KOMPLET

KOMPLET is leader in the world of construction of treatment systems and waste recycling equipment.

KOMPLET develops easy to use machines and modular systems that are easy to transport as well, in this way offering customers the option to choose between widening and/or upgrading an existing system. The peculiarity of the KOMPLET standards has made the brand well known and appreciated throughout the world. KOMPLET cares about protecting the environment and people and for the future plans to continue to widen their business and equipment offers with progressive solutions.

For KOMPLET the protection of the planet is a challenge that is renewed every day, a challenge that Komplet will never tire to face and win.

KJC503 KJC704

KJC805

CITYCRUSHER 704 LEM 4825

JAW CRUSHERS

KJC503

Weight: 3.400kg Length: 4,54m Width: 1,5m Height: 1,9m Hopper capacity: 0,6m3 Jaw opening: 0,48m x 0,25m Production: 5-30 t/h

KJC704

Weight: 11.500kg Length: 8,15m Width: 2,25m Height: 2,69m Hopper capacity: 2,3m3 Jaw opening: 0,6m x 0,4m Production: 10-80 t/h

KJC805

Weight: 18.000kg Length: 10,50m Width: 2,20m Height: 2,90m Hopper capacity: 3,0m3 Jaw opening: 0,8 x 0,5m Production: 200 t/h

CITYCRUSHER 704

Weight: 9.500kg Length: 6,33m Width: 2,19m Height: 2,76m Hopper capacity: 2,3m3 Jaw opening: 0,68m x 0,4m Production: 80 t/h

LEM 4825

Weight: 2.100kg Length: 6,30m Width: 1,15m Height: 2,42m Hopper capacity: 0,5m3 Jaw opening: 0,48m x 0,25m Production: 5-30 t/h

SHREDDER

KROKODILE

Weight: 14.000kg Length: 8,0m Width: 2,20m Height: 3,28m Hopper capacity: 2,3m3 Production: 180 t/h

KROKODILE

MT5000

HAMMER MILLS

MT5000

Weight: 3.400kg Length: 4,70m Width: 1,50m Height: 1,88m Hopper capacity: 0,6m3 Production: 5-25 t/h

M5000

Weight: 1.900kg Length: 6,20m Width: 1,30m Height: 1,60m Hopper capacity: 0,5m3 Production: 20 t/h

KOMPATTO 221

KOMPATTO 104

SCREENS

KOMPATTO 221

Weight: 3.200kg Length: 3,83m Width: 1,45m Height: 2,235m Production: 80 t/h

KOMPATTO 104

Weight: 7.000kg Length: 7,77m Width: 2,24m Height: 3,00m Hopper capacity: 2,5m3 Production: tot 200 t/h

WV20-80

KOMPATTO 5030

Weight: 12.000kg Length: 9,86m Width: 2,25m Height: 2,50m Hopper capacity: 2,5m3 Production: 50-350 t/h

WV20-80

Weight: 520kg Length: 2,65m Width: 1,55m Height: 1,93m Production: 10-40 t/h

KOMPATTO 5030

DST1020

TB3400

TROMMEL SCREEN

DST1020

Weight: 3.400kg Length: 5,50m Width: 2,00m Height: 2,565m Drum length: 2,0m Drum diameter: 1,0m Hopper capacity: 1,3m3 Production: 60 t/h

CONVEYOR

TB3400

Weight: 2.600kg Length: 6,4m Belt width: 0,6m Discharge height: 3,20m

The MDS trommel screens are real heavy duty trommel screens. The robust and durable MDS trommels clean clay bound rock and rocks mixed with other sticky materials very effectively. The remote controlled modular drums can handle rocks with extreme sizes. The MDS trommel screens, both static and mobile versions, are built to last. They are thicker than regular drums, 5-6cm!

Different feeder options: > Rubber belt > Apron feeder > Hydraulic push feeder

HYDRAULIC GRID RUBBER CLEANER

M412

TROMMEL SCREENS

M412

Weight: 21.500kg Length: 12,836m Width: 2,50m Height: 3,00m Capacity: 300 t/h Drum length: 4m Drum diameter: 1,25m Hopper capacity: 4m3

M515

Weight: 48.000kg Length: 17,047m Width: 2,98m Height: 3,497m Capacity: 350-450 t/h Drum length: 5,5m Drum diameter: 1,5m Hopper capacity: 12,6m3

M515

M518R

Weight: 20.000kg Length: 10,374m Width: 2,5m Height: 3,145m Drum length: 5m Drum diameter: 1,8m Hopper capacity: 3,12m3
