Site Prep Earthmoving:
Sponsored By SITE PREP & EARTH MOVING
Dynapac CA2500 and CA3500 Soil Rollers
The Tier 4i CA2500 and CA3500 feature the Efficiency Eccentrics system, which reduces energy consumption at startup to significantly save on fuel consumption. • Low power requirement makes it possible to reduce engine size without sacrificing compaction performance • ECO Mode system further reduces fuel consumption by as much as 15% • Cross-mounted engines ensure optimal weight distribution and easy service access to engine components and hydraulic systems
ForConstructionPros. com/12211954
The compact BW 124-5 roller series is available in smooth (BW 124 DH-5) and padfoot (BW 124 PDH-5) drums with a 47.2 in. drum width. • Smooth drum model offers a 0.67 in. amplitude and the padfoot model provides a 0.63 in. amplitude • Dual pump drive allows rollers to climb up to 55% grades • BOMAG ECONOMIZER compaction measurement system • Tight turning radius of just 88.2 in. • Four-post structure safeguards operator and enables a 360° view around the machine • 46 hp Tier 4 Final diesel engine
Volvo Compact Assist for Soil
Volvo Compact Assist for Soil is available through the Volvo Co-Pilot Interface and provides real-time operator feedback for fast, accurate soil compaction. • Offers real-time guidance by displaying number of passes and
Compaction Meter Value (CMV) • Displays each compactor pass and drum overlap with a unique color
ForConstructionPros.com/20977357
CASE DL550B Compact Dozer Loader
The roughly 18,000 lb., 114 hp DL550B leverages the footprint of a compact track loader with the chassisintegrated C-frame and blade of a dozer to create a two-in-one machine for grading and loading applications. • Provides a vertical lift geometry and a rated operating capacity of 5,500 lbs. (at 50% tipping load) • True dozer-style undercarriage available in steel or rubber track configurations • Features a six-way blade and a
C-frame that attaches directly into the chassis • Hydraulically detach C-frame and blade to match up with skidsteer and compact track loader attachments
ForConstructionPros. com/21121343
Bobcat 60 Framesize R-Series Compact Track Loaders
The 8,727 lb. 68 hp T64 offers a 2,300 lb. rated operating capacity, while the 8,927 lb., 74 hp T66 has a 2,450 lb. operating capacity. • Redesigned lift arms with cast steel segments and optimized lift arm linkage provide increased strength and 120 in. lift height to hinge pin • 17.6 gpm auxiliary hydraulic flow with a 26.9 gpm high-flow option • Features a redesigned, no-DPF
Bobcat 2.4 liter Tier 4 inline engine design and direct-drive system • One-piece, sealed and pressurized, roomier cab with standard 5-in. display or optional 7 in. display with
Bluetooth, eye-level push-button controls and keyless start and theft protection • Cast-steel Bob-Tach attachment mounting system
ForConstructionPros. com/21134287
Caterpillar 140 GC Motor Grader
The 140 GC features a 147-hp Cat C7.1 Tier 4 Final engine, 6F/3R automatic power-shift transmission and precisely designed hydraulic system to ensure balanced performance in all operating situations. • Standard 12 ft. moldboard or 14 ft. moldboard option • No-spin differential activates with no operator input to increase traction in poor ground conditions and protect drivetrain components • ECO operating mode and demand-fan reduce fuel consumption • All-wheel-drive option provides added performance in rough terrain or poor underfoot conditions
