SMART.POLE
Externally attached accessories using the unique SMART.POLE track mounting system.
The SMART.POLE is a track-based system that relies on a unique aluminium extrusion to achieve its functionality. Accessories fix to the pole by utilising this track which provides a discrete connection detail. This is a truly multi-functional system that accommodates a full range of pole mounted accessories and Digital Services that are typically deployed within the public domain.
ENE.HUB’s family of SMART.POLEs contain a vast range of structural capability to comply with the growing needs of modern environments.
Each suite offers an array of customisable product options, ensuring a tailored approach for every level of complexity within the evolving public domain.
For many Council’s the SMART.POLE is the most robust solution for high-traffic city areas. It’s structure allows housing for the broadest range of accessories, accommodating to the busy modern day CBD environment. Most common external attachments integrated into SMART.POLE include long-arm traffic outreaches, street lighting and signage.
THE TECHNOLOGY ACCOMMODATED BY THE SMART.POLE IS CONTINUOUSLY EVOLVING. ENE.HUB CAN INVESTIGATE THE ACCOMMODATION OF ADDITIONAL DIGITAL SERVICES DEVICES. www.ene-hub.com
Regent St
The S1 SMART.POLE is the original CBD system implemented across a large scale of high-traffic city areas. It’s structure allows housing for the broadest range of accessories.
Most common external attachments integrated into S1 include long-arm traffic outreaches, street lighting and signage. S1’s height range is taken advantage of through the use of dual banners, variable message signage (VMS) and other signage outreaches, being the perfect companion for public messaging and advertising.
The S2 SMART.POLE is a suburban pole solution for moderate traffic areas. It’s smaller scale makes this suite a more efficient option for suburban roads which do not require heavier external attachments. The S2 suite most commonly mounts streetlight outreaches, street name signs and banners.
All SMART.POLE options are available with single or double outreach luminaires and in a select range of colours:
THE TECHNOLOGY ACCOMMODATED BY THE SMART.POLE IS CONTINUOUSLY EVOLVING. ENE.HUB CAN INVESTIGATE THE ACCOMMODATION OF ADDITIONAL DIGITAL SERVICES DEVICES. www.ene-hub.com
Black Silver
Charcoal
THE TECHNOLOGY ACCOMMODATED BY THE SMART.POLE IS CONTINUOUSLY EVOLVING. ENE.HUB CAN INVESTIGATE THE ACCOMMODATION OF ADDITIONAL DIGITAL SERVICES DEVICES. www.ene-hub.com MULTI-FUNCTIONAL POLE SMART.POLE
Options Audio Tactile Unit Outreach Sign Long Arm Sign Kerbside Single CCTV Access Hatch Bike Ring Power Terminal Board Traffic Terminal Board Streetlight Outreach Banners MicroCell Pedestrian Lighting Solar Antenna VMS Traffic Lantern Outreach Pedestrian Push Button 4G Small Cell Enclosure Traffic Lantern Flower Basket Outreach Pedestrian Lantern Feature Lighting Street Name Sign Kerbside Multi Wayfinding Traffic Monitoring Technology
Services Options Wireless Charging USB Outlet Wi-Fi Feature Lighting Fibre Outlet Image Projection Power Outlet CCTV PTZ Camera LoRaWAN Gateway 4G/5G
Accessories
Digital
SMART.POLE
PRODUCT SPECIFICATION SHEET
THE TECHNOLOGY ACCOMMODATED BY THE SMART.POLE IS CONTINUOUSLY EVOLVING. ENE.HUB CAN INVESTIGATE THE ACCOMMODATION OF ADDITIONAL DIGITAL SERVICES DEVICES. www.ene-hub.com
Type SMART.POLE S1B Height 5m-12m Light Height 5m-11.5m Max. Weight 320 - 890kg Steel Core Material Mild Steel Q345 Finish Hot Dipped Galvanised Min Local Thickness 70µm Min Average Thickness 85µm Lower Cladding Material Aluminium Grade 6063-T6 Finish Anodised Min Local Thickness 20μm Min Average Thickness 25μm Colour Clear Diameter 250mm to 300mm Transition Ring Material Aluminium Grade CC601-T6 Finish Powder Coated Min Local Thickness 70µm Min Average Thickness 85µm Colour RAL 9006 Semi-Gloss Upper Pole Extrusion Material Aluminium Grade 6063-T6 Finish Anodised Min Local Thickness 20µm Min Average Thickness 25µm Colour Clear Diameter 215mm Pole Cap Material Aluminium Grade CC601-T6 Finish Powder Coated Min Local Thickness 70µm Min Average Thickness 85µm Colour RAL 9006 Semi-Gloss Diameter 215mm Cast Aluminium Brackets Material Aluminium Grade CC601-T6 Finish Powder Coated Min Local Thickness 70µm Min Average Thickness 85µm Colour RAL 9006 Semi-Gloss Extruded Aluminium Brackets Material Aluminium Grade 6063-T6 Finish Anodised Min Local Thickness 20µm Min Average Thickness 25µm Colour Clear Stainless Brackets Material 316 Stainless Steel Finish Brushed Finish Colour Clear Fasteners Material 316 Stainless Steel Colour Clear Regent St
