SMART.NODE™
Discreetly Integrated Services.
The SMART.NODE™ is a revolution in Digital Services design and delivery. By integrating the widest possible range of Digital Services available today, one SMART.NODE™ can discreetly accommodate the variety of digital services selected by the Council or Land Authority.
With a sleek, integrated design, the SMART.NODE™ allows authorities to adapt to the changing urban environment without compromising on aesthetic.
At the same time, every SMART.NODE™ is pre-provisioned with communications and power connections. This means that deploying more devices, or upgrading them, is a simple process with minimum disruption to the public realm.
With state-of-the-art telecommunications technology and 24-hour power supply, the SMART.NODE™ is future-proofed to accommodate the services, data sensors and communications needs of the modern public space.
The modular design of the SMART.NODE™ allows for the discrete integration of a range of Digital Services.
Every Multi-Technology Module (MTM) zone is a blank canvas ready to facilitate the our public places and spaces.
The SMART.NODE™ has an upper pole diameter of 260mm, and the lower pole diameter is available in 400mm and 260mm.
Due to the modularity of its design, the SMART.NODE™ is provided in a range of off-the-shelf heights, including:
• S.N 11m
• S.N 9m
• S.N 7m
The SMART.NODE™ is a fully integrated and modular Digital Services Enabler. It replaces the humble streetlight and transforms it into a discreet enabler for the widest possible range of Digital Services technologies and data capture devices.
The SMART.NODE™ is available in a select range of colours supplied by Interpon Powder Coatings. As part of the Interpon Textura Range (Grade D1000), the three standard powder-coat colours offered are:
Textura Silver
Texture, GY35LA
Textura Monument Black
Texture, GL329A
Textura Woodland Grey
Texture , GL333A
SMART.NODE™
MULTI-FUNCTIONAL POLE
The SMART.NODE™ is comprised of four Functional Zones, each performing different functions that enable digital services and data collection.
The Functional Zones include:
• Beacon Zone
• Multi-Technology Modules Zone
• Wayfinding Zone
• Base Zone
Digital Services Options
BEACON ZONE
Accessories Options
MULTI-TECHNOLOGY MODULES ZONE
WAYFINDING ZONE
BASE ZONE
The SMART.NODE™
PRODUCT SPECIFICATION SHEET
Type SMART.NODE™
Height 7m-11m
Light Height 6m-11.5m
Max. Weight 550 - 865kg
Steel Core
Material Mild Steel Q345
Finish Hot Dipped Galvanised Min Local Thickness 70µm Min Average Thickness 85µm
Lower Cladding
Material Aluminium Grade A380
Finish Powder Coated Min Local Thickness 60µm Min Average Thickness 80µm
Diameter 260mm to 400mm
Transition Ring
Material Aluminium Grade A356
Finish Powder Coated Min Local Thickness 60µm Min Average Thickness 80µm
Upper Pole Extrusion
Material Aluminium Grade 6063-T6
Finish Anodised Min Local Thickness 20µm Min Average Thickness 25µm
Diameter 260mm
Upper Pole MTM
Material Aluminium Grade A356
Finish Powder Coated Min Local Thickness 60µm Min Average Thickness 80µm
Diameter 260mm
Stainless Brackets
Material 316 Stainless Steel
Finish Brushed Finish
Colour Clear
Fasteners
Material 316 Stainless Steel
Colour Clear
