Knotwood - Aluminium Cladding Brochure 2019

DECKING | CLADDING | BALUSTRADES | FACADES | SOFFITS | CEILINGS | SCREENS | FENCING | GATES | AWNINGS & PERGOLAS

CLASS A FIRE RATED TO EN13501-1 25 YEAR WARRANTY

It’s not wood.

It’s aluminium.

Better Than Wood?

Lighter, stronger, straighter than real wood.

By using Knotwood, you can have the beauty and warmth of wood without the time consuming maintenance and expense. Knotwood is 99% recyclable, has a smaller environmental footprint than wood and is stronger and easier to use than real wood. Knotwood has the strength and durability of aluminium and the ability to be attached to any existing structure meaning it’s capable of spanning large areas and requires minimal posts and fixings. Knotwood not only looks great but will ensure the test of time with minimal maintenance.

SLIP RESISTANT

CLASS A FIRE RATED

To ensure maximum safety and reduce

Fire resistance and resilience are important

the risk of slips, Knotwood has created

no matter where we live. This is where

an exclusive slip resistant formula that

Knotwoods benefits truly surpass the use

can be applied to our decking system.

wood. Knotwood is the UK’s only wood grain

E EN13036-4 PTV Slip Resistance

a aluminium non combustible range

Rating of 40 (wet) / 60 (dry) - see

manufactured with Class A Fire Rating.

results below

NON WARPING

COLOUR STABILITY

ECO FRIENDLY

STAIN & SCRATCH RESISTANT

LIGHTWEIGHT

DISSIPATES HEAT

FREEZE & FROST RESISTANT

CORROSION RESISTANT

INSECT PROOF

NON POROUS

Pendulum Slip Test Values (PTV) in accordance with BS7976: Parts 1-3 Dry Directions: Classification - Low slip potential*

Wet Directions: Classification - Low slip potential

Slip 1

Slip 2

Slip 3

Slip 4

Slip 5

Slip 6

Slip 7

Median Slip 8 (of 4-8)

A

55

58

53

55

59

55

52

60

55

B

56

56

57

50

60

56

56

56

56

B

44

45

45

45

45

45

C

58

59

60

60

58

60

56

60

60

C

45

46

45

45

45

45

Direction

* A PTV of 36 and above is considered low slip potential

Direction

A

Slip 1

Slip 2

Slip 3

Slip 4

Slip 5

Slip 6

Slip 7

Median Slip 8 (of 4-8)

45

45

45

46

45

45

45

43

45

43

45

45

45

46

45

The 5 Systems...

Simple Design, Concealed Fixings and Easy Installation.

Knotwood’s state of the art aluminium modular systems are designed to conceal joins, screws, rivets and fixings. Our focus is on simple systems that are versatile, durable and require effortless installation.

From a simple gate to sophisticated architectural designs, the possibilities are endless.

All systems are EN 13501-1 Class A Fire Rated.

Applications: Decking

D DECKING SYSTEM

Based on a simple interlocking design with a BS EN 13036-4 PTV Slip Resistance Rating of 40(Wet) / 60(Dry). Knotwood’s decking system is the perfect outdoor solution. Decking boards come in various sizes, are non porous, dissipate heat and will not rot, split or warp.

Applications: Soffits Facades

Applications: Fences Gates Screening

Soffits Ceilings Facades

C

SM

Great for both walls and soffits, Knotwood’s cladding system offers a clean, simple and contemporary aesthetic. The cladding c boards work on an interlocking design with minimal components and can be laid horizontally and vertically.

Knotwood offers four different cladding styles using just one system which means you can mix and match components to create a unique look.

Working with leading UK balcony manufacturers, Knotwood have developed a simple, cost effective, self-mating system for use in Balcony Decking applications. A surface fixed bottom board is concealed with a unique top-board profile, leaving a sleek and stylish finish.

CLADDING SYSTEM

SELF MATING SYSTEM

Applications: Fences Gates Screening Balustrades

S

SLAT SYSTEM

A traditional solution that offers flexibilty in application. Slats are easily inserted horizontally, vertically or diagonally into U channel framing with the option of spacers to create gaps between each slat.

Applications: Fences Gates Screening Soffits

Ceilings Facades Pergolas & Awnings Balustrades

B BATTEN SYSTEM

The batten system is ideal to create a contemporary linear look. Using m minimal posts and framing, the finished look is clean and sophisticated, with more creative options available when used with the self-mating slat system.

Knotwood’s decking system allows you to spend more time enjoying the outdoors without the ongoing arduous maintenance. Unlike traditional decking materials, aluminium is impermeable to insects and won’t rot, crack or warp. It’s easy to install and uses a simple interlocking design that conceals all screws and fixings.

01

BOARDS

Our overlapping board system is designed to hide the join and screws of each previous board leaving a seamless finish.

02

END PIECES

Hides the last join, conceals screws and H leaves a nice rounded edge to the deck.

150mm

01

D DECKING SYSTEM

02

APPLICATIONS: DECKING

Knotwood’s cladding system offers custom lightweight design solutions that will compliment any building, adding visual appeal and value. Our cladding is strong, durable and easy to install. It’s designed to keep out the elements and will protect from rot, corrosion and mould. Knotwood’s cladding dissipates heat, is non porous and non combustible. It doesn’t require repainting or resealing, making it a practical and cost effective solution. Whether your architectural design is classic classi or modern, Knotwood’s extensive colour range can create your look.

01

BOARD

Our overlapping board system is designed to hide the join and screws of each previous board leaving a seamless finish.

02

C

02

03

01

CLADDING SYSTEM

2 PART BOTTOM FINISHING PIECE

APPLICATIONS: SOFFITS FACADES

The base end pieces hide joins and nd ensure a clean finish.

T

03

2 PART TOP FINISHING G PIECE

out.

The top finisher piece ensure no gaps and helps keep the elements out

DIMENSIONAL CLADDING

Board widths: 100mm, 150mm, 200mm

Flat

Ship Lap

Shadow Line

Dimensional Board

Clip Ins

Knotwood’s facade solutions can create bold architectural statements, stylish sun shields or sophisticated screens. Our aluminium lengths are lighter, straighter and stronger than real wood, offering a more cost effective solution for large expanses. All systems a re weather resistant and require no recoating or resealing. They are designed to conceal joins, screws and fixings, resulting in a clean and seamless finish. Knotwood’s facade systems are versatile and can be adapted to suit all structural elements, making it a practical and appealing solution for any exterior.

A great alternative to standard ceiling panels and soffits, Knotwoods systems bring beauty and uniqueness to any building. They can be used to conceal an unsightly building structure or add overhead visual interest to any space. Knotwood has designed specialised perforated boards that ensure complete ventilation without compromising on durability and performance. They dissipate heat, are non and resistant to the elements. p porous

SM

03

01

BACK PANEL

Self mating slat which is screwed to a bracket, frame or any existing structure.

02

SELF MATING SYSTEM

COVER PANEL C

Self mating slat which interlocks with the back panel, concealing screws and fixings.

03

Can be attached to a frame, wall or any substrate.

16mm /

01

TOP HAT BRACKET (OPTIONAL)

38mm

65mm

02

100mm

150mm

APPLICATIONS: FENCES GATES SCREENING SOFFITS CEILINGS FACADES

Knotwood’s slat systems are a simple, stylish and innovative solution to create fences, garages, screens and baulustrades. Durable Dura and low maintenance, the system offers flexibility to adapt the components, using them horizontally, diagonally or vertically and with optional spacing, to create a stylish and practical solution for your building.

S

02 01

SLATS

01

Slats can be used vertically, horizontally and diagonally. Slat spacers can be adjusted for desired spacing.

02

SLAT SYSTEM

IINFILLS & CAPS

Infills and Caps conceal screws and fixings.

03

POSTS

03

Designed with U channels for easy installation. Can be attached to an existing surface or concreted into the ground.

Post Size: 50 x 50mm and 65 x 65mm

16mm / 38mm

65mm

100mm

150mm

APPLICATIONS: FENCES GATES SCREENING BALUSTRADES

Though simple in design, Knotwood battens can be used in a broad range of applications to create designs that are stylish and impactful. Used either vertically or horizontally and spaced to suit your needs, they provide a versatile solution offering: • Privacy • Protection from elements • Camouflage for unsightly areas • Control of airflow and sun exposure • Safety and security • Creative design

03 01

B

02

BATTEN

Battens come in a range of shapes and sizes and can be used vertically or horizontally. Spacing can be adjusted to suit your needs.

02

BATTEN SYSTEM

BRACKETS B 01

Can be screwed to existing wall or suspended by top and bottom caps.

03

CAPS

Caps conceal screws and fixings and keep the elements out.

JOINERS

50mm /

50mm

100mm

150mm

200mm

Elliptical / 150mm

200mm

50mm

Angular / 50mm

25mm / 50mm

75mm

100mm

150mm

50mm / 50mm

150mm

APPLICATIONS: FENCES GATES SCREENING CEILINGS & SOFFITS FACADES BALUSTRADES PERGOLAS & AWNINGS

Our wood grain colour range is textured and reproduced from handpicked natural timbers.

Knotwood combines the natural beauty and timeless appeal of wood with the capabilities of aluminium. Our specialty powder coating process produces natural wood grain colours that are textured to feel like real wood. All of our aluminium systems and products are available in our extensive range of powder coated and wood grain colours.

Our Core Range

BLACK ASH

LIGHT OAK

KWILA

Wood Grain Colour Range JARRAH

AUSTRALIAN CEDAR

IROKO

ROSE MAHOGANY

SYDNEY BLUE GUM

ENGLISH CHESTNUT

Our extended colour range available on a 3 weeks leadtime - please contact us for more details

RED GUM

KOA

TIGER WOOD

IRON BARK

MERBAU

BLACKBUTT

MAPLE

TASSIE OAK

KNOTTY PINE

CHESTNUT

ROYAL OAK

SAVANNAH OAK

TEAK BROWN

BUSH CHERRY

WESTERN RED CEDAR

WENGE

BLACK WALNUT

EASTERN MAHOGANY

EBONY

AFRICAN BLACK WOOD

SPOTTED GUM

HICKORY

“Our wood grain colour range is textured and reproduced from handpicked natural timbers.”

CHARCOAL ASH

ZEBRANO

ASPEN

ATLANTIC CEDAR

WHITE ASH

BEACHWOOD

DRIFTWOOD

ASH

MERBAU WEATHERED

Please note: These colours are a guide only.

To ensure best accuracy, test your colour choice at home by requesting a free sample.

Textura Colour Range PRIMROSE

PAPERBACK

DUNE

SILVER

WHITE

JASPER

MONUMENT

DEEP OCEAN

IRONSTONE

SURFMIST

WOODLAND GREY

BLACK

Knotwood’s Textura coating is the ideal finish for high traffic areas. We have p preformed rigorous testing to create a product for performance and toughness that will withstand hard wearing environments. The f fine texture finish and advanced powder coating technology create the ultimate scratch, scrub and abrasion resistance.

Please note: These colours are a guide only.

To ensure best accuracy, test your colour choice at home by requesting a free sample.

R Rust, Copper & Concrete Colour Range BRONZE RUST

CANTALOUPE RUST

AMBER RUST

TIGER RUST

COPPER PATINA

CONCRETE

Please note: These colours are a guide only.

To ensure best accuracy, test your colour choice at home by requesting a free sample.

PEACH RUST

Knotwood has taken inspiration from natural textures found in today’s urban environment to bring you a unique colour palette of rusts, coppers and concrete. Our unique range is based on our Textura colour paints to ensure long lasting colour that will withstand harsh environments.

T The fine texture finish and advanced powder coating technology create the ultimate scratch, scrub and abrasion resistance.

25 Year Warranty* Knotwood offers a full manufacturers warranty: • 25 year structural warranty covering aluminium boards • 15 year performance warranty on the powder coated finish The coating technologies used in Knotwood products meet globally recognized AAMA 2604 standards with regards to gloss retention, colour uniformity, weathering durability, humidity resistance, impact resistance and chemical resistance. The Knotwood range of powder coated products are supported by a 15 year performance warranty on the powder coating - the only one of its kind in the British market.

Environmentally friendly Choosing a material with sustainability in mind is paramount. Aluminium is economical, safe and ecologically sensible. Aluminium is light weight yet extremely strong and 100% recyclable. Knotwood uses VOC free coatings and lead free finishes resulting in a smaller environmental footprint, for us and for you.

Knotwood remains committed to ecologically responsible production processes.

Consulting Knotwood’s consultants can help advise which systems and components will best suit your project. They are p proficient in dealing with both small and large projects in competitive price markets and understand designing for low maintenance without compromising on aesthetics.

BIM and CAD Knotwood products can be requested in various file types.

Drawings include product componentry to general detailing for a wide range of applications.

Basic 2D DWG are also available.

Project Costings Our range of services include budgeting options through to pricing for tenders. We are set-up to measure from PDF drawings, which are returned with itemised quotes, enabling cross-reference of quantities.

Email: sales@knotwood.co.uk

Knotwood is committed to making a product that is cleaner, safer and better for the environment

Unit 12B Metcalf Drive, Altham Industrial Estate, Altham, Lancashire, BB5 5TU Telephone 0845 034 6008

Email sales@knotwood.co.uk

SEPT19

www.knotwood.co.uk
