PROCESS OF REVERSE ENGINEERING BY TOP COMPANIES IN DUBAI

PROCESS OF REVERSE ENGINEERING

BY TOP COMPANIES IN DUBAI

http://www.falcon3dme.com/

• Reverse Engineering is the process of redeveloping the original product with its exact measurements of dimensions. The need for reverse engineering arises in the case if the manufacturer doesn't exist or make that particular product. The fact is that the entire process of reverse engineering can be highly time-consuming and challenging. • However, using 3D scanning for reverse engineering can be efficient.

It generates a 3D CAD model from the original product by capturing millions of measurement points. It is said to be an extremely beneficial and cost-effective process. The below-mentioned details would describe the step-by-step process of 3D reverse engineering used by several mechanical engineering companies in the UAE.

http://www.falcon3dme.com/

• Preparation to ensure the accuracy • For increasing scan accuracy, sprinkle the temporary matte powder on the product. The quality of the scan can be affected even by a little shining surface. Kindly, note that without a matte coating, transparent and reflective surfaces can't be scanned.

• Scanning the critical sections • For capturing the critical sections of the product, always use a highly accurate 3D scanner. Many engineering companies in Dubai use laser scanners, as it is considered an ideal tool that provides a hundred percent accuracy. If the product has deep holes, multiple rescanning and orientation are required. http://www.falcon3dme.com/

• Processing to bring the finishing • Small gaps can be repaired, and the scan can be simplified using scanner software. By doing this, the data can be easily managed in CAD. Therefore, without damaging the essential details, try reducing the model as much as possible. The next is to import the data into the CAD software that has tools for reverse engineering.

• Surfacing to ensure perfection • For creating a robust model that can be edited using CAD, there are three ways to extract the essential surfaces and are described below. http://www.falcon3dme.com/

 Semi-automatic surfacing It is quite challenging to draw the complex curved surfaces manually. Hence, semi-automatic surfacing seems ideal. Surfaces that fit the best with the model are generated using this type of surfacing.  Automatic surfacing From any watertight scan, a solid model can be generated using automatic surfacing. For any addition or subtraction, standard CAD tools can be used. However, it is not easy to alter the basic characteristics. You will notice after comparing the results of the above two types of surfacing that the model is a little less accurate, particularly around fine edges.  Manual redrawing Manual redrawing is considered the most accurate and quick way for features like pockets or holes.

The scan model can be used as a reference for the same.

http://www.falcon3dme.com/

Integration & Print • For creating the jig that holds the original product, the scan can be subtracted from another solid body, once it has been converted to a solid. The dimensions of the scan are the reference for the new product's design. The last step is to print that jig using a highly accurate 3D printer, and the final reproduced product is ready for use. • Hence, if you are looking for the right place to ensure the perfect process of engineering companies in Dubai, Falcon 3D is the right place for you. Reach out to the company to get the best assistance at all times. http://www.falcon3dme.com/
