1552 COMPACT TRACTOR 652123 TABLE OF CONTENT Page00-TOC Page NumberPage Title Page Reference 01-000-TOC ENGINE, FUEL AND EXHAUST SYSTEM01-000-TOC 02-000-TOC STEERING SYSTEM 02-000-TOC 03-000-TOC DRIVE TRAIN SYSTEM 03-000-TOC 04-000-TOC BRAKE SYSTEM 04-000-TOC 05-000-TOC HYDRAULIC SYSTEM 05-000-TOC 06-000-TOC ELECTRICAL SYSTEM 06-000-TOC 07-000-TOC CHASSIS 07-000-TOC 08-000-TOC DECALS 08-000-TOC 09-000-TOC WHEELS 09-000-TOC 10-000-TOC IMPLEMENT LIFT SYSTEM 10-000-TOC
Massey Ferguson
1552 COMPACT TRACTOR 652123 ENGINE, FUEL AND EXHAUST SYSTEM Page01-000-TOC Page NumberPage Title Page Reference 01-0001 FILTER AND BELT GUIDE 2012851 01-0002 CYLINDER HEAD 2011896 01-0003 CYLINDER HEAD COVER 2011897 01-0004 INLET MANIFOLD 2011898 01-0005 EXHAUST MANIFOLD 2011899 01-0006 CYLINDER BLOCK 2011900 01-0007 OIL PAN 2011901 01-0008 REAR PLATE 2011902 01-0009 TIMING GEAR CASE 2011903 01-0010 HANGER 2011904 01-0011 VALVES 2011905 01-0012 CAM SHAFT 2011906 01-0013 PISTON 2011907 01-0014 CRANKSHAFT 2011908 01-0015 OIL PUMP 2011909 01-0016 WATER PUMP 2011910 01-0017 COOLING FAN 2011911 01-0018 INJECTION NOZZLE 2011912 01-0019 COMPONENT PARTS - INJECTION NOZZLE2011913 01-0020 INJECTION PUMP 2011914 01-0021 COMPONENT PARTS - INJECTION PUMP 2011915 01-0022 FUEL PIPE 2011916 01-0023 ADAPTER 2011917 01-0024 STARTER AND ALTERNATOR 2011918 01-0025 COMPONENT PARTS - STARTER 2011919 01-0026 COMPONENT PARTS - ALTERNATOR 2011920 01-0027 ELECTRICAL COMPONENTS 2011921 01-0028 BEARING - UNDERSIZE 2011922 01-0029 PISTON - OVERSIZE 2011923 01-0030 REPAIR PARTS - ENGINE 2011924 01-0031 COOLING SYSTEM MFC14771 1 OF 2 01-0032 COOLING SYSTEM MFC14772 2 OF 2 01-0033 EXHAUST MFC14773 01-0034 AIR FILTER MFC14774 01-0035 FUEL SYSTEM - TANK & ATTACHMENTS MFC14775 1 OF 2 01-0036 FUEL SYSTEM - TANK & ATTACHMENTS MFC14776 2 OF 2 01-0037 THROTTLE CONTROL MFC14777
Massey Ferguson
1552 COMPACT TRACTOR 1552FIL 4 5 6 3 2 1 8 7 Ref2012851 Page01-0001
Massey Ferguson 1552 COMPACT TRACTOR 652123 FILTER AND BELT GUIDE Page01-0001 ItemPart NumberQtyDescription Comments Technical Specification 1 3757038M2 1 ENGINE OIL FILTER 2 6242781M91 1 INNER ELEMENT SECONDARY 3 6242573M92 1 AIR FITR.ELEMENT PRIMARY 4 6241165M2 1 STRAINER 5 3702815M1 1 FUEL FILTER 6 4268939M91 1 FUEL FILTER 7 6258697M1 1 V BELT R5 A 43.5 8 6252978M2 1 CARTRIDGE 20/R
1552 COMPACT TRACTOR MFC14956 4 4 2 2 7 3 8 8 8 1 5 6 Ref2011896 Page01-0002
Massey Ferguson 1552 COMPACT TRACTOR 652123 CYLINDER HEAD Page01-0002 ItemPart NumberQtyDescription Comments Technical Specification 1 4267902M95 1 CYLINDER BLOCK 2 3710542M1 2 SEALING CUP ?50 MM 3 3707877M2 7 PIPE PLUG 1/2" 4 3710256M1 8 VALVE OIL SEAL 5 3711713M1 1 BALL 6 6243037M3 1 CYLINDER HEAD GASKET 7 4264534M1 18HEXAGONAL BOLT M11-1.5 X 105 8 3607420M1 3 STUD BOLT M8 X 71 (1.25)
1552 COMPACT TRACTOR MFC14957 6 5 2 4 3 11 7 1 9 8 10 Ref2011897 Page01-0003
Ferguson 1552 COMPACT TRACTOR 652123 CYLINDER HEAD COVER Page01-0003 ItemPart NumberQtyDescription Comments Technical Specification 1 4265610M92 1 CYLINDER HEAD COVER 2 3607106M1 1 RUBBER FLANGE 3 3607108M1 1 SPRING 4 3607109M1 1 SPRING SEAT 5 3607110M1 1 BLOW BY COVER 6 3710529M1 4 HEXAGONAL HEAD BOLT 4 X 8" 7 3710188M1 1 OIL FILLER CAP 8 6255009M1 1 CYLINDER HEAD GASKET 9 3710127M2 3 CAP NUT M8 104267629M1 3 SEAL 114265609M2 1 RUBBER HOSE
Massey
1552 COMPACT TRACTOR MFC14958 3 1 2 4 Ref2011898 Page01-0004
Massey Ferguson 1552 COMPACT TRACTOR 652123 INLET MANIFOLD Page01-0004 ItemPart NumberQtyDescription Comments
1 INLET MANIFOLD
1 4264651M91
1 INLET MANIFOLD GASKET
2 4264653M1
HEXAGON FLANGE BOLT
3 4267568M1 5
3 HEXAGON FLANGE BOLT
4 4267570M1
1552 COMPACT
MFC14959 4 3 2 1 5 Ref2011899 Page01-0005
TRACTOR
Massey Ferguson 1552 COMPACT TRACTOR 652123 EXHAUST MANIFOLD Page01-0005 ItemPart NumberQtyDescription Comments Technical Specification 1 6243085M1 1 EXHAUST MANIFOLD 2 4264655M1 1 EXHAUST MANIFOLD GASKET 3 3702273M1 4 HEXAGONAL HEAD BOLT 4 3607227M1 4 HEXAGONAL BOLT M8 X 35 5 3756141M1 2 STUD BOLT M10 X 25
COMPACT
MFC14960 6 6 3 30 21 21 31 31 23 22 20 20 20 5 15 17 18 18 26 27 24 25 4 7 7 32 33 19 19 12 12 12 12 12 14 14 8 8 29 13 13 13 13 13 28 2 2 11 1 9 10 16 Ref2011900 Page01-0006
1552
TRACTOR
1552 COMPACT TRACTOR 652123 CYLINDER BLOCK Page01-0006 ItemPart NumberQtyDescription Comments Technical Specification 1 6243089M94 1 CYLINDER BLOCK 2 4264535M1 10HEXAGONAL BOLT M14 X 1.5 3 4265578M1 2 SEALING CUP ?16 MM 4 3710130M2 3 SEALING CAP ?28 MM 5 4265580M1 1 SEALING CUP ?36 MM 6 3710542M1 4 SEALING CUP ?50 MM 7 6254909M2 9 PLUG 1/8" 8 4264627M2 1 IDLE GEAR PIN 9 4264566M1 4 BEARING CAP SEAL 103710161M1 2 BEARING CAP SEAL ?7 MM 116258432M1 1 BEARING 12NS -NON-SERVICEABLE PART 13NS -NON-SERVICEABLE PART 146258441M1 2 CRANK ARM BEARING 154264543M1 1 OIL SEAL 163710137M2 2 DOWEL PIN 174266242M1 2 STRAIGHT PIN ?8 X 16 MM 183757960M1 2 PIN ?6 X 12 MM 193607420M1 2 STUD BOLT M8 X 71 (1.25) 203704353M1 3 STUD BOLT M8 X 22 213758287M1 2 DOWEL PIN 223754123M1 1 WATER DRAIN PIPE 234264261M1 1 OIL FILTER CONNECTOR 243756975M3 1 INJECTION PUMP COVER 253710163M1 1 COVER SEAL 264267405M1 4 HEXAGON FLANGE BOLT 273710411M1 1 SPRING PIN 286256450M2 1 GAUGE 296242061M91 1 GUIDE 30NS -NON-SERVICEABLE PART 313702509M1 2 PIPE PLUG 3/8 NPT 323756982M1 1 OIL FILTER CAP 333756940M1 1 O-RING
Massey Ferguson
1552 COMPACT TRACTOR MFC14961 1 5 4 3 2 Ref2011901 Page01-0007
Massey Ferguson 1552 COMPACT TRACTOR 652123 OIL PAN Page01-0007 ItemPart NumberQtyDescription Comments Technical Specification 1 6255949M1 1 OIL PAN 2 3607358M2 2 PLUG M14 (1.5) 3 3707793M1 2 O-RING 4 3710481M1 23HEXAGONAL BOLT M8 X 40 5 3710113M1 1 HEXAGONAL BOLT M8 X 75
1552 COMPACT TRACTOR MFC14962 1 3 2 2 Ref2011902 Page01-0008
Massey Ferguson 1552 COMPACT TRACTOR 652123 REAR PLATE Page01-0008 ItemPart NumberQtyDescription Comments Technical Specification 1 6255943M1 1 PLATE 2 3757959M1 2 PIN ?10 X 18 MM 3 3607086M1 8 HEXAGONAL BOLT M12-1.5 X 35
MFC14963 45 50 50 48 49 10 10 10 44 44 44 44 51 21 21 52 17 47 46 16 34 36 36 5 25 35 26 2423 41 4 13 27 42 8 3 7 15 28 43 2 54 14 53 9 9 33 5556 32 38 1 30 37 11 11 29 12 31 6 39 40 20 22 Ref2011903 Page01-0009
1552 COMPACT TRACTOR
1552 COMPACT TRACTOR 652123 TIMING GEAR CASE Page01-0009 ItemPart NumberQtyDescription Comments Technical Specification 1 6259042M92 1 GEAR CASE ASM 2 3710543M1 1 SEALING CUP ?20 MM 3 3704353M1 4 STUD BOLT M8 X 22 4 3704354M1 2 STUD BOLT 5 3710484M1 1 STUD BOLT M8 X 50 6 4264542M1 1 OIL SEAL 7 6240916M1 1 HEXAGON FLANGE BOLT 8 6240915M1 3 HEXAGON FLANGE BOLT 9 4260467M1 2 HEX NUT M8 103757910M1 3 HEXAGONAL HEAD BOLT M8 X 30 114267571M1 4 HEXAGON FLANGE BOLT 123704081M1 1 HEXAGONAL BOLT M8 X 62 134264537M1 1 BOLT M8 X 118 143704596M1 1 HEXAGONAL HEAD BOLT 153756923M1 1 FLAT WASHER ?8-14 X 1 MM 164264666M1 1 STOP 173710125M1 1 NUT 203708581M1 1 CAP NUT M8 213758721M1 2 SEAL 223710400M1 1 ARM PIN 233754238M1 2 PIN 244266440M2 1 PIN 254266261M1 1 SCREW PLUG M8 (1.25) 263756923M1 1 FLAT WASHER ?8-14 X 1 MM 273710135M1 1 GROOVE PIN 3 X 40 284264571M1 1 GEAR CASE GASKET 293607433M91 1 RELIEF VALVE 303605697M2 1 RELIEF VALVE PISTON 313710279M1 1 RELIEF SPRING 323711702M1 1 SNAP RING 333707793M1 1 O-RING 343710119M1 1 HEX CAP SCREW 353710120M1 1 HEXAGONAL HEAD BOLT M6 36339030X1 2 NUT METRIC M6 (1.5) CL8 374267406M1 2 HEXAGON FLANGE BOLT 383607083M1 1 CLAMP 7" 393606142M92 1 TACHOMETER DRIVE 403708632M1 1 O-RING 413710083M1 1 BLANK CAP 30 426259043M1 1 PLATE 434264570M1 1 PLATE GASKET 443702272M1 4 HEX CAP SCREW 453710169M1 1 SPACER 463708634M1 1 O-RING 473710137M2 2 DOWEL PIN 483704353M1 1 STUD BOLT M8 X 22 496259047M91 1 HYDRAULIC SHAFT 50339064X1 2 BALL BEARING 511440203X1 4 HEX NUT M8 52SN3723 4 LOCKWASHER 5/16" 53NS -NON-SERVICEABLE PART 54NS -NON-SERVICEABLE PART 551440203X1 4 HEX NUT M8 56SN3723 4 LOCKWASHER 5/16"
Massey Ferguson
1552 COMPACT TRACTOR MFC14964 3 1 2 Ref2011904 Page01-0010
Massey Ferguson 1552 COMPACT TRACTOR 652123 HANGER Page01-0010 ItemPart NumberQtyDescription Comments Technical Specification 1 6243051M2 1 HANGER 2 3757910M1 2 HEXAGONAL HEAD BOLT M8 X 30 3 4267566M1 2 HEXAGON FLANGE BOLT
