Advantages of the Series 19 include:
• Precise, flexible and high-performance machining
• Mobile gantry design for high static and dynamic rigidity
• Best thermal stability thanks to actively cooled drive components
• Gantry round axes with direct torque drive
• Many tools in the machining centre for extensive processing operations
• Easy access to the working area for set-up, automation and crane loading
• Tool change during machine operation for maximum output
• Intuitive operation via TouchLine
Advantages of the Micro 5 include:
Advantages of the Series 16 include:
Highly flexible – due to the modular building block principle: Mobile gantry design
Small footprint even with a large number of tools
Mineral casting machine bed, inherently stiff and vibration-damping
High static and dynamic stiffness
Excellent thermal stability
Highly productive motor spindles
Rotary axes with torque direct drive
A new string to the Chiron bow whilst keeping with traditional values of speed and accuracy. The result of a smart revolution whose exceptional technical performance is made possible by High-Speed Machining (HSM) technology.
Performance:
• Very low measurement dispersion
• Ultra compact machine
• Very Low degree of thermal influence
• Total weight of the axis base: 35kg
Precision:
• Flatness < 1 [µm]
• Straightness < 4 [µm]
• Parallelism < 3 [µm]
• Cylinder diameter < 3 [µm]
Advantages of the high-speed Eagle V-Line include:
• True high speed machining technology
• Various spindle configurations available up to 42,000rpm
• Thermo symmetric gantry design
• Optimum performance of footprint to axis travel
• ‘Multitool’ and ‘Multichange’ offer various tooling and automation options and can be combined
• Torque motors on all rotary axis
• Twin ‘Y’ axis drive system
• Fully sealed for dusty materials as well as non-ferrous and hardened ferrous materials
PRISMATIC
HBZ Horizontal 5 axis machining centres – Aerocell 200 | 250:
The HBZ® Aerocell ® series is designed for maximum material removal rates, the machining of large aerospace aluminium structural parts. These 5-axis CNC machining centres offer precise cutting with high material removal rates, ensuring optimal productivity in a compact footprint.
• 5-axis HSC horizontal machining
• 5-sided machining in one setup
• Highly dynamic machining of aluminium
• High material removal rate and productivity
• Integrated pallet changing system as standard
• Very high path velocities
• Significant reduction in machining times and costs per piece
• Compact machine design with low space requirement
• Fully enclosed workzone
• Numerous options for automation available
• Reduced downtime with dual workpiece loading
• Proprietary bavius milling head: robust, dynamic, and versatile
• Effective chip and coolant removal via horizontal machining
• Compact design with no special foundation required
HBZ Horizontal 5 axis machining centres – Aerocell 160:
• 5-axis HSC horizontal machining for optimum chip management and disposal
• 5-sided machining in one setup
• Highly dynamic machining of aluminium
• High material removal rate and productivity
• High productivity due to Integrated pallet changing system, as standard
• Very high path velocities
• Significant reduction in machining times and costs per piece
High speed milling
When producing large aluminium structural parts the AeroCell horizontal machining centre ensures optimum results from start to finish. High chip removal rates are the result of a machine concept designed for high performance: the synergy between high travel speeds, accelerations, jerk values and high spindle power and speed.
Integrated pallet change
The swivel and rotation function of the space-saving pallet changer with two pallets on the AeroCell allows loading and unloading while production is in progress. This proven bavius concept keeps non-productive time to a minimum!
• Fully enclosed workzone
• Numerous options for automation available
• Reduced downtime with dual workpiece loading
• Proprietary bavius milling head: robust, dynamic, and versatile
• Effective chip and coolant removal via horizontal machining
• Compact design with no special foundation required
• Siemens SINUMERIK ONE control with all its advantages like Digital Twin
ETG brings together the strengths of the world’s most advanced manufacturers of high technology machine tools, fabrication machines, automation, laser cutting, wire EDM, workholding systems and industry 4.0 advancements to deliver highly productive and effective metal cutting solutions.
In the world of advanced manufacturing, prismatic multi-axis machines redefine precision metal cutting by enabling complex geometries, high efficiency, and superior surface finishes. These state-of-the-art CNC systems utilise multiple axes of motion to execute intricate cuts with unmatched accuracy, reducing setup times and enhancing production flexibility.
Whether for aerospace, automotive, medical, or industrial applications, multi-axis machining ensures optimal material utilisation and high repeatability, meeting the most demanding industry standards. With innovative tooling and intelligent programming, these machines push the boundaries of modern metal cutting technology, delivering components with exceptional precision, quality and surface finish.
The Chiron range of machines available from ETG
The OPS Ingersoll range of machines available from ETG
The Bavius range of machines available from ETG
The Axile range of machines available from ETG
The Quaser range of machines available from ETG
Precision metal cutting on Prismatic Multi-Axis Machines from the Engineering Technology Group (ETG)
