Schöck Combar provides strong, interference-free foundations A French cancer treatment centre is utilising groundbreaking equipment that combines MRI and external-beam radiation therapy. This innovative solution is heavy and required special foundations incorporating Schöck Combar glass fibre reinforcement – installed for both its strength and its ability to guarantee no electromagnetic interference. The Paoli-Calmettes Institute in Marseille is one of the leading cancer treatment centres in France. It is an extremely innovative environment and one particular piece of equipment is among the world’s first radiotherapy appliances to combine MRI and external-beam radiation therapy in order to to simultaneously image and treat the cancer. Unlike conventional X-ray
This image (and below left): To ensure high-precision radiation of moving tumours, the ‘MRIDIAN’ combines real-time imaging using magnetic resonance tomography (MR) with a linear particle accelerator (Linac). Photos: ViewRay.
scanners the ‘MRIDIAN’ does not utilise ionising radiation. It focuses solely on the tumour and leaves the surrounding tissue unharmed.
New unit weighs over ten tons The new high-tech system, which weighs over ten tons and cost around £7m, is sophisticated in its performance. But to ensure
the highest levels of precision, two main installation challenges had to be overcome – the strength of the foundations and the avoidance of any electromagnetic interference. Schöck Combar glass fibre reinforced polymer was the ideal solution. A load bearing reinforcement that absorbs tensile forces in concrete and is also completely non-metallic – so no risk of electromagnetic interference.
Electromagnetic interference can affect precision
14
Structural engineer Jean-Luc Galéa explains: “The ‘MRIDIAN’ generates a strong magnetic field and can respond very sensitively to electromagnetic interference, impairing imaging precision. No iron whatsoever may be present in any of the materials within the safety zone and that includes the concrete reinforcement. We opted for Schöck Combar as it met all the technical requirements and has very reliable certifications.” The strength of Combar was vital too, given that the foundations had to support over ten tons of technology (a required load-bearing capacity of over 5000lb/m2).
