1.Introduction to PU/ EPS Shortboard Repairs
2. Common Types of Damage
3. M aterials N eeded
4. Step - by- Step Repair Process
5. Preventative M aintenance
6. Conclusion
Welcome to our presentation on PU/EPS shortboard repairs. As a surfer, you know that your equipment is everything. A damaged board can mean the difference between catching the perfect wave and wiping out.
That's why it's crucial to know how to repair your
surfboard.
In this presentation, we'll cover the most common types
of damage that can occur to a PU/EPS shortboard, the materials needed for repairs, and a step-by-step process for fixing your board. We'll also discuss
preventative maintenance to keep your board in top
condition. By the end of this presentation, you'll have
the knowledge and skills to keep your surfboard in great shape.
The most common types of damage that can occur to a
PU/EPS shortboard are dings, cracks, and delamination.
Dings are small indentations or punctures in the board's
surface, caused by impact with hard objects such as
rocks or other surfboards. Cracks are more severe than
dings and can be caused by the same types of impacts,
but also by stress on the board from flexing or bending.
Delamination occurs when the layers of the board start
to separate, usually due to water damage or exposure to
extreme temperatures.
It is important to address these types of damage as soon
as possible, as they can weaken the structure of the board and lead to further damage if left untreated. In
addition to affecting the performance of the board,
unaddressed damage can also reduce its resale value.
Before we dive into the step-by-step process of repairing your surfboard, let's first go over the materials you'll need. The most essential item is the resin. This is what will hold everything together and make your board
watertight again. You'll also need hardener to mix with
the resin and create a chemical reaction that will cause it
to harden.
In addition to the resin and hardener, you'll need
fiberglass cloth or matting to reinforce the repair area.
Sandpaper is also necessary to rough up the surface and
ensure the resin adheres properly. A razor blade or utility
knife can be used to cut the fiberglass to size, and a
mixing cup and stir stick are required to mix the resin and hardener together. Lastly, masking tape and a
paintbrush will come in handy for applying the resin and
keeping it contained to the repair area.
Step 1: Clean the damaged area with acetone to remove any dirt, wax or debris. Use sandpaper to roughen the surface around the damage.
Step 2 : Apply a thin layer of resin to the damaged area and let it dry for 10-15 minutes. Repeat this step until
the damaged area is level with the surrounding surface.
Step 3 : Cut a piece of fiberglass cloth slightly larger
than the damaged area. Place the cloth over the
damaged area and saturate it with resin using a brush or
roller.
Step 4 : Once the cloth is fully saturated, use a squeegee
to remove any excess resin and air bubbles. Let it dry
for 24 hours.
Step 5 : Sand the repaired area with fine-grit sandpaper
until it is smooth and flush with the surrounding surface.
Step 6 : Apply a coat of wax to the repaired area
to protect it from w ater damage.
P r e v en t a t i v e Main t enance
To properly care for and maintain your surfboard, it's important to rinse it with fresh water after each use to
remove any salt or sand that could cause damage over
time. Additionally, store your board in a cool, dry place
out of direct sunlight and avoid exposing it to extreme
temperatures.
Regularly inspect your board for any signs of damage, such as cracks or dings, and address them promptly
before they worsen. Finally, consider investing in a board bag or cover to protect your surfboard during transportation and storage.
In conclusion, learning how to repair your surfboard is essential for any surfer. Not only does it save you money in the long run, but it also ensures that you can continue to enjoy your favorite hobby without
interruption. By taking the time to properly care for and maintain your equipment, you can prevent future
damage and extend the life of your surfboard.
Remember, prevention is key when it comes to surfboard repairs. By regularly inspecting your board for signs of damage and addressing any issues promptly, you can avoid more costly and time-consuming repairs down the line. So don't wait until it's too late - start taking care of your surfboard today!
