS fish feed factory at Bergeneset in Norway, which now belongs to Cargill, Cimbria supplied an installation of a new bulk silo for fish feed pellets. The site is situated in the very north of Norway, close to Tromsø in the town of Bergneset, where EWOS has one of its three production locations for fish feed in Norway. The plant consists of a square silo system with 27 silo cells. The silo has been raised with a steel deck being mounted at a height of approximately six m. below the deck, there is a flat storage area for storing big-bags.
98 | June 2018 - Milling and Grain
As the silo is designed for storage of fish feed pellets, the importance of gentle handling of the product has very high priority. After the feed pellets leave the production department, they are sifted on two sieves mounted in a tower above the silo. After the sieves, there are buffer bins and the pellets are transported from here to the storage bins by means of an X-Y robot-car moving along and across the silo deck on specially designed rails. Underneath the silo deck, reception bins with the same volume as the moving car are installed, thus enabling the bins to be emptied very fast. Emptying of the silo takes place by means of belt conveyors connected to the existing conveyor system running to the quay for loading onto ships. As the silo is installed so close to the sea, the silo walls and decks are manufactured as hot-dip galvanised in order to provide as much protection for the steel as possible. The parts for both the Marine Harvest and Cargill orders were delivered directly to the sites by ship from the port in Thisted.
Storage of coffee beans
Since its foundation in 1960, the Danish-based company BKI Kaffe A/S (Brazilian Coffee Import) has delivered quality coffee to Danish consumers, whilst in recent years exports to the rest of Scandinavia have increased significantly. Today, BKI roasts and packs coffee from all over the world at its high-tech coffee plant in Højbjerg near Aarhus, in Denmark. BKI is one of the biggest operators in the coffee market and is the only 100 percent Danish-owned coffee producer with production facilities in Denmark selling to the retail and food service sector. Food safety and quality are important at BKI, which aims to produce safe foodstuffs of high quality. The enterprise is certified and BKI’s employees receive ongoing training in food safety and quality. Recently, BKI Kaffe ordered an extension of its square silo installation. This involved 72 new silo cells with ancillary steel constructions and conveying equipment for integration with the
