Architecture Portfolio

Gayatri Singh

About

Gayatri Singh (She/her) Architecture student

I am a fourth year architecture student pursuing my bachelor’s degree from Amity School of Architecture and Planning, Uttar Pradesh. Being a creative person, I’ve always looked to buildings for inspiration, and coming from the small village of Ranikhet fascinated me as to how they were able to use only wood, mud and stone to turn a place into a “home” and staying in a historic city like Delhi further stoked my passion in architecture.

My design process is always rooted in the original character of the site and its surroundings. This helps me create a grounded design that brings out the best of the intended space and keeps the design connected to its beginnings. Another design philosophy that I abide by is making inclusive spaces that act as a social condenser so that placemaking through community building can be achieved.

As a member of a design team I believe I can bring new insight to the discussion and work efficiently in order to not compromise with the quality of work regardless of a tight schedule. I would love to learn new things and gain real world experience so that i can be a better architect

CONTACT INFORMATION

Email: gayatri.jhijaria@gmail.com Phone no.: 9953771581

Curriculum Vitae

EDUCATION

Bachelor’s in Architecture (Batch 2019-2024)

Amity School Of Architecture & Planning Uttar Pradesh

Higher Secondary Education 2019 R.D. Rajpal Public School New Delhi

under Ar. Neha Prakash

COMPETETIONS

2018-2019 2019-2020 2020-2021 2021-2022 2021-2022

2019-2020

Top 10 shortlisted, Chokling Monastery Documentation

Louis I. Kahn Trophy

3rd Korea-India Friendship Quiz Winner Glazed Tiles, Restoration of Archaic Era Unknown Crafts Person Trophy

Top 24, Post-Pandemic Bus Terminal Annual Nasa Design Competetion Ply Split Braiding, Documentation and Product design Industrial Design Trophy

Top 24, Migrant Worker’s Mobile Housing Annual Nasa Design Competetion

RESEARCH

Designing multisensory spaces for enhancing museum experience.

Analysing the change in the architectural character of Mohallas in old Delhi. This paper aims at analyzing the changes that have taken place in the settlement of a mohalla throughout its existence, starting from the Mughal period to present times.

AUTOCAD SKETCHUP REVIT RHINO RHINO eQUEST ENSCAPE LUMION PHOTOSHOP ILLUSTRATOR INDESIGN PROCREATE CLIPART STUDIO SOFTWARE SKILL SKILLS Digital Illustration Architectural sketching Conceptualising Team coordination ELECTIVE COURSES

Building under

Conservation

Agenda

INTERESTS Travelling Character design Fashion Design Digital Art LANGUAGES Hindi (Fluent) English (Fluent) Drafting Modelling Simulations Visualisation Post Production

Intelligent

Dr. Bandana Jha Architecture

under Ar. Shubhru Gupta Brown and Green

06.

Exhibition Centre, Design Studio semester 4 Louis I. Kahn Trophy, 2019-2020 Annual Nasa Design Competetion, 2020-2021 01. 02. 05. 03.

Hospital Design, Design Studio semester 6 Mixed-Use Project, Design Studio semester 5

Working Drawings, Building Construction semester 6 Annual Nasa Design Competetion, 2021-2022 Industrial Design, 2021-2022 Miscellaneous 07. 08. 09. 10.

Exhibition Centre

4th Semester, Individual

Site Location: Dwarka Sec 25, Delhi

Site Area: 93,789.56 Sqm (23.17 Acres)

Brief:

The site is located near Indira Gndhi International Airport with efficient transport to the city. With that in mind the idea was to create an exhibition center that would help in the growth of the exhibition industry and aid in creating a central hub which would attract people from all around the world.

The site lies in Dwarka Sector 25, a sub-city located in South West Delhi district in India.

The site is accessible via 45M wide Urban Extension Road connecting NH 1,8 and 10 and service roads 18M wide and 24M wide.

Roof form:

The structure would be supported by space frames with an exterior cladding of metal cladding. The exhibition center has a higher height with admin block and Lobby having a lower height enhancing the experience of the stakeholders.

The metall cladding will also be made through recyled materials.

24M WIDE SERVICE ROAD

45M WIDE UER-II

CONCEPT

The aim of this exercise was to create a dynamic form that would compliment the site and act as an iconic structure attracting new investments and boost economic activity in the area.

Design strategies:

Long facades oriented towards north south for minimum heat gain.

The vehicular moment has been kept separate with service drop offs at the back.

With a naturally organic form it allows the space to be a multifunctional and due to the central foyer opening all the areas get direct ventialtion and light.

Form Development

PLANS

BLOCK A

BLOCK B

BLOCK C

12 SECTION ELEVATION

ELEVATION

ELEVATION C

A B C D

Mixed-Use Project

5th Semester, Individual

Site Location: Sector 96, Noida, Uttar Pradesh

Site Area: 62769.21 Sqm (15.5 Acres)

Brief:

The intent was to design a mixed use project according to the location and context of the region and based on that product mix was derived.

The aim was to enhance an area’s unique identity and development potential and to promote a sense of commuinty.

16 SITE CONTEXT

DESIGN CONFIGURATION

Vision: To design a hip establishment that will enhance economic development, spur placemaking, and improve connectivity and health of the community.

Retail Zone: Cultural Zone:

• Since the area is mostly residential and surrounded by colonies it would be reasonable to provide a retail section.

• Open space for temporary shops could be provided for Flea markets etc. to connect the shopper, the foodie and the small business.

• Cultural spaces have become social condensers: they are not discriminating, they are free and they offer free services like laboratories, books, presentations and access to the web, to the weakest bracket of the population.

• Such spaces can be provided to bring the communitytogether through inclusivity.

• Open theatres, library, art workshops and shops, community exhibition spaces where anyone can exhibit their work etc.

Entertainment Zone: Hospitality Zone:

• Providing an indoor and outdoor entertainment hub with a direct access for the hotel would make for an interesting dynamic.

• Indoor entertainment spaces like Movie theatres, Mystery rooms, Arcades, Balling bowl, and a sports center with activities like rock climbing, trampoline parks, ice rink, kids play area etc. that would be quite unique for Noida.

• These hotels will keep lodging simple, providing a place to stay on a budget with direct access to all of the amenities already available on site the guests will be able to enjoy a wide variety of activities.

• This will be the friendly neighborhood hotel offering comfort, efficiency, convenience and affordability to its millennial customers who are looking for premium features at budget prices.

Design strategies:

Retail block placed at the entrance to attract customers to site.

Entertainment block placed purposely at the back to strategically allow people to walk through the retail block to reach it.

Keeping the hotel near retail and cultural blocks allow for easy access to restaurants, shops and exhibitions that might be held in rhe cultural centre.

Providing a cultural centre to bring community building since near the site there are more abadi’s then residential apartments. This makes the site accessible not only to the rich and privileged but also to the people who might not be that financial well off, destroying the set hierarchy of mixed use developments that favours the rich.

CONCEPT

To create breathing spaces and visual connection inside and from the outside of the site.

To create air vacuums throughout the built form so as to create vertical ventilation making a shape mimicking a storage.

The atriums will also allow natural light to come in reducing the cost of lighting. Green roofs to be added to create a cooler microclimate throughout teh space.

LIVING GREEN SPONG

Roofing tiles made from waste of fabric dying facilities. These tiles have high water retention capacity.

AIR IN - HOT AIR OUT

COLD

RETAIL GROUND FLOOR PLAN

Category killer - 700sqm

Anchor store - 300 to 400sqm

Vanilla store - 100 to 200sqm

RETAIL FIRST FLOOR PLAN

Category killer - 700sqm

Anchor store - 300 to 400sqm

Vanilla store - 100 to 200sqm

Hyper Market - 400sqm

Specialty store - 300 to 400sqm

Category killer - 700sqm

Anchor store - 300 to 400sqm

Vanilla store - 100 to 200sqm

Hyper Market - 400sqm

Specialty store - 300 to 400sqm

Restaurant - 300 to 500sqm

Cafe - 300sqm

Bakery - 200sqm

20 liftlobby lobbylift lift lobby MALETOILET FEMALETOILET FIREEXIT STAIRCASE OPENTOSKY COURTYARD MALE TOILET TOILETFEMALE FIRE IRCASE OPENTO URTYARD MALETOILET FEMALEOILET FIREEXIT STAI ASE +600MM +600MM +600MM +600MM +600MM CATEGORY KILLER CATEGORY KILLER SPECISALTY STORE ANCHOR STORE SPECISALTY STORE SPECISALTY STORE ANCHORSTORE ANCHORSTORE VANILLA STORE VANILLA STORE VANILLA STORE VANILLA STORE VANILLA STORE VANILLA STORE VANILLA STORE VANILLA STORE VANILLA STORE VANILLA STORE VANILLA STORE VANILLA STORE VANILLA STORE VANILLA STORE SPECISALTY STORE VANILLA STORE MULTI

USE PROJECT ARCHITECTURAL DESIGN STUDIO - V GAYATRI,

A11904019013

PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION

ARCHITECTURAL

MULTI - USE PROJECT

DESIGN STUDIO - V GAYATRI, A11904019013

liftlobby lobbylift lift lobby MALETOILET FEMALETOILET STAIRCASE OPENTOSKY COURTYARD MALE TOILET TOILETFEMALE STAIRCASE OPEN COURTYARD MALETOILET FEMALETOILET STAIRCASE COURTYARD CATEGORY KILLER CATEGORY KILLER SPECIALTY STORE ANCHOR STORE SPECIALTY STORE ANCHORSTORE ANCHORSTORE VANILLA STORE VANILLA STORE VANILLA STORE VANILLA STORE VANILLA STORE VANILLA STORE VANILLA STORE VANILLA STORE SPECIALTY STORE VANILLA STORE ANCHOR STORE ANCHOR STORE HYPER MARKET VANILLA STORE VANILLA STORE STORAGE PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION MULTI - USE PROJECT ARCHITECTURAL DESIGN STUDIO - V GAYATRI, A11904019013 RETAIL FIRST FLOOR PLAN 1. Category killer - 700sqm 2. Anchor store - 300 to 400sqm 3. Vanilla store - 100 to 200sqm 4. Hyper Market - 400sqm 5. Specialty store - 300 to 400sqm 6. Food court - 800sqm 7. Eating hub - 650sqm 8. Restaurant/ Lounge Bar - 300 to 400sqm 9. Cafe - 300sqm 10. Tea shop - 200sqm liftlobby lobbylift lift lobby MALETOILET FEMALETOILET STAIRCASE OPENTOSKY COURTYARD MALE TOILET TOILETFEMALE STAIRCASE OPEN COURTYARD MALETOILET FEMALETOILET STAIRCASE CATEGORY KILLER SPECIALTY STORE ANCHORSTORE VANILLA STORE VANILLA STORE VANILLA STORE VANILLA STORE VANILLA STORE STORAGE VANILLA STORE VANILLA STORE VANILLA STORE CAFE TEASHOP LOUNGE ANCHOR STORE FOODCOURT FOOD CORNER FOOD CORNER FOOD CORNER FOOD CORNER FOOD CORNER FOOD CORNER FOOD CORNER FOOD CORNER FOOD CORNER FOOD CORNER FOOD CORNER FOOD CORNER OUTDOOR SPACE SPECIALTY STORE RESTAURANT VANILLA STORE VANILLA STORE CAFE SPECIALTY STORE CAFE KITCHEN FOOD CORNER FOOD CORNER FOOD CORNER FOOD CORNER CORNER FOOD CORNER FOOD CORNER EATINGHUB PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION MULTI - USE PROJECT ARCHITECTURAL DESIGN STUDIO - V GAYATRI, A11904019013 RETAIL SECOND FLOOR PLAN 1.

liftlobby lobbylift lift lobby MALETOILET FEMALETOILET STAIRCASE OPEN SKYCOURTYARD MALE TOILET TOILETFEMALE STAIRCASE SKYCOURTYARD MALETOILET FEMALETOILET STAIRCASE CATEGORY KILLER CATEGORY KILLER SPECIALTY STORE ANCHOR STORE SPECIALTY STORE ANCHORSTORE VANILLA STORE VANILLA STORE VANILLA STORE VANILLA STORE VANILLA STORE SPECIALTY STORE VANILLA STORE ANCHOR STORE STORAGE VANILLA STORE VANILLA STORE VANILLA STORE OPEN SEATINGBALCONY CAFE CAFE BAKERY RESTAURANT HYPER MARKET KITCHEN KITCHEN KITCHEN PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION RETAIL FLOOR PLANS

FRONT ELEVATION

SECTION

Hospital Design

6th Semester, Individual Brief: The intent of the project was to design a 100-bedded multi-specialty hospital which provides an atmosphere of healing and comfort to its occupants.

Site Location: Omicron Sector, Greater Noida Site Area: 14598 Sqm (3.6 Acres)

SITE PLAN

The building is oriented along the E-W axis to reduce heat gain.

All the living areas including IPD are also oriented Along the E-W axis.

Central courtyard acts as the core which divides the structures and allows the access of light to all the corridors.

The spaces are planned to allow maximum efficiency and seperated the public and staff/patient movements.

Creating terrace gardens along IPD floors to encourage healthy recreational activities.

VERTICAL ZONING Entrance Lobby OT Service floor ICU & NICU IPD IPD General Ward Obstetric Ward Admin OPD Blood Bank

strategies:

Design

CONCEPT

Humans find nature restorative and healing,By integrating nature throughout creating a forest like environment we introduce an holistic approach to healthcare.

Studies show that proper lighting within hospitals through controlling the bodies Circadian system, help to reduce depression amongst patients, decrease length of stay in hospitals and ease pain. Hence, excellent natural lighting throughout the hospital has been provided through courtyards.

Vision: To de stigmatize hospitals as rigid and unwelcoming spaces by re humanizing through stimulation of healing and therapeutic experiences.

Massing

with respect to the

Opening the space from the center to create courtyards for daylighting and ventilation.

Adjusting the shape according to vertical zoning hence creaing the emergency block.

Final massing of the structure with terrace gardens for recreational purposes.

25 IPD IPD ( Paediatric ward) Service floor Diagnostics (CATH & PATH) OPD

Form Development

26 SERVICE CORE CORRIDOR CORE RECEPTION BLEEDING AREA DOCTOR REST AREA BLOOD STORAGE REFRESHMENT AREA DONOR REST AREA RECORD ROOM STERLISATION SERIOLOGY COMPONENT LAB CATH LAB AHU STERLISATION ROOM STAFF ROOM COLLECTION URINE/STOOL MEETING ROOM ROOM SCRUB ROOM ROOM CLINICAL LAB SUB WAITING OT RECEPTION/ HELP DESK RECEPTION WAITING HEAD DOCTOR ROOM PROCEDURE UTILITY UTILITY NURSE CONTROL ROOM ANGIO ANGIO PATH LAB ROOM PRE OPERATION SCRUB DOCTOR DUTY OT 1 SCRUB AHU OT 2 SCRUB AHU OT 3 SCRUB AHU OT 4 STERILE STORE STERILE STORE STERILE STORE WASHING DISINFECTANT PACKING AREA DOCTOR LOUNGE/ REST AREA ISSUE COUNTER NURSE STATION ADMIN OFFICE CSSD METER ROOM X1 X2 X3 X4 X5 X6 X7 X8 Y10 Y9 Y8 Y7 Y6 Y5 Y4 Y3 Y2 Y11 Y12 POST OPERATION AHU DIRTY CORRIDOR CLEAN CORRIDOR TECHNICIAN (MALE) (FEMALE) (MALE) 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION RECEPTION TREATMENT ROOM STAFF STATION DRT UTILITY SLUICE ROOM CLEAN UTILITY TRIAGE OBSERVATION/ RECOVERY ROOM BOUGHT IN DEAD MINOR OT ECG FIRST AID WAITING CORRIDOR PSYCHIATRIST CLINIC OBSTETRIC CLINIC MEDICAL CLINIC PEDIATRIC CLINIC EXAMINATION ROOM CONSULTATION ROOM OPD RECEPTION COUNSELING ROOM EQUIPMENT ROOM WAITING AREA RECEPTION HELPDESK PHARMACY FOOD COURT GIFT SHOP COURTYARD GENERAL STORE FLORIST COURTYARD BANK ATM DENTAL CLINIC ORTHO-PAEDIC CLINIC FAMILY PLANNING CLINIC KIDS PLAY AREA X1 X2 X3 X4 X5 X6 X7 X8 Y10 Y9 Y8 Y7 Y6 Y5 Y4 Y3 Y2 Y11 RECORD ROOM SCRUB CONSULTATION ROOM CONSULTATION ROOM CONSULTATION ROOM KITCHEN AHU ROOM Y12 PHYSIOTHERAPY SERVICE CORE PATIENT CORE AHU AHU WAITING AREA PATIENT CORE PUBLIC TOILET (MALE) (FEMALE) PUBLIC TOILET (FEMALE) GROUND FLOOR PLAN 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 CORRIDOR CORE STERLISATION OT RECEPTION/ CHANGING ROOM PRE OPERATION SCRUB DOCTOR ROOM AHU OT 1 SCRUB AHU OT 2 SCRUB AHU OT 3 SCRUB AHU OT 4 STERILE STORE STERILE STORE STERILE STORE AND DOCTOR LOUNGE/ REST AREA NURSE STATION X1 X2 X3 X4 Y10 Y9 Y8 Y7 Y6 Y5 Y4 Y3 Y2 Y11 Y12 POST OPERATION AHU DIRTY CORRIDOR CLEAN CORRIDOR PUBLIC TOILET (MALE) (FEMALE) FIRST FLOOR PLAN 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION GROUND FLOOR PLAN Emergency OT Entrance Lobby CSSD OPD PATH lab Core Core Canteen Blood Bank Corridor CATH lab Corridor FIRST FLOOR PLAN

27 SECOND FLOOR PLAN (Service Floor) Admin Labour Room Obstetric Ward ICU Core Core NICU Pediatric Ward Corridor General Ward IPD Kitchen THIRD FLOOR PLAN CORRIDOR AHU METER X1 X2 X3 X4 X5 X6 X7 X8 Y10 Y9 Y8 Y7 Y6 Y5 Y4 Y3 Y2 Y11 Y12 SERVICE CORE CORE AHU AHU SECOND FLOOR PLAN (SERVICE FLOOR) TECHNICIAN ADMIN MEETING CHIEF CHIEF OFFICE PANTRY/KITCHEN STORAGE 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 CORRIDOR IPDRECEPTION NURSE STATION ICU TPA CONSUL. ROOM X1 X2 X3 X4 Y10 Y9 Y8 Y7 Y6 Y5 Y4 Y3 Y2 Y11 Y12 CORE AHU NURSE TWIN TWIN SHARING WARD TWIN SHARING WARD BED SHARING WARD 2 BED SHARING WARD 2 BED SHARING WARD NURSE WAITING MEETING ROOM TWIN SHARING WARD THIRD FLOOR PLAN 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION CORRIDOR IPDRECEPTION NURSE ICU PANTRY AHU METER HOUSEKEEPING LABOUR IPD KITCHEN FROZEN STORAGE TPA CONSUL. SUB WAITING X1 X2 X3 X4 X5 X6 X7 X8 Y10 Y9 Y8 Y7 Y6 Y5 Y4 Y3 Y2 Y11 Y12 SERVICE CORE CORE AHU STATION OBSTETRIC WARD STATION NURSE PEDIATRIC WARD NICU 6 BED SHARING WARD AHU TWIN SHARING TWIN SHARING WARD TWIN SHARING BED SHARING WARD 2 BED SHARING WARD 2 BED SHARING WARD 2 BED SHARING WARD WAITING MEETING DAYCARE (MALE) TOILET (FEMALE) TWIN SHARING WARD THIRD FLOOR PLAN 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION

28 CORRIDOR AHU TECHNICIAN HOUSEKEEPING STORE IPDHELPDESK CORRIDOR X1 X2 X3 X4 X5 X6 X7 X8 X1 X2 X3 X4 Y10 Y9 Y8 Y7 Y6 Y5 Y4 Y3 Y2 Y11 Y12 Y10 Y9 Y8 Y7 Y6 Y5 Y4 Y3 Y2 Y11 Y12 SERVICE CORE CORE AHU CORE AHU AHU NURSE NURSE CLINICAL SIDE ROOM SHARING WARD 4 BED SHARING WARD NURSE GENERAL WARD STATION SINGLE BED WARD SINGLE BED WARD SINGLE BED WARD SINGLE BED WARD SUB WAITING NURSE STATION NURSE STATION 6 BED SHARING WARD 4 BED SHARING WARD 4 BED SHARING WARD MRO METER ROOM ADMIN SUB WAITING WAITING SINGLE BED WARD IPDHELPDESK SUB WAITING (MALE) (FEMALE) (MALE) FOURTH FLOOR PLAN FIFTH FLOOR PLAN 17 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION AHU TECHNICIAN HOUSEKEEPING SERVICES DOCTOR DUTY ROOM CORRIDOR X1 X2 X3 X4 X5 X6 X7 X8 Y10 Y9 Y8 Y7 Y6 Y5 Y4 Y3 Y2 Y11 Y12 CORE CORE AHU ROOM NURSE STATION STATION 6 BED SHARING WARD 4 BED SHARING WARD 4 BED SHARING SINGLE BED WARD SINGLE BED WARD SINGLE BED WARD SINGLE BED WARD STATION BED SHARING WARD IPDHELPDESK SUB WAITING WAITING NURSE ROOM NURSE REST AREA STAFF LOUNGE (MALE) (FEMALE) 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION FOURTH FLOOR PLAN IPD Wards IPD Wards Clinical Side room Staff Lounge Admin Core Core Corridor Corridor FIFTH FLOOR PLAN

29 BASEMENT FLOOR PLAN 1 Diagnostics Mortuary Core Core Laundry BASEMENT FLOOR PLAN 2 MORTUARY SERVICE Y10 Y9 Y8 Y7 Y6 Y5 Y4 Y3 Y2 Y1 X1 X2 X3 X4 X5 X6 X7 X8 X9 Y11 Y12 Y13 ADMIN DOCTOR'S OFFICE RECORD ROOM CHEMICAL LAB AUTOPSY AND POSTMORTEM EQUIPMENT ROOM WAITING CT SCAN MRI RECEPTION WAITING CONTROL ROOM CONTROL ROOM CONTROL ROOM CHANGE AREA GENERAL XRAY CONTROL ROOM CHANGE AREA ULTRASOUND CONTROL ROOM CONTROL ROOM CHANGE AREA AREA ECO ROOM ECO ROOM CHANGE AREA CONTROL ROOM SPECIAL XRAY SUB WAITING TECHNICIAN ROOM RADIOLOGIST ROOM RECORD ROOM ASST. SERVICE CORE LAUNDRY MORTUARY SEWING CLOTHES PATIENT CORE PATIENT CORE BASEMENT FLOOR PLAN (B1) AHU 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 Y10 Y9 Y8 Y7 Y6 Y5 Y4 Y3 Y2 Y1 X1 X2 X3 X4 Y11 Y12 Y13 LOWER BASEMENT FLOOR 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION Y10 Y9 Y8 Y7 Y6 Y5 Y4 Y3 Y2 Y1 X1 X2 X3 X4 X5 X6 X7 X8 X9 Y11 Y12 Y13 CORE PATIENT CORE 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION

To create an organic form through interwoven pieces of sheer tensile fabric to cast a shadow and invoke feelings of peace, serenity, calm and hope for the patients.

Using PVC coated polyester fabric to protect the visual transparency and reduce the energy consumption.

FRONT ELEVATION

FACADE

SIDE ELEVATION

31 SECTION CONSULTATION ROOM OPD WAITING AREA WAITING AREA POST OPERATION FLASH STERLIZER WAITING AREA SCRUB WASHING AND STERLIZATION PATH LAB CLEAN UTILITY ICU PATIENT WARD DOCTOR DUTY ROOM NICU ASSIST TOILET SERVICE FLOOR SERVICE FLOOR CLEAN UTILITY GENERAL WARD PATIENT WARD DOCTOR 4 BED SHARING WARD ASSIST TOILET DOCTOR DUTY ROOM 4 BED SHARING WARD ASSIST TOILET COURTYARD RADIOLOGY WAITING AREA LVL 0 LVL +600 LVL +17400 LVL +21600 LVL +25800 LVL +13200 LVL +9000 LVL +4800 X1 X2 X3 X4 X5 X6 X7 X8 ECG WAITING COURTYARD X1 X2 X3 X4 X5 X6 X7 X8 Y9 Y8 Y7 Y6 Y5 Y4 WAITING AREA TEMPLE OF HEALING TEMPLE OF HEALING SECTION CONSULTATION ROOM OPD WAITING AREA WAITING AREA POST OPERATION STERLIZER WAITING AREA SCRUB WASHING AND STERLIZATION PATH LAB UTILITY ICU WARD ROOM NICU ASSIST TOILET SERVICE FLOOR SERVICE FLOOR CLEAN UTILITY GENERAL WARD PATIENT DUTY 4 BED SHARING WARD ASSIST TOILET DOCTOR 4 BED SHARING WARD ASSIST TOILET COURTYARD RADIOLOGY WAITING AREA LVL 0 LVL +600 LVL +17400 LVL +21600 LVL +25800 LVL +13200 LVL +9000 LVL +4800 X1 X2 X3 X4 X5 X6 X7 X8 X1 X2 X3 X4 X5 X6 X7 X8 Y9 Y5 Y4 WAITING AREA TEMPLE OF HEALING MULTI SPECIALTY HOSPITAL TEMPLE OF HEALING GAYATRI SINGH A1904019013 SECTION PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION

Louis I. Kahn Trophy

Top 10 shortlisted (2019-2020)

Brief Objective:

To document a place which is sacred in nature and also functions as an institute and or has another usage which in turn compliments the main sacred space in order to study, understand its architectural style, construction techniques & its cultural significance.

Documentation of Chokling Monastery in Bir, Himachal Pradesh

Personal Contribution:

- Decoding of brief and shortlisting of site.

- Primary documentation on site including sketching, measuring and photographing the site.

- Graphic design and stippling for the sheets.

Annual Nasa Design Competetion

Top 24 (2020-2021)

Post Pandemic Bus Terminal

Brief Objective:

To design a post pandemic bus terminal to de-stigmatize covid ridden public transportation and create a safe environment which people can use without fear.

Personal Contribution:

- Problem analysis.

- Site planning and zoning.

- Graphic design for the sheets and the poster.

- Design of activity mapping and its graphics.

Annual Nasa Design Competetion

Top 24 (2021-2022)

Migrant Workers Mobile Housing

Brief Objective:

To design a portable settlement for migrant constructiom workers for various terrains and weather which works as a solution for problems concerning their safety, security, privacy and a right to better living conditions.

Personal Contribution:

- Documentation and problem analysis.

- Mobile housing design and dismantling technology.

- Graphics and first sheet illustration.

- Further ideation regarding the construction materials required for the housing that would be easily affordable and acquired.

Industrial Design Trophy

Craft & Community documentation with Product design

Ply-Split Braiding

Brief Objective:

The aim of the trophy was to research any craft in the country, understand the process, the materials, and the community and based on this research to create a product that imbibes the values that the craft represents and yet creating an object/ range of objects which could represent Indian craft at international levels.

Personal Contribution:

- Coordinator hence planning, shortlisting craft, team management and communication.

- On site documentation, analysis and research.

- Product design and graphics for the sheets including the first sheet illustration.

- Further ideation regarding the material that can be used for further production of the product.

42 Working Drawings 6th Semester, Individual 25870 28236 LIVING ROOM (6100MM X 5200MM) ENTRANCE FOYER (3000MMX2500MM) STUDY (3000MMX3600MM) POWDER ROOM (1500MX2000M) COURTYARD (4000MMX3400MM) KITCHEN (3900MMX4000MM) BEDROOM 1 (4000MMX5600MM) BEDROOM 2 (4000MMX5600MM) DINING ROOM (6000MMX4000MM) TOILET 2 (2400MMX2300MM) VERANDA SWIMMING POOL (6MX12M) (19'-8''X39'-4'') KIDS POOL (2MX2M) (6'-7''X6'-7'') OUTDOOR BAR (2MX4M) (6'-10''X13'-2'') X7 X6 X5 X4 X3 X2 X1 Y1 Y2 Y3 Y4 Y5 Y6 Y7 NO. OF RISERS 20 TREAD 270MM [11''] LANDING 1000MM [3'- 5''] TOILET 1 (2400MMX2300MM) VERANDA LAUNDRY (1500MMX1700MM) GROUND FLOOR PLAN 1049 1473 1637 2100 4207 5762 2392 2503 2792 3708 4196 3900 2559 1721 1721 2559 1700 2815 2486 1180 D5 WALK IN CLOSET (1484MM X 2511MM) WALK IN CLOSET (1484MM X 2511MM) 208 764 996 1881 494 1083 620 2021 390 2021 748 494 1083 230 357 3914 230 3408 1060 3890 641 1325 1234 3414 230 230 230 230 512 3600 FFL -10MM 1500 5321 1500 9686 1500 UP SLOPING ROOF ABOVE RISER 150MM [6''] This drawing is the property of Amity school of Architecture & Planning, Noida DRG. NO. GFC/ARC/BLOCK-XXXX R E V S O N S REV. NO. NAME ARCHITECT BY THE CONTRACTOR OR PROJECT MANAGER BEFORE N.G.L. AS BENCHMARKED AT SITE NOTES 1. DRAWING AND DIMENSIONS ARE ONLY TO BE READ AND NOT SCALED. 3. THIS DRAWING SHALL BE READ IN CONJUNCTION WITH RELEVANT 4. ALL LEVELS GIVEN IN DRAWING ARE WITH REFERENCE TO THE 5. ANY DISCREPANCY BETWEEN THE ARCHITECTURAL/STRUCTURAL OR EXCECUTION OF THE SAME KEY PLAN G.F.C PURPOSE OF DRAWING F.I.O TENDER REMARKS NAME: ROLL NO.: FARMHOUSE GAYATRI SINGH SECTION: A1904019013 A SCALE FRAMING PLAN 1:100 NAME AMITY UNIVERSITY NOIDA CHATTARPUR DELHI PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION A A' B B' A B C D GROUND LVL ±0 LVL GROUND FLOOR LVL ±450 LVL FIRST FLOOR LVL +3600 LVL ROOF LVL +7600 LVL FRONT ELEVATION (A) X7 X6 X5 X4 X3 X2 X1 LINTEL LVL +2550 LVL LINTEL LVL +5700 LVL 5762 2392 2503 2792 3708 4196 2100 1050 2097 1903 LVL ±0 MM RAILING LVL +5450 LVL ± 0 MM - 4154 MM 2524 MM 1044 MM LOW VOC PAINT FINISH WOODEN KING POST ROOF GROUND LVL ±0 LVL GROUND FLOOR LVL +450 LVL FIRST FLOOR LVL ROOF LVL +7600 LVL BACK ELEVATION (B) X7 X6 X5 X4 X3 X2 X1 +2550 LVL LINTEL LVL +5700 LVL D5 5762 3708 5762 2792 2503 2392 2100 1050 2097 1903 LVL ±0 MM RAILING LVL ± 0 MM 3900 MM LOW VOC PAINT FINISH WOODEN KING POST ROOF GFC/ARC/BLOCK-XXXX R E V S O N S REV. NO. PROJECT DATE DESCRIPTION NAME MILIMETERS. NOTES 2. UNLESS OTHERWISE MENTIONED, ALL DIMENSIONS ARE GIVEN IN ARCHITECTURAL, STRUCTURAL, AND SERVICES DRAWINGS. SERVICES DRAWINGS MUST BE BROUGHT TO THE ATTENTION OF THE KEY PLAN PURPOSE OF DRAWING REMARKS NAME: ROLL NO.: FARMHOUSE GAYATRI SINGH SECTION: A1904019013 A SCALE ELEVATIONS 1:100 CLIENT NAME AMITY UNIVERSITY NOIDA CHATTARPUR DELHI PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION FAMILY LOUNGE (6100MM X 5200MM) X4 X3 X2 X1 Y1 Y2 Y3 Y4 Y5 Y6 Y7 25 15 FIRST FLOOR PLAN 1049 1473 1637 2100 4207 3900 2559 1721 2559 1721 D3 WALK IN CLOSET (1484MM X 2511MM) WALK IN CLOSET (1484MM X 2511MM) 494 1083 230 620 390 748 494 1198 230 230 230 2021 2021 3914 254 641 254 5762 2392 2503 2792 BEDROOM 3 (4000MMX5600MM) BEDROOM 4 (4000MMX5600MM) TOILET 4 (2400MMX2300MM) TOILET 3 (2400MMX2300MM) D2 D2 RISER 150MM [6''] PRODUCED BY AN AUTODESK PRODUCED BY AN AUTODESK STUDENT VERSION AUTODESK STUDENT VERSION Y7 Y6 Y5 Y4 Y3 Y2 Y1 1049 1473 1637 2100 4207 3900 ± 0 MM - 4190 MM -3990 MM 15586 MM SIDE ELEVATION (C) - 17158 MM Y2 Y1 4207 3900 SIDE ELEVATION (D) PRODUCED BY AN AUTODESK PRODUCED BY AN AUTODESK STUDENT VERSION AUTODESK STUDENT VERSION

43 28236 X7 X6 X5 TERRACE (11900MM X 4200MM) 230 230 230 3918 230 230 300 1635 3990 3900 4490 3708 4196 COURTYARD (4000MMX3400MM) W13 SLOPING ROOF KHURRA KHURRA 850 MM HIGH RAILING AS/DET. R E V S O N S REV. NO. DESCRIPTION NAME ARCHITECT BY THE CONTRACTOR OR PROJECT MANAGER BEFORE MILIMETERS. NOTES : 1. DRAWING AND DIMENSIONS ARE ONLY TO BE READ AND NOT SCALED. 3. THIS DRAWING SHALL BE READ IN CONJUNCTION WITH RELEVANT 4. ALL LEVELS GIVEN IN DRAWING ARE WITH REFERENCE TO THE 5. ANY DISCREPANCY BETWEEN THE ARCHITECTURAL/STRUCTURAL OR KEY PLAN G.F.C PURPOSE OF DRAWING F.I.O TENDER REMARKS NAME: ROLL NO.: FARMHOUSE GAYATRI SINGH SECTION: A1904019013 A SCALE FRAMING PLAN 1:100 NAME AMITY UNIVERSITY NOIDA LOCATION CHATTARPUR DELHI AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK PRODUCED BY AN AUTODESK STUDENT VERSION A A' B B' A B C D GROUND LVL GROUND FLOOR LVL +450 LVL FIRST FLOOR LVL +3600 LVL ROOF LVL LINTEL LVL LINTEL LVL +5700 LVL RAILING LVL +5450 LVL LOW VOC PAINT FINISH WOODEN KING POST ROOF GROUND LVL ±0 LVL GROUND FLOOR LVL +450 LVL FIRST FLOOR LVL +3600 LVL ROOF LVL LINTEL LVL LINTEL LVL +5700 LVL RAILING LVL +5450 LVL LOW VOC PAINT FINISH WOODEN KING POST ROOF ± 0 MM Y3 Y4 Y5 Y6 Y7 1049 1473 1637 2100 GFC/ARC/BLOCK-XXXX G.F.C R E V S O N S REV. NO. PROJECT DATE DESCRIPTION NAME ARCHITECT BY THE CONTRACTOR OR PROJECT MANAGER BEFORE MILIMETERS. NOTES : 2. UNLESS OTHERWISE MENTIONED, ALL DIMENSIONS ARE GIVEN IN ARCHITECTURAL, STRUCTURAL, AND SERVICES DRAWINGS. SERVICES DRAWINGS MUST BE BROUGHT TO THE ATTENTION OF THE KEY PLAN PURPOSE OF DRAWING REMARKS NAME: ROLL NO.: FARMHOUSE GAYATRI SINGH SECTION: A1904019013 A SCALE ELEVATIONS 1:100 CLIENT NAME AMITY UNIVERSITY NOIDA CHATTARPUR DELHI AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK PRODUCED BY AN AUTODESK STUDENT VERSION 2587 ROOF PLAN X7 X6 X5 X4 X3 X2 X1 Y1 Y2 Y3 Y4 Y5 Y6 Y7 1049 1473 1637 2100 4207 3900 5762 2392 2503 2792 3708 4196 TERRACE (11900MM X 4200MM) SWIMMING POOL (6MX12M) (19'-8''X39'-4'') KIDS POOL (2MX2M) (6'-7''X6'-7'') OUTDOOR BAR (2MX4M) (6'-10''X13'-2'') 3211 3251 3526 3484 7200 3115 3600 500 203 This drawing is the property of Amity school of Architecture & Planning, Noida DRG. NO. GFC/ARC/BLOCK-XXXX R E V S O N S REV. NO. NAME ARCHITECT BY THE CONTRACTOR OR PROJECT MANAGER BEFORE N.G.L. AS BENCHMARKED AT SITE NOTES 1. DRAWING AND DIMENSIONS ARE ONLY TO BE READ AND NOT SCALED. 3. THIS DRAWING SHALL BE READ IN CONJUNCTION WITH RELEVANT 4. ALL LEVELS GIVEN IN DRAWING ARE WITH REFERENCE TO THE 5. ANY DISCREPANCY BETWEEN THE ARCHITECTURAL/STRUCTURAL OR EXCECUTION OF THE SAME KEY PLAN G.F.C PURPOSE OF DRAWING F.I.O TENDER REMARKS NAME: ROLL NO.: FARMHOUSE GAYATRI SINGH SECTION: A1904019013 A SCALE FRAMING PLAN 1:100 NAME AMITY UNIVERSITY NOIDA CHATTARPUR DELHI PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION A A' B B' A B C D ROOF LVL X7 X6 X5 X4 X3 X2 X1 LINTEL LVL +5700 LVL 5762 2392 2503 2792 3708 4196 2100 1050 2100 1903 LVL +450MM GROUND LVL ±0 LVL GROUND FLOOR LVL +450 LVL FIRST FLOOR LVL +2550 LVL LVL +1950MM +5450 LVL 75 CERAMIC TILE SECTION AA' LIVING ROOM (6100MM 5200MM) LIVING ROOM (6100MM 5200MM) COURTYARD (4000MMX3400MM) TERRACE (11900MM X 4200MM) KITCHEN (3900MMX4000MM) BEDROOM 1 (4000MMX5600MM) BEDROOM 3 (4000MMX5600MM) 2100 COURTYARD (4000MMX3400MM) WOODEN KING POST TRUSS Y2 Y3 Y4 Y5 Y6 Y7 ROOF LVL +7600 LVL +5700 LVL GROUND LVL ±0 LVL GROUND FLOOR LVL +450 LVL FIRST FLOOR LVL +3600 LVL LINTEL LVL WALK IN CLOSET WALK IN CLOSET (1484MM X 2511MM) (1484MM X 2511MM) TOILET 2 (2400MMX2300MM) TOILET 1 TOILET 4 (2400MMX2300MM) TOILET 3 (2400MMX2300MM) 75 300 75 300 CERAMIC TILE 1637 4207 SECTION BB' V1 V1 75 300 75 300 WOODEN KING POST TRUSS GFC/ARC/BLOCK-XXXX R E V S O N S REV. NO. PROJECT DATE DESCRIPTION NAME MILIMETERS. NOTES 2. UNLESS OTHERWISE MENTIONED, ALL DIMENSIONS ARE GIVEN IN ARCHITECTURAL, STRUCTURAL, AND SERVICES DRAWINGS. SERVICES DRAWINGS MUST BE BROUGHT TO THE ATTENTION OF THE KEY PLAN PURPOSE OF DRAWING REMARKS NAME: ROLL NO.: FARMHOUSE GAYATRI SINGH SECTION: A1904019013 A SCALE SECTIONS 1:100 CLIENT NAME AMITY UNIVERSITY NOIDA CHATTARPUR DELHI PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION

LIVING ROOM (6.1MX5.2M) (20'-3''X17'-3'')

(12'-1O''X13'-3'')

DINING ROOM (6MX4M) (20'-2''X13'-3'')

44 X7 X6 Y1 Y2 TILE START 2300 600 3070 500 800 1070 PLAN A B C C' BAR STOOL S.O.P R.C.C SLAB 300 MM SUNKEN SLAB SKIRTING LOWER CABINET GAS STOVE WITH OVEN TILE START GLAZED CERAMIC TILE UPPER CABINET RANGE HOOD 3600 300 810 3598 600 330 730 300 75 953 1230 SECTION A S.O.P WOOD SHUTTER LAMINATION BOARD (25MM TH.) GLAZED TILES 30MM THICK MARBLE TOP (75 X 300MM) DEODAR WOOD SHUTTER PANNELED FLOOR FINISH TUBE LIGHT LAMINATION BOARD (25MM TH.) 1155 610 475 810 725 DETAIL

CC' R.C.C SLAB 300 MM SUNKEN SLAB SKIRTING LOWER CABINET KITCHEN ISLAND TILE START GLAZED CERAMIC TILE UPPER CABINET MARBLE FLOOR FINISH 3600 2100 810 600 75 300 1230 2620 330 610 730 300 SECTION

This drawing is the property of Amity school of Architecture & Planning, Noida DRG. NO. GFC/ARC/BLOCK-XXXX R E V S O N S REV. NO. NAME ARCHITECT BY THE CONTRACTOR OR PROJECT MANAGER BEFORE N.G.L. AS BENCHMARKED AT SITE NOTES 1. DRAWING AND DIMENSIONS ARE ONLY TO BE READ AND NOT SCALED. 3. THIS DRAWING SHALL BE READ IN CONJUNCTION WITH RELEVANT 4. ALL LEVELS GIVEN IN DRAWING ARE WITH REFERENCE TO THE 5. ANY DISCREPANCY BETWEEN THE ARCHITECTURAL/STRUCTURAL OR EXCECUTION OF THE SAME KEY PLAN G.F.C PURPOSE OF DRAWING F.I.O TENDER REMARKS NAME: ROLL NO.: FARMHOUSE GAYATRI SINGH SECTION: A1904019013 A SCALE KITCHEN DETAIL 1:100 NAME AMITY UNIVERSITY NOIDA CHATTARPUR DELHI PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION 36322

FOYER

ENTRANCE

(3MX2.5M) (10'-3''X8'-5'') STUDY (3MX3.6M) (9'-10''X12')

POWDER ROOM (1.5MX2M) (5'X6'-7'') COURTYARD (4MX3.4M) (13'-3''X11'-2'') KITCHEN (3.9MX4M)

BEDROOM 1 (4MX5.6M) (13'-3''X18'-5'') BEDROOM 2 (4MX5.6M) (13'-3''X18'-5'')

TOILET 2

UP DN 10 18 14 11 LVL +1950MM LVL +450MM TOILET 1

(8'X7'-10'')

GROUND FLOOR PLAN 2559 2511 2511 2557 G. G. TV TV G. TV G. CHANDELIER LIGHT POINT CEILING FAN EXHAUST FAN INDUSTRIAL SOCKET 16A SWITCH SOCKET (FOR GEYSER, LEGENDS FREEZER & WASHING MACHINE) POINT WIRING This drawing the property of Amity school of Architecture & Planning, Noida CHECKED DATE DEALT GFC/ARC/BLOCK-XXXX STATUS APPROVED R E V S O N S REV. NO. NAME ARCHITECT BY THE CONTRACTOR OR PROJECT MANAGER BEFORE NOTES 2. UNLESS OTHERWISE MENTIONED, ALL DIMENSIONS ARE GIVEN IN ARCHITECTURAL, STRUCTURAL, AND SERVICES DRAWINGS. EXCECUTION OF THE SAME KEY PLAN G.F.C PURPOSE OF DRAWING F.I.O REMARKS NAME: ROLL NO.: FARMHOUSE GAYATRI SINGH SECTION: A1904019013 A SCALE ELECTRICAL LAYOUT 1:100 NAME AMITY UNIVERSITY NOIDA LOCATION CHATTARPUR DELHI PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION D3 V1 FFL -10MM FFL -25MM Y5 Y6 Y7 X2 F.D. F.D. 4 TILE START F-01 500 500 1606 2444 1277 230 1198 1167 1318 500 PLAN S.O.P V1 FFL -10MM PLUMBING DETAIL 150 150 150 150 F-01 TAG 500X500 FLOOR TILES W-01 D3 V1 V1 F-01 F-01 W-01 W-01 D3 SECTIONAL ELEVATION 2 SECTIONAL ELEVATION 1 SECTIONAL 900 280 TILE START FFL -25MM 300 75 1066 TILE START SHOWER HEAD 2100 600 300 1535 600 2537 S.O.P PRODUCED BY AN AUTODESK PRODUCED BY AN AUTODESK STUDENT VERSION AUTODESK STUDENT VERSION FAMILY LOUNGE (6.1MX5.2M) (20'-3''X17'-3'') DN 22 26 10 18 14 BEDROOM 3 (4MX5.6M) (13'-3''X18'-5'') BEDROOM 4 (4MX5.6M) (13'-3''X18'-5'') TOILET 4 (2.4MX2.3M) (8'X7'-10'') TOILET 4 (2.4MX2.3M) (8'X7'-10'')

TV TV G. TV G. PRODUCED BY AN AUTODESK PRODUCED BY AN AUTODESK STUDENT VERSION AUTODESK STUDENT VERSION Working Drawings

(2.4MX2.3M) (8'X7'-10'') PORCH

(2.4MX2.3M)

PORCH LAUNDRY (1.5MX1.7M) (5'X5'-10'')

FIRST FLOOR PLAN

45 D3 V1 FFL -25MM 150 150 PIPE SCHEDULE OF PIPES 3 2 1 110 OD uPVC WASTE & VENT PIPE 110 OD uPVC SOIL & VENT PIPE DESCRIPTION 4 5 90 OD uPVC ANTI-SYPHONAGE PIPE DOMESTIC WATER SUPPLY D/N TAKE PIPE FLUSHING WATER SUPPLY D/N TAKE PIPE NO. MM ANTI SKID VITRIFIED TILES AS PER SELECTION FLOOR TILE SCHEDULE MODEL/MAKE LOCATION ALL TOILETS D3 V1 F-01 F-01 W-01 W-01 SECTIONAL ELEVATION 4 ELEVATION 3 TILE START SHOWER HEAD TILE START 600 2100 900 600 721 S.O.P R E V S O N S REV. NO. DESCRIPTION NAME ARCHITECT BY THE CONTRACTOR OR PROJECT MANAGER BEFORE MILIMETERS. NOTES : 1. DRAWING AND DIMENSIONS ARE ONLY TO BE READ AND NOT SCALED. 3. THIS DRAWING SHALL BE READ IN CONJUNCTION WITH RELEVANT 4. ALL LEVELS GIVEN IN DRAWING ARE WITH REFERENCE TO THE 5. ANY DISCREPANCY BETWEEN THE ARCHITECTURAL/STRUCTURAL OR KEY PLAN G.F.C PURPOSE OF DRAWING F.I.O TENDER REMARKS NAME: ROLL NO.: FARMHOUSE GAYATRI SINGH SECTION: A1904019013 A SCALE NAME AMITY UNIVERSITY NOIDA LOCATION CHATTARPUR DELHI TOILET DETAIL 1:30 AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK PRODUCED BY AN AUTODESK STUDENT VERSION 36322 34510 TERRACE (11.9MX4.2M) (39'-2''X14') COURTYARD (4MX3.4M) (13'-3''X11'-2'') CHANDELIER LIGHT POINT BULK HEAD 1X11W CFL FITTING CEILING FAN EXHAUST FAN 16A SWITCH SOCKET DESCRIPTION LEGENDS FREEZER & WASHING MACHINE) POINT WIRING GFC/ARC/BLOCK-XXXX G.F.C R E V S O N S REV. NO. DESCRIPTION NAME ARCHITECT BY THE CONTRACTOR OR PROJECT MANAGER BEFORE N.G.L. AS BENCHMARKED AT SITE NOTES 2. UNLESS OTHERWISE MENTIONED, ALL DIMENSIONS ARE GIVEN IN ARCHITECTURAL, STRUCTURAL, AND SERVICES DRAWINGS. 5. ANY DISCREPANCY BETWEEN THE ARCHITECTURAL/STRUCTURAL OR EXCECUTION OF THE SAME KEY PLAN : G.F.C PURPOSE OF DRAWING F.I.O TENDER REMARKS NAME: ROLL NO.: FARMHOUSE GAYATRI SINGH SECTION: A1904019013 A SCALE ELECTRICAL LAYOUT 1:100 NAME AMITY UNIVERSITY NOIDA LOCATION CHATTARPUR DELHI AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK PRODUCED BY AN AUTODESK STUDENT VERSION UP DN 1 2 3 4 5 6 7 8 9 10 19 18 17 16 15 14 13 12 11 20 LVL +1950MM NO. OF RISERS 20 TREAD 270MM [11''] RISER - 150MM [6''] WIDTH 1000MM [3'- 5''] W9 X3 X2 Y2 Y3 2300 1127 1030 270 PLAN 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 1000 300 1000 1000 LVL +1950MM LVL +450MM LVL +3600MM RAILING W9 WAIST BEAM 150 250 150 STRINGER BEAM I- SECTION LANDING 3150 1500 35MM TH. STEP FINISH TREAD SUPPORT GROUND FLOOR LVL +450 LVL HANDRAIL LVL +1600LVL LANDING LVL +1950 LVL FIRST FLOOR LVL +3600 LVL SECTION LGSF WALL PLYWOOD BOARD (4MM) GYPSUM BOARD (8MM) INSULATION PLYWOOD BOARD (4MM) GYPSUM BOARD (8MM) STEEL SECTION (100X50X2OMM & 3MM THICK) 160 230 250 LANDING DETAIL RISER TREAD DETAIL 150 270 50 RISER WEDGE PLATE 35MM TH. STEP FINISH WAIST BEAM 10 END PLATE (300X120X12MM) BOLTED WITH 8.8 GRADE This drawing is the property of Amity school of Architecture & Planning, Noida DRG. NO. GFC/ARC/BLOCK-XXXX R E V S O N S REV. NO. NAME ARCHITECT BY THE CONTRACTOR OR PROJECT MANAGER BEFORE N.G.L. AS BENCHMARKED AT SITE NOTES 1. DRAWING AND DIMENSIONS ARE ONLY TO BE READ AND NOT SCALED. 3. THIS DRAWING SHALL BE READ IN CONJUNCTION WITH RELEVANT 4. ALL LEVELS GIVEN IN DRAWING ARE WITH REFERENCE TO THE 5. ANY DISCREPANCY BETWEEN THE ARCHITECTURAL/STRUCTURAL OR EXCECUTION OF THE SAME KEY PLAN G.F.C PURPOSE OF DRAWING F.I.O TENDER REMARKS NAME: ROLL NO.: FARMHOUSE GAYATRI SINGH SECTION: A1904019013 A SCALE STAIRCASE DETAIL 1:100 NAME AMITY UNIVERSITY NOIDA CHATTARPUR DELHI PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION S.NO. TYPE SCHEDULE OF DOOR WIDTH HEIGHT SILL LVL LINTEL LVL DESCRIPTION 1. 2. 3. 4. 5. D1 D2 D3 D4 D5 2000 2100 2100 1000 800 1500 DOUBLE DOOR WOOD PANEL DOOR FLUSH DOOR SLIDING DOOR DOUBLE DOOR S.NO. TYPE SCHEDULE OF WINDOW WIDTH HEIGHT SILL LVL LINTEL LVL DESCRIPTION 1. 2. 3. 4. 5. 6. 7. W1 V1 W2 W3 W4 1825 1250 2100 2100 850 600 1965 CASEMENT WINDOW 1550 2540 2770 FIXED WINDOW 8. W6 1725 DW1 9. W7 10. 11. 12. 13. W8 1635 FIXED WINDOW W9 2310 FIXED WINDOW W10 FIXED WINDOW 1500 TOILET VENTILATOR 1250 CASEMENT WINDOW 1015 1250 CASEMENT WINDOW 1250 FIXED WINDOW 600 1550 1740 2100 2100 2100 850 850 850 2100 2100 2100 2100 2100 2100 2100 2100 2100 2100 2100 2100 2100 2100 2100 2100 S.NO. TYPE WIDTH HEIGHT SILL LVL LINTEL LVL DESCRIPTION 1. 800 GLASS DOOR 2100 2100 2950 GLASS WALL 3000 2100 450 W12 W11 W13 W5 14. FIXED WINDOW 1070 1250 850 2100 2950 GLASS WALL 3000 2100 3460 GLASS WALL 3000 2030 FIXED WINDOW 2100 2100 FIXED WINDOW 2950 1250 850 2100 2100 2000 935 935 2100 1000 680 680 2100 1000 2100 800 D1, MAHOGANY WOOD DOOR D2, MAHOGANY WOOD DOOR D2, WOODEN FLUSH DOOR D3, PVC FINISH FLUSH DOOR 1500 2100 690 690 40 60 D5, GLASS PANELED DOOR 1500 2100 690 690 40 60 D4, SLIDING DOOR (PVC) 1070 200 511 200 200 690 200 40 1250 1725 200 1163 200 200 690 200 40 40 W5 W4 600 1013 500 600 1535 502 1245 2951 2411 200 200 200 710 200 40 V1 W9 W13 2029 1479 200 200 200 1520 200 2100 W10 1813 1250 1150 608 610 50 80 2517 785 782 788 80 1250 1130 W3 W1 2100 2769 200 2189 200 200 1520 200 W6 GFC/ARC/BLOCK-XXXX R E V S O N S REV. NO. PROJECT DATE DESCRIPTION NAME MILIMETERS. NOTES 2. UNLESS OTHERWISE MENTIONED, ALL DIMENSIONS ARE GIVEN IN ARCHITECTURAL, STRUCTURAL, AND SERVICES DRAWINGS. SERVICES DRAWINGS MUST BE BROUGHT TO THE ATTENTION OF THE KEY PLAN PURPOSE OF DRAWING REMARKS NAME: ROLL NO.: FARMHOUSE GAYATRI SINGH SECTION: A1904019013 A SCALE CLIENT NAME AMITY UNIVERSITY NOIDA CHATTARPUR DELHI DOOR WINDOW SCHEDULE 1:20 PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION

Miscellaneous

Selection of work (2019 - 2022)

ILLUSTRATIONS

Being creative always came naturally to me since I was a kid, this perhaps might be due to the presence of my mother who is equally as creative of a person as me. So making art was my escape and the best self help guide.

Logo design: Design for a small ceramic accessory based business with nautical themed mascot Aria.
