MASSEY FERGUSON MF 210/210-4 COMPACT TRACTOR - 651425EA 651425EA CYLINDER BLOCK - 210, 210-4 2 ItemPart NumberQtyDescriptionComments 210, 210-4 1 Kit ENGINE (A) 2 3280523M911 Block 3 3280112M16 Bolt 4 3280117M12 Bearing 5 3280551M11 Connector 6 3280118M11 Shaft 7 3280119M11 Plug Diameter 58MM 8 3280120M12 Plug 9 3280121M13 Plug Diameter 40MM 10 3 Stud Not serviced, order 390789X1 11 390789X12 Stud 12 3280940M14 Stud 15 3280944M14 Stud 16 1440690X12 Pin 17 3280932M11 Pin 18 3280102M11 Plug 19 3280784M11 Gasket 20 3280115M12 Plug 21 3280500M12 Pin 26 3280093M11 Gasket 27 3280550M11 Cover 28 1440712X12 Screw 29 3280072M12 Washer 30 3280549M11 Rod 31 3280934M11 Pin (A) NOT SERVICED Ref2 Page2
MF 210/210-4 COMPACT TRACTOR - 651425EA 31 14 15 16 32 38 38 38 17 19 18 2 3 1 39 39 28 35 30 33 5 44 44 43 41 41 42 24 26 23 36 25 40 4 7 6 8 27 37 29 34 Ref5 Page5
MASSEY FERGUSON MF 210/210-4 COMPACT TRACTOR - 651425EA 651425EA CAMSHAFT, TIMING GEAR - 210, 210-4 5 ItemPart NumberQtyDescription Comments 210, 210-4 1 3282486M11 Camshaft 2 3280929M11 Key 3 3280154M11 Plate 4 339123X12 Screw Metric 5 3280153M11 Gear 6 1442558X11 Bolt 7 339376X11 Lock Washer 8 3280148M11 Washer 14 3280149M911 Gear 15 1 Gear Not serviced, order 3280149M91 16 3280151M11 Bearing 17 3280146M11 Washer 18 1442558X11 Bolt 19 339376X11 Lock Washer 23 3280100M911 Cover 24 1 Cover Not serviced, order 3280100M91 25 3280091M11 Seal 26 391000X14 Stud 27 3280092M11 Point 28 3280103M911 Plate 29 3280101M11 Injector 30 3004509X11 Plough Bolt 31 3280090M11 Gasket 32 3280089M11 Gasket 33 391000X13 Stud 34 339123X13 Screw Metric 35 339374X13 Lock Washer 36 3280196M11 Bracket 37 339368X11 Bolt Metric 38 339374X110 Lock Washer 39 1440203X18 Nut Metric 40 339337X14 Screw Metric 41 339374X14 Lock Washer 42 339011X12 Bolt Metric 43 339291X15 Bolt Metric 44 390972X114 Washer Metric Ref5 Page5
210/210-4 COMPACT TRACTOR - 651425EA 33 30 32 1 6 38 17 40 31 44 12 45 16 16 13 43 34 15 39 46 18 8 5 7 48 48 47 49 35 36 19 19 4 3 2 20 14 22 23 24 21 Ref6 Page6
MF
MASSEY FERGUSON MF 210/210-4 COMPACT TRACTOR - 651425EA 651425EA
CONNECTING RODS, CRANKSHAFT AND FLYWHEEL - 210, 210-4 6 ItemPart NumberQtyDescription Comments 210, 210-4 1 3280524M12 Piston 3280921M12 Piston 2 3280131M12 Pin 3 3280132M14 Ring 4 3280133M12 Segment 3280134M12 Segment 5 3281925M912 Rod End 6 3280573M12 Bolt 7 3280138M11 Bush 8 3280135M14 Bearing 3280136M14 Bearing 3280137M14 Bearing 12 3280143M911 Crankshaft 13 3280144M11 Gear 14 3280001M12 Key 15 3280931M11 Pin 16 3280122M11 Kit, Bearing 17 3 Bearing Not serviced, order 3280122M1 18 3 Bearing Not serviced, order 3280122M1 16 3280123M11 Kit, Bearing 17 3 Bearing Not serviced, order 3280123M1 18 3 Bearing Not serviced, order 3280123M1 16 3280124M11 Kit, Bearing 17 3 Bearing Not serviced, order 3280124M1 18 3 Bearing Not serviced, order 3280124M1 19 3280125M11 Parts Pack 20 4 Flange Not serviced, order 3280125M1 19 3280978M11 Parts Pack 20 4 Flange Not serviced, order 3280978M1 21 3280947M14 Pin 22 3280525M11 Pulley 23 3280140M11 Washer 24 1441611X11 Nut Metric 30 3280142M11 Flywheel 31 3280141M11 Gear 32 3280930M13 Pin 33 1442558X16 Bolt 34 3436488M11 Bearing (A) 1440487X11 Bearing Assy (B) 35 3280097M11 Plate 36 3280933M11 Pin 38 3280095M11 Cover 39 3280098M11 Seal 40 3280096M11 Gasket 43 391001X13 Stud 44 339374X13 Lock Washer 45 1440203X13 Nut Metric 46 339337X13 Screw Metric 47 339187X13 Bolt Metric 48 339369X17 Lock Washer 49 1440218X14 Nut Metric (A) USED 2 WHEEL DRIVE TRACTOR SERIAL NUMBER 04933 AND UP. USED 4 WHEEL DRIVE TRACTOR SERIAL NUMBER 02289 AND UP. (B) USED PRIOR TO 2 WHEEL DRIVE TRACTOR SERIAL NUMBER 04933. USED PRIOR TO 4 WHEEL DRIVE TRACTOR SERIAL NUMBER 02289. Ref6 Page6
PISTONS,
COMPACT
59 57 58 19 39 39 55 49 41 41 56 43 40 38 36 35 29 4 25 20 28 24 5 3 23 13 10 1 11 22 21 18 42 42 27 26 12 2 8 7 6 37 50 47 44 48 46 45 9 Ref9 Page9
MF 210/210-4
TRACTOR - 651425EA
MASSEY FERGUSON MF 210/210-4 COMPACT TRACTOR - 651425EA 651425EA CYLINDER HEAD - 210, 210-4 9 ItemPart NumberQtyDescription Comments 210, 210-4 1 3280519M911 Head 2 3280057M14 Guide 3 3280054M12 Stud 4 3280055M11 Cover 5 3280056M11 Gasket 6 3280058M13 Plug Diameter 18MM 7 3280059M16 Stud 8 3280060M11 Stud 9 390379X14 Bolt Metric 10 3280312M14 Plug Diameter 20MM 11 3280547M12 Pin 12 3280923M12 Valve 13 353446X14 Lock Washer 18 3280518M11 Gasket 19 3280053M12 Bolt 20 3280052M110 Bolt 21 3280046M12 Valve 22 3281972M12 Valve 23 3280051M14 Seal 24 3280049M14 Spring 25 3280048M14 Spring 26 3280050M14 Retainer 27 3280023M18 Lock 28 3280558M12 Thermostat 29 3280559M11 Plate 1 Kit ROCKER ORDER COMPONENTS 35 3280062M11 Shaft 36 3280064M911 Bracket 37 3280068M11 Bolt 38 1443847X11 Ring 39 3280063M914 Arm 40 3280975M11 Bush 41 3280069M12 Plate 42 1441970X12 Circlip 43 3280066M11 Spring 44 3280065M11 Bracket 45 3280145M14 Valve 46 3280147M14 Stem 47 3280067M14 Bolt 48 3280070M14 Nut 49 339376X12 Lock Washer 50 1441409X12 Nut Metric 55 3280647M911 Cover 56 3280071M11 Gasket 57 3280074M11 Cap 58 3280072M12 Washer 59 3005908X12 Nut Ref9 Page9
27 29 30 22 37 32 35 21 28 25 26 44 43 55 51 52 57 48 48 53 2 7 12 13 10 10 8 54 15 50 47 14 16 11 11 9 3 38 31 4 6 1 5 34 24 33 36 23 45 56 49 58 Ref10 Page10
MF 210/210-4 COMPACT TRACTOR - 651425EA
MASSEY FERGUSON MF 210/210-4 COMPACT TRACTOR - 651425EA 651425EA
210-4 10 ItemPart NumberQtyDescription Comments 210, 210-4 1 3280189M911 Head 2 1 Housing Not serviced, order 3280189M91 3 3280191M11 Insert 4 3280192M11 Spring 5 3280193M11 Bolt 6 3280194M11 O Ring 7 3280187M11 Gasket 8 1440712X13 Screw 9 391898X12 Bolt Metric 10 390972X15 Washer Metric 11 353446X15 Lock Washer 12 3280185M911 Filter 13 3280195M11 Tube 14 1444745X14 Ring 15 3280188M12 Bolt 16 3280026M11 Switch,Indirect 3280556M911 Oil Pump 21 3280179M11 Body 22 3280180M11 Cover 23 3280557M911 Shaft 24 1 Shaft Not serviced, order 3280557M91 25 3280181M11 Parts Pack 26 3280184M11 Pin 27 3280183M11 Pin 28 3280182M11 Gear 29 3437357M12 Screw 30 353441X12 Lock Washer 31 3280177M11 Gasket 32 3280915M11 Tube 210 33 3281378M911 Tube 210-4 34 3282201M11 Gasket 210 3282201M11 Gasket 210-4 35 339123X12 Screw Metric 36 353446X12 Lock Washer 37 339132X13 Screw 38 353446X13 Lock Washer 43 3282441M911 Housing 210 (A) 43 3280094M911 Housing 210 (B) 44 3281926M16 Stud 210 (A) 44 3280945M16 Stud 210 (B) 45 3280498M11 Adaptor 210 46 391001X13 Stud 210 47 3281904M911 Housing 210-4 48 3281926M16 Stud 210-4 49 3280498M11 Adaptor 210-4 50 391001X13 Stud 210-4 51 3280104M11 Plug 52 3280105M11 Gasket 53 3280499M11 Gauge 210 54 3281377M11 Gauge 210-4 55 339084X17 Bolt Metric 210 339084X19 Bolt Metric 210-4 56 353446X113 Lock Washer 57 3281144M16 Screw 210 (A) 57 339008X15 Bolt Metric 210 (B) 58 3281144M14 Screw 210-4 (A) USED MF 210 TRACTOR SERIAL NUMBER 01245 AND UP. (B) USED PRIOR TO MF 210 TRACTOR SERIAL NUMBER 01245. Ref10 Page10
LUBRICATING SYSTEM - 210,
MF 210/210-4 COMPACT TRACTOR - 651425EA 29 5 6 9 33 24 32 30 28 27 31 25 26 22 23 8 4 2 7 3 Ref13 Page13
MASSEY FERGUSON MF 210/210-4 COMPACT TRACTOR - 651425EA 651425EA GASKET SETS - 210, 210-4 13 ItemPart NumberQtyDescriptionComments 210, 210-4 3280528M911 Kit, Joint 2 3280518M11 Gasket 3 3280056M11 Gasket 4 3280071M11 Gasket 5 3280080M11 Gasket 6 3280083M12 Gasket 7 3280084M11 Gasket 8 3280173M11 Gasket 9 3280025M12 Gasket 3282199M911 Kit, Joint 22 3280089M11 Gasket 23 3280090M11 Gasket 24 3280093M11 Gasket 25 3280096M11 Gasket 26 3280105M11 Gasket 27 3281924M11 Gasket 28 3280156M11 Gasket 29 3280177M11 Gasket 30 3282201M11 Gasket 31 3280187M11 Gasket 32 3280194M11 O Ring 33 1444745X14 Ring Ref13 Page13
MF 210/210-4 COMPACT TRACTOR - 651425EA 51 61 62 59 28 53 57 29 39 38 30 31 33 10 11 11 8 40 15 9 9 42 54 50 64 63 44 45 43 6 3 5 4 12 1413 32 37 41 24 25 52 27 23 58 5556 26 7 Ref14 Page14
MASSEY FERGUSON MF 210/210-4 COMPACT TRACTOR - 651425EA 651425EA RADIATOR AND WATER PUMP - 210, 210-4 14 ItemPart NumberQtyDescription Comments 210, 210-4 3280526M911 Radiator 2 1 Radiator Not serviced, order 3280526M91 3 3280783M11 Radiator Cap 4 3280863M11 Shroud 5 3280785M11 Protector 6 3280786M11 Pipe 7 3280102M11 Plug 8 3280784M11 Gasket 9 3280772M11 Screen 10 3280168M11 Water Hose 11 832713M14 Clamp 12 1440711X14 Bolt Metric 13 339374X14 Lock Washer 14 390972X14 Washer Metric 15 3280167M11 Water Hose 23 3280162M911 Water Pump 24 3280166M11 Hub 25 3280165M11 Shaft 26 3280164M11 Seal 27 3280163M11 Turbine Wheel 28 3280156M11 Gasket 29 1440712X12 Screw 30 390972X14 Washer Metric 31 339374X14 Lock Washer 32 1440203X14 Nut Metric 33 3280555M11 Support 37 339168X12 Bolt Metric 38 339374X12 Lock Washer 39 3280160M11 Pulley 40 3280157M11 Belt 41 3280158M11 Spacer 42 3280502M11 Fan 43 3280504M11 Plate 44 3280925M14 Screw 45 339375X14 Lock Washer 50 3280175M911 Housing 51 3005263X12 Stud 52 3280173M11 Gasket 53 391898X13 Bolt Metric 54 3007617X11 Screw 55 339374X11 Lock Washer 56 390972X11 Washer Metric 57 3280169M11 Water Hose 58 3280171M12 Clamp 59 3280172M11 Flange 61 3280574M11 Thermostat 62 3280174M11 Gasket 63 339374X12 Lock Washer 64 1440203X12 Nut Metric Ref14 Page14
