1 1808128M31 Engine
1869374M11 Engine (J)
2 906055M31 Alternator (D-L)
3 906316M11 Draglink
354619X11 Bolt Unc
353755X11 Washer
909591M1 Spacer
4 963418M11 Thermometer
1650480M11 Washer
5 963929M11 Blade Fan (M)
963930M11 Blade Fan (M)
6 963929M11 Blade Fan (N)
7 897057M12 Brake
8 361444M14 Screw
9 909319M31 Belt
10 353521X11 Bolt Unf
353755X11 Washer
353446X11 Lock Washer
353916X11 Nut Unf
11 359582X11 Screw
339376X11 Lock Washer
339402X11 Nut Metric
12 906513M11 Spacer
13 906640M911 Bearer
15
355565X11
16 960028M11 Pulley (B)
17 962184M11 Belt (B)
18 353521X12 Bolt Unf (B)
353916X12 Nut Unf (B)
353446X12 Lock Washer (B)
19 962182M11 Bearer (B)
20 353679X12 Screw Unc (B)
375703X13 Washer (B)
353446X13 Lock Washer (B)
21 962183M11
25
26
33
34
See
1 967605M11
2 1 Cable (J)
3 903078M11 Earth Strap (A)
4 1 Cable (A-K)
5 906565M931 Bearer
6 908430M11 Gauge
7 1867831M11 Harness
8
10 883930M12 Ignition Key
11 1662420M11 Nut
12 1443606X11 Washer
13 1660754M11 Plate
1660755M11 Plate (B) 1660756M11 Plate (C)
14 969188M12 Clip 656447M11 Collar
656447M12 Collar (A) 950295M11 Strap (A)
15
16 353501X12
17 963498M11
18
19
20
21 906578M11 Plate
22 362431X12
26
(A)
LUCAS (B)
IN ENGLISH (C)
IN GERMAN (D)
Alternative GABRIEL (E)
Alternative TORRIX (F)
NOT REQUIRED (G) (H)
Not serviced, order 1874120M93 (J)
Not serviced, order 2191023K1 (K)
Not serviced, order 2191022K1
6
15
16
17
1 1802033M11 Nut
2 1805203M11 Washer
3 1805197M911 Bearing CarrierCOMP. NO. 3, 7, 8 1805199M11 Clip 1805202M11 Gasket
4 1802035M11 Bush
5 1802032M11 Washer
6 1802027M11 Bearing Assy
7 1805201M11 Washer
8 1805200M11 SIDE PLATE
9 1802967M11 Armature
10 1802037M12 Screw
11 1802961M12 Brush
12 1805196M911 Bearing CarrierCOMP. 1802963M1, NO. 13 1802963M11 Greaser
13 1802020M11 Bush
14 1802036M11 Washer
15 1802964M12 Spring
16 1802968M12 Inductor NOT ILLUSTRATED 1804249M11 Kit
ItemPart NumberQtyDescription Comments
1 1888292M911 Driving
2 1805998M11 Bracket
3 1887953M911 Coil
4 1887962M912 Kit, Bolt
5 1887964M911 Armature
6 1806001M11 Kit, Brush
7 1887952M911 Kit, Brush Plate
8 1806009M11 Housing 1887965M911 Spring
9 1887956M911 Kit, Brake
10 1887961M911 Housing
11 1806226M11 Spring 1887960M911 Solenoid SwitchCOMP. NO. 10, 11 1806003M11 Kit, Seal 1888293M11 O Ring
12 1887958M911 Fork
13 1806180M11 Bearing Carrier 1806002M11 Kit, Seal 1887955M911 Kit, Bush 1887967M911 Kit, Sundry
1808449M11 Startermotor
1 1807149M11 Fork
2 1807157M11 Kit
3 1807158M11 Solenoid
4 1807156M11 Gasket
5 1807161M11 Parts Pack
6 1807160M11 Gasket
7 1807159M11 Bonnet
8 1630966M11 Kit, Brush
9 1807142M14 Spring
14 1807152M11 Bearing Carrier
15 1802147M11 Bearing
16 1807156M11 Gasket
17 1807155M11 Joint
18 1807138M11 Plug
19 1807151M11 Pin
20 1601858M11 Bush
21 1807232M11 Bearer
22 1807153M11 Race
23 1807145M11 Inductor
24 1807146M14 Weight
25 1802713M14 Screw
26 1601044M11 Bush
27 1807139M11 Bearing
28 1807143M11 Cover
29 1807134M11 Parts Pack
30 1807133M11 Armature
31 1807154M12 Stem
32 1807135M11 Thrower
33 1807136M11 Parts Pack
34 1807150M11 Skid
35 1807162M11 Parts Pack
ItemPart NumberQtyDescriptionComments
1 1809112M911 Tube
2 962495M11 Strap
4 907529M11 Wire
5 907150M11 Strap
6 1850407M12 Stub
7 354118X11 Nut Unc
8 195441X11 Washer
9 1809124M911 Cover
10 880120M921 Switch
11 338676X11 Bolt
12 354011X11 Bolt 1809114M11 Plate
13 880117M1X Shim
14 1809080M11 Tube
ItemPart NumberQtyDescription Comments
1 968976M11 Radiator Cap
2 338617X12 Hose Clip
353515X11 Screw Unf
353446X11 Lock Washer
4 906601M11 Draglink
5 906502M11 Water Hose
6 360369X112 Screw
7 906503M11 Water Hose
8 338616X12 Hose Clip
9 906491M921 Cowl
10 353559X12 Screw Unf
353757X12 Washer
11 182318M12 Shock Absorber
12 907398M911 Radiator COMP. NO. 1, 907399M1
907399M11 Radiator
13 1851095M21 Tap
1 962384M31 Dipstick
2 189604M15 Screw
3 189605M21 Gasket
4 963023M21 Radiator Cap
5 906506M921 Reservoir COMP. NO. 4, 6
6 731391M11 Plug
375754X11 Washer
7 354781X12 Bolt Unf
8 892339M12 Catch
9 890485M12 Pad
10 890486M12 Washer
11 962869M12 Spring
12 353755X12 Washer
13 376447M12 Nut
14 353801X12 Bolt Unf
15 890486M12 Washer
16 890485M12 Pad
17 962869M12 Spring
18 376447M12 Nut
19 353755X12 Washer
MASSEY
ItemPart NumberQtyDescription Comments
1 906673M921 Tube
909782M911 Tubing COMP. NO. 906673M92, NO. 376525X1
376525X12 Olive
2 906667M921 Tube
1808036M911 Tube COMP. NO. 906667M92, NO. 376524X1
376524X12 Olive
906675M921 Tube
909975M911 Tubing COMP. NO. 906675M92, NO. 376525X1
376525X12 Olive
4 906678M921 Tube
909974M911 Tube COMP. NO. 906678M92, NO. 376524X1
376524X11 Olive
5 906680M921 Tube
1808035M911 Tubing COMP. NO. 906680M91, NO. 376524X1
376524X12 Olive
6 353446X11 Lock Washer
353916X11 Nut Unf
353518X11 Screw Unf
7 1851653M911 Cock
8 908750M911 Pipe
908749M12 Olive
9 884748M11 Plug (B)
1871779M11 Plug (C) 880961M11 Washer (B)
1871780M11 Washer (C)
10 909781M911 Tubing COMP. NO. 906671M92, NO. 376525X1
906671M921 Tube 376525X11 Olive
